Furrion FEHS19H3A User manual

LED HDTV19"
Model: FEHS19H3A
USER’S MANUAL

Warning
To prevent fire and/or electric shock, do not use this plug with an extension
cord, receptacle or other outlet unless the blades can be fully inserted to
prevent blade exposure. Do not expose this appliance to rain or moisture.
Important Safety Instructions
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Please, unplug the TV power cord when the following conditions occur:
-When there is a thunderstorm (Please, pull out the power cord and antenna).
-When cleaning the TV set.
-When the TV set is not used for a long time.
Do not use corrosive depurative when cleaning the TV set.
Do not put the TV set under direct sunlight or near heat.
Do not put a heat source, such as a candle or heater, on top of or near the TV set.
Leave plenty of space (at least 10cm) around the TV set for ventilation.
Place the TV set away from where it can be ruined by rain or water (such as near a
window).
Don't put a container with liquid (such as a vase) on top of the TV set.
Do not move the TV set when the power is on.
Do not touch, push or scratch the surface of the TV set with hard materials or items.
When TV surfaces are dirty, please use a wet cotton cloth or soft cloth with non-
corrosive cleaners to clean it carefully. Don´t use acetone, toluene or alcohol to
clean the TV set.
Be aware and careful of moisture, which can damage inner electronic components.
When condensed moisture is present, the TV screen may appear blurry or spotty.
It is recommended that a technician install the TV set on a wall, if such placement is
desired.
An incorrect wall installation will be unsafe and hazardous.
Do not let children climb on or play around the TV set to avoid falls, collissions,
damages and injuries.
Do not hit the TV panel with hard objects to prevent damages.
Do not cover the TV set with blankets or other objects when it is connected to a
power source to prevent overheating and fire.
Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
Mains plug is used as disconnect device from the mains, the disconnect
device shall remain readily operate.
Apparatus with class I construction shall be connected to a mains socket
outlet with a protective earthing connection.
Safety Information
AVIS RISQUE DE CHOC ELEC TRIOUE/NE PAS OUVRIR

Important Safety PrecautionsImportant Safety Precautions
Do not place the power cord or other cables
across a walkway in case it is trampled on. Do
not overload the power cord or power socket.
When the power plug is used to disconnect and
connect the device, it should easily into the
power source.
Do not place the LED TV on an unstable
surface.
Do not disassemble the back cover, as it
contains high voltages inside and will cause
electric shock. Only qualified professionals
sh ou ld co nd uc t i nt er na l a dj us tm en ts ,
maintenance, and checks.
The TV set should not be subjected to
water droplets, vapor, or splash. This
equipment should not be placed on objects
filled with liquids. Do not place flame
sources, such as lit candles, on or near the
LED TV. Please, pull out the power plug
and contact after sales support if there are
abnormal objects or water in the TV.
Pull out the power cord and antenna cable
during electrical storms so the LED TV is not
damaged by electrical surges. Keep all
people away from the antenna cable during
electrical storms.
Please, immediately pull out the AC power
plug from adapter if there is an abnormal
sound or smell or the LED TV has sound
but no picture, and contact after sales
support.
The LED TV should be kept free from rain,
moisture and dust to prevent electrical
shock and short circuits. Do not cover the
ventilation openings with table clothes,
curtains, newspapers, etc.
The LED TV should be kept from high
temperature heating sources or direct
sunlight. Good ventilation is required.
Allow 10 cm. between the LED TV and
other appliances or built-in cabinet walls.
When you wipe the front cabinet, please
make sure the power plug is pulled out and
use a soft, dry, lint-free cloth and handle it
with care. Do not repeatedly wipe the panel,
nor scrape, tap or strike the panel with a hard
object.
Do not wipe the LED TV with any petrol,
chemical or alcohol based solvents as it
will lead to product damage of the panel
and cabinet.
When the television receiver is not used for an
extended period of time, it is advisable to disconnect
the AC power cord from the AC outlet.
The MAINS plug or an appliance coupler is used as the
disconnect device, The disconnect device shall remain
readily operable.

1
Table of Contents
2
Troubleshooting 19
Introduction
Features
Specifications
2
3
Accessories
General Description
Overview of front and side panel
Overview of back panel
Overview of remote control
Installing Batteries in the Remote Control
4
4-7
4
5
6
7
External Connection
Connecting VCR
Connecting DVD Player/Set-Top Box via HDMI
Connecting PC
11
12
9
AUDIO
15
14
OSD Menu Operations
BASIC OPERATION 14
14
Picture defects and the reason 20
9
Supporting signals
13
TIME
CHANNEL
15
16
W arnings
Features
Introduction
Input terminals used for external equipment connection
One computer VGA/PC inpu t
One AV input
l TV adopts TFT LED display screen
l HDTV Compatible( 480p,720p, 1080i, 1080p)
l Support American TV Standard 8VSB/Free 64/256QAM,NTSC System, ATSC System
l Connect to computer directly to realize TV/monitor combo.
l Zero X radiation complies to green environment protection requirement
l Advanced Chroma Processing
l Closed captioning/PARENTAL LOCK
l SAP/STEREO/MONO; ATSC.
l HDMI input
l USB input (for factory use only)
One ANTENNA jack
One PC Audio input
One HDMI input
One USB for factory use only
SETUP 16
LOCK 17
One L/R output
One Earphone output
Connecting DVD Player/Set-Top Box 10
One Component input
Connecting Amplifier/DVD Home Theater
13
Install LED SET
8

34
Please make sure the following items are included with your LED TV. If any items are
missing, contact your dealer.
Accessories
Remote Control &
Batteries (AAAx 2)
Owner’s
Instructions
SPEAKER
REMOTE CONTROL SENSOR
Aim the remote control towards this
spot on the TV.
POWER INDICATOR
Green: In power on mode.
Red: In standby mode.
Toggles between all the available input
CH+/-
Press to change channels.
In the on-screen menu, use the CH +/-
buttons as up/down arrow buttons.
VOL+/-
Press to increase or decrease the volume.
In the on-screen menu, use the VOL +/-
buttons as left/right arrow buttons.
POWER
Press POWER button to toggle between
and standby mode.normal
MENU
Press to see an on-screen menu of your
TV's features.
SOURCE
sources ( TV, AV, Component, HDMI,
PC)
Fine digital control
NTSC3.58
75W (Unbalance)
32 W
Color active matrix LED display
NTSC System, ATSC System
Antenna: 2~69; Cable: 1~135 (Analog: 1-125,
Digital: 1-135)
Note:
Introduction
W arnings
Specifications
DC 3V (Two AAA size batteries)
o
0C-40C
o
Design and specification modification maybe made at any time without
prior notice; all data and dimensions are approximations.
Power supply
1366X768
FEHS19H3A
Model
AC 100-240V 50/60Hz
2 x 5 W
General Description
Overview of front and side panel
18.0 x 1.8 x 11.9 inch
Warranty card
