ASSEMBLY & INSTALLATION INSTRUCTIONS
STYLE “B” FLOOR PLATE
MODEL NUMBER
151651461

Doc 151751465
Gared Holdings, LLC
9200 East 146
th
Street, Suite A
Noblesville, ndiana 46060
800-325-2682
MODEL NUMBER
151651461
ASSEMBLY PARTS L ST
KEY DESCR PT ON QTY
1 ¼ X 1-1/2” TAP SCREW 4
2 ½-13 X ¾ CAP SCREW 1
3 “B” PLATE ASSEMBLY 1
4 ANCHOR CEMENT BAG 1
BEFORE YOU BEG N NSTALLAT ON
1. YOUR “B” PLATE COMES N ONE PACKAGE. MAKE SURE YOU
HAVE RECE VED ALL THE PARTS L STED ABOVE. THE CAP
SCREW S USED TO A D N CORRECT NSTALLAT ON
2. YOU W LL NEED THE FOLLOW NG TOOLS AVA LABLE DUR NG
NSTALLAT ON:
HAMMER DR LL
1-1/8” MASONRY B T
REGULAR DR LL W/ 1-1/8” WOOD DR LL B T
ONE 5/32” DR LL B T
ROUTER
SCREWDR VER W TH W DE BLADE
M X NG CONTA NER AND WATER
SMALL VACUUM CLEANER, T RE PUMP, OR BATTERY F LLER
ST FF C RCULAR BRUSH
PUTTY KN FE
ABSORBENT RAG
3. READ ALL NSTRUCT ONS CAREFULLY BEFORE STAR NG
NSTALLAT ON. CALL GARED W TH ANY QUEST ONS
REGARD NG PROPER NSTALLAT ON
NSTALLAT ON NSTRUCT ON:
1. LOCATE AND MARK THE CENTER LOCAT ONS OF THE FLOOR PLATES US NG THE LAYOUT D AGRAM
PROV DED W TH THE APPARATUS BE NG NSTALLED. RE-CHECK ALL CENTER LOCAT ONS FOR ACCURACY
BEFORE NSTALL NG THESE PLATES
CAUT ON: MPROPER NSTALLAT ON CAN
CREATE A HAZARD WHEN FLOOR PLATES ARE
USED W TH APPARATUS. FOLLOW
D RECT ONS CAREFULLY
WARNING: This product can expose you to crystalline silica, which is known
to the State of California to cause cancer and Portland cement, which is known to
the State of California to cause birth defects or other reproductive harm.
For more information go to www.p65warnings.ca.gov
Prop 65 Warning for California Customers

Doc 151751465
Gared Holdings, LLC
9200 East 146
th
Street, Suite A
Noblesville, ndiana 46060
800-325-2682
MODEL NUMBER
151651461
NSTALLAT ON NSTRUCT ON CONT:
2. US NG THE 1-1/8” WOOD
DR LL B T, DR LL A
HOLE N TO THE WOOD
FLOOR AND SUB FLOOR
TO THE CONCRETE
SURFACE
3. NEXT, USE THE 1-1/8”
MASONRY B T AND
DR LL TO AN APPROX DEPTH OF
4-3/4” (3-3/4” M N) AS SHOWN
N THE F GURE TO THE R GHT.
4. MAKE A TEMPLATE US NG A P ECE OF MASON TE OR TH CK PLAST C. MAKE A HOLE N THE TEMPLATE MATER AL
SO THAT WHEN THE ROUTER S USED W TH T, THE COUNTERBORED D AMETER S 2-29/32”. USE A SCRAP BOARD TO
PRACT CE, AND FOR CHECK NG THE F N SHED HOLE S ZE BEFORE ATTEMPT NG TH S ON YOUR FLOOR.
5. CREATE A COUNTERBORED HOLE 2-29/32” D AMETER AND ¼” DEEP CENTERED ON THE 1-1/8” D AMETER HOLE
PREV OUSLY DR LLED NTO FLOOR.
WHEN MAK NG THE COUNTERBORE,
KEEP PRESSURE ON THE TEMPLATE AT
ALL T MES. TH S W LL KEEP THE TEMPLATE
FROM SL PP NG, T W LL ALSO HELP TO KEEP
THE WOOD FLOOR FROM SPL NTER NG
AROUND THE HOLE. DO NOT SET THE
DEPTH AT ¼” FOR THE F RST PASS ON
THE ROUT NG STEP. GRADUALLY WORK
DOWN TO THE DEPTH AT WH CH THE
FLOOR PLATE S JUST FLUSH W TH THE
SURFACE OF THE FLOOR. PLACE THE FLOOR
PLATE NTO THE HOLE SEVERAL T MES
TO ENSURE THAT THE HOLE S NOT
MADE TOO DEEP. THE FLOOR PLATE
MUST BE PERFECTLY FLUSH W TH THE
TOP SURFACE OF THE FLOOR.
6. COMPLETELY REMOVE THE DUST FROM THE HOLE BY SUCK NG T OUT W TH A VACUUM CLEANER, OR BLOW NG
T OUT W TH A T RE PUMP OR BATTERY F LLER.

Doc 151751465
Gared Holdings, LLC
9200 East 146
th
Street, Suite A
Noblesville, ndiana 46060
800-325-2682
MODEL NUMBER
151651461
NSTALLAT ON NSTRUCT ON CONT:
7. F LL THE HOLE W TH WATER AND SCRUB S DES AND BOTTOM W TH ST FF C RCULAR BRUSH, SUCH AS A BOTTLE
BRUSH. TH S STEP S CR T CAL!
8. REMOVE EXCESS WATER AND ANY LOOSE PART CLES W TH A RAG OR PAPER TOWEL. THE HOLE MUST BE CLEAN
AND UN FORMLY DAMP.
9. MEASURE ONE-PART WATER TO F VE PARTS CEMENT BY VOLUME (PROV DED) AND M X TOGETHER N CLEAN
CONTA NER. MEASURE WATER TO CEMENT RAT O AS ACCURATELY AS POSS BLE. M X SHOULD REACH A FLOWABLE
CONS STENCY.
10. NSERT THE CAP SCREW NTO THE FLOOR PLATE UNT L F NGER T GHT.
11. POUR CEMENT M XTURE NTO THE CLEANED DAMP
HOLE UNT L T S APPROX MATELY ¾ FULL.
12. WET THE KNURLED (ROUGH) SURFACE OF
THE FLOOR PLATE BODY W TH WATER,
DO NOT ALLOW WATER TO GET NTO
THE WORK NGS OF THE FLOOR
PLATE ASSEMBLY. NSERT THE FLOOR
PLATE ASSEMBLY NTO THE CEMENT
F LLED HOLE. PRESS DOWN ON
CAP SCREW UNT L THE TOP PLATE S
PROPERLY SEATED N THE COUNTERBORED
HOLE. EXCESS CEMENT SHOULD
FLOW OUT AROUND THE TOP OF THE
PLATE. F TH S DOES NOT HAPPEN, THE
FLOOR PLATE BODY SHOULD BE REMOVED,
MORE CEMENT ADDED, AND RE- NSERTED
NTO HOLE. SCRAPE THE EXCESS CEMENT
M XTURE W TH A PUTTY KN FE OR SCRAPER.
CAUT ON
:
DO NOT ADD SAND, GRAVEL, OR OTHER FORE GN SUBSTANCES TO THE CEMENT, DO NG SO W LL WEAKEN THE
CEMENT.
DO NOT ADD TOO MUCH WATER, OR ATTEMPT TO “RE-TEMPER” CEMENT THAT HAS BEGUNTO CURE BY ADD NG
WATER. TH S W LL RESULT N FA LURE OF THE CEMENT TO ACH EVE PROPER STRENGTH.

Doc 151751465
Gared Holdings, LLC
9200 East 146
th
Street, Suite A
Noblesville, ndiana 46060
800-325-2682
MODEL NUMBER
151651461
NSTALLAT ON NSTRUCT ON CONT:
13. US NG THE TOP OF THE FLOOR PLATE AS A GU DE, CENTER THE 5/32” DR LL B T N EACH HOLE AND DR LL FOUR (4)
HOLES N THE WOOD FLOOR 1-5/8” DEEP FOR THE WOOD SCREWS AS SHOWN ABOVE. NSTALL THE WOOD SCREWS,
MAK NG SURE THAT THEY ARE STRA GHT AND WELL SEATED N THE COUNTERS NK OF THE TOP PLATE.
14. ALLOW TO CURE FOR AT LEAST 15 M NUTES. AFTER TH S T ME THE CEMENT S N T ALLY SET. REMOVE THE CAP
SCREW FROM THE TOP PLATE
15. ALLOW 12 HOURS TO FULLY CURE. AFTER 12 HOURS, THE APPARATUS MAY BE SET UP AND USED W TH FLOOR
PLATE
16. WHEN NSTALL NG THE APPARATUS TO THE FLOOR PLATE, NSERT THE EYE SCREWS F NGER T GHT ONLY. NO
TOOLS SHOULD BE REQU RED FOR TH S OPERAT ON. AFTER THE EYE SCREW HAS BEEN T GHTENED F NGER T GHT,
LOOSEN ONLY ENOUGH TO ALLOW PROPER AL GNMENT BETWEEN APPARATUS ATTACH NG BRACKET(S) AND
EYEBOLT.
USE OF YOUR “B” PLATE
1. TH S FLOOR PLATE S NTENDED FOR USE N FLOORS W TH A LAYER OF WOOD NSTALLED D RECTLY OVER
CONCRETE. T S NOT NTENDED FOR USE W TH FLOAT NG FLOORS OR CONCRETE ONLY FLOORS. F THERE S ANY
QUEST ON ABOUT THE APPROPR ATE FLOOR PLATE FOR YOUR FLOOR SURFACE, CONTACT GARED FOR ASS STANCE
BEFORE NSTALL NG.
2. CLEAN AND NSPECT FLOOR PLATES REGULARLY. ENSURE THAT THREADS ARE ENGAG NG PROPERLY AND THERE S
NO BREAKDOWN OF CEMENT. PROPERLY NSTALLED TH S FLOOR PLATE S DES GNED TO W THSTAND ANY LOAD
APPL ED BY THE APPARATUS.
3. F THERE S ANY DOUBT AS TO THE NTEGR TY OF THE FLOOR PLATE, DO NOT USE IT. CONTACT A PROFESS ONAL
NSTALLER OR GARED FOR EVALUAT ON.

Doc 151751465
Gared Holdings, LLC
9200 East 146
th
Street, Suite A
Noblesville, ndiana 46060
800-325-2682
MODEL NUMBER
151651461
KEY PART NAME
1 REMOVABLE CAP
2 FLOOR PLATE PLUG
3 EXTERNAL E-R NG
4 FLOOR PLATE SPR NG (2X)
5 FLOOR PLATE ANCHOR SCREW
6 3/8” HEX NUT
7 3/8-16 X 1-1/2 CARR AGE BOLT
1
6
5
7
4
2
3
REPLACEMENT PARTS L ST
(ALL PARTS NCLUDED N PART # 151651422)
