Furrion FEHD19S0N User manual
Welcome
Thank you and congratulations for purchasing this Furrion® LED HD TV. Before placing your
new appliance into operation, please read these operating instructions carefully. This
instruction manual contains important information for safe use, installation and
maintenance of the appliance.
Please keep this instruction manual in a safe place for future reference. This will ensure safe
use and reduce the risk of injury to persons. Pass it onto possible new owners of the
appliance.
The manufacturer does not accept responsibility for any damages that may arise due to non-
observation of these instructions.
2
Contents
Welcome
.....................................................................................................1 Contents
.....................................................................................................2
Safety Warnings .........................................................................................3
Important Safety Instructions
.............................................................................................................3
Safety Precautions
...................................................................................................................................5
Function Overview ....................................................................................7
Control Panel
.............................................................................................................................................
7
Rear Panel
...............................................................................................................................................
....8
Remote Control
........................................................................................................................................9
About Your LED HD TV
...............................................................................11
Features
...............................................................................................................................................
........11
Power Source
............................................................................................................................................1
1
Before Operation
.......................................................................................12
What’s in the Box
.....................................................................................................................................12
Preparation of your Remote Control
................................................................................................12
Getting Started
..........................................................................................13
Change Settings ........................................................................................15
Picture Menu
.............................................................................................................................................
15
Sound menu
..............................................................................................................................................
16
Channel menu
..........................................................................................................................................17
Feature menu
............................................................................................................................................1
8
Setup menu
...............................................................................................................................................
22
USB Operation
...........................................................................................23
3
DVD
Operation...........................................................................................27
DVD Player Setup
.....................................................................................................................................27
DVD Player Controls
................................................................................................................................28
Loading a Disc
...........................................................................................................................................2
9
DVD/VCD/SVCD Playback
.....................................................................................................................29
Video/Audio/Picture Playback
............................................................................................................29
Trouble Shooting .......................................................................................31
Specifi cations
.............................................................................................32
Safety Warnings
6
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
This ‘bolt of lightning’ indicates
uninsulated material within your unit
may cause an electrical shock. For the
safety of everyone in your household, please do
not remove product covering.
The ‘exclamation mark’ calls attention
to features for which you should read
the enclosed literature closely to
prevent operating and maintenance problems.
WARNING: To reduce the risk of fi re or electric
shock, this apparatus should not be exposed to
rain or moisture and objects fi lled with liquids,
such as vases, should not be placed on this
apparatus.
CAUTION: To prevent electric shock, fully insert
the plug. (For regions with polarized plugs: To
prevent electric shock, match wide blade to wide
slot.)
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any of the ventilation openings.
Install in accordance with the manufacturers
instructions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifi ers) that produce
heat.
9. Protect the power cord from being walked on
or pinched, particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
10. Only use attachments/accessories specifi ed
by the manufacturer.
11. Use only with a cart, stand, tripod, bracket, or
table specifi ed by the
manufacturer or sold with the
apparatus. When a cart is used,
use caution when moving the
cart/apparatus combination to avoid injury
from tip-over.
12. Unplug this apparatus during lightning storms
or when unused for long periods of time.
13. Refer all servicing to qualifi ed service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as if the power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, or when the
apparatus has been exposed to rain or
moisture, does not operate normally, or has
been dropped.
14. Apparatus should not be exposed to dripping
or splashing, and objects fi lled with liquids,
such as vases, should not be placed on the
apparatus.
15. An outside antenna system should not be
located in the vicinity of overhead power
lines or other electric light or power circuits,
or where it can fall into such power lines or
circuits. When installing an outside antenna
system, extreme care should be taken to
keep from touching such power lines or
circuits as contact with them might be fatal.
16. Do not overload wall outlets, extension cords,
or integral convenience receptacles as this
can result in a risk of fi re or electric shock.
Safety Warnings
7
17. Never push objects of any kind into this
product through openings as they may touch
dangerous voltage points or short-out parts
that could result in a fi re or electric shock.
Never spill liquid of any kind on the product.
18. When replacement parts are required, be
sure the service technician uses replacement
parts specifi ed by the manufacturer or those
that have the same characteristics as the
original part. Unauthorized substitutions may
result in fi re, electric shock or other hazards.
19. Upon completion of any service or repairs to
this unit, ask the service technician to
perform safety checks to determine that the
unit is in proper operating condition.
20. When you connect the product to other
equipment, turn off the power and unplug all
of the equipment from the wall outlet.
Failure to do so may cause an electric shock
and serious personal injury. Read the owner’s
manual of the other equipment carefully and
follow the instructions when making any
connections.
21. Sudden high volume sound may cause
hearing or speaker damage. When you use
headphones, (if the unit is equipped with a
headphone jack) keep the volume at a
moderate level. If you use headphones
continuously with high volume sound, it may
cause hearing damage.
22. Do not allow the product to output distorted
sound for an extended period of time. It may
cause speaker overheating and fi re.
23. The socket-outlet must be installed near the
unit and easily accessible.
24. The mains plug is used as the disconnect and
shall remain readily operable.
CONDENSATION
Moisture will form in the operating section
of the unit if the unit is brought from cool
surroundings into a warm room or if the
temperature of the room rises suddenly.
When this happens, unit’s performance will
be impaired. To prevent this, let the unit
stand in its new surroundings for about an
hour before switching it on, or make sure
that the room temperature rises gradually.
Condensation may also form during the summer
if the unit is exposed to the breeze from an air
conditioner. In such cases, change the location of
the unit.
HOW TO HANDLE THE LCD PANEL
●Do not press hard or jolt the LCD panel. It
may cause the LCD panel glass to break and
injury may occur.
●If the LCD panel is broken, make absolutely
sure that you do not touch the liquid in the
panel. This may cause skin infl ammation. If
the liquid gets in your mouth, immediately
gargle and consult with your doctor. Also, if
the liquid gets in your eyes or touches your
skin, consult with your doctor after rinsing
for at least 15 minutes or longer in clean
water.
Possible Adverse Eff ects on LCD Panel: If a fi xed
(non-moving) pattern remains on the LCD Panel
for long periods of time, the image can become
permanently engrained in the LCD Panel and
cause subtle but permanent ghost images. This
type of damage is NOT COVERED BY YOUR
WARRANTY. Never leave your LCD Panel on for
long periods of time while it is displaying the
following formats or images:
●Fixed Images, such as stock tickers, video
game patterns, TV station logos, and
websites.
●Special Formats that do not use the entire
screen. For example, viewing letterbox style
(16:9) media on a normal (4:3) display (black
bars at top and bottom of screen); or viewing
normal style (4:3) media on a wide screen
(16:9) display (black bars on left and right
sides of screen).
Safety Warnings
8
The following symptoms are not signs of
malfunction but technical limitation. Therefore
we disclaim any responsibility for these
symptoms.
●LCD Panels are manufactured using an
extremely high level of precision technology,
however sometimes parts of the screen may
be missing picture elements or have
luminous spots. This is not a sign of a
malfunction.
●Do not install the LCD Panel near electronic
equipment that produces electromagnetic
waves. Some equipment placed too near this
unit may cause interference.
●Eff ect on infrared devices –There may be
interference while using infrared devices
such as infrared cordless headphones.
Warning: To reduce the risk of fi re or electric
shock, do not expose this apparatus to rain or
moisture.
Caution: Never remove the back cover of the LED
television as this can expose you to very high
voltages and other hazards. If the television does
not operate properly, unplug the LED television
and call your authorized dealer or service center.
Adjust only those controls that are covered in the
instructions, as improper changes or modifi
cations not expressly approved by Furrion could
void the user’s warranty.
Safety Precautions
WARNING: Never place a television set in an
unstable location. A television set may fall,
causing serious personal injury or death. Many
injuries, particularly to children, can be avoided
by taking simple precautions such as:
–Using cabinets or stands recommended by
the manufacturer of the television set.
–Only using furniture that can safely support
the television set.
–Ensuring the television set is not
overhanging the edge of the supporting
furniture.
–Not placing the television set on tall
furniture (for example, cupboards or
bookcases) without anchoring both the
furniture and the television set to a suitable
support.
–Not placing the television set on cloth or
other materials that may be located
between the television set and supporting
furniture.
–Educating children about the dangers of
climbing on furniture to reach the television
set or its controls.
If your existing television set is being retained and
relocated, the same considerations as above
should be applied.
The unit emits heat when in operation. Do not
place any covers or blankets on the unit, this may
cause overheating. Do not block ventilation
holes, or set up near radiators. Do not place in
direct sunlight. When placing on a shelf leave 4
inches (10 cm) free space around the entire unit.
Notes when mounting the LED TV on
the wall
If the unit is to be mounted on the wall, contact
the retailer where you purchased the LED TV for
advice, and have the equipment professionally
installed. Incomplete or improper installation
may cause injury to you, and/or damage to the
LED TV.
Safety Warnings
9
Please refer to the table below to ensure the
correct size VESA mount is used with the TV
VESA MOUNTING PATTERN
TV Model
Width
mm
Height
mm
Screw Size
Quantity
FEHD19S0N
100
100
PM4*8mm
4
FEFD22S0D
100
100
PM4*8mm
4
FEHD24S0D
100
100
PM4*8mm
4
Notice for TV Cabinet
If the unit is to be mounted on a cabinet smaller
than length of the unit, it could result in an
unstable location and the unit may tumble over,
making a risk of personal, possibly fatal injury.
Also, this would damage the product seriously.
Accordingly, Furrion accepts no responsibility or
liability for any injuries or property damage
resulting from the improper installation.
WARNING:
●Do not use this TV with wall mounts that
allow the TV to tilt vertically. Vertical tilting
wall mounts may cause structural damage
to the TV.
●Use ONLY fi xed or horizontal swiveling wall
mounts with this TV.
Function Overview
1
0
Control Panel
* Please note that the button layout of the
controls may vary from model to model.
Control Panel
Ejects DVD/ CD
Press to directly enter the channel
search mode
Press to start or pause the playback
VOL+
Press to increase the volume
VOL-
Press to decrease the volume
CH+
Press to skip to the next channel
CH-
Press to skip to the previous channel
MENU
Press to enter the main menu
SOURCE
Press to select the input source
POWER
Press to switch the TV on/off
1
2
3
4
5
6
7
8
9
1
2
4
5
6
8
9
7
3
Function Overview
1
1
EARPHONE
OUT
Connects to 3-conductor (TRS)
phone connector of earphone,
compatibility of earphone with
4-conductor (TRRS) phone
connector is not guaranteed
COAXIAL
Connects to the COAXIAL AUDIO IN
port of an audio device.
VIDEO IN
Connects to the COMPOSITE
VIDEO/ AUDIO OUT ports of a DVD
Player, Cable Box or other
compatible device
AUDIO IN
USB IN
USB Port, view pictures/movies/text
and listen to MP3s via a compatible
USB stick
HDMI 2 ARC
Connects to the HDMI OUT port of a
DVD Player, Games Console, Cable
Box or other HDMI device.
ARC Audio Return Channel When
connected with a HDMI 1.4 cable to
an ARC compatible audio system,
the TV links with the device to give
extra audio functionality
Please see page13
HDMI 1
Connects to the HDMI OUT port of a
DVD Player, Games Console, Cable
Box or other HDMI device. CEC
Consumer Electronics Control When
connected to the CEC compatible
Furrion Entertainment Systems or
other CEC Compatible devices, the TV
links with the system to give extra
functionality. Please see page13.
HDMI 3
VGA IN
+PC AUDIO
IN
Connects to the VGA OUT port of a
PC to use the TV as a monitor.
Connects to the AUDIO OUT port of
a PC.
RF IN
Connects to the ANTENNA, CABLE, or
CABLE BOX
AUDIO OUT
L/R
Connects to the AUDIO IN ports of an
audio device
Function Overview
1
2
Rear Panel
10
YPbPr
Connect to the COMPONENT VIDEO
OUT ports of a DVD Player, Cable Box
or other compatible device
Function Overview
1
3
* The confi guration of the connection ports may
vary from model to model.
Function Overview
1
4
No.
Button
Function
TV
Switches to TV mode
TV/
FIREPLACE
Selects Furrion Fireplace remote
control functions.
* Please refer to your Furrion
Fireplace manual for more
information.
Press to turn the TV/Entertainment
System on/off
NUMBER
BUTTONS
Enters numbers or select channels
Toggles between single & double
digit input
REPEAT
Press to change the playing mode
DVD SETUP
DVD menu setup
T.SHIFT
Press to pause current DTV program
and start recording
TV/RADIO
Press to switch between DTV and
radio programs
EPG
Pres to display EPG information
10
SOURCE
Cycles through input sources
11
NAVIGATION
BUTTONS
Confi rms selections
12
VOL+/-
Increases/decreases volume
13
/ AUTO
TUNE
Ejects DVD/ CD
Press to directly enter the channel
search mode
14
/ HOLD
During playback, press to select
the previous track/chapter. Press
to hold On/Off the current page
display in Teletext mode
15
/ STEP
REVEAL
Press to forward frame by frame
during DVD/ VCD playback.
Dial or accept a call (when the
system is connected to a cell
phone)
Function Overview
1
5
16
DVD/USB
Selects TDVD/USB
17
AM/FM
Selects AM/FM/WB Radio
18
SLEEP/
CLOCK
Sets the sleep timer
Function Overview
1
6
Remote Control
Function Overview
1
7
Function Overview
1
8
1
9
No.
Button Function
19
NICAM /
AUDIO
Cycles through NICAM sound
modes
20
RDM / P.LIST
Toggles random playback mode on
& off
Press to display the recorded
segment
21
SEARCH /
GOTO
Jumps to a specifi c time on a DVD/
VCD/MP3/WMA or CD
22
S.MODE
Select the diff erent sound mode
directly
23
P.MODE
Select the diff erent picture mode
directly
24
SEL
Toggles between Volume, Bass,
Treble & Balance; Hours & Minutes
for adjusting
25
LOC*/SLOW
Toggles radio reception strength.
Presses to start slow motion
playback.
26
ST#/ANGLE
Toggles Stereo & Mono sound/
switches viewing angles on
compatible media.
27
EQ
Toggles the sound mode Cinema,
Rock, Classic & Flat
28
DISPLAY
Toggles on screen on the selected
source On & Off
29
ASPECT
Cycles through available display
aspect ratios
30
PBC/TITLE
Uses to start the programmed
playback function
31
A-B/TTX
Press to start the A-B repeat
function (playback loop of a
segment of track)
Press to turn the Teletext On/Off
No.
Button
Function
36
/ APS
SIZE
Press to scan radio stations: A brief
press searches through each stored
station. Press & hold to scan and
store the 6 strongest stations. End
or reject a call (when the
system is connected to a cell
phone)
37
Press to start or pause the playback
38
/ S.PAGE
During playback, press to select
the next track/ chapter. Display
a sub-page of upper
options
39
/ INDEX
Stops playback
Press to return to the index/initial
page
40
CH+/-
Channel Up/Down
41
Toggles audio On or Off
42
EXIT
Exits the current menu
43
FAV
Press to add the channel to favorite
list
44
C.LIST
Displays the channel list
45
MENU
Enters the main menu
46
REC / AUTO
Press to record the program
immediately
Automatically adjusts the picture in
PC mode
47
PROG
Uses to start the programmed
playback function
48
ZOOM
Press to enlarge screen images
2
0
32
SUBT
Select subtitle language (DVD)
33
FREEZE
To freeze current picture
34
AV
Selects AV Mode
35
AUX/ARC
Selects AUX/ ARC Mode
49
Toggles between the current and
previous channel
50
STEREO
Switches to Stereo mode
This manual suits for next models
2
Table of contents
Other Furrion HDTV manuals
