Frank Hudson by Gallery Home - SPIRE 2 DOOR WARDROBE
Code Number 5055299480069
PRE - ASSEMBLY PREPARATION
Please Check the pack contents before attempting to assemble this product.
A full checklist of components is given in this leaflet. If any components are missing, please contact
the store of purchase.
This product is
HEAVY
, it should be assembled as close as possible to the point of use.
TAKE CARE WHEN LIFTING
to avoid personal injury (or) damage to the product.
This product takes approximately
30 MINUTES
to assemble with
2 people
.
The fittings pack contains SMALL ITEMS which should be
KEPT AWAY FROM YOUNG CHILDREN
.
Read this leaflet in full before commencing assembly.
You will require a crosshead screwdriver.
Important Safety Note
Always lift the unit from the base when moving it, do not drag along the ground. It is recommended
that two people should move the unit, never move it alone.
A cross head screwdriver only, should be used to assemble this Wardrobe; an electric screw driver
may cause damage to the product and is not recommended.
S tep B y S tep A ssembly I nstructions
Page: 1 / 8

2
2
3
SPIRE 2 DOORS WARDROBE
Items qty
1 1
2 1
3
1
4 1
5 Left & Right Side Panel & Center Panel (each 1 piece) 1
Description
Packaging Identification
Back Panel
Base
Top Wardrobe (1) + Wooden Shelf (2 small) + hanging rail (1 small + 2
large)
Left & Right Door (each 1 piece)
Page: 2 / 8

DOWEL
RONDORFIX PIN
RONDORFIX
RONDORFIX
HOUSING
DOWEL
RONDORFIX
PIN
Item Qty
1 1
A
4
A1 4
B 8
B1 8
2 1
3 2
4 1
5 2
6 1
7 2
8 3
Description
Rondorfix Pin
Panel and Connection Identification
Rondorfix Housing
Base
Top
Side Panel
Maxifix Housing
Maxifix Pin
Center Panel
Hanging Rail (Large: 2 piece + Small : 1 Pieces)
Shelves (Small: 2 pieces)
Back Panel
Door (R/L)
Page:
3
/
8

Step 1. Put the Maxifix housing (A) & Screw the Rondorfix pins (B1) into the holes provided
in the base of wardrobe (1) using a screw driver ( - ).
A
Step 2.
Put the Rondorfix housing (B) & using screw driver (+) the Maxifix Pin (A1) into the holes
provided in the side panels (3, 4, 3).
Page: 4 / 8

Step 3. Screw the Maxifix housing which is located on the upper and bottom of each side panel
(3 ).
Step 4.
Put the center panel and screw the Rondorfix housing into the holes provided (4).
Page: 5 / 8

Step 5.
Fit the top Crown in the place & secure, using the upper Rondorfix housing.
Step 6.
Then put the back panel (6) on and screw together using a screw driver (+) .
Step 6.
Then put the back panel (6) on and screw together using a screw driver (+) .
Page: 6 / 8

Step 7.
Slot in place the adjustable smaller shelf (7) and screw the hanging rail (8) using
Then hang the doors (5) with the hinges attached to the inside of front panel.
pilot holes provided.
Page: 7 / 8

FINISH
Page: 8 / 8
