Gaggenau DF 461-161 User manual

Gaggenau Operating instructions
Dishwasher
DF 460-161
DF 461-161
W3127_A (AU) (Ref. 9000 407 068 (8811) en )

en Index
Safety instructions 4. . . . . . . . . . . . . . . . . . . .
Delivery 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 4. . . . . . . . . . . . . . . . . . . . . . . . . . .
In daily use 4. . . . . . . . . . . . . . . . . . . . . . . . . .
Children in the household 4. . . . . . . . . . . . . .
Childproof lock (door lock) 4. . . . . . . . . . . . .
Damage 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disposal 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Getting to know your appliance 5. . . . . . . .
Control panel 5. . . . . . . . . . . . . . . . . . . . . . . . .
Appliance interior 5. . . . . . . . . . . . . . . . . . . . .
Water softening system 5. . . . . . . . . . . . . . . .
Set 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Salt 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using salt 6. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Switching off salt refill indicator/
water softening system 6. . . . . . . . . . . . . . . .
Rinse aid 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting amount of rinse-aid 7. . . . . . . . . . . . .
Switching off rinse-aid refill indicator 7. . . . .
Utensils 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Not suitable 7. . . . . . . . . . . . . . . . . . . . . . . . . .
Glass and utensil damage 7. . . . . . . . . . . . .
Loading the dishwasher 7. . . . . . . . . . . . . . .
Unloading the dishwasher 7. . . . . . . . . . . . . .
Cups and glasses 8. . . . . . . . . . . . . . . . . . . . .
Pans 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cutlery basket 8. . . . . . . . . . . . . . . . . . . . . . . .
Folding spikes 8. . . . . . . . . . . . . . . . . . . . . . . .
Small accessories holder 8. . . . . . . . . . . . . .
Knife shelf 8. . . . . . . . . . . . . . . . . . . . . . . . . . .
Adjusting the height of the basket 9. . . . . . .
Removing the upper basket 9. . . . . . . . . . . .
Installing the upper basket 9. . . . . . . . . . . . .
Detergent 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding detergent 10. . . . . . . . . . . . . . . . . . . . .
Overview of programmes 11. . . . . . . . . . . . . .
Programme selection 11. . . . . . . . . . . . . . . . . .
Information about comparability tests 11. . . .
Additional options 12. . . . . . . . . . . . . . . . . . . .
Turbo 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Energy Save 12. . . . . . . . . . . . . . . . . . . . . . . . .
Half load 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hygiene 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IntensiveZone 12. . . . . . . . . . . . . . . . . . . . . . . .
Extra drying 12. . . . . . . . . . . . . . . . . . . . . . . . . .
Washing the dishes 12. . . . . . . . . . . . . . . . . . .
Programme data 12. . . . . . . . . . . . . . . . . . . . . .
Aqua sensor 12. . . . . . . . . . . . . . . . . . . . . . . . .
Zeolith drying 12. . . . . . . . . . . . . . . . . . . . . . . .
Switching on the appliance 13. . . . . . . . . . . . .
Optical display while the programme
is running 13. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Remaining running time display 13. . . . . . . . .
Timer programming 13. . . . . . . . . . . . . . . . . . .
End of programme 13. . . . . . . . . . . . . . . . . . . .
Switching off the appliance 14. . . . . . . . . . . . .
Interrupting the programme 14. . . . . . . . . . . .
Terminating the programme (Reset) 14. . . . .
Changing the programme 14. . . . . . . . . . . . . .
Intensive drying 14. . . . . . . . . . . . . . . . . . . . . .
Interior light 14. . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance and care 15. . . . . . . . . . . . . . . . .
Overall condition of the machine 15. . . . . . . .
Filters 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Spray arms 15. . . . . . . . . . . . . . . . . . . . . . . . . .
Waste water pump 16. . . . . . . . . . . . . . . . . . . .
Troubleshooting 16. . . . . . . . . . . . . . . . . . . . . .
... when the appliance is switched on 16. . . .
... on the appliance 16. . . . . . . . . . . . . . . . . . . .
... changing settings 16. . . . . . . . . . . . . . . . . . .
... during the wash cycle 17. . . . . . . . . . . . . . .
... on the utensils 17. . . . . . . . . . . . . . . . . . . . .
Customer service 18. . . . . . . . . . . . . . . . . . . . .
Installation 18. . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety instructions 18. . . . . . . . . . . . . . . . . . . .
Delivery 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 19. . . . . . . . . . . . . . . . . . . . . . . . . . .
Waste-water connection 19. . . . . . . . . . . . . . .
Fresh-water connection 19. . . . . . . . . . . . . . . .
Electrical connection 19. . . . . . . . . . . . . . . . . .
Removing the appliance 19. . . . . . . . . . . . . . .
Transportation 20. . . . . . . . . . . . . . . . . . . . . . . .
Protection against frost 20. . . . . . . . . . . . . . . .
Waste disposal 20. . . . . . . . . . . . . . . . . . . . . . . .
Packaging 20. . . . . . . . . . . . . . . . . . . . . . . . . . .
Old appliances 20. . . . . . . . . . . . . . . . . . . . . . .

4
Safety instructions
Delivery
Check the packaging and dishwasher immediately
for damage caused in transit. Do not switch on a
damaged appliance, but contact your supplier.
Please dispose of the packaging material in an
environmentally friendly manner.
Do not let children play with packaging and its parts.
There is a risk of suffo- cation from collapsible boxes
and film.
Installation
Read the “Installation” chapter to learn how to install
and connect the appliance correctly.
In daily use
Use the dishwasher only in the household and only
for its designed purpose, i.e. for washing domestic
dishes.
Do not lean or sit on the open door. The appliance
could tip.
Please note that free-standing appliances may tip
over if the baskets are overloaded.
Do not add any solvents to the washing chamber.
Danger of explosion!
Open the door carefully when the programme is still
running. There is a risk of hot water spraying out of
the appliance.
To prevent injuries, e.g. caused by stumbling, open
the dishwasher only briefly in order to load and
unload the dishwasher.
Read and observe the safety infor- mation and
instructions for use on the packaging for cleaning
and rinsing agents.
Warning
Knives and other utensils with sharp points must be
placed in the cutlery basket with the points downwards
or horizontally on the knife shelf *.
* depending on model
Children in the household
If fitted, use the childproof lock. An exact description
can be found in the back of the envelope.
Do not allow children to play with or operate the
appliance.
Keep children away from detergents and rinse aid.
These may cause chemical burns in the mouth,
throat and eyes or asphyxiation.
Keep children away from open dishwasher. The
water in the rinsing compartment is not drinking
water and could contain detergent residue.
Ensure that children do not place fingers in the tablet
collecting tray 24 . Small fingers could become
caught in the slots.
If the appliance is installed at eye-level, ensure when
opening and closing the door that children are not
caught or crushed between the appliance door and
the cupboard door situated below.
Childproof lock (door lock)
The description of the childproof lock is at the back in
the envelope.
Damage
The appliance may be repaired and opened up by a
technician only. To do this, disconnect the appliance
from the power supply. Pull out the mains plug
or switch off the fuse. Turn off the tap.
Disposal
Make redundant appliances unusable to prevent
subsequent accidents.
Dispose of the appliance in an environmentally
friendly manner.
Warning
Children could become locked in the appliance (risk of
suffocation) or find themselves in other dangerous
situations.
Therefore: Pull out the mains plug, sever and dispose
of the power cord. Destroy the door lock so that the
door can no longer be closed.
Warning
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.
Warning
Dishwasher detergents are strongly alkaline.
They can be extremely dangerous if swallowed.
Avoid contact with skin and eyes and keep children
away from dishwasher when the door is open.
Check that the detergent receptacle is empty after
completion of wash cycle.

5
Getting to know your appliance
Diagrams of the control panel and the interior of the
appliance can be found in the envelope at the front.
Individual positions are referred to in the text.
Control panel
1ON/OFF switch
2Programme buttons **
3Digital display
4Display “Check water supply”
5Salt refill indicator
6Rinse-aid refill indicator
7Timer programming display
8Time delay
9Additional options **
10 START button
11 Door Opener
** Number depending on model
Appliance interior
20 Interior light *
21 Top basket
22 Knife shelf *
23 Top spray arm
24 Tablet collecting tray
25 Intake opening
26 Blow opening (Zeolith container)
27 Bottom spray arm
28 Dispenser for salt
29 Filters
30 Cutlery basket
31 Bottom basket
32 Dispenser for rinse aid
33 Detergent dispenser
34 Lock for detergent dispenser
35 Rating plate
* depending on model
Water softening system
To ensure good washing results, the dishwasher
requires soft water, i.e. containing low amounts of lime,
otherwise white limescale will be deposited on the
utensils and inner container.
Tap water above 7_dH (from set value ) must be
softened.
The water is softened with salt (regeneration salt) in the
water softening system of the dishwasher.
The setting and therefore the required amount of salt
depends on the degree of hardness of your tap water
(see table).
Set
The amount of salt dispensed can be set from to
.
Sal is not required at the set value .
Find out about the hardness value of your tap water.
Your water supply company will assist you.
Set value can be found in the water hardness table.
Open the door.
Switch on ON/OFF switch 1.
Hold down programme button Aand press START
button 10 until on the digital display is indicated
.
Release both buttons.
The LED for button Aflashes and the digital
display displays the factory setting .
To change the setting,
press programme button C.
Each time the button is pressed, the set value
increases by one level; when the value of has
been reached, the display jumps back to (off).
Press START button 10 .
The chosen setting has now been stored.
Close the door.
Water hardness table

6
Salt
Using salt
Always refill with salt immediately before switching on
the appliance. This ensures that overrun salt solution is
immediately washed out and does not corrode the
rinsing tank.
Open the screw-type cap of the compartment 28 .
Fill the tank with water (only required when switching
on the appliance for the first time).
Then add dishwasher salt (not table salt or
tablets).
The water is displaced and runs out.
As soon as the salt refill indicator 5on the fascia is
lit, top up the salt.
* depending on model
Using detergents with salt component
If combined detergents with a salt component are used,
salt can usually be omitted up to a water hardness of
21°dH (37°fH, 26°Clarke, 3.7 mmol/l). If the water
hardness is over 21°dH, salt must be used.
Switching off salt refill indicator/water
softening system
If the salt refill indicator 5is impaired (e.g. when
using combined detergents containing salt component),
it can be switched off.
Proceed as described under “Setting water softening
system” and set the value to .
The water softening system and salt refill indicator
are now switched off.
Warnings
Never fill the salt dispenser with detergent. You will
destroy the water softening system.
To prevent corrosion, always refill with salt
immediately before switching on the appliance.
Rinse aid
As soon as the rinse-aid refill indicator 6lights up on
the control panel, refill with rinse aid.
The rinse aid is required for stain-free utensils and
clear glasses.
Use only rinse aid for domestic dish- washers.
Combined detergents with rinse-aid com- ponent may
be used up to a water hard- ness of 21 _dH (37 _fH,
26 _Clarke, 3,7 mmol/l) only. If the water hardness
is over 21 _dH, rinse-aid must be used.
Open the dispenser 32 by pressing and lifting the
plate on the cover.
Carefully pour rinse aid up to the max. mark in the
filler opening.
Close cover until it clicks shut.
To prevent excessive foam formation during the next
rinse cycle, remove any rinse aid which has run over
with a cloth.

7
Setting amount of rinse-aid
The amount of rinse-aid dispensed can be set from
to . The factory setting is .
Do not change the amount of rinse-aid unless streaks
(select lower setting) or water stains (select higher
setting) are left on the utensils.
Open the door.
Switch on ON/OFF switch 1.
Hold down programme button Aand press START
button 10 until on the digital display is indicated
.
Release both buttons.
The LED for button Aflashes and the digital
display displays the factory setting .
Press programme button Auntil the factory set
value is indicated on the digital display 3.
To change the setting,
press programme button C.
Each time the button is pressed, the set value
increases by one level; when the value of has
been reached, the display jumps back to (off).
Press START button 10 .
The set value is saved.
Close the door.
Switching off rinse-aid refill indicator
If the rinse-aid refill indicator 6is impaired (e.g. when
using combined detergents containing rinse-aid
component), it can be switched off.
Proceed as described under “Setting amount of
rinse-aid” and set the value to .
The rinse-aid refill indicator 6is now switched off.
Utensils
Not suitable
Cutlery and utensils made of wood.
Delicate decorative glasses, craft and antique
utensils. These decors are not dishwasher-proof.
Plastic parts not resistant to heat.
Copper and tin utensils.
Utensils which are soiled with ash, wax, lubricating
grease or ink.
Aluminium and silver parts have a tendency to
discolour and fade during the wash cycle. Even some
types of glass (e.g. crystal glass objects) may turn
cloudy after many wash cycles.
Glass and utensil damage
Causes:
Glass type and glass production process.
Chemical composition of the detergent.
Water temperature of the wash programme.
Recommendation:
Use only glasses and porcelain which the
manufacturer designates as dishwasher-proof.
Use a detergent which protects utensils.
Take glass and cutlery out of the dishwasher as soon
as possible after the programme ends.
Loading the dishwasher
Remove large food remnants.
It is not necessary to prerinse utensils under running
water.
Place the utensils so that
Dthey are secure and cannot tip over.
Dall utensils with their openings face down.
Dparts with curves or indentations are at an angle,
thereby allowing water to drain.
Ddoes not obstruct rotation of the two spray arms
23 and 27 .
Very small utensils should not be washed in the
machine, as they may fall out of the baskets.
Unloading the dishwasher
To prevent water from dripping off the upper basket
onto the utensils in the lower basket, it is
recommended to empty the appliance from the bottom
up.

8
Cups and glasses
Top basket 21
* depending on model
Pans
Bottom basket 31
Cutlery basket
You should always place cutlery unsorted with the
points downwards.
To prevent injuries, place long, pointed implements and
knives on the knife shelf.
Folding spikes
*
* depending on model
The spikes can be folded down to improve
arrangement of pans, bowls and glasses.
Small accessories holder
*
* depending on model
Light-weight plastic accessories, e.g. cups, lids, etc.
can be held securely in the small accessories holder.
Knife shelf
*
* depending on model
Long knives and other utensils can be arranged
horizontally.
You can remove the knife shelf to wash taller utensils.
Re-insert the knife shelf in the correct position.

9
Adjusting the height of the basket
The height of the upper utensils basket can be adjusted
in 3 stages to create more space either in the upper or
lower basket.
Appliance height 81.5 cm
Top basket Bottom basket
Setting 1
max. ∅16 cm 30 cm
Setting 2
max. ∅18.5 cm 27.5 cm
Setting 3
max. ∅21 cm 25 cm
Appliance height 86.5 cm
Top basket Bottom basket
Setting 1
max. ∅18 cm 33 cm
Setting 2
max. ∅20.5 cm 30.5 cm
Setting 3
max. ∅23 cm 28 cm
Pull out the top basket 21 .
To lower the basket, press in the left and then the
right lever on the outside of the basket. In doing so,
hold the sides of the basket along the upper edge to
prevent it from suddenly dropping.
To raise the basket, hold the basket on the sides of
the upper edge and lift it up.
Before re-inserting the basket again, ensure that it is
at the same height on both sides. Otherwise, the
appliance door cannot be closed and the upper
spray arm will not be connected to the water circuit.
Removing the upper basket
Pull out the basket all the way.
Lift the basket at the front and pull it over the front
catch (1) on the rails.
Lower the basket again and pull it out forwards.
Installing the upper basket
Pull the rails all the way out.
Install the basket by inserting the rails between the
two metal nubs (2) situated opposite each other on
the left and right sides of the basket.
Lift the basket over the front catch (1) on the rails.
Then lower the basket and push it into the rear
catch (3) on the rails.
Snap the basket into the front catch (1) and push in
the basket all the way.

10
Detergent
You can use tablets as well as powder or liquid
detergents for dishwashers, but never use washing up
liquid. Tablets contain not only detergent but also
rinse-aid and salt (3in1) and, depending on the
combination (4in1, 5in1, etc.), additional components
such as glass protection or stainless steel cleaner.
If tablets contain rinse-aid and salt, it is usually not
necessary to add additional rinse-aid and salt up to a
specific degree of hardness. If the degree of hardness
is higher and if using solo detergents (powder or liquid
detergents or tablets without rinse-aid and salt)
rinse-aid and salt must be added. The appliance doses
these automatically according to the preset values for
water hardness and amount of rinse-aid.
As soon as combined detergent products are used,
the rinse programme is adjusted automatically
to ensure the best possible rinsing and drying
result.
Tip
Follow the instructions for use or the instructions on the
detergent packaging to ensure that rinse-aid and salt
are used effectively.
If you have further questions, we recom- mend that you
contact the detergent manufacturers’ helpline.
Detergent dispenser with dosing aid
The graduated detergent dispenser 33 helps you add
the correct amount of powder or liquid detergent:
lower line: 15 ml
middle line: 25 ml
full: 50 ml
Adding detergent
Pour detergent into the dispenser 33 (insert tablet
flat, not on its edge).
Dosage: see manufacturer’s instructions on the
packaging.
Close the cover on the detergent dispenser by
sliding it up until the lock engages without difficulty.
The detergent dispenser opens automatically at the
optimum time depending on the programme.
The powder or liquid detergent is distributed in the
appliance and is dissolved, the tablet falls into the
tablet collecting tray where it dissolves in doses.
Tip
If the utensils are only lightly soiled, slightly less than
the indicated amount of detergent is usually adequate.
Warnings
Do not place small parts for washing in the tablet
collecting tray 24 ; this prevents the tablet from
dissolving evenly.
If you want to add more utensils after the
programme has started, do not use the tablet
collecting tray 24 as a handle for the upper basket.
The tablet could already be there and you will touch
the partially dissolved tablet.
Note
You will obtain optimum rinsing and drying results by
using solo detergents and applying salt and rinse-aid
separately.
f programmes are short, tablets may not have full
cleaning effect due to different dissolving properties
and there may even be undissolved detergent
residue. It is recommended to use washing powder
for these programmes.
The Intensive programme (on some models)
requires one tab only. When using washing powder,
you can apply some of this cleaning agent to the
inside of the appliance’s door.
Even if the rinse-aid and/or salt refill indicator is lit,
the rinse programme will run correctly if combined
detergents are used (when using combined
detergents, add rinse-aid at a water hardness above
21 _dH – see chapter entitled “Rinse-aid”).
If you switch from combined detergents to solo
detergents, ensure that the water softening system
and amount of rinse-aid have been set to the correct
value.
If using detergents in a water-soluble protective
cover: Take hold of the cover with dry hands only
and put the detergent into an absolutely dry
detergent dispenser only, otherwise the detergent
may stick.

11
Overview of programmes
The max. possible number of programmes is illustrated in this overview. The corresponding programmes for your
appliance can be found on the fascia.
Programme Type of utensils
and soiling
Programme sequence Possible additional options
Auto 65 –75 Pots, utensils
and cutlery
Highly soiled
Is optimised according
to the soiling with the aid
of sensors.
all
Auto 45 –65 Utensils and cutlery
Normally soiled
Is optimised according
to the soiling with the aid
of sensors.
all
Eco 50 Utensils and cutlery
Normally soiled
Prerinse
Clean 50
Intermediate rinse
Final rinse 65
Dry
all
Auto 35 –45 Utensils and cutlery
Lightly soiled
Is optimised according
to the soiling with the aid
of sensors.
Turbo
Energy Save
Half load
Extra drying
Quick 45 Utensils and cutlery
Lightly soiled
Clean 45
Intermediate rinse
Final rinse 55
Extra drying
Prerinse Lightly soiled Prerinse none
Programme selection
You can select a suitable programme according to the
type of utensils and degree of soiling.
Information about comparability tests
The conditions for running comparability tests can be
found on the supplementary sheet “Information for
comparability tests”.
Open the door approximately 50 mm at the end of the
drying cycle

12
Additional options
* depending on model
Additional options 9can be set with the buttons.
Turbo
*
The programme running time is reduced significantly in
the Turbo programme. The energy consumption is
increased by up to 30% due to more intensive heating.
The time reduction affects the following programmes:
Auto: Time reduction up to 25 %
Eco: Time reduction up to 58 %
Energy Save
*
Water and energy consumption can be reduced with
the Energy Save"function. The running time is
extended for optimum cleaning and drying results.
Half load
*
If you have only a few items to wash (e.g. glasses,
cups, plates), you can switch to “half load”. This will
save water, energy and time. It is recommended to put
a little less detergent in the detergent dispenser than
for a full load.
Hygiene
*
The temperature is increased during the rinsing
process. This increases the hygiene status. This
additional option is ideal for cleaning e.g. chopping
boards and baby bottles.
IntensiveZone
*
Perfect for a mixed load. You can wash very soiled pots
and pans in the lower basket together with normally
soiled utensils in the upper basket. The spray pressure
in the lower basket is intensified, the rinsing
temperature is increased slightly.
Extra drying
*
An increased temperature during the final rinse and an
extended drying phase mean that even plastic parts dry
well. There is a slight increase in the energy
consumption.
Washing the dishes
Programme data
The programme data (consumption values) can be
found in the summary of instructions. They refer to
normal conditions and the water hardness set value
. Different influencing factors such as water
temperature or line pressure may result in deviations.
Aqua sensor
*
* depending on model
The Aqua sensor is an optical measuring device (light
barrier) which measures the turbidity of the rinsing
water.
The Aqua sensor is used according to the programme.
If the Aqua sensor is active, “clean” rinsing water can
be transferred to the next rinse bath and water
consumption can be reduced by 3–6 litres. If the
turbidity is greater, the water is drained and is replaced
with fresh water. In the automatic programmes the
temperature and running time can also be adjusted
to the degree of soiling.
Zeolith drying
The appliance features a Zeolith-container. Zeolith is a
mineral which can store moisture and heat energy and
release them again.
During the washing step this heat energy is used to dry
the mineral and heat up the rinsing water.
During the drying phase moisture from the washing
compartment is stored in the mineral and heat energy
is released.
This released heat energy is blown into the washing
compartment with dry air. This accelerates and
improves drying.
These processes therefore save a great deal of energy.
Warning
Please ensure that the intake opening 25 is not
obstructed and do not place any temperature-sensitive
utensils in the lower basket at the rear right side above
the blow opening 26 .
Do not touch the blow opening 26 . The blow opening
becomes hot and, furthermore, any damage will result
in a callout by customer service.

13
Switching on the appliance
Turn on the tap fully.
Open the door.
Switch on ON/OFF switch 1.
The display of the last selected programme flashes.
This programme remains selected if no other
programme button 2is pressed.
The expected programme duration flashes on the
digital display 3.
Press the START button 10 .
Close the door.
The programme starts running.
Optical display while the programme
is running
*
* depending on model
While the programme is running, a light spot shines on
the floor under the appliance door. Do not open the
dishwasher door until the light point is no longer visible
on the floor.
If the appliance is installed at eye-level, with flush
furniture front, the light point is not visible.
This function can be changed as follows:
Open the door.
Switch on ON/OFF switch 1.
Hold down programme button Aand press START
button 10 until on the digital display is
indicated.
Release both buttons.
The LED for button Aflashes and the digital
display displays the factory setting .
Press programme button Auntil the factory set
value is indicated on the digital display 3.
To change the setting:
By pressing the Cbutton, you can switch the
function off or on .
Press START button 10 .
The set value is saved.
Close the door.
Remaining running time display
When the programme is selected, the remaining
running time of the programme is indicated on the
digital display 3.
The running time is determined during the programme
by the water temperature, the number of utensils as
well as the degree of soiling and may vary (depending
on the selected programme).
Timer programming
You can delay the start of the programme in 1-hour
steps up to 24 hours.
Open the door.
Switch on ON/OFF switch 1.
Press 8+ button until the timer programming
display 7jumps to .
Press 8+ or – button until the displayed time
corresponds with your requirements.
Press START button 10 , timer programming is
activated.
To delete timer programming, press the 8+ or –
button until is indicated on the digital display 7.
You can change your programme selection at any
time until the programme starts.
Close the door.
End of programme
The programme has ended when the value is
indicated on the numerical display 3.
The end of the programme is also indicated by an
acoustic signal.
This function can be changed as follows:
Open the door.
Switch on ON/OFF switch 1.
Hold down programme button Aand press START
button 10 until on the digital display is
indicated.
Release both buttons.
The LED for button Aflashes and the digital
display displays the factory setting .
Press programme button Auntil the factory set
value is indicated on the digital display .
To change the setting,
press programme button C.
Each time the button is pressed, the set value
increases by one level; when the value of has
been reached, the display jumps back to (off).
Press START button 10 , the set value is saved.
Close the door.

14
Switching off the appliance
Short time after the end of the programme:
Open the door.
Switch off ON/OFF switch 1.
Turn off the tap (not applicable if Aqua-Stop fitted).
Remove the utensils when they have cooled down.
Warning
At the end of the programme please open the door fully
and not partially when emptying the dishwasher. Any
escaping water vapour could damage sensitive
worktops.
Interrupting the programme
Open the door.
Switch off ON/OFF switch 1.
The LEDs go out. The programme is saved.
If the door was opened on an appliance which has a
warm water connection or is heated, first leave the
door ajar for several minutes and then close.
Otherwise, expansion (pressure) may cause the
appliance door to spring open or water to run out of
the appliance.
To continue the programme, switch on the ON/OFF
switch 1again.
Close the door.
Terminating the programme (Reset)
Open the door.
Press START button 10 for approx 3 sec. is
indicated on the digital display 3.
Close the door.
The programme sequence lasts approx. 1 min.
is indicated on the digital display 3(buzzer
sounds).
Open the door.
Switch off ON/OFF switch 1.
Close the door.
Changing the programme
When the START button 10 has been pressed, the
programme cannot be changed.
The only way a programme can be changed is by
Cancel programme (reset).
Intensive drying
The final rinse uses a higher temperature which
improves the drying result. The running time may
increase slightly. (Caution if utensils are delicate!)
Open the door.
Switch on ON/OFF switch 1.
Hold down programme button Aand press START
button 10 until on the digital display is
indicated.
Release both buttons.
The LED for button Aflashes and the digital
display displays the factory setting .
Press programme button Auntil the factory set
value is indicated on the digital display 3.
To change the setting,
Press the button Cto switch intensive drying on
or off .
Press START button 10 .
The set value is saved.
Close the door.
Interior light
*
20
The interior light comes on when the door is opened
irrespective of whether the ON/OFF switch 1is
switched on or off. When the door is closed or ajar, the
light is off.
Open the door.
Switch on ON/OFF switch 1.
Hold down programme button Aand press START
button 10 until is indicated on the digital
display.
Release both buttons.
The LED for button Aflashes and the digital
display displays the factory setting .
Press programme button Auntil the factory set
value is indicated on the digital display 3.
To change the setting,
Press the button Cto switch the interior light off
or on .
Press START button 10 .
The set value is saved.
Close the door.
* depending on model

15
Maintenance and care
A regular inspection and maintenance of your machine
will help to prevent faults. This saves time and prevents
problems.
Overall condition of the machine
Check spray arm for grease and limescale deposits.
If you find such deposits:
Fill detergent dispenser with detergent. Start the
appliance without utensils in the programme with the
highest rinsing temperature.
Clean the appliance with detergents/ appliance
cleaners which are particularly suitable for use with
dishwashers.
Regularly clean door seal with a damp cloth.
Never use a steam cleaner to clean your dishwasher.
The manufacturer is not liable for any consequential
damage.
Regularly wipe the front of the appliance and fascia
with a damp cloth; water and a little washing up liquid
are adequate. Do not use sponges with a rough
surface or abrasive detergents, as these could scratch
the surfaces.
Stainless steel appliances: To prevent corrosion, avoid
using sponge cloths or wash them out thoroughly
several times before using for the first time.
Warning
Never use other chlorinated household detergents!
Health hazard!
Salt and rinse-aid
Check the refill indicators 5and 6. If required,
refill salt and/or rinse-aid.
Filters
The filters 29 keep large foreign objects in the rinsing
water away from the pump. These foreign objects may
occasionally block the filters.
The filter system consists of a coarse filter, a flat fine
filter and a microfilter.
After each washing cycle check the filters for
residue.
Unscrew filter cylinder as illustrated and take out
filter system.
Remove any residue and clean filters under running
water.
Re-install filter system in reverse sequence and
ensure that the arrow marks are opposite each other
after closing the filter system.
Spray arms
Limescale and contaminants in the rinsing water may
block nozzles and bearings on the spray arms 23 and
27 .
Check outlet nozzles on the spray arms for
blockages.
Unscrew the upper spray arm 23 .
Remove the lower spray arm 27 upwards.
Clean spray arms under running water.
Re-engage or screw on spray arms.

16
Waste water pump
Large food remnants in the rinsing water not retained
by the filters may block the waste water pump. The
rinsing water is then not pumped out and covers the
filter. In this case:
First disconnect the appliance from the power
supply.
Remove the filters 29 .
Scoop out water, use a sponge if required.
Using a spoon, prise off pump cover (as illustrated)
until it clicks, then grip the cover by the lug and first
pull it upwards until it resists and then pull it out
forwards.
Check inner compartment and remove any foreign
objects.
Place cover in the original position, press down and
engage.
Install filters.
Troubleshooting
Experience has shown that you can rectify most faults
which occur in daily operation without calling customer
service. Obviously this will save on costs and ensure
that the machine is quickly available again. The
following overview should help you locate the causes of
faults which may occur.
Warning
If an error code (E:01 to E:30) is indicated on the
digital display 3, always disconnect the appliance
from the power supply and then turn off the tap.
You can rectify certain faults yourself (see following
fault description), for all other faults please contact
customer service and state the indicated fault E:XX.
Warning
Remember: Repairs may be carried out by technicians
only. If a component has to be replaced, ensure that
only original spare parts are used. Improper repairs or
use of non-original spare parts may cause considerable
damage and put the user at considerable risk.
... when the appliance is switched on
The appliance does not start.
The mains fuse has tripped.
The appliance plug has not been inserted.
The appliance door has not been shut properly.
... on the appliance
Lower spray arm rotates sluggishly.
Spray arm blocked.
The door is difficult to open. *
Child-proof lock is activated. The deactivation
instructions are at the back in the envelope.
* depending on model
Door cannot be closed.
Door lock has been activated. To reset, close
the door with greater force.
... changing settings
A setting cannot be changed, a programme
starts.
Wrong programme button pressed.
Terminate the programme (see chapter entitled
“Terminating the programme (Reset)”) and start
all over again.
You did not wait until programme ended.
Cover on the detergent dispenser cannot be
closed.
Detergent dispenser overfilled or mechanism
blocked by sticky detergent residue.
Detergent residue in the detergent dispenser.
Dispenser was damp when filled.

17
“check water supply” 4display lights up.
Tap turned off.
Water supply interrupted.
Supply hose kinked.
Filter in the water supply blocked.
Switch off the appliance and pull out the
mains plug.
Turn off the tap.
Clean filter in the supply hose.
Reconnect power supply.
Turn on the tap.
Switch on the appliance.
Water is left in the appliance at the end of
the programme.
(E24) Waste water hose is blocked or kinked.
(E25) Waste water pump blocked, cover on
the waste water pump is not locked in
position (see Maintenance and Care).
Filters blocked.
The programme has not yet ended. Wait until
programme ends (digital display indicates
0:00) or implement the ”Reset” function.
Refill indicator for salt 5and/or rinse-aid 6
is not lit.
Refill indicator/s switched off.
Adequate salt/rinse-aid available.
Refill indicator for special salt 5is lit.
No salt.
Refill with salt.
Sensor does not detect salt tablets.
Use different special salt.
... during the wash cycle
Unusual foam formation
Handwash liquid in the rinse aid dispenser.
Spilled rinse-aid causes excessive frothing,
therefore please remove with a cloth.
Appliance stops during the wash cycle.
Power supply interrupted.
Water supply interrupted.
Knocking/rattling noise during rinsing
Spray arm is striking utensils.
Utensils not arranged correctly.
Filling valves making striking noises
Caused by the installation of the water line and
has no effect on the function of the machine.
Remedial action is not possible.
... on the utensils
Food residue on the utensils.
Utensils placed too closely together, utensils
basket overfilled.
Too little detergent.
Rinse programme too weak.
Spray arm rotation obstructed.
Spray arm nozzles blocked.
Filters blocked.
Filters incorrectly inserted.
Waste water pump blocked.
Top basket on right and left not set to same
height.
Tea or lipstick residue is not completely
removed.
Detergent has inadequate bleaching effect.
Too low rinsing temperature.
Too little/unsuitable detergent
White stains on the utensils/glasses remain
milky.
If phosphate-free detergents are used with hard tap
water, white deposits may be deposited more easily on
utensils and the container walls.
Too little/unsuitable detergent.
Too weak programme selected.
No/too little rinse-aid.
No/too little salt.
Water softening system set to the wrong value.
Salt dispenser lock not fastened.
Contact the detergent manufacturer, in particular if:
the utensils are very wet at the end of the
programme.
limescale forms.
Dull, discoloured glasses, film cannot be
washed off.
Unsuitable detergent.
Glasses not dishwasher-proof.
Streaks on glasses and cutlery, glasses have
metallic appearance.
Too much rinse-aid.
Plastic parts discoloured.
Too little/unsuitable detergent.
Too weak programme selected.
Rust spots on the cutlery.
Cutlery not rust-resistant.
Salt content in the rinsing water too high, as salt
dispenser lock not fastened firmly or salt was
spilled while being refilled.
Utensils not dry.
Appliance door opened too early and utensils
taken out too early.
Programme selected without drying.
Too little rinse-aid.

18
Customer service
If you are unable to rectify the fault, please contact
your customer service. Your nearest customer service
centre can be found in the customer service list. When
calling customer service, please quote the appliance
number (1) and the FD number (2) which can be found
on the rating plate 35 on the appliance door.
FD
1
2
Warning
Please note that a visit by a customer service
technician to repair a malfunction or one of the
described faults will not be free of charge even during
the warranty period.
Installation
The dishwasher must be connected correctly,
otherwise it will not function properly. The specifications
for the inlet and outlet as well as the electrical
connected loads must correspond with the required
criteria as specified in the following paragraphs or in
the installation instructions.
Install the appliance in the correct sequence:
Checking appliance on delivery
Installing the appliance
Waste-water connection
Fresh-water connection
Electrical connection
Safety instructions
Install and connect the appliance according to the
installation and assembly instructions.
Prior to installation, disconnect the dishwasher from
the power supply.
Ensure that the protective conductor system of the
domestic supply has been correctly installed.
The electrical connection conditions must
correspond with the specifications on the dishwasher
rating plate.
If the power cord of this appliance is damaged, it
must be replaced with a particular power cord.
To prevent injury, the power cord may be replaced by
customer service only.
If the dishwasher is installed in a high- sided unit, the
unit must be secured properly.
Install built-under or integratable appliances only
under continuous worktops which have been
screwed to adjacent cupboards to ensure stability.
Do not install the appliance near heat sources
(radiators, heat storage tanks, cookers or other
appliances which generate heat) and do not install
under a hob.
After installing the appliance, ensure that the plug is
easily accessible.
Some models:
The plastic housing on the water connection
contains an electric valve, the connecting cables are
in the supply hose. Do not cut through this hose,
do not immerse the plastic housing in water.

19
Warning
If the appliance is not in a cavity and a side panel is
accessible, the door hinge area must be covered at the
side for reasons of safety (risk of injury). The covers
are available as optional accessories from customer
service or specialist outlets.
Delivery
Your dishwasher has been checked thoroughly in the
factory to ensure that it is in working order. This may
cause small water stains. These will disappear after the
first wash cycle.
Installation
The required installation dimensions can be found in
the installation instructions. Level the appliance with the
aid of the height-adjustable feet. Ensure that the
appliance is situated securely on the floor.
A built-under or integrated appliance which is
installed subsequently as a free-standing appliance
must be secured to prevent it from overturning, e.g.
by screwing it to the wall or by installing it under a
continuous worktop which is screwed to adjacent
cupboards.
The appliance can easily be installed in a fitted
kitchen between wooden and plastic walls. If the
plug is not freely accessible following installation,
an allpole disconnector with a contact opening of at
least 3 mm must be fitted on the installation side to
satisfy the relevant safety regulations.
Waste-water connection
The required work sequence can be found in the
installation instructions. If required, fit a siphon with
an drainage connection.
Connect the waste-water hose to the drainage
connection of the siphon with the enclosed parts.
Ensure that the drainage hose is not kinked, crushed
or twisted and that there is no cover plate in the
drainage to prevent the waste water from flowing
out!
Fresh-water connection
Connect the fresh-water connection to the tap
according to the installation instructions with the
enclosed parts.
Ensure that the fresh-water connection is not kinked,
crushed or twisted.
When replacing the appliance, always use a new
water supply hose.
Water pressure:
at least 0.05 MPa (0.5 bar), maximum 1 MPa (10 bar).
At a higher water pressure: connect pressure-reducing
valve ahead.
Inlet rate:
minimum 10 litres/minute
Water temperature:
Electrical connection
Connect the appliance to an alternating current only,
ranging from 220 V to 240 V and 50 Hz via a
correctly installed socket with protective earth
conductor. See rating plate for required fusing 35 .
The socket must be near the appliance and freely
accessible following installation.
The connection may be modified by technicians only.
A power cord extension may be purchased from
customer service only.
Use only a residual-current-operated circuit-breaker
which features the symbol. Only this extension
guarantees compliance with the currently valid
regulations.
The appliance features a water damage protection
system. Please note the system will function only
when the power supply is connected.
Removing the appliance
Also observe the sequence of worksteps here.
Disconnect the appliance from the power supply.
Turn off the water supply.
Disconnect the waste water and fresh water
connections.
Loosen the fastening screws under the worktop.
If fitted, remove the base panel.
Pull out the appliance, carefully pulling the hose
behind.
connect to COLD WATER ONLY.

20
Transportation
Empty the dishwasher and secure loose parts.
Drain the appliance according to the following steps:
Turn on the tap.
Open the door.
Switch on ON/OFF switch 1.
The displays of the last selected programme
light up.
Select programme with the highest temperature.
The expected programme duration is indicated
on the numerical display 3.
Press START button 10 .
Close the door.
The programme starts running.
Open door after approx. 4 minutes.
Press the START button 10 until on the digital
display is indicated .
Close the door.
Open door after approx. 1 minutes.
The numerical display indicates .
Switch off appliance 1and turn off the tap.
Transport appliance upright only.
(This prevents residual water from running into the
machine control and damaging the programme
sequence).
Protection against frost
If the appliance is in a room where there is a risk of
frost (e.g. holiday home), empty the appliance
completely (see Transportation).
Turn off the tap, disconnect supply hose and drain
water.
Waste disposal
Both the packaging of new appliances and the old
appliances themselves contain valuable raw materials
and recyclable materials.
Please dispose of the individual parts separated
according to type.
Please ask your dealer or inquire at your local authority
about current means of disposal.
Packaging
All plastic parts of the appliance are identified with
internationally standardised abbreviations (e.g. >PS<
polystyrene).
Therefore, plastic waste can be sorted out when the
appliance is being disposed of.
Please follow the safety instructions under “Delivery of
your appliance”.
Old appliances
Please follow the safety instructions under “Disposal of
your appliance”.
This appliance is identified according to the
European guideline 2002/96/EC on waste electrical and
electronic equipment – WEEE. The guideline specifies
the framework for an EU-wide valid return and re-use
of old appliances.
