Futurecom VRX1000 Operating instructions

VRX1000
P25 VEHICLE RADIO EXTENDER
8M087X01 R2 October 2015
Installation & Programming Guide

8M087X01 R2
ii
NOTES

8M087X01 R2
iii
Related Publications
Publication
Number
Description
8A087X02
VRX1000 User’s Guide
8A087X01
VRX1000 Ordering Guide
8K087X02
VRX1000 Functional Description
Manual Revisions
Rev #
Date
ECN
Notes & References
0
November 10, 2014
na
Original Release
1
July 22, 2015
15026
Firmware1.20/SR7.15.5 Update
2
October15, 2015
15053
Firmware1.21/Q4 2015 SERUpdate

8M087X01 R2
iv
Foreword
This manual provides Installation and Programming guidelines for the Futurecom
Vehicle Radio Extender (VRX1000) which is interfaced to a remote mount APX2500,
APX4500, APX5500, APX6500 or APX7500 Mobile radio with a corresponding
compatible control head.
For details on the VRX1000 Operation, please refer to the VRX1000 User’s Guide
8A087X02.
For details on the APX™4500,APXTM6500 or APXTM7500 Mobile Radio operation, please
refer to the applicable Manuals available from Motorola.
The VRX1000 Operation described in this Document requires the following
Firmware:
APX2500/APX4500/APX6500/APX7500 - firmware release: Host R14.04.00 or later.
APX Mobile Radios operating as the host mobile for the VRX1000 require subscriber
option GA00631 for operation.
APX2000/APX4000 / APX6000 / APX7000 –firmware release R13.00.00 or later.
APX Portable Radios operating through a DVR/VRX, utilizing the enhanced DVR/VRX
digital feature set require subscriber option QA00631.
APX Control Head - firmware release R20.00.00 or later.
VRX must be loaded with application firmware release version: R1.21.
Tweaker Programming software version 1.06 or later.

8M087X01 R2
v
Computer Software Copyrights
The products described in this manual include copyrighted Futurecom computer programs
stored in semiconductor memories or other media. Laws in the United States, Canada and
other countries preserve for Futurecom certain exclusive rights for copyrighted computer
programs, including but not limited to, the exclusive right to copy or reproduce in any form
the copyrighted computer programs. Any copyrighted computer program contained in the
Futurecom products described in this manual may not be copied, reproduced, modified,
reverse-engineered, or distributed in any manner without the express written permission of
Futurecom. The purchase of Futurecom products shall not be deemed to grant either
directly or by implication, estoppels, or otherwise, any license under the copyrights, patents
or patent applications of Futurecom, except for the normal non-exclusive license to use that
arises by operation of law in the sale of a product.
The Tweaker Programming Software provided by Futurecom Systems Group ULC includes
the following Publicly Available Software.
Publicly Available Software List
Name: MFC Grid Control
Version: 2.24
Modified: Yes
Software Site: http://www.codeproject.com/KB/miscctrl/gridctrl.aspx
Source Code: No Source Code Distribution Obligations. The Source Code may be obtained from the
original Software Site.
License: The Article associated with the Source Code is licensed under the Code Project Open License
(CPOL), version 1.02. Referencethe CommonLicenses Section for the terms of the CPOL. The Source Code
licensed is under Custom Freeware / Open Source Software License, see below:
Written by Chris Maunder <[e-mail]>
Copyright (c) 1998-2002. All Rights Reserved.
This code may be used in compiled form in anywayyou desire. This file maybe redistributed unmodified by
any means PROVIDING it is not soldfor profit withoutthe authors writtenconsent,andprovidingthat this notice
and the authors name and all copyright notices remains intact.
An email letting me know how you are using it would be nice as well.
This file is provided "as is" with no expressed or implied warranty.
The author accepts no liabilityfor anydamage/loss of business that this productmaycause.
Additional Notices:
CInPlaceEdit,http://www.codeguru.com/listview/edit_subitems.shtml, licensed under the CodeGuru License.

8M087X01 R2
vi
Refer to the Common Licenses Section for the terms of the CodeGuru License.
Credits:
Zafir Anjum
Eric Woodruff
Ken Bertelson
Joe Willcoxson
Publicly Available Software –Common Licenses
The Code Project Open License (CPOL) 1.02
Preamble
This License governs Your use of the Work. This License is intended to allow developers to use the Source
Code and Executable Files provided as part of the Work in anyapplication in anyform.
The main points subject to the terms of the License are:
Source Code and Executable Files can be used in commercial applications;
Source Code and Executable Files can be redistributed; and
Source Code can be modified to create derivative works.
No claim of suitability, guarantee, or any warranty whatsoever is provided. The software is provided
"as-is".
The Article accompanyingtheWork maynot be distributed orrepublishedwithouttheAuthor's consent
This Licenseis entered betweenYou, the individualorother entity readingorotherwisemakinguseoftheWork
licensed pursuantto this Licenseand the individual orother entity whichoffers the Work underthe terms of this
License ("Author").
License
THE WORK (AS DEFINED BELOW) IS PROVIDED UNDER THE TERMS OF THIS CODE PROJECT OPEN
LICENSE ("LICENSE"). THE WORK IS PROTECTED BY COPYRIGHT AND/OR OTHER APPLICABLE LAW.
ANY USE OF THE WORK OTHER THAN AS AUTHORIZED UNDER THIS LICENSE OR COPYRIGHT LAW
IS PROHIBITED.
BY EXERCISING ANY RIGHTS TO THE WORK PROVIDED HEREIN, YOU ACCEPT AND AGREE TO BE
BOUND BY THE TERMS OF THIS LICENSE. THE AUTHOR GRANTS YOU THE RIGHTS CONTAINED
HEREIN IN CONSIDERATION OF YOUR ACCEPTANCE OF SUCH TERMS AND CONDITIONS. IF YOU DO
NOT AGREE TO ACCEPT AND BE BOUND BY THE TERMS OF THIS LICENSE, YOU CANNOT MAKE ANY
USE OF THE WORK.
1. Definitions.
a. "Articles" means, collectively, all articles written by Author which describes how the Source
Code and Executable Files for the Work maybe used bya user.
b. "Author" means the individual or entitythatoffers the Work under the terms of this License.
c. "Derivative Work" means a work based upon the Work or upon the Work and other pre-
existing works.
d. "Executable Files" refer to the executable files, binary files, configuration and any required
data files included in the Work.
e. "Publisher" means the provider of the website, magazine, CD-ROM, DVD or other medium
from or bywhich the Work is obtained byYou.
f. "Source Code" refers to the collection of source code and configuration files used to create
the Executable Files.

8M087X01 R2
vii
g. "Standard Version" refers to sucha Work if it has notbeenmodified,or has been modified in
accordance with the consent of the Author, such consent being in the full discretion ofthe
Author.
h. "Work" refers to the collectionof files distributed bythe Publisher,includingthe SourceCode,
Executable Files, binaries, data files, documentation, whitepapers and the Articles.
i. "You" is you, an individual or entity wishing to use the Work and exercise your rights under
this License.
2. Fair Use/Fair Use Rights. Nothing in this License is intended to reduce, limit, or restrict any rights
arising from fair use, fair dealing, first sale or other limitations on the exclusive rights of the copyright
owner under copyright law or other applicable laws.
3. License Grant. Subject to the terms and conditions of this License,the Author herebygrants You a
worldwide, royalty-free, non-exclusive, perpetual (for the duration of the applicable copyright) license
to exercise the rights in the Work as stated below:
a. You may use the standard version of the Source Code or Executable Files in Your own
applications.
b. You may apply bug fixes, portability fixes and other modifications obtained from the Public
Domain or from the Author. A Work modified in such a way shall still be considered the
standard version and will be subjectto this License.
c. You may otherwise modify Your copy of this Work (excluding the Articles) in any way to
create a Derivative Work, provided that You insert a prominent notice in each changed file
stating how,when and where You changed that file.
d. You may distribute the standard version of the Executable Files and Source Code or
Derivative Work in aggregate with other (possiblycommercial) programs as part of a larger
(possiblycommercial) software distribution.
e. The Articles discussing the Work published in anyform bythe author maynot be distributed
or republished without the Author's consent. The author retains copyright to any such
Articles. You may use the Executable Files and Source Code pursuant to this License but
you maynot repostorrepublishorotherwise distributeormakeavailablethe Articles, without
the prior written consent of the Author.
Any subroutines or modules supplied byYou and linked into the Source Code or Executable Files of
this Work shallnotbe consideredpartof this Work and willnot be subjectto the terms of this License.
4. Patent License. Subject to the terms and conditions of this License, each Author hereby grants to
You a perpetual, worldwide, non-exclusive, no-charge, royalty-free, irrevocable (except as stated in
this section) patent license to make,have made, use,import,and otherwise transfer the Work.
5. Restrictions. The licensegranted in Section 3 above is expresslymade subjectto and limited bythe
following restrictions:
a. You agree not to remove any of the original copyright, patent, trademark, and attribution
notices andassociated disclaimersthatmayappear in the Source Code or Executable Files.
b. You agree not to advertise or in anywayimplythat this Work is a productof Your own.
c. The name of the Author may not be used to endorse or promote products derived from the
Work without the prior written consent of the Author.
d. You agree not to sell, lease, or rent any part of the Work. This does not restrict you from
including the Work or any part of the Work inside a larger software distribution that itselfis
being sold. The Work byitself, though, cannot be sold, leased or rented.
e. You may distribute the Executable Files and Source Code only under the terms of this
License,and You mustincludea copy of, or the Uniform Resource Identifier for, this License
with every copy of the Executable Files or Source Code You distribute and ensure that
anyone receiving such Executable Files and Source Code agrees that the terms of this
License apply to such Executable Files and/or Source Code. You may not offer or impose
any terms on the Work that alter or restrict the terms of this License or the recipients'
exercise of the rights granted hereunder. You maynot sublicense the Work. You must keep
intact all notices that refer to this License and to the disclaimer of warranties. You maynot
distributethe Executable Files or Source Code with anytechnological measures that control
access or use of the Work in a manner inconsistent with the terms of this License.
f. You agree not to use the Work for illegal, immoral or improper purposes, or on pages
containing illegal, immoral or improper material. The Work is subject to applicable export
laws.You agreeto complywith allsuch laws andregulations thatmayapplyto the Work after
Your receipt of the Work.

8M087X01 R2
viii
6. Representations, Warranties and Disclaimer. THIS WORK IS PROVIDED "AS IS", "WHERE IS"
AND "AS AVAILABLE", WITHOUT ANY EXPRESS OR IMPLIED WARRANTIES OR CONDITIONS
OR GUARANTEES. YOU, THE USER, ASSUME ALL RISK IN ITS USE, INCLUDING COPYRIGHT
INFRINGEMENT, PATENT INFRINGEMENT, SUITABILITY, ETC. AUTHOR EXPRESSLY
DISCLAIMS ALL EXPRESS, IMPLIED OR STATUTORY WARRANTIES OR CONDITIONS,
INCLUDING WITHOUT LIMITATION, WARRANTIES OR CONDITIONS OF MERCHANTABILITY,
MERCHANTABLE QUALITY OR FITNESS FOR A PARTICULAR PURPOSE, OR ANY WARRANTY
OF TITLE OR NON-INFRINGEMENT, OR THAT THE WORK (OR ANY PORTION THEREOF) IS
CORRECT, USEFUL, BUG-FREE OR FREE OF VIRUSES. YOU MUST PASS THIS DISCLAIMER
ON WHENEVER YOU DISTRIBUTE THE WORK OR DERIVATIVE WORKS.
7. Indemnity. You agree to defend, indemnifyand hold harmlessthe Author and the Publisher from and
againstanyclaims,suits,losses,damages,liabilities,costs,and expenses(including reasonable legal
or attorneys’ fees) resulting from or relating to any use of the Work by You.
8. Limitation on Liability. EXCEPT TO THE EXTENT REQUIRED BY APPLICABLE LAW, IN NO
EVENT WILL THE AUTHOR OR THE PUBLISHER BE LIABLE TO YOU ON ANY LEGAL THEORY
FOR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL, PUNITIVE OR EXEMPLARY DAMAGES
ARISING OUT OF THIS LICENSE OR THE USE OF THE WORK OR OTHERWISE, EVEN IF THE
AUTHOR OR THE PUBLISHER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
9. Termination.
a. This License andthe rights granted hereunder will terminate automaticallyupon anybreach
by You of any term of this License. Individuals or entities who have received Derivative
Works from You underthis License,however, will not have their licensesterminatedprovided
such individuals orentities remain in full compliance with those licenses. Sections 1, 2, 6, 7,
8, 9, 10 and 11 will survive anytermination of this License.
b. If You bring a copyright, trademark, patent or any other infringement claim against any
contributor over infringements You claim are made by the Work, your License from such
contributor to the Work ends automatically.
c. Subject to the above terms and conditions, this License is perpetual (for the duration of the
applicablecopyrightinthe Work). Notwithstandingthe above, the Author reserves the right to
release the Work under different license terms or to stop distributing the Work at anytime;
provided, howeverthat anysuchelectionwillnot serve to withdrawthis License (or anyother
licensethathas been,or is required to be, granted under the terms ofthis License), and this
License will continue in full force and effect unless terminated as stated above.
10. Publisher. The parties hereby confirm that the Publisher shall not, under any circumstances, be
responsible for and shall not have any liability in respect of the subject matter of this License. The
Publishermakesnowarrantywhatsoeverin connectionwiththe Work andshall not be liable to You or
any party on any legal theory for any damages whatsoever, including without limitation anygeneral,
special, incidental or consequential damages arising in connection to this license. The Publisher
reserves the right to cease making the Work available to You at anytime without notice
11. Miscellaneous
a. This License shall be governed bythe laws of the location of the head office of the Author or
if the Author is an individual, the laws of location of the principal place of residence of the
Author.
b. If any provision of this License is invalid or unenforceable under applicable law, it shall not
affect the validity or enforceability of the remainder of the terms of this License, and without
further action by the parties to this License,suchprovisionshall be reformedto the minimum
extent necessaryto make such provision valid and enforceable.
c. No term or provision of this License shall be deemed waived and no breach consented to
unless suchwaiver or consent shall be in writing and signed bythe partyto be charged with
such waiver or consent.
d. This License constitutes the entire agreement between the parties with respect to the Work
licensed herein.Thereareno understandings,agreements orrepresentationswith respect to
the Work not specified herein. The Author shall not be bound by any additional provisions
that mayappear in anycommunication from You. This License maynot be modified without
the mutual written agreement of the Author and You.

8M087X01 R2
ix
CodeGuru License
http://www.codeguru.com/submission-guidelines.php#permission
As you know, this site is a valuable resource for the developer community. Please note, however,
that to avoid legal complications, we need to obtain your permission to use any computer code and
any related materials ("resources") that you are providing to us. Accordingly, by submitting any such
resource to CodeGuru, you grant to QuinStreet a nonexclusive, worldwide, perpetual license to
reproduce, distribute, adapt, perform, display, and sublicense the submitted resource (in both object
and source code formats, as well as on and off the Web), and you acknowledge that you have the
authority to grant such rights to QuinStreet.
By submitting the resource, you also grant your article's readers the permission to use any source
code in the resource for commercial or noncommercial software. PLEASE NOTE THAT YOU
RETAIN OWNERSHIP OF ANY COPYRIGHTS IN ANY RESOURCES SUBMITTED!
ALSO, IN MAKING THE RESOURCE AVAILABLE TO OTHER SITE VISITORS FOR
DOWNLOADING, QUINSTREET WILL INFORM SUCH OTHER VISITORS THAT, ALTHOUGH
THEY MAY DOWNLOAD ANY RESOURCES FOR COMMERCIAL OR NONCOMMERCIAL USES,
THEY MAY NOT REPUBLISH THE SOURCE CODE SO THAT IT IS ACCESSIBLE TO THE
PUBLIC WITHOUT FIRST OBTAINING THE COPYRIGHT OWNER'S PERMISSION.
Document Copyrights
No part of this manual may be reproduced, distributed or transmitted in any form or by any
means, for any purpose without written permission of Futurecom.
Disclaimer
The information in this document is carefully examined and is believed to be entirely
reliable. However, no responsibility is assumed for inaccuracies.
Futurecom Systems Group, ULC reserves the right to make changes to any products
herein to improve readability, function or design. Futurecom does not assume any liability
arising out of the application or use of any product or circuit described herein.
Trademarks
MOTOROLA, ASTRO, XTLTM 2500, XTLTM5000, XTSTM1500, XTSTM2500, XTSTM5000,
APXTM4000, APXTM4500, APXTM6000, APXTM7000, APXTM6500, APXTM7500, MDC1200
are trademarks of Motorola Solutions Inc.

8M087X01 R2
x
Commercial Warranty
Futurecom Systems Group, ULC. warrants to the original purchaser all standard
products sold by Futurecom Systems Group, ULC to be free of defects in material and
workmanship for one (1) year from the date of shipment from Futurecom Systems Group,
ULC.
Futurecom’s warranty hereunder DOES NOT cover the following:
(i) Defects or damage resulting from use of the product in other than its normal
and customary manner.
(ii) Defects or damage from improper installation, testing, operation, or
maintenance.
(iii) Defects or damage due to alterations, modifications or adjustments carried out
by the Buyer without Futurecom’s explicit approval.
(iv) Defects or damage from misuse, accident, water or neglect.
(v) Freight costs to the repair depot.
(vi) Scratches or other cosmetic damage to the product surfaces that does not
affect the operation of the product.
(vii) Normal wear and tear.
The warranty set forth herein is conditioned upon proper storage, installation, use and
maintenance in accordance with applicable written recommendation of Futurecom. The
warranty furnished hereunder does not extend to damage to items purchased hereunder
resulting in whole or in part from the use of components, accessories, parts of supplies not
furnished by Futurecom Systems Group, ULC.
Futurecom’s sole obligation shall be to repair or replace, at Futurecom’s option, any
defective component or item and pay transportation expenses for such replacement at no
charge to Buyer who shall provide labor for the removal of the defective component or item
and installation of its replacement at no charge to Futurecom. Buyer shall bear all risk of
loss or damage to returned goods while in transit. In the event no defect or breach of
warranty is discovered by Futurecom upon receipt of any returned item, the item will be
returned to Buyer at Buyer’s expense and Buyer will reimburse Futurecom for the
transportation charges, labor and associated charges incurred in testing the allegedly
defective item.
Except as expressly provided herein, Futurecom makes no warranty of any kind,
expressed or implied, with respect to any goods, parts and service provided by Futurecom
including, but not limited to, the implied warranties or merchantability and fitness for a
particular purpose. The sole and exclusive remedy for breach of any warranty is limited to
the remedies provided in the paragraph above. Futurecom shall not in any event be liable
for any other damages arising out of or in connection with furnishing of goods, parts or
service hereunder, or the performance, use of, or inability to use any goods, parts or
service, or otherwise, whether based on contract, tort or any other legal theory.
To exercise this warranty, please contact Futurecom’s Administration Department in
Concord, Ontario, Canada at 1-800 701 9180 to obtain a return material authorization
(RMA) and shipping instructions. No product will be accepted for return without an RMA.
The repair of a product by Futurecom pursuant to this warranty is warranted for the balance
of the original warranty period, or at least 90 days from date of shipment to Buyer of the
repaired product.
If Extended Warranty is required, it must be purchased either at the time of original
purchase or while the unit is under the standard first year warrantycoverage.

Part I –VRX1000 INSTALLATION

8M087X01 R2
VRX1000
Installation & Programming Guide –PART I
October 2015 Page 2 of 25
Part I - Installation
Notations Used in This Manual......................................................................................4
Declaration of Conformity..............................................................................................5
RF Energy Exposure Compliance, Awareness and Control Information and
Operational Instructions.................................................................................................6
RF Exposure Label .......................................................................................................7
FCC Label.....................................................................................................................7
Installation Requirements for Compliance with Radio Frequency (RF) Energy
Exposure Safety Standards ...........................................................................................8
Introduction.....................................................................................................................9
Identifying Your VRX1000 Model................................................................................10
Frequency Band of Operation................................................................................................ 10
Cross-Band............................................................................................................................ 10
Cross Band VRX1000 Dimensions................................................................................................ 11
In-Band .................................................................................................................................. 12
In-Band VRX1000 Dimensions..................................................................................................... 13
VRX1000 Installation Basics.......................................................................................14
Planning the Installation......................................................................................................... 14
Installation Tools Required.................................................................................................... 14
Mounting the VRX1000...............................................................................................15
Cross-Band VRX1000 Mounting............................................................................................ 15
In-Band VRX1000 Mounting.................................................................................................. 16
Mounting the Mobile Radio .........................................................................................17
Connecting the VRX1000 Cables ...............................................................................17
Power Cable .......................................................................................................................... 18
RF Cables.............................................................................................................................. 19
Control Cables....................................................................................................................... 19
VRX1000 Auxiliary Cable ...................................................................................................... 22
AVRA ............................................................................................................................................ 23
Status Lights................................................................................................................................... 23
External Alarm............................................................................................................................... 23
VRX1000 Antenna Installation .....................................................................................24
Index...............................................................................................................................25

8M087X01 R2
VRX1000
Installation & Programming Guide –PART I
October 2015 Page 3 of 25
List of Tables
Table 1 Minimum Lateral Distance from Antenna –VRX1000..........................................7
Table 2 VRX1000 vs Infrastructure Compatibility .............................................................9
Table 3 VRX1000 RF Cables..........................................................................................19
Table 4 VRX1000 Control Cable Types..........................................................................19
List of Figures
Figure 1 Cross-Band VRX1000 - Conceptual Diagram...................................................10
Figure 2 Cross-Band VRX1000 - Dimensions mm / [in]..................................................11
Figure 3 In-Band VRX1000 - Conceptual Diagram.........................................................12
Figure 4 In-Band VRX1000 –Flat Mount Dimensions mm / [in] .....................................13
Figure 5 Cross-Band VRX1000 Mounting Details...........................................................15
Figure 6 In-Band VRX1000 - Flat Mount Details.............................................................16
Figure 7 In-Band VRX1000 Stacked Mount Details........................................................16
Figure 8 VRX1000 Connectors.......................................................................................17
Figure 9 VRX1000 Standard Control Cable (PN 7W087X07).........................................20
Figure 10 VRX1000 Y-Control Cable with AUX Extension (PN 7W087X08) ..................20
Figure 11 MSU Side DB25 Pinout (All Control Cables) ..................................................21
Figure 12 Auxiliary Options - DB15 Pinout......................................................................22

8M087X01 R2
VRX1000
Installation & Programming Guide –PART I
October 2015 Page 4 of 25
Notations Used in This Manual
The following notations are used throughout this document:
NOTE:
A clarifying statement that expands on the text that follows.
IMPORTANT!
An important statement that should be considered and / or implemented in order
to achieve adequate equipment operation.
ATTENTION!
An instruction that must be followed to insure compliance with the appropriate
standards or proper equipment operations.

8M087X01 R2
VRX1000
Installation & Programming Guide –PART I
October 2015 Page 5 of 25
Declaration of Conformity
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
FCC LABELS:
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference.
and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
FCC SECTION 15.105 INFORMATION TO THE USER:
NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.

8M087X01 R2
VRX1000
Installation & Programming Guide –PART I
October 2015 Page 6 of 25
RF Energy Exposure Compliance, Awareness and
Control Information and Operational Instructions
ATTENTION!
Changes or modifications not expressly approved by Futurecom Systems Group,
ULC. could void the User’s authority to operate the equipment. To satisfy FCC/IC
RF exposure requirements for mobile transmitting devices, the minimum
separation distances specified in Table 1 should be maintained. To ensure
compliance, operations at closer than this distance is not allowed.
ATTENTION!
Futurecom requires the P25 VRX1000 operator to ensure FCC Requirements for
Radio Frequency Exposure are met. The minimum distance between all possible
personnel and the body of the VRX1000 equipped vehicle is specified in the “RF
Safety” booklet. Failure to observe the Maximum Permissible Exposure (MPE)
distance exclusion area around the antenna may expose persons within this area
to RF energy above the FCC exposure limit for bystanders (general population). It
is the responsibility of the repeater operator to ensure MPE limits are observed at
all times during repeater transmissions. The repeater operator must ensure at all
times that no person comes within MPE distance from the vehicle body.
USA Users:Do not use the VRX1000 in the frequency band 406.0 –406.1MHz. This
frequency band is reserved for distress beacons.
ATTENTION!
This radio is intended for use in occupational / controlled conditions, where users
have full knowledge of their exposure and can exercise control over their
exposure to meet FCC limits. This radio device is NOT authorized for general
population, consumer, or any other use.
It is the responsibility of the VRX1000 Operator to ensure that Maximum
Permissible Exposure (MPE) limits are observed at all times during repeater
transmissions. If this vehicular repeater is used in combination with a separate
mobile radio transmitter, the Repeater operator must ensure at all times that no
person comes within the MPE distance from the vehicle body to ensure
compliance with the FCC’s/IC’s RF energy exposure limits for the general
population.
The minimum lateral distance between all possible personnel and the body of the
VRX1000 equipped vehicle must be as specified in Table 1.
Failure to observe the MPE distance exclusion area around the antenna may
expose persons within this area to RF energy above the FCC exposure limit for
bystanders (general population).

8M087X01 R2
VRX1000
Installation & Programming Guide –PART I
October 2015 Page 7 of 25
VRX1000 (3W)
Minimum Lateral Distance from Antenna
VHF
67.0cm (26.4 inches) (up to 100% Tx duty
cycle)
UHF 380-512MHz
40.0cm (15.75 inches) (up to 100% Tx duty
cycle)
700MHz
28.3cm (11.1 inches) (up to 100% Tx duty
cycle)
800MHz
26.8cm (10.6 inches) (up to 100% Tx duty
cycle)
Table 1 Minimum Lateral Distance from Antenna –VRX1000
50% Tx duty cycle is defined as Push To Talk (PTT), 50% Talk - 50% Listen.
100% Tx duty cycle is defined as Push To Talk (PTT), 100% Talk
IMPORTANT
The maximum allowed gain of the λ/4 Omni-directional antenna for the VRX1000 is Unity
(0dBd).
RF Exposure Label
The RF Exposure Label should be affixed in the vehicle beside the mobile radio
control head. The label should be in the direct view of the Repeater operator. The
label is supplied with the VRX1000.
FCC Label
including interference that may cause undesired
2) This device must accept any interference received,
1) This device may not cause harmful interference, and
Operation is subject to the following two conditions:
This device complies with Part 15 of the FCC Rules.
operation.

8M087X01 R2
VRX1000
Installation & Programming Guide –PART I
October 2015 Page 8 of 25
Installation Requirements for Compliance with
Radio Frequency (RF) Energy Exposure Safety
Standards
ATTENTION!
To ensure compliance with RF Energy Safety Standards:
Install only Futurecom / Motorola Solutions approved antennas and accessories and
set conducted power into the VRX1000 antenna equal to or lower than the approved
power levels –refer to Table 1.

8M087X01 R2
VRX1000
Installation & Programming Guide –PART I
October 2015 Page 9 of 25
Introduction
The VRX1000 is a simplex radio coverage extender, which is interfaced to a compatible
remote mount Motorola Solutions Mobile Radio and enables Portable Subscriber Units
(PSU) to be used in areas where only Mobile Subscriber Unit (MSU) coverage is
available and PSU coverage is either intermittent or completely absent.
Installed in the trunk of a car, fire truck, armored vehicle, ambulance, the VRX1000
extends radio communications to the PSU users who are outside of the vehicle, inside a
nearby building or in any marginal portable radio coverage areas. The VRX1000 extends
voice (analog or digital, clear or encrypted) communications and supports key trunking
system features. The VRX1000 can be configured to provide various advanced options
to the users.
The Vehicular Radio Extender (VRX1000) is designed to be seamlessly interfaced to the
following Motorola Solutions Mobile Radios:
Mobile Radio Model
Firmware Requirements
Notes
APX2500
R13.00.00 or later
Requires option GA00631
APX4500
R13.00.00 or later
Requires option GA00631
APX5500
R10.00.00 or later
Requires option GA00631
APX6500
R10.00.00 or later
Requires option GA00631
APX7500
R10.00.00 or later
Requires option GA00631
NOTE:
Mobile Radio must be configured as Remote Mount in order to be compatible with the
VRX1000.
Table 2below provides information on the VRX1000 infrastructure compatibility options.
FIXED NETWORK TYPE / MOBILE RADIO MODE
Portable
Radio Type /
Mode
Conventional
Analog incl.
Mixed Receive
Conventional
P25 incl.
Mixed Receive
3600 Analog /
Digital
Trunking
9600 P25
Trunking
FDMA
9600 P25
Trunking
TDMA
Conventional
Analog
YES
A
YES
A/M
YES
A
YES
A/M
YES
A
Generic P25
Conventional
NO
YES
D/FA/M
NO
YES
D/M
NO
P25
Conventional
‘DVRS
Enabled’
YES
FA
YES
D/FA/M
YES
FA
YES
D/FA/M
YES
FA
Table 2 VRX1000 vs Infrastructure Compatibility
VRX1000 Channel Types:
A = Analog, D = Digital, M = Mixed, FA = Forced Analog (see Part II of this manual)

8M087X01 R2
VRX1000
Installation & Programming Guide –PART I
October 2015 Page 10 of 25
Identifying Your VRX1000 Model
Frequency Band of Operation
Depending on the frequency band of operation of the APX Mobile Subscriber Unit (MSU)
and VRX1000, the VRX1000 models are classified as follows:
In-Band –when the MSU and VRX1000 operate in the same frequency band.
Cross-Band –when the MSU and VRX1000 operate in two different frequency
bands.
Cross-Band
Cross-Band VRX1000 models do not include any filters on the MSU side since the MSU
and VRX1000 are not intended to simultaneously operate in the same frequency band.
In single band MSU configurations the MSU and VRX1000 operate in different frequency
bands.
In dual band MSU configuration either the MSU & VRX1000 operate in 3 different
frequency bands or one of the MSU frequency bands is locked out when VRX1000
operation is enabled as shown on Figure 1.
VRX1000
APX2500
APX4500
APX5500
APX6500
APX7500
CONTROL HEAD
& ACCESSORIES
TX=RX=F1
CONVENTIONAL P25
OR
CONVENTIONAL ANALOG
Figure 1 Cross-Band VRX1000 - Conceptual Diagram
