Fust NOVAMATIC EKI2712RE User manual

EKI2712RE
EKI2712LI
User Manual
Benutzerinformation
Refrigerator
Kühlschrank

CONTENTS
Safety information 2
Safety instructions 3
Operation 5
First use 7
Daily use 7
Hints and tips 10
Care and cleaning 11
Troubleshooting 12
Installation 16
Technical data 17
Subject to change without notice.
SAFETY INFORMATION
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
for any injuries or damages that are the result of incorrect
installation or usage. Always keep the instructions in a safe
and accessible location for future reference.
Children and vulnerable people safety
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.
•Do not let children play with the appliance.
•Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
•Keep all packaging away from children and dispose of it
appropriately.
General Safety
•This appliance is intended to be used in household and
similar applications such as:
–Farm houses; staff kitchen areas in shops, offices and
other working environments
–By clients in hotels, motels, bed and breakfast and other
residential type environments
•Keep ventilation openings, in the appliance enclosure or in
the built-in structure, clear of obstruction.
2

•Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by
the manufacturer.
•Do not damage the refrigerant circuit.
•Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer.
•Do not use water spray and steam to clean the appliance.
•Clean the appliance with a moist soft cloth. Only use neutral
detergents. Do not use abrasive products, abrasive cleaning
pads, solvents or metal objects.
•Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
•If the supply cord is damaged, it must be replaced by the
manufacturer, its Authorised Service Centre or similarly
qualified persons in order to avoid a hazard.
SAFETY INSTRUCTIONS
Installation
WARNING! Only a qualified
person must install this
appliance.
• Remove all the packaging and the transit
bolts.
• Do not install or use a damaged
appliance.
• Follow the installation instruction
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Make sure the air can circulate around
the appliance.
• Wait at least 4 hours before connecting
the appliance to the power supply. This
is to allow the oil to flow back in the
compressor.
• Do not install the appliance close to
radiators or cookers, oven or hobs.
• The rear of the appliance must stand
against the wall.
• Do not install the appliance where there
is direct sunlight.
• Do not install this appliance in areas that
are too humid or too colds, such as the
construction appendices, garages or
wine cellars.
• When you move the appliance, lift it by
the front edge to avoid scratching the
floor.
Electrical connection
WARNING! Risk of fire and
electrical shock.
• The appliance must be earthed.
• Make sure that the electrical information
on the rating plate agrees with the
power supply. If not, contact an
electrician.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
electrical components (e.g. mains plug,
mains cable, compressor). Contact the
Authorised Service Centre or an
3

electrician to change the electrical
components.
• The mains cable must stay below the
level of the mains plug.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
Use
WARNING! Risk of injury,
burns, electrical shock or fire.
• Do not change the specification of this
appliance.
• Do not put electrical appliances (e.g. ice
cream makers) in the appliance unless
they are stated applicable by the
manufacturer.
• Be careful not to cause damage to the
refrigerant circuit. It contains isobutane
(R600a), a natural gas with a high level of
environmental compatibility. This gas is
flammable.
• If damage occurs to the refrigerant
circuit, make sure that there are no
flames and sources of ignition in the
room. Ventilate the room.
• Do not let hot items to touch the plastic
parts of the appliance.
• Do not put soft drinks in the freezer
compartment. This will create pressure
on the drink container.
• Do not store flammable gas and liquid in
the appliance.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
• Do not touch the compressor or the
condenser. They are hot.
• Do not remove or touch items from the
freezer compartment if your hands are
wet or damp.
• Do not freeze again food that has been
thawed.
• Obey the storage instructions on the
packaging of frozen food.
Care and cleaning
WARNING! Risk of injury or
damage to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• This appliance contains hydrocarbons in
the cooling unit. Only a qualified person
must do the maintenance and the
recharging of the unit.
• Regularly examine the drain of the
appliance and if necessary, clean it. If
the drain is blocked, defrosted water
collects in the bottom of the appliance.
Disposal
WARNING! Risk of injury or
suffocation.
• Disconnect the appliance from the mains
supply.
• Cut off the mains cable and discard it.
• Remove the door to prevent children
and pets to be closed inside of the
appliance.
• The refrigerant circuit and the insulation
materials of this appliance are ozone-
friendly.
• The insulation foam contains flammable
gas. Contact your municipal authority for
information on how to discard the
appliance correctly.
• Do not cause damage to the part of the
cooling unit that is near the heat
exchanger.
4

OPERATION
Control Panel
Functions
32 45
6
1
1Display
2Temperature warmer button
3Temperature colder button
4OK
5Functions
6ON/OFF
It is possible to change predefined sound of
buttons by pressing together Functions and
temperature colder button for a few
seconds. Change is reversible.
Display
GH
A B C D
F E
A. Timer indicator
B. Shopping function
C. FastFreeze function
D. Temperature indicator
E. Alarm indicator
F. ChildLock function
G. DrinksChill function
H. FreeStore function
Switching on
Connect the mains plug to the power
socket.
Press the ON/OFF button if the display is
off.
The temperature indicators show the set
default temperature.
To select a different set temperature refer to
"Temperature regulation".
If DEMO appears on the display, refer to
"Troubleshooting".
If the door remains open for
some minutes, the light will turn
off automatically. The light is
reset by closing and opening the
door itself.
Switching off
Press the ON/OFF button for 5 seconds.
The display turns off.
To disconnect the appliance from the
power, disconnect the mains plug from the
power socket.
5

Temperature regulation
Set the temperature of the appliance by
pressing the temperature regulator.
Default set temperature:
• +5°C for the fridge.
The temperature indicators show the set
temperature.
The set temperature will be
reached within 24 hours.
After a power failure the set
temperature remains stored.
Shopping function
If you need to insert a large amount of
warm food, for example after doing the
grocery shopping, we suggest activating
the Shopping function to chill the products
more rapidly and to avoid warming the
other food which is already in the
refrigerator.
1. Press the Functions until the
corresponding icon appears.
The Shopping indicator flashes.
2. Press the OK to confirm.
The Shopping indicator is shown.
The Shopping function shuts off
automatically after approximately 6 hours.
To switch off the function before its
automatic end, repeat the procedure.
The function switches off by
selecting a different fridge set
temperature.
FastFreeze function
The FastFreeze function accelerates the
freezing of fresh food and, at the same
time, protects foodstuffs already stored
from undesirable warming.
1. Press the Functions button until the
corresponding icon appears.
The FastFreeze indicator flashes.
2. Press the OK button to confirm.
TheFastFreeze indicator is shown.
This function stops automatically after 28
hours.
To switch off the function before its
automatic end repeat the procedure until
the FastFreeze indicator goes off.
The function switches off by
selecting a different set
temperature.
Door open alarm
An acoustic alarm will sound if the door is
left open for a few minutes. The door open
alarm conditions are indicated by:
• a flashing Alarm indicator;
• an acoustic buzzer.
When normal conditions are restored (door
closed), the alarm will stop. The buzzer can
also be switched off by pressing any
button.
ChildLock function
Activate the ChildLock function to lock the
buttons from unintentional operation.
1. Press Functions button until the
corresponding icon appears.
The ChildLock indicator flashes.
2. Press OK to confirm.
The ChildLock indicator is shown.
To deactivate the ChildLock function,
repeat the procedure until the ChildLock
indicator goes off.
DrinksChill function
The DrinksChill function is to be used to set
an acoustic alarm at the preferred time,
useful for example when a recipe requires
to cool down food products for a certain
period of time.
It is also useful when a reminder is needed
in order not to forget the bottles placed in
the freezer for fast cooling.
1. Press Functions until the corresponding
icon appears.
The DrinksChill indicator flashes.
The Timer shows the set value (30 minutes)
for a few seconds.
2. Press the Timer regulator to change the
Timer set value from 1 to 90 minutes.
3. Press OK to confirm.
6

The DrinksChill indicator is shown.
The Timer start to flash (min).
At the end of the countdown the DrinksChill
indicator flashes and an audible alarm
sounds. Press OK to switch off the sound
and terminate the function.
To switch off the function repeat the
procedure until the DrinksChill goes off.
It is possible to change the time
at any time during the
countdown and at the end by
pressing the Temperature colder
button and the Temperature
warmer button.
FreeStore function
To switch on the function:
1. Press the Functions button until the
corresponding icon appears.
The FreeStore indicator flashes.
2. Press the OK button to confirm.
The FreeStore indicator is shown.
To switch off the function repeat the
procedure until the FreeStore indicator icon
goes off.
If the function is activated
automatically the FreeStore
indicator is not shown (refer to
"Daily use").
The activation of the FreeStore
function increase the energy
consumption.
FIRST USE
Cleaning the interior
Before using the appliance for the first time,
the interior and all internal accessories
should be washed with lukewarm water
and some neutral soap to remove the
typical smell of a brand-new product, then
dried thoroughly.
CAUTION! Do not use
detergents, abrasive powders,
chlorine or oil-based cleaners as
they will damage the finish.
DAILY USE
WARNING! Refer to Safety
chapters.
Movable shelves
The walls of the refrigerator are equipped
with a series of runners so that the shelves
can be positioned as desired.
WARNING! For better use of
space, the front half-shelves (A)
can be placed under the rear
ones. (B)
A
B
Do not move the glass shelf
above the vegetable drawer to
ensure correct air circulation.
7

Positioning the door shelves
To permit storage of food packages of
various sizes, the door shelves can be
placed at different heights.
1. Gradually pull the shelf in the direction
of the arrows until it comes free.
2. Reposition as required.
FreshZone drawer
The drawer inside the module is suitable for
storing fresh food like fish, meat, seafood,
because the temperature is lower here than
in the rest of the fridge.
The FreshZone drawer is equipped with
runners.
To remove the drawer:
1. Pull toward yourself and remove the
basket by tilting its front upwards
2. Remove the glass shelf above the
drawer.
2
1
CAUTION! Before placing or
removing the FreshZone drawer
inside the appliance, pull out the
vegetable drawer and glass
cover.
FreeStore
The refrigerator compartment is equipped
with a device that allows rapid cooling of
food and keeps a more uniform
temperature in the compartment.
This device activates automatically when
needed, for example for a quick
temperature recovery after door opening or
when the ambient temperature is high.
It is possible to switch on the
device manually when needed
(refer to "FreeStore function").
8

The FreeStore device stops
when the door is open and
restarts immediately after the
door closing.
Humidity control
The glass shelf incorporates a device with
slits (adjustable by means of a sliding lever),
which makes it possible to regulate the
humidity in the vegetable drawer(s).
When the ventilation slots are closed:
the natural moisture content of the food in
the fruit and vegetable compartments is
preserved for longer.
When the ventilation slots are opened:
more air circulation results in a lower air
moisture content in the fruit and vegetable
compartments.
Freezing fresh food
The freezer compartment is suitable for
freezing fresh food and storing frozen and
deep-frozen food for a long time.
To freeze fresh food activate the FastFreeze
function and place the food to be frozen in
the freezer compartment.
The maximum amount of food that can be
frozen in 24 hours is specified on the rating
plate, a label located on the inside of the
appliance.
The freezing process lasts 24 hours: during
this period do not add other food to be
frozen.
When the freezing process is completed,
return to the required temperature (see
"FastFreeze Function").
In this condition, the refrigerator
compartment temperature might
drop below 0°C. If this occurs
reset the temperature regulator
to a warmer setting.
Storage of frozen food
When first starting-up or after a period out
of use, before putting the products in the
compartment let the appliance run at least
2 hours on the higher settings.
In the event of accidental
defrosting, for example due to a
power failure, if the power has
been off for longer than the
value shown in the technical
characteristics chart under
"rising time", the defrosted food
must be consumed quickly or
cooked immediately and then
re-frozen (after cooling).
Thawing
Deep-frozen or frozen food, prior to being
used, can be thawed in the refrigerator
compartment or at room temperature,
depending on the time available for this
operation.
Small pieces may even be cooked still
frozen, directly from the freezer: in this
case, cooking will take longer.
Ice-cube production
This appliance is equipped with one or
more trays for the production of ice-cubes.
Do not use metallic instruments
to remove the trays from the
freezer.
1. Fill these trays with water
2. Put the ice trays in the freezer
compartment.
9

HINTS AND TIPS
Normal operating sounds
The following sounds are normal during
operation:
• A faint gurgling and bubbling sound from
coils sound when refrigerant is pumped.
• A whirring and pulsating sound from the
compressor when refrigerant is pumped.
• A sudden cracking noise from inside
appliance caused by thermic dilatation (a
natural and not dangerous physical
phenomenon).
• A faint click noise from the temperature
regulator when the compressor switches
on or off.
Hints for energy saving
• Do not open the door frequently or leave
it open longer than absolutely necessary.
• If the ambient temperature is high and
the Temperature Regulator is set to low
temperature and the appliance is fully
loaded, the compressor may run
continuously, causing frost or ice on the
evaporator. If this happens, set the
Temperature Regulator toward warmer
settings to allow automatic defrosting
and so a saving in electricity
consumption.
Hints for fresh food refrigeration
To obtain the best performance:
• do not store warm food or evaporating
liquids in the refrigerator
• do cover or wrap the food, particularly if
it has a strong flavour
• position food so that air can circulate
freely around it
Hints for refrigeration
Useful hints:
• Meat (all types): wrap in a suitable
packaging and place it on the glass shelf
above the vegetable drawer. Store meat
for at most 1-2 days.
• Cooked foods, cold dishes: cover and
place on any shelf.
• Fruit and vegetables: clean thoroughly
and place in a special drawer. Bananas,
potatoes, onions and garlic must not be
kept in the refrigerator if not packed.
• Butter and cheese: place in a special
airtight container or wrap in an
aluminium foil or a polythene bag to
exclude as much air as possible.
• Bottles: close with a cap and place on
the door bottle shelf, or (if available) on
the bottle rack.
Hints for freezing
To help you make the most of the freezing
process, here are some important hints:
• the maximum quantity of food which can
be frozen in 24 hours is shown on the
rating plate;
• the freezing process takes 24 hours no
further food to be frozen should be
added during this period;
• freeze only top quality, fresh and
thoroughly cleaned, foodstuffs;
• prepare food in small portions to enable
it to be rapidly and completely frozen
and to make it possible subsequently to
thaw only the quantity required;
• wrap up the food in aluminium foil or
polythene and make sure that the
packages are airtight;
• do not allow fresh, unfrozen food to
touch food which is already frozen, thus
avoiding a rise in temperature of the
latter;
• lean foods store better and longer than
fatty ones; salt reduces the storage life
of food;
• water ices, if consumed immediately
after removal from the freezer
compartment, can possibly cause the
skin to be freeze burnt;
• it is advisable to show the freezing in
date on each individual pack to enable
you to keep tab of the storage time.
Hints for storage of frozen food
To obtain the best performance from this
appliance, you should:
10

• make sure that the commercially frozen
foodstuffs were adequately stored by the
retailer;
• be sure that frozen foodstuffs are
transferred from the foodstore to the
freezer in the shortest possible time;
• not open the door frequently or leave it
open longer than absolutely necessary;
• once defrosted, food deteriorates rapidly
and cannot be refrozen;
• do not exceed the storage period
indicated by the food manufacturer.
CARE AND CLEANING
WARNING! Refer to Safety
chapters.
General warnings
CAUTION! Unplug the
appliance before carrying out
any maintenance operation.
This appliance contains
hydrocarbons in its cooling unit;
maintenance and recharging
must therefore only be carried
out by authorized technicians.
The accessories and parts of
the appliance are not suitable for
washing in a dishwasher.
Periodic cleaning
CAUTION! Do not pull, move or
damage any pipes and/or
cables inside the cabinet.
CAUTION! Take care of not to
damage the cooling system.
CAUTION! When moving the
cabinet, lift it by the front edge
to avoid scratching the floor.
The equipment has to be cleaned regularly:
1. Clean the inside and accessories with
lukewarm water and some neutral soap.
2. Regularly check the door seals and
wipe clean to ensure they are clean and
free from debris.
3. Rinse and dry thoroughly.
4. If accessible, clean the condenser and
the compressor at the back of the
appliance with a brush.
This operation will improve the
performance of the appliance and save
electricity consumption.
The lowest shelf, dividing the cooler
compartment from the compartment can
be removed only for cleaning. To remove
pull out the shelf straight.
To make sure fully functionality
of the CrispFresh compartment
the lowest shelf and cover
plates must be put back in their
original position after cleaning.
The cover plates above the drawers in the
compartment can be taken out for cleaning.
Defrosting of the refrigerator
Frost is automatically eliminated from the
evaporator of the refrigerator compartment
every time the motor compressor stops,
during normal use. The defrost water drains
out through a trough into a special
container at the back of the appliance, over
the motor compressor, where it evaporates.
It is important to periodically clean the
defrost water drain hole in the middle of the
refrigerator compartment channel to
prevent the water overflowing and dripping
onto the food inside.
11

Defrosting the freezer
CAUTION! Never use sharp
metal tools to scrape off frost
from the evaporator as you
could damage it. Do not use a
mechanical device or any
artificial means to speed up the
thawing process other than
those recommended by the
manufacturer. A temperature
rise of the frozen food packs,
during defrosting, may shorten
their safe storage life.
About 12 hours prior to
defrosting, set a lower
temperature, in order to build up
sufficient chill reserve for the
interruption in operation.
A certain amount of frost will always form
on the freezer shelves and around the top
compartment.
Defrost the freezer when the frost layer
reaches a thickness of about 3-5 mm.
1. Switch off the appliance, or pull out
electrical plug from the wall socket.
2. Remove any stored food, wrap it in
several layers of newspaper and put it in
a cool place.
WARNING! Do not touch
frozen goods with wet
hands. Hands can freeze to
the goods.
3. Leave the door open.
In order to speed up the defrosting
process, place a pot of warm water in
the freezer compartment. In addition,
remove pieces of ice that break away
before defrosting is complete.
4. When defrosting is completed, dry the
interior thoroughly.
5. Switch on the appliance.
After three hours reload the previously
removed food into the freezer
compartment.
Periods of non-operation
When the appliance is not in use for long
periods, take the following precautions:
1. Disconnect the appliance from
electricity supply.
2. Remove all food.
3. Defrost (if necessary) and clean the
appliance and all accessories.
4. Clean the appliance and all accessories.
5. Leave the door/doors open to prevent
unpleasant smells.
WARNING! If you want to keep
the appliance switched on, ask
somebody to check it once in a
while to prevent the food inside
from spoiling in case of a power
failure.
TROUBLESHOOTING
WARNING! Refer to Safety
chapters.
12

What to do if...
Problem Possible cause Solution
The appliance does not oper-
ate.
The appliance is switched off. Switch on the appliance.
The mains plug is not con-
nected to the mains socket
correctly.
Connect the mains plug to
the mains socket correctly.
There is no voltage in the
mains socket.
Connect a different electrical
appliance to the mains sock-
et. Contact a qualified electri-
cian.
The appliance is noisy. The appliance is not suppor-
ted properly.
Check if the appliance stands
stable.
Audible or visual alarm is on. The door is left open. Close the door.
A rectangular symbol is
shown instead of numbers on
the Temperature Display.
Temperature sensor prob-
lem.
Contact the nearest Author-
ized Service Centre (the cool-
ing system will continue to
keep food products cold, but
temperature adjustment will
not be possible).
The lamp does not work. The lamp is in stand-by. Close and open the door.
The lamp is defective. Contact the nearest Author-
ized Service Centre.
The compressor operates
continually.
Temperature is set incorrect-
ly.
Refer to "Operation" chapter.
Many food products to be
frozen were put in at the
same time.
Wait a few hours and then
check the temperature again.
The room temperature is too
high.
Refer to climate class chart
on the rating plate.
Food products placed in the
appliance were too warm.
Allow food products to cool
to room temperature before
storing.
The FastFreeze function is
switched on.
Refer to "FastFreeze func-
tion".
The Shopping function is
switched on.
Refer to " Shopping func-
tion".
There is too much frost and
ice.
The door is not closed cor-
rectly or the gasket is de-
formed/dirty.
Refer to "Closing the door".
13

Problem Possible cause Solution
The water drainage plug is
not correctly positioned.
Position the water drainage
plug in the correct way.
Food products are not wrap-
ped properly.
Wrap the food products bet-
ter.
Temperature is set incorrect-
ly.
Refer to "Operation" chapter.
The compressor does not
start immediately after press-
ing the FastFreeze , Shop-
ping or after changing the
temperature.
This is normal, no error has
occurred.
The compressor starts after a
period of time.
Water flows on the rear plate
of the refrigerator.
During the automatic defrost-
ing process, frost melts on
the rear plate.
This is correct.
Water flows into the refrigera-
tor.
The water outlet is clogged. Clean the water outlet.
Food products prevent that
water flows into the water
collector.
Make sure that food prod-
ucts do not touch the rear
plate.
Water flows on the floor. The melting water outlet is
not connected to the evapo-
rative tray above the com-
pressor.
Attach the melting water out-
let to the evaporative tray.
Temperature cannot be set. The FastFreeze or Shopping
function is switched on.
Switch off FastFreeze or
Shopping manually, or wait
until the function resets auto-
matically to set the tempera-
ture. Refer to "FastFreeze
function" or " Shopping func-
tion".
Temperature cannot be set. The FastFreeze function is
switched on.
Switch off FastFreeze man-
ually, or wait until the function
resets automatically to set
the temperature. Refer to
"FastFreeze function"
Temperature cannot be set. The Shopping function is
switched on.
Switch off Shopping manual-
ly, or wait until the function
resets automatically to set
the temperature. Refer to "
Shopping function".
14

Problem Possible cause Solution
DEMO appears on the dis-
play.
The appliance is in demon-
stration mode.
Keep the OK button pressed
for approximately 10 sec-
onds until a long sound is
heard and display shuts off
for a short time.
The temperature in the appli-
ance is too low/too high.
The temperature regulator is
not set correctly.
Set a higher/lower tempera-
ture.
The door is not closed cor-
rectly.
Refer to "Closing the door".
The food products' tempera-
ture is too high.
Let the food products tem-
perature decrease to room
temperature before storage.
Many food products are stor-
ed at the same time.
Store less food products at
the same time.
The thickness of the frost is
greater than 4-5 mm.
Defrost the appliance.
The door has been opened
often.
Open the door only if neces-
sary.
The FastFreeze function is
switched on.
Refer to "FastFreeze func-
tion".
The Shopping function is
switched on.
Refer to " Shopping func-
tion".
There is too much con-
densed water on the rear wall
of the refrigerator.
Door was opened too fre-
quently.
Open the door only when
necessary.
Door was not closed com-
pletely.
Make sure the door is closed
completely.
Stored food was not wrap-
ped.
Wrap food in suitable pack-
aging before storing it in the
appliance.
Door does not open easily. You attempted to re-open
the door immediately after
closing.
Wait a few seconds between
closing and re-opening of the
door.
If the advice does not lead to
the desired result, call the
nearest Authorized Service
Centre.
Replacing the lamp
The appliance is equipped with a longlife
LED interior light.
Only service is allowed to replace the
lighting device. Contact your Authorised
Service Centre.
15

Closing the door
1. Clean the door gaskets.
2. If necessary, adjust the door. Refer to
assembly instructions.
3. If necessary, replace the defective door
gaskets. Contact the Authorised
Service Centre.
INSTALLATION
WARNING! Refer to Safety
chapters.
Location
Refer to the assembly
instructions for the installation.
To ensure best performance, install the
appliance well away from sources of heat
such as radiators, boilers, direct sunlight
etc. Make sure that air can circulate freely
around the back of the cabinet.
Positioning
Install the appliance in a dry, well ventilated
indoors where the ambient temperature
corresponds to the climate class indicated
on the rating plate of the appliance.
Cli-
mate
class
Ambient temperature
SN +10°C to + 32°C
N +16°C to + 32°C
ST +16°C to + 38°C
T +16°C to + 43°C
Some functional problems might
occur for some types of models
when operating outside of that
range. The correct operation
can only be guaranteed within
the specified temperature range.
If you have any doubts
regarding where to install the
appliance, please turn to the
vendor, to our customer service
or to the nearest Authorised
Service Centre.
Ventilation requirements
The airflow behind the appliance must be
sufficient.
5 cm min.
200 cm2
min.
200 cm2
Electrical connection
• Before plugging in, ensure that the
voltage and frequency shown on the
rating plate correspond to your domestic
power supply.
• The appliance must be earthed. The
power supply cable plug is provided with
a contact for this purpose. If the
domestic power supply socket is not
earthed, connect the appliance to a
separate earth in compliance with
current regulations, consulting a qualified
electrician.
• The manufacturer declines all
responsibility if the above safety
precautions are not observed.
• This appliance complies with the E.E.C.
Directives.
16

TECHNICAL DATA
Technical data
Height mm 1523
Width mm 547
Depth mm 575
Rising time Hours 14
Voltage Volts 230 - 240
Frequency Hz 50
The technical information is situated in the
rating plate, on the external or internal side
of the appliance and in the energy label.
WARRANTY / CUSTOMER SERVICE
For each product we provide a two-year
guarantee from the date of purchase or
delivery to the consumer (with a guarantee
certificate, invoice or sales receipt serving
as proof).
The guarantee covers the costs of
materials, labour and travel. The guarantee
will lapse if the operating instructions and
conditions of use are not adhered to, if the
product is incorrectly installed, or in the
event of damage caused by external
influences, force majeure, intervention by
third parties or the use of non-genuine
components.
CONDITIONS DE GARANTIE / SERVICE
Nous octroyons sur chaque produit 2 ans
de garantie à partir de la date de livraison
ou de la mise en service au consommateur
(documenté au moyen d’une facture, d’un
bon de garantie ou d’un justificatif d’achat).
Notre garantie couvre les frais de mains
d’oeuvres et de déplacement, ainsi que les
pièces de rechange.
Les conditions de garantie ne sont pas
valables en cas d’intervention d’un tiers non
autorisé, de l’emploi de pièces de rechange
non originales, d’erreurs de maniement ou
d’installation dues à l’inobservation du
mode d’emploi, et pour des dommages
causés par des influences extérieures ou de
force majeure.
GARANTIEBEDINGUNGEN / KUNDENDIENST
Für jedes Produkt gewähren Wir ab Verkauf
bzw. Lieferdatum an den Endverbraucher
eine Garantie von 2 Jahren. (Ausweis durch
Garantieschein, Faktura oder
Verkaufsbeleg).
Die Garantieleistung umfasst die Kosten für
Material, Arbeits- und Reisezeit.
Die Garantieleistung entfällt bei
Nichtbeachtung der Gebrauchsanweisung
und Betriebsvorschriften, unsachgerechter
17

Installation, sowie bei Beschädigung durch
äussere Einflüsse , höhere Gewalt, Eingriffe
Dritter und Verwendung von Nicht-Original
Teilen.
CONDIZIONI DI GARANZIA / SERVIZIO CLIENTELA
Per ogni prodotto concediamo una
garanzia di 2 anni a partire dalla data di
consegna o dalla sua messa in funzione.
(Fa stato la data della fattura, del certificato
di garanzia o dello scontrino d’acquisto)
Nella garanzia sono comprese le spese di
manodopera, di viaggio e del materiale.
Dalla copertura sono esclusi il logoramento
ed i danni causati da agenti esterni,
intervento di terzi, utilizzo di ricambi non
originali o dalla inosservanza delle
prescrizioni d’istallazione ed istruzioni per
l’uso.
ENVIRONMENTAL CONCERNS
Recycle the materials with the symbol .
Put the packaging in applicable containers
to recycle it. Help protect the environment
and human health and to recycle waste of
electrical and electronic appliances. Do not
dispose appliances marked with the symbol
with the household waste. Return the
product to your local recycling facility or
contact your municipal office.
For Switzerland:
Where should you take your old
equipment?
Anywhere that sells new
equipment or hand it in to official
SENS collection points or official
SENS recycling firms.
The list of official SENS
collection points can be found at
www.erecycling.ch
18

INHALTSVERZEICHNIS
Sicherheitshinweise 19
Sicherheitsanweisungen 20
Betrieb 22
Erste Inbetriebnahme 25
Täglicher Gebrauch 25
Tipps und Hinweise 27
Reinigung und Pflege 29
Fehlersuche 31
Montage 35
Technische Daten 36
Änderungen vorbehalten.
SICHERHEITSHINWEISE
Lesen Sie die mitgelieferte Gebrauchsanleitung sorgfältig vor
Montage und Inbetriebnahme des Geräts. Bei Verletzungen
oder Schäden infolge nicht ordnungsgemäßer Montage oder
Verwendung des Geräts übernimmt der Hersteller keine
Haftung. Bewahren Sie die Anleitung immer an einem sicheren
und zugänglichen Ort zum späteren Nachschlagen auf.
Sicherheit von Kindern und schutzbedürftigen
Personen
•Das Gerät kann von Kindern ab 8 Jahren und Personen mit
eingeschränkten physischen, sensorischen oder geistigen
Fähigkeiten oder mit mangelnder Erfahrung und/oder
mangelndem Wissen nur dann verwendet werden, wenn sie
durch eine für ihre Sicherheit zuständige Person
beaufsichtigt werden oder in die sichere Verwendung des
Geräts eingewiesen wurden und die mit dem Gerät
verbundenen Gefahren verstanden haben.
•Kinder dürfen nicht mit dem Gerät spielen.
•Kinder dürfen keine Reinigung und Wartung ohne
Beaufsichtigung durchführen.
•Halten Sie sämtliches Verpackungsmaterial von Kindern fern
und entsorgen Sie es auf angemessene Weise.
Allgemeine Sicherheit
•Dieses Gerät ist für die Verwendung im Haushalt und
ähnliche Zwecke vorgesehen, wie z. B.:
–Bauernhöfe, Personalküchenbereiche in Geschäften,
Büros und anderen Arbeitsumfeldern
19

–Für Gäste in Hotels, Motels, Pensionen und anderen
wohnungsähnlichen Räumlichkeiten
•Achten Sie darauf, dass die Belüftungsöffnungen im
Gehäuse, um das Gerät und in der Einbaunische nicht
blockiert sind.
•Versuchen Sie nicht, den Abtauvorgang durch andere als
vom Hersteller empfohlene mechanische oder sonstige
Hilfsmittel zu beschleunigen.
•Beschädigen Sie nicht den Kältekreislauf.
•Betreiben Sie in den Lebensmittelfächern des Geräts keine
anderen als die vom Hersteller empfohlenen Elektrogeräte.
•Reinigen Sie das Gerät nicht mit einem Wasser- oder
Dampfstrahl.
•Reinigen Sie das Gerät mit einem weichen, feuchten Tuch.
Verwenden Sie ausschließlich Neutralreiniger. Benutzen Sie
keine Scheuermittel, scheuernde Reinigungsschwämmchen,
Lösungsmittel oder Metallgegenstände.
•Bewahren Sie in dem Gerät keine explosiven Substanzen,
wie Spraydosen mit entzündlichen Treibgasen auf.
•Wenn das Netzkabel beschädigt ist, muss es vom Hersteller,
seinem autorisierten Kundenservice oder einer
gleichermaßen qualifizierten Person ausgetauscht werden,
um Gefahrenquellen zu vermeiden.
SICHERHEITSANWEISUNGEN
Montage
WARNUNG! Nur eine
qualifizierte Fachkraft darf den
elektrischen Anschluss des
Geräts vornehmen.
• Entfernen Sie die
Verpackungsmaterialien und die
Transportschrauben.
• Montieren Sie ein beschädigtes Gerät
nicht und benutzen Sie es nicht.
• Halten Sie sich an die mitgelieferte
Montageanleitung.
• Seien Sie beim Bewegen des Gerätes
vorsichtig, da es sehr schwer ist. Tragen
Sie stets Sicherheitshandschuhe und
festes Schuhwerk.
• Stellen Sie sicher, dass die Luft um das
Gerät zirkulieren kann.
• Warten Sie mindestens 4 Stunden,
bevor Sie das Gerät an das Stromnetz
anschließen. Dies ist erforderlich, damit
das Öl in den Kompressor zurückfließen
kann.
• Stellen Sie das Gerät nicht in der Nähe
von Heizkörpern, Herden, Backöfen
oder Kochfeldern auf.
• Die Geräterückseite muss gegen die
Wand gestellt werden.
20
