Galleon NTS-6001 Instruction sheet

NTS-6001 WEB CONFIGURATION
www.galsys.co.uk
galleonsupport.com
TEL: [phone]
FAX: [phone]
NTS-6001 VERSION 11
WEB CONFIGURATION MANUAL

NTS-6001 WEB CONFIGURATION
www.galsys.co.uk
galleonsupport.com
TEL: [phone]
FAX: [phone]
CONTENTS
Introduction……………………………………………………………………………………………………………………………. 4
Web configuration features………………………………………………………………………………………… 4
Web configuration………………………..…………………………………………………………………………………………. 5
Logging-on to the unit……………………………………………………………………………………………………………… 5
Dashboard……………………………………………………………………………………………………………………………… 6
Network tab…………………………………………………………………………………………………………………………… 7
Networking……………………………………………………………………………………………………………… 7
Teaming………………………………………………………………………………………………………………………. 8
Services tab…………………………………………………………………………………………………………………………… 9
Service status………………………………………………………………………………………………………………. 9
SSH……………………………………………………………………………………………………………………………. 10
SNMP………………………………………………………………………………………………………………………… 10
NTP tab………………………………………………………………………………………………………………………………… 11
NTP status…………………………………………………………………………………………………………………. 11
Broadcast…………………………………………………………………………………………………………………… 12
NTP keys……………………………………………………………………………………………………………………. 13
NTP customisation……………………………………………………………………………………………………… 14
Certificate tab………………………………………………………………………………………………………………………… 15
View certificate………………………………………………………………………………………………………… 15
Self-signed certificate……………………………………………………………………………………………………………… 16
SSL certificate…………………………………………………………………………………………………………………………. 17
Logs tab………………………………………………………………………………………………………………………………… 18
Authentication log…………………………………………………………………………………………………… 18
Daemon log………………………………………………………………………………………………………………… 18
Message log…………………………………………………………………………………………………………………19
Radio antenna debug…………………………………………………………………………………………………..19
GPS antenna debug……………………………………………………………………………………………………..20
Network tools tab…………………………………………………………………………………………………………………….21
Network tools –ping……………………………………………………………………………………………………21
Network tools traceroute…………………………………………………………………………………………….21
Network tools –DNS lookup………………………………………………………………………………………..22

NTS-6001 WEB CONFIGURATION
www.galsys.co.uk
galleonsupport.com
TEL: [phone]
FAX: [phone]
Administration tab…………………………………………………………………………………………………………………. 23
Restart………………………………………………………………………………………………………………………. 23
Shutdown………………………………………………………………………………………………………………… 23
Firmware update……………………………………………………………………………………………………… 24
Factory reset……………………………………………………………………………………………………………… 24
Software versions……………………………………………………………………………………………………… 25
Backup………………………………………………………………………………………………………………………. 25
Restore……………………………………………………………………………………………………………………… 26
Custom scripts…………………………………………………………………………………………………………… 27
Change password………………………………………………………………………………………………………. 28
Support……………………………………………………………………………………………………………………… 29
Advanced…………………………………………………………………………………………………………………… 30
Certificates……………………………………………………………………………………………………………. 30-32
Debug………………………………………………………………………………………………………………………….33
GPS antenna debug……………………………………………………………………………………………………. 33
Radio antenna debug…………………………………………………………………………………………………. 34
Additional information…………………………………………………………………………………………………………… 35
NTP customisation……………………………………………………………………………………………………… 35
Configuration commands………………………………………………………………………………………. 35-37
Command options…………………………………………………………………………………………………. 38-39
Auxiliary commands…………………………………………………………………………………………………… 40
Authentication commands…………………………………………………………………………………………..41
NTP keys……………………………………………………………………………………………………………………. 42
SNMP…………………………………………………………………………………………………………………………. 43
System group……………………………………………………………………………………………………………… 43
Interfaces group………………………………………………………………………………………………………… 43
Process monitoring………………………………………………………………………………………………………44
System load monitoring……………………………………………………………………………………………… 44
Technical support………………………………………………………………………………………………………………. 45-46
Support website…………………………………………………………………………………………………… 45-46
Warranty and maintenance……………………………………………………………………………………………………..47

NTS-6001 WEB CONFIGURATION
www.galsys.co.uk
galleonsupport.com
TEL: [phone]
FAX: [phone]
INTRODUCTION
The NTS-6001 is a rack-mount time server based on an embedded Linux operating system and is
designed to serve as a time source for medium to large companies. The rack-mount unit combines
the ability to synchronise time across networks and peer multiple time servers, with the stability of a
dedicated operating system to provide a stable and reliable time source.
WEB CONFIGURATION FEATURES
New, fresh User Interface (UI)
New HTTP daemon with the support for the latest technologies (TLS 1.2, Modern Cipher
Suites, Strict Transport Security)
Failover support
Configuration backups
Custom SSL certificate support
Better SNMP support
More advanced debugging
Performance improvements
Reduced requirement to restart the unit when changing configuration files
Customisation of NTP Authentication Keys and the NTP Configuration
Checks the status of the time source connected to the unit
Checks the overall status of the unit

NTS-6001 WEB CONFIGURATION
www.galsys.co.uk
galleonsupport.com
TEL: [phone]
FAX: [phone]
WEB CONFIGURATION
LOGGING ON TO THE UNIT
Using a web browser, such as Firefox, Chrome or Internet Explorer, navigate to the address of your
unit. The address of your unit will use the following format: ‘https://<IP Addr>’ where <IP Addr> is
the IP Address of your unit as shown on the front LCD.
This is to be entered into the Address Bar of the browser.
Upon navigating to the address of your unit, a login prompt will appear before allowing you access
to the Web Configuration. The Default username and password are ‘administrator’ and ‘password’.
If your network does not support DHCP, then your unit may not appear on the network to start with.
In order to ‘see’ your unit on the network, you may need to set the IP Address manually on the unit
itself. To do this, please see ‘Setting the IP Address Manually’ in the Technical Support section [Page
7].

NTS-6001 WEB CONFIGURATION
www.galsys.co.uk
galleonsupport.com
TEL: [phone]
FAX: [phone]
DASHBOARD
Upon successful login, you will be taken to the Configuration System Homepage. To the left side of
the screen, you’ll find the navigation menu. Use this menu to work through the Status and
Configuration for the unit.
This page displays the current date and time that the unit has been set to and whether or not the
unit is synchronised. It also shows the Network Card configuration and antenna status identifying if
anything isn’t working properly.
Note: It’s highly recommended to make changing your password one of the first things you do when
setting up the unit.
Note: The time displayed is in the UTC time zone. It may not match your wall clock depending on
what time zone you are in and whether daylight savings time is in effect. This does not affect
whether the correct time is shown on client PCs. Clients use the time in UTC from the server plus
information about their local time to calculate the correct local time.

NTS-6001 WEB CONFIGURATION
www.galsys.co.uk
galleonsupport.com
TEL: [phone]
FAX: [phone]
NETWORK TAB
NETWORKING
This shows the current network settings, and allows you to customise them however you wish. To
make them active the settings must be saved to flash and the system rebooted.
Both Ethernet ports on the unit will be displayed. Port 0 (eth0) is the default primary port and Port 1
(eth1) is the secondary port.
By default eth0 will be set to DHCP and will be provided by your network, unless you configured it
manually before connecting to your network (explained in the hardware manual).
You can disable DHCP and set Static settings by changing the IP Address, the Subnet Mask, the
Gateway and Hostname for both IPv4 and IPv6 for each available network port.
You can also configure up to 2 DNS Servers, the Domain Name and appoint a Syslog Server for the
unit.
Note: Changing these settings requires the unit to be rebooted for them to take effect.

NTS-6001 WEB CONFIGURATION
www.galsys.co.uk
galleonsupport.com
TEL: [phone]
FAX: [phone]
TEAMING
This enables you to allow both Network cards to work together as one single card. This provides
more bandwidth for the network and also allows for redundancy.
When this feature is disabled, each network card remains separate and cannot pass data between
each other, keeping both network connections secure.
Modes for the Linux bonding driver (network interface aggregation modes) are supplied in the
configuration file. The behaviour of the single logical bonded interface depends upon its specified
bonding driver mode. The default parameter is balance-rr.
balance-rr - This provides load balancing and fault tolerance.
active-backup - This mode provides fault tolerance.
balance-xor - This selects the same slave for each destination MAC address and provides
load balancing and fault tolerance.
broadcast - This mode is least used (only for specific purpose) and provides only fault
tolerance.
balance-tlb - This is called as adaptive transmit load balancing.
balance-alb - This is Adaptive load balancing mode, this includes balance-tlb + receive load
balancing (rlb) for IPV4 traffic.

NTS-6001 WEB CONFIGURATION
www.galsys.co.uk
galleonsupport.com
TEL: [phone]
FAX: [phone]
SERVICES TAB
SERVICE STATUS
Here you can see the status of any of the services on the Network Time Server.
Note: The clock services may be running, but it does not indicate that the physical clock is either
connected and/or providing a time. The NTP Service will not run until the unit has received an initial
time signal.

NTS-6001 WEB CONFIGURATION
www.galsys.co.uk
galleonsupport.com
TEL: [phone]
FAX: [phone]
SSH
This allows you to toggle SSH on/off to remotely access the unit's operating system, using software
such as PuTTY.
SNMP
This allows for the configuration of SNMP.
Here you can add custom information to the SNMP configuration. The MIBs can be downloaded
from the unit itself or alternatively they can be found on the support site at galleonsupport.com for
your reference.

NTS-6001 WEB CONFIGURATION
www.galsys.co.uk
galleonsupport.com
TEL: [phone]
FAX: [phone]
NTP TAB
NTP STATUS
This is where you can check the status of the NTP process and see the sources that this process is
synchronised with, including the state of these sources.
The host names or addresses shown in the remote column correspond to the server and peer entries
listed in the configuration file; however, the DNS names might not agree if the names listed are not
the canonical DNS names.
The refid column shows the current source of synchronisation, while the st column reveals the
stratum, t the type (u = unicast, m = multicast, l = local), and poll, the poll interval in seconds.
The when column shows the time since the peer was last heard in seconds, while the reach column
shows the status of the reachability register (see RFC-1305) in octal.
The remaining entries show the latest delay, offset and jitter in milliseconds. Note that in NTP
Version 4, what used to be the dispersion column has been replaced by the jitter column.
The currently selected peer is marked *, while additional peers designated acceptable for
synchronisation, but not currently selected, are marked +. Peers marked * and + are included in the
weighted average computation to set the local clock; the data produced by peers marked with other
symbols are discarded. See the ntpq page for the meaning of these symbols.

NTS-6001 WEB CONFIGURATION
www.galsys.co.uk
galleonsupport.com
TEL: [phone]
FAX: [phone]
BROADCAST
This allows you to set the unit to Broadcast and/or Multicast in addition to answering NTP requests,
enabling these options does not stop the unit from responding to NTP requests.

NTS-6001 WEB CONFIGURATION
www.galsys.co.uk
galleonsupport.com
TEL: [phone]
FAX: [phone]
NTP KEYS
The NTP Keys section allows you to enter your pre-configured security keys to allow the unit to
communicate with other devices on the network for various purposes.

NTS-6001 WEB CONFIGURATION
www.galsys.co.uk
galleonsupport.com
TEL: [phone]
FAX: [phone]
NTP CUSTOMISATION
The NTP Customisation section provides a way to enter commands to customise the operation of the
NTP Server. This enables peering, network based servers, authentication keys and other standard
NTP features.

NTS-6001 WEB CONFIGURATION
www.galsys.co.uk
galleonsupport.com
TEL: [phone]
FAX: [phone]
CERTIFICATE TAB
VIEW CERTIFICATE
Here you can see the currently installed certificate information for the Web Configuration panel.

NTS-6001 WEB CONFIGURATION
www.galsys.co.uk
galleonsupport.com
TEL: [phone]
FAX: [phone]
SELF-SIGNED CERTIFICATE
Self-Signed Certificates allow the unit to sign itself. This process involves entering the required
information and applying the generated certificate.
Note: There are 3 different key lengths to choose from; 1024, 2048 and 4096. The larger the key
length, the more secure it is.
Note: The longer the key the longer it can take to generate the certificate. Please do not leave or
refresh the page during this process as this may cause issues with the web server that runs this
configuration panel.

NTS-6001 WEB CONFIGURATION
www.galsys.co.uk
galleonsupport.com
TEL: [phone]
FAX: [phone]
SSL CERTIFICATE
SSL-Signed Certificates allow you to get a certificate signed by your CA (Certificate Authority). This
process involves entering the required information, submitting the request to the CA, entering the
response and applying the certificate.
Note: There are 3 different key lengths to choose from; 1024, 2048 and 4096. The larger the key
length, the more secure it is.
Note: The longer the key the longer it can take to generate the certificate. Please do not leave or
refresh the page during this process as this may cause issues with the web server that runs this
configuration panel.

NTS-6001 WEB CONFIGURATION
www.galsys.co.uk
galleonsupport.com
TEL: [phone]
FAX: [phone]
LOGS TAB
AUTHENTICATION LOG
Below are Authentication Events (logs) for both SSH and Web Interface.
Contains system authorisation information, including user logins and authentication mechanisms
that were used.
DAEMON LOG
Below is a list of background Services logs (/var/log/daemon.log) –Contains information logged by
the various background daemons that runs on the system.

NTS-6001 WEB CONFIGURATION
www.galsys.co.uk
galleonsupport.com
TEL: [phone]
FAX: [phone]
MESSAGE LOG
Below is a complete list of all system messages (/var/log/messages) –This is the general system
activity log. Everything is logged to this file including logins, authentication failed, anonymous logins,
network connections, ntp info etc.
RADIO ANTENNA DEBUG
This allows you to debug the Radio antenna by seeing what data they are sending to the unit. This
will help identify any cabling/wiring or antenna issues. Debug lines are output with the newest line
at the top and show the 20 most recent entries.
Note: Disable Debug after use.

NTS-6001 WEB CONFIGURATION
www.galsys.co.uk
galleonsupport.com
TEL: [phone]
FAX: [phone]
GPS ANTENNA DEBUG
This allows you to debug the GPS antenna by seeing what data they are sending to the unit. This will
help identify any cabling/wiring or antenna issues. Debug lines are output with the newest line at
the top and show the 20 most recent entries.
Note: Disable Debug after use.
