FUTURETE HORIZONT User manual
Instruction Manual
EN
1
INTRODUCTION
This manual provides all the necessary information regarding the correct use
of the machine and its maintenance, as well as safety standards to take into
account to ensure safe use.
The information in this manual should be preserved and respected
since the manufacturer is not liable for damage caused to persons and objects
due to improper installation or use.
The manufacturer reserves the right to modify the instruction manual
without the obligation to revise previous editions.
Cleaning and user maintenance shall not be made by children without
supervision.
This device can be used by children over eight years old, persons with reduced
physical, sensory or mental capabilities or lacking experience and
knowledge unless they are supervised or were given instructions regarding
the use of the machine, in a safe way and understanding the risks involved.
Children should not play with the device.
The device should not be installed in an area where water jets can be used.
If the power cord is damaged, it should be substituted by FUTURETE,
by its after-sales service or a similarly qualified person in order to avoid any
danger.
Always connect the machine to an earthing system.
Remove the plug from the socket to disconnect the device before performing
any cleaning and maintenance (only for machines that have a plug).
EN
2
The user must comply with the safety standards in force in the country of
installation. The user should avoid operating the machine barefooted or
with wet feet and should not touch the device’s hot surfaces or the power
cord, at risk of serious injuries.
The device should not be placed on extremely hot surfaces or near flammable
materials, in order to avoid damaging the housing.
EN
3
SPECIFICATIONS
Table 1 - Properties of machines with a > 8 L Boiler.
Oberon
Digital
Nominal
Tension [V] 220/240
Nominal
Current [A] 10 AMP
Nominal Power
[W]
2400
Table 5 - Common properties of all machines.
All Equipments
Boiler Nominal Pressure
0.05 –0.2 [MPa]
Pump Nominal Pressure
0.8 –1 [MPa]
Ambient Temperature [min - max]
5 –50 [ºC]
Average Sound pressure Level-A
84dB ± 3dB
FUTURETE coffee machines operate according to the variables described
in the previous tables and it is not FUTURETE’s responsibility the
damage caused by the non-compliance of these numbers.
EN
4
ACCESSORIES
The FUTURETE coffee machine is supplied with the following accessories:
•Filter holder for two cups;
•Filter holder for one cup;
•Blind filter;
•3/8-3/8 stainless steel connector for water inlet;
•1500mm drain hose.
EN
5
INSTALLATION
When installing the FUTURETE coffee machine verify if the location gathers the
necessary conditions for its correct use. Never install it in places with water
jets.
Choose a levelled support surface, with easy electrical supply, running or
bottled water access and sewage.
IMPORTANT: the access to running water must be earthed in order to
guarantee differential protection, so that there is no electrocution hazard for
the user. The device is provided with fixed electrical installation, therefore it
is strictly forbidden to use wall sockets (only for 3 group models), or
multiple sockets and extensions (for 1 group, 2 group and 3 group
models).
The installation of the equipment must be settled in a place where its
maintenance is always made by trained personnel, so that they can keep the
machine under surveillance.
It is important that the rated residual operating current not exceed 30
mA, given that it has a leakage current superior to 10mA.
When performing all the previously described procedures, turn the main
switch to position 1, wait for the automatic filling of the boiler to be complete.
Turn the switch to position 2 so that the red signal lights up and the resistance
is activated. Wait until the the right pointer of the manometer reaches 1 bar.
At this moment, the equipment can be used, but always verify if the coffee
grind used is adequate.
EN
6
The device has 1 or 2 steam wands that should be opened before being used, to
clean eventual residue of a previous use.
The connection of the device should be performed according to the following
scheme:
Figure 1 - Single-phase and multiphase machine connection scheme.
As shown in the above picture, for single-phase machines (230V 1N ~), the
brown wire of the power cord should be connected to the main switch L1
connector, the blue wire of the power cord should be connected to the
main switch N connector, and the yellow and green wire should be
connected to the ground wire that protects the machine. For multiphase
machines (400V 2N ~), instead of one brown wire, there is one black wire
connector to the L1 connector and one brown wire connected to the
L2 connector, the other connections remain the same.
EN
7
PROGRAMMING THE ELECTRONIC MACHINE PANEL
1. One short shot function;
2. One normal shot function;
3. Two short shots function;
4. Two normal shots function;
5. Panel programming function;
6. Tea function.
As shown in the above picture, buttons 1, 2, 3 and 4 are used to make coffee.
The last button, number 5, is used to make coffee continuously (pulse
function) and program the remaining buttons, in key 6 you will find the tea
function.
To program the shots of each one of the first four buttons, press number 5
until the light above it flashes continuously. Press the programming button
until the coffee level is to your liking; to stop, press the same button again.
Repeat the process for all the buttons and you will finish programming
your FUTURETE coffee machine.
EN
8
Activate Pre-Infusion
a. With the equipment turned off, and the main switch is in position 0,
press for 5 seconds the 1st button on the 1st keyboard. Turn the
main switch to position 2, keeping pressing the button until the
LED on the * key lights up, release the button.
b. Turn the equipment off again, so that the schedule is saved.
Deactivate Pre-Infusion
a. With the equipment turned off, and the main switch is in position 0,
press for 5 seconds the 2st button on the 1st keyboard. Turn the
main switch to position 2, keeping pressing the button until the
LED on the * key lights up, release the button.
b. Turn the equipment off again, so that the schedule is saved.
WATER TANK CONNECTION
Turning the tap to the left will drain the water from the reservoir, the center
will be off, and turning to the right will turn on the mains water.
Note: When the tank is without water, the machine locks and the keyboards
flash.
EN
9
MAINTENANCE
All and any maintenance and repair must be performed by qualified
personnel.
Equipment maintenance is essential to its proper functioning, it should be
performed by qualified personnel, semi-annually, if not, it can lead to severe
damage in the equipment.
Use only original components.
In case the power cord is damage, it should be replaced by FUTURETE,
by the retailer or by similarly qualified personnel in order to avoid any
hazard.
Cleaning and maintenance should not be carried out by children, unless
supervised.
Cleaning:
Never use water jets while cleaning the equipment.
Other cleaning accessories can be used, which are not provided with the
equipment, such as:
•Sponges;
•Cleaning cloths;
•Non-harmful chemicals, only and exclusively for cleaning.
This equipment is supposed to be used in ambient temperatures between 5
and 50°C, FUTURETE does not allow using it outside this temperature range.
EN
10
The FUTURETE coffee machine can be used with coffee, milk and tea. The
equipment should be cleaned daily so that the food used is not contaminated
nor it causes contamination.
Daily:
Before switching off the machine after everyday use, you should clean the
groups and replace the filters with the machine’s blind filter. This operation
should be repeated once or twice per group.
The filter-holder guides should also be cleaned with a damp cloth, as well as
the filters and filter-holder, using detergent specific for removing
accumulated coffee oil. Clean the drip tray and grid.
Weekly:
Remove the cup holder grids and wash them adequately.
The device’s housing should be cleaned with a damp cloth, avoiding
abrasive detergents and solvents, and never using water jets.
Descaling:
Only the manufacturer’s technical team can descale the
equipment.
EN
11
EXTRA INFORMATION
All the information present in this manual can be found online by accessing the
machine area in the website: www.FUTURETE.pt
The Machine must be connected to a water source and water must be running
to the machine before being plugged in to an electric source.
By plugging the equipment in without water, you will damage it.
If you are not sure how to install the machine we highly recommend you get a
professional to set it up for you.
