G-Tek CYBORG 3000 User manual

GA-CBKB104
G-TEK CYBORG 3000
MECHANICAL GAMING KEYBOARD
Manual

CONNECTION
Connect the Keyboard cable to a USB
port on your PC (plug and play)
1
2

CABLE
MANAGEMENT
1
2

FN + ‘+’ or ‘-‘ To increase or decrease LED light brightness
FN + ↑ Light wave moves from top to bottom
FN + ↓ Light wave moves from bottom to top
FN + ← Light wave moves right to left
FN + → Light wave moves left to right
LED LIGHT
CONTROLS
INSTALLING
THE COVER
1 2 3

1. Press FN + F12.
The F1 to F5 keys will
start flashing which
indicates the keyboard
is ready to record a
custom pattern.
2. Select any key from
F1 to F5.
3. Next select the keys
you want to program
a light pattern to. For
example, press WSAD
keys then use the ‘LED
Light Controls’
instructions from this
manual to set your own
light pattern.
4. After you have finished
setting a light pattern,
press FN + F12 to save
the custom pattern.
5. The custom light
patterns can be toggled
by pressing FN + F1 to F5.
FN
F12
F2
F4
F1
F3
F5
CUSTOMIZING
THE LED LIGHTS

FN + F6 = Wave Mode: Press
FN + ↑↓←→ to change the
direction of the wave.
FN + F7 = Ripple Mode: When
pressing any key, the light will
spread out from that key in
multiple directions.
FN + F8 = Marquee Mode: The
lights will form an ‘S’ pattern from
ESC to CTRL (bottom left) keys.
FN + F9 = Fading Mode: When
pressing any key, the light will turn
on then slowly fade out.
FN + F10 = Breathing Mode: The
light fades in and out in a circular
motion.
FN + F11 = Lights Always On.
FN + PAUSE = Press and hold for
3 seconds to reset all settings to
Factory Default.
Pause
F11
F9
F7
F10
F8
F6
FN
PRESET LED
CONTROLS

KEYBOARD
SPECIFICATIONS
Power Consumption: 100mA (no LED) - 350mA (brightest LED)
Weight: 1200g
Keyboard Dimensions (without cover): 444 x 131 x 44mm
Cover Dimensions: 451 x 136 x 44mm
LED: Customizable RGB Lighting
Number of Keys: 104
Rollover: NKey
Keycaps: PBT Double Shot
KEY SWITCH
SPECIFICATIONS
Switch Type: Cherry MX Red (linear)
Actuation force: 45 ± 15 cN
Total Travel: 3.7mm
Pre -travel: 1.9mm
Bounce Time: < 5ms
Durability: > 50 million actuations

WARRANTY AGAINST DEFECTS
For more
helpful guides
visit us at
LASER
www.youtube.com/LasercoAu
www.laserco.com.au
Laser warrants your new product to be free from defects in materials and workmanship
for 12 months, from the date of purchase, provided that the product is used in accordance
with accompanying recommendations or instructions where provided. The benet of this
warranty is in addition to your rights under the Australian Consumer Law and to other rights
and remedies of the consumer under a law in relation to the goods or services to which the
warranty relates.
Through a network of retailers and resellers, Laser will provide you with your choice of a
refund, repair, or exchange (where possible) for this product if it becomes defective within
the warranty period. This warranty will no longer apply where the defect is a result of
alteration, accident, misuse, abuse, normal wear and tear, neglect, or improper storage.
Please retain your receipt as proof of purchase
How to make a product warranty claim:
1. Find your receipt with date of purchase. If this is not available, Laser will make an
assessment based on the date of manufacture, condition of the product and type of defect.
2. Please contact your original place of purchase. They will assess the nature of the fault and
refund or replace the product as per their store refund or warranty policy.
3. If your original place of purchase cannot be contacted, please contact Laser with a
description of the fault. To assist our team in providing you with a quick resolution, please
include any photos and/or a short video demonstrating the fault with your product.
• Phone: [phone]
• Email: [email protected]
• Online: www.laserco.net/support/warranty and follow the website instructions
• Business Address: U1 6-8 Byeld Street, Macquarie Park, 2113, NSW, Australia
4. Laser will review your claim and in the rst instance, attempt to troubleshoot and resolve
the issue for you without the need to return the product.
5. If it is determined via troubleshooting that your product may be faulty, our team will
provide instructions to have the product returned for assessment. If the product does
need to be returned within the warranty period, Laser will arrange return shipping at no
cost to you.
6. Once we receive the product, our experienced technicians will assess it and determine how
best to resolve the issue.
Our goods come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and compensation for
any other reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure does not
amount to a major failure.
