IPM650
Intelligent Panel-Mount Display

2
Getting Help
SP1184-A
FUTEK reserves the right to modify its design and specifications without notice.
Please visit http://www.futek.com/salesterms for complete terms and conditions.
10 Thomas, Irvine, CA 92618 USA
Tel: [phone]
Fax: [phone]
www.futek.com
TECHNICAL SUPPORT
For more IPM650 support, please visit: http://www.futek.com/ipm650/support.aspx

3
Display Features . . . . . . . . . . . . . . . . . . . . . 4
Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connector Pin Configuration. . . . . . . . . . . . . . . 6
Wiring Layout . . . . . . . . . . . . . . . . . . . . . . 7
Profile Quick Setup (Calibration) . . . . . . . . . . . . . 9
TEDS and Channel Select . . . . . . . . . . . . . . . .11
Profile Lockout and LCD Settings . . . . . . . . . . . .12
Analog Output Quick Setup . . . . . . . . . . . . . . .13
Alarm and Relay Quick Setup . . . . . . . . . . . . . .14
Data Logging. . . . . . . . . . . . . . . . . . . . . . .16
SENSIT Test and Measurement Software . . . . . . . .18
Performance Review . . . . . . . . . . . . . . . . . . .20
Specifications . . . . . . . . . . . . . . . . . . . . . .21
Setting Sampling rate and number of digits . . . . . . .22
Troubleshooting . . . . . . . . . . . . . . . . . . . . .23
Table of Contents

4
Display Features
16×4 Character LCD
Active Channel Number
Peak Value
Tracking Value
Valley Value
Sampling Rate
1
2
3
4
5
6
IPM650
Channel
Enter
Reset Menu
Track/Hold
Tare/Gross
Unit
Power
Exit
Shunt
Display
Back
1
+2.00001 Peak
+2.00000 mV/V
+1.99999 Valley
01 Gross 5 SPS
4
5
6
3
2
The Units button can change between
similar units.
Hold will flash on the LCD when active.
Shunt will be displayed on the LCD
when active.
The Tare function can be used to zero
out a sensor’s no load state, or to
account for a fixture.
TIPS FOR DISPLAY AND KEY FUNCTIONS

5
Buttons
Channel
Enter
Reset Menu
Track/Hold
Tare/Gross
Unit
Power
Exit
Shunt
Display
Back
Channel
Enter
Reset Menu
Track/Hold
Tare/Gross
Unit
Power
Exit
Shunt
Display
Back
Channel
Enter
Reset Menu
Track/Hold
Tare/Gross
Unit
Power
Exit
Shunt
Display
Back
Channel
Enter
Reset Menu
Track/Hold
Tare/Gross
Unit
Power
Exit
Shunt
Display
Back
Channel
Enter
Reset Menu
Track/Hold
Tare/Gross
Unit
Power
Exit
Shunt
Display
Back
Channel
Enter
Reset Menu
Track/Hold
Tare/Gross
Unit
Power
Exit
Shunt
Display
Back
Channel
Enter
Reset
Menu
Track/Hold
Tare/Gross
Unit
Power
Exit
Shunt
Display
Back
Channel
Enter
Reset Menu
Track/Hold
Tare/Gross
Unit
Power
Exit
Shunt
Display
Back
Channel
Enter
Reset
Menu
Track/Hold
Tare/Gross
Unit
Power
Exit
Shunt
Display
Back
Displays Channel Information
IN MENU MODE: Enter
Toggles between engineering units (force,
torque, pressure, and displacement) and the
standard mV/V.
IN MENU MODE: ▶Arrow
Toggles between displaying the tare and gross
values. Used to remove any fixture weights.
IN MENU MODE: ▲Arrow
Performs a shunt action using internal resistor
IN MENU MODE: Exit
Resets peak/valley
IN MENU MODE: ◀Arrow
ON/OFF
IN MENU MODE: ON/OFF
Start navigation
IN MENU MODE: n/a
Changes display to show peak, tracking,
valley, or all values
IN MENU MODE: Back
Freezes the current reading. HOLD will appear
on the LCD when active. Pressing any key on
the keypad will cancel the hold command.
IN MENU MODE: ▼Arrow

6
IPM650
Channel
Enter
Reset Menu
Track/Hold
Tare/Gross
Unit
Power
Exit
Shunt
Display
Back
A1
B1 C1
D1
A2
B2 C2
D2
A3
B3 C3
D3
A4
B4 C4
D4
A5
B5
A6
B6
A7 A8
Amplified Input (page 7)
Strain Gauge Input
(page 7) Relays (page 8)
Analog Output
(page 8)
Power
Adapter USB Compatible with
USB 2.0 only
CONNECTION TIPS
The +/– Excitation and +/– Signal
connections are used with mV/V output
sensors with the
+/– Excitation used to supply
power to the sensor.
The 24V output supply can be used to
power amplified sensors, such as our
amplified Rotary Torque sensors (for
instance the TRS605).
View online wiring code here:
http://www.futek.com/wirecode.aspx
Connector Pin Configuration

7
Wiring Layout
STRAIN GAUGE INPUT
PIN SYMBOL DESCRIPTION
B1 G Ground/Shield
B2 TEDS TEDS Data
B3 –S –Signal
B4 +S +Signal
B5 –E –Excitation
B6 +E +Excitation
AMPLIFIED INPUT
PIN SYMBOL DESCRIPTION
A1 G Ground/Shield
A2 G Ground/Shield
A3 24V OUT 24VDC Output
A4 5V OUT 5VDC Output
A5 –V –V and –mA Amplified Input Connections
A6 +V +V and +mA Amplified Input Connections
A7 PLEAD n/a
A8 PLAG n/a
Note: Shield should only be connected on either sensor side or instrument side. If connected on instrument side use follow-
ing directions. Connect shield to pin A1 or pin A2 of Amplified Input if sensor is amplified. Connect shield to pin B1 of Strain
Gauge Input if sensor is strain gauge.

8
RELAYS
PIN SYMBOL DESCRIPTION
C1 –R2 Solid State Relay 2 (–)
C2 +R2 Solid State Relay 2 (+)
C3 –R1 Solid State Relay 1 (–)
C4 +R1 Solid State Relay 1 (+)
ANALOG OUTPUT
PIN SYMBOL DESCRIPTION
D1 –VOUT Voltage Output (–)
D2 +VOUT Voltage Output (+)
D3 G Ground (current)
D4 IOUT Current Output
Ground (G) connections can be used to
connect a cable shield.
Strain Gauge Input is for sensors with a
mV/V output level.
Green screw terminals can be
removed to allow easy access to
connect the wires.
TIPS FOR WIRING
Wiring Layout (continued)
IPM650 Wiring Connection Examples: http://www.
futek.com/files/Pdf/Manuals_and_Technical_
Documents/IPM650Wiring.pdf

9
The IPM650 can store up to 15 profiles with channel 2 through 15 being user selectable.
1. Menu
2. Sensor Profile
3. New Channel
4. Set channel using left and right
arrow keys followed by Enter
5. Sensor Config and choose sensor
output type
6. Direction
7. Unit Selection
8. Sensor Capacity
9. Sensitivity (+)
10. Sensitivity (–) if applicable
11. Serial Number, (Serial number on
sensor)
12. Back to go back one menu
13. Save Changes
14. Back to exit Main Menu and put the
IPM650 into normal reading display
Profile Quick Setup (Calibration)

10
The decimal point can be moved by selecting it first and
turning it into a number, and then selecting another
digit to change it into a decimal point.
Sensitivity (+) must be entered. If only one direction is
selected, then sensitivity (+) will be applied to both directions
of output or negative direction output.
Sensitivity is the sensor’s output level, such as mV/V output,
and is found on the calibration certificate.
Pressing back without saving will prompt to exit without
saving. Enter can be used for Yes, and Back for No.
Current profiles cannot be set up manually and must be set up
using the Live Calibration feature in the profile setup.
Full bridge sensor type is for mV/V output sensors. Voltage
output and current output are for amplified inputs to the
IPM650.
Online sensor calibration data may be available by sensor
serial number at http://www.futek.com/CalibrationData.aspx
to assist in finding your sensor’s output or sensitivity.
TIPS FOR SETTING UP A PROFILE
A full profile setup guide can be found on our
FUTEK website at: http://www.futek.com/files/
Pdf/QuickStartGuide/IPM650ProfileSetup.pdf

11
TEDS MENU
1. Menu
2. TEDS Data
3. TEDS Device — Will show information about TEDS chip.
4. TEDS Pages — Shows programmed information stored
in chip.
5. Load Data — Will load TEDS information into IPM650.
6. Auto Detection — Sets the IPM650 to automatically
load TEDS information upon power on.
CHANNEL SELECT (CALIBRATION PROFILE SELECT)
1. Menu
2. System Setting
3. Channel Select
4. Use the left and right arrow key to choose the desired
channel.
5. Enter to load Channel or Profile.
TEDS and Channel Select
TEDS is a small chip that can store a sensor’s calibration infor-
mation. The IPM650 can read it upon power up, or by loading
it through the menu, and setup a profile with the stored
information.
TEDS calibration information can be viewed upon loading
TEDS, either during a power on or while selecting Load Data
under the TEDS menu.
The TEDS chip should be placed within 5ft. of the IPM650
sensor connection to maintain proper power. Typically the
TEDS chip is placed in the sensor binder connector.
An auto-calibration may be performed when loading TEDS
information, or a new channel or profile.
TIPS FOR USING TEDS AND CHANNEL SELECT

12
LOCK SETTING MENU
1. Menu
2. Lock Setting
a. Lockout Profile
b. Unlock Profile
c. Change Password
LCD SETTINGS
1. Menu
2. LCD Setting
a. Contrast
b. Brightness
c. Auto LCD Off
Profile Lockout and LCD Settings
To lockout the ability to create, edit, or delete a calibration
profile in the IPM650, use the Lock Settings menu.
The default lockout password will be the serial number on
the back of the IPM650. The password can be changed to a
new numerical combination.
The LCD contrast and brightness can be set to maximum
and the levels can be saved as default for all future usage
of the IPM650.
Use the left and right arrow keys to increase or decrease
the brightness and contrast of the LCD display in the LCD
display setup menu.
A message stating, “Selected feature is not available at this
time,” will be displayed when profile control is
locked out.
Profile will be locked out when a system calibration at
FUTEK is performed.
TIPS FOR PROFILE LOCKOUT & LCD SETTINGS
IPM650
Channel
Enter
Reset Menu
Track/Hold
Tare/Gross
Unit
Power
Exit
Shunt
Display
Back
SELECTED FEATURE
IS NOT AVAILABLE
AT THIS TIME
(HIT ENTER/BACK)

13
VOLTAGE OUTPUT
Output Type Setup:
1. Menu
2. Output Config.
3. Voltage Config.
4. Select Bi-polar or Uni-polar
Turn on voltage output:
5. Back to exit to main menu
6. Interfaces
7. Voltage Output
8. Select Enable
9. Back to main menu
10. Back again to exit
CURRENT OUTPUT
Output Type Setup:
1. Menu
2. Output Config.
3. Current Value
4. Select current output range
5. Current Config.
6. Select Uni-direction or Bi-direction
Turn on current output:
7. Back to exit to main menu
8. Interfaces
9. Current Output
10. Select Enable
11. Back to exit to main menu
Analog Output Quick Setup
Bi-polar and Uni-polar for voltage
configurations will determine if the
output would be ±5VDC for both
directional outputs from the sensor, or
map both directional outputs to +5VDC
with the zero at 2.5VDC.
Analog Low is set to zero load readings
and Analog High is set to the full
capacity of the sensor profile.
Uni-direction or Bi-direction for current
will determine if the current output range
is for the positive output of the sensor, or
if the zero should be shifted to allow the
selected current output range to adjust
for both directions from the sensor.
A Tare function will affect the reading
on the IPM650 as well as the Analog
Output.
TIPS FOR ANALOG OUTPUT

14
ALARM SETUP
Alarm Limit set points:
1. Menu
2. Sensor Profile
3. Edit Channel (Choose appropriate channel)
4. Limit & THD
5. Alarm Limit Hi and Alarm Limit Lo
(Set the appropriate percentage of the full sensor’s
output for Hi and Lo limits)
6. Back to Edit Profile Menu
7. Back to Profile Menu
8. Save Changes
9. Back to Main Menu
10. Back to Display Screen
Alarm Configuration and Alarm Activity:
11. Menu
12. System Settings
13. Alarm Config (Latched or Non-Latched)
14. Alarm Activity (Enable or Disable)
15. Back to Main Menu
16. Back to Display Screen
Alarm and Relay Quick Setup

15
RELAY SETUP
Output configuration:
1. Menu
2. Output Config.
3. Alarm Relay 1 and Alarm Relay 2
4. Choose Normally Open or Normally Closed
5. Back to Output Config. Menu
6. Back to Main Menu
7. Back to Display Screen
Activate Relays:
8. Menu
9. Interfaces
10. Relay 1 and Relay 2 Output (Enable or Disable)
11. Back to Main Menu
12. Back to Display Screen
Alarm Relay 1 is mapped to Alarm High
and Alarm Relay 2 is mapped to Alarm
Low.
Threshold limits are set as a percentage
of the capacity of the sensor.
Pressing Reset on the IPM650 will reset
any alarm status.
Peak will flash on the IPM650 for an
active alarm high state, and Valley will
flash for an active low alarm state.
Alarms function off GROSS
readings.
TIPS FOR ALARMS AND RELAYS

16
Data logging is the ability to capture readings over a specified time period for later evaluation. The Data logging information
can be uploaded into the FUTEK SENSIT software and further exported into other programs, such as Microsoft Excel.
DATA LOGGING QUICK SETUP
1. Menu
2. Data Logging
3. Logging Rate
4. Choose Full speed or Half Speed
5. Duration
6. Enter duration of data logging test in seconds
7. Action
8. Choose to Start or Stop data logging session
Data Logging

17
The IPM650 can store up to 21,000 data
logging points. Each point is a captured
reading.
The sampling rate used will be the
current sample per second setting in the
IPM650 when Full Speed is selected and
half the current set sampling rate when
Half Speed is selected.
The maximum data logging duration
will be the 21,000 data logging points
divided by the sampling rate used.
The data logging information is lost
when power is turned off on the IPM650.
At slower sampling it is possible to exit
the data logging menu to view a count-
down timer.
A check mark will be present next to
Action to show a data logging session is
active.
When the data logging session is
complete the IPM650 will display a
successful message and return to the
display screen.
Pressing stop before the end of a session
will result in the captured readings
overwriting the prior readings up till the
run time.
TIPS FOR USING DATA LOGGING

18
The IPM650 can be used with the FUTEK SENSIT software, which can be purchased separately or evaluated through a free trial
version available on the FUTEK website.
FUNCTIONS AVAILABLE IN SENSIT WITH THE
IPM650:
• Ability to see current reading in Display table
• Ability to upload, list, plot, and export data logging
information from the IPM650
• Ability to view, list, and export a live graphing session
• Ability to remotely control the IPM650 through a virtual
front panel
TO SETUP DATA LOGGING IN SENSIT FOR IPM650:
1. Data Logging Mode Tab
2. Settings
3. File Path
4. Start Test
In SENSIT the items that do not apply to the IPM650 will be
grayed out in the Data logging Settings.
Start Test will import the data logging information into
SENSIT.
SENSIT™Test and Measurement Software

19
The IPM650 should be turned on and
connected to the computer prior to
starting SENSIT.
USB output, under Interfaces in the
IPM650, should be enabled with a check
mark to confirm its operation.
TIPS FOR USING SENSIT WITH THE IPM650

20
Performance Review
INPUT
PARAMETER MIN MAX UNIT
Input Range 1 –500 500 mV/V nom.
Input Range 2 –12 12 VDC
Input Range 3 0 30 mA
OUTPUT
PARAMETER MIN MAX UNIT
Analog Voltage 0 5 VDC
–5 5 VDC
Analog Current 0 20 mA
4 20 mA
0 25 mA
5 25 mA
POWER ADAPTER
PARAMETER MIN MAX
Input 90–264 VAC 0.5 A 50/60 Hz
Output 15 VDC 1.2A
