Futon On Line VIENNA User manual

BIFOLD BODY
i
Page 1 of 3
Assembly
Instructions
Parts in this box.
Hardware attached to Back Deck Side Rail.
FUTON FRAME
1A
2FA-0300-I
1B
i
Queen
Chair
Instructions apply to all sizes:
Love seat
Full/Double
Instructions for the Arm assembly, are packed in the Arm box.
Stretchers x 2
Pieces
Back Deck
Stretchers x 2
Pieces
Seat Deck
Seat Deck
Back Deck
Chair Size Full Size
Back Deck Back Deck
Stretchers x 2
Pieces
Seat DeckSeat Deck
Stretchers x 2
Pieces
Love seat Size Queen Size
Locking Pins
x2 Pieces
Clevis Pins
x2 Pieces
Washers
x2 Pieces

Page 2 of 3
Assembly Instructions BIFOLD FUTON FRAME
Prepare Arms for Assembly.
2A
Fit Wooden Dowels.
Rear stretcher ( no plates )
2B Attach Arms to Stretchers.
Your arm style may vary.
The Front Stretcher has metal plates which should face upwards.
Using Bolts and Barrel Nuts provided with the Arms,
attach the Arms LOOSELY to the Stretchers as shown..
FA-0300
Queen
Chair
Love seat
Full/Double
It is important that these bolts are left loose!
Fasten Stretcher Brackets to Arm.
NOTE: The hardware for these steps is included with the Arms.
Some Arms may not have these features, so just skip these steps.
Cleat
A.
C.
Insert the Stretcher
Bracket Cleat into
the hole provided.
Each arm requires
two brackets, front
and back.
B. IMPORTANT: Don't
fully tighten Bracket
until Stretchers are
all in place for easy
alignment.
Stretcher
Bracket
Hole for cleat
Leg
Dowel Hole Stretcher
Bracket
16mm Bolt
Allen Key
Hole for bolt
Wooden Dowel
Stretcher
Tap dowels all the way into the middle
hole, at each end of the Stretchers
Middle
hole
THIS END
FRONT
Wooden Dowel
(See above)
Barrel Nuts
Allen Key -
Leave bolts LOOSE!
Bolts
Bolts
Bolts
Do not tighten
the Bolts at
this stage!
Be sure the holes are
free of wood chips
and saw dust.
Do not force the Bolt
as you may strip the
thread. Be sure the
thread is properly started.
Barrel Nut
Bolt
Allen Key Screwdriver
BOLT AND BARREL NUT
ASSEMBLY SYSTEM
Insert Barrel Nuts as shown
using a screwdriver. This will
help you position the Nut in
line with the Bolt.
Bolt

See separate page enclosed in this box for Operating Instructions.
Your arm style may vary
When you have the Back Deck fitted lying
flat, tighten all the Bolts. From the back,
lift the Back Deck to upright as illustrated.
iPage 3 of 3
Insert the Back Deck lying flat. Insert one
end first, then gently lower the other end into position.
Your arm style may vary
A.
B.
Fit the seat deck between
the Arms and into the Back
Deck as shown. Use the
Clevis Pins to connect the
two decks. Secure with a
Washer and Locking Pin.
Remember that the Bolts on the
Arm should be LOOSE.
Be careful not to scratch the Arms
with the Plastic Runners when you
lower the ends of the Back Deck.
This step can be tricky - it is best
done with two people
CAREFUL!
These can
scratch the
Arms.
All four joints
must be left
LOOSE.
The Seat Deck has a
sticker to indicate the top.
A.
3A
Assembly Instructions BIFOLD FUTON FRAME
Fit Back Deck into Position.
FA-0300-I
Queen
Chair
Love seat
Full/Double
3B Fit Seat Deck into Position.
Clevis Pin
Clevis Pin
Locking Pin
Washer
THIS END
FRONT
Tighten all the Bolts

Fasten Stretcher Brackets to Arm
VIENNA ARM
BIFOLD ARMS See below for
Preparation of arms
for assembly.
i
Hardware in this box
2
3
Page 1 of 1
Assembly
Instructions
1One pair of Bifold Arms
i
4
5
Instructions for Bifold Body assembly, are packed in the Body box.
Assemble the Bifold Body
BODY INSTRUCTIONS: Instructions for assembly of
arms to bifold body are in the bifold body box.
Outside View
Inside View
Stretcher Bracket
x4 Pieces
16mm bolts x 4 Pieces
60mm bolts x 8 Pieces Allen Key x 1 Piece
Barrel nuts
x8 Pieces
Wooden dowel
x4 Pieces
Cleat
A.
C.
Insert the Stretcher Bracket Cleat
into the hole provided.
Each arm requires two brackets, front and back.
B. IMPORTANT: Don't fully tighten Bracket until
Stretchers are all in place for easy alignment.
Stretcher
Bracket
16mm Bolt
Allen Key
Hole for
cleat
Leg
Dowel
Hole
Hole for
bolt
Stretcher Bracket
Dowel from
THIS BOX
Stretcher Rail
from BODY BOX
Tap dowel all the way into this
hole before assembly to arm.
NOTE: Fitting
Wooden Dowels
