Assembly Instructions for:
31600 Motor Carrier
PO Box 8, 644 2nd Street
St. Paul Park, MN 55071
Form 12.121
Phone: [phone]
E-mail: [email protected]
On the Web: www.garelick.com
Revision Date: 08/07
TOOLS Required: Page 1
Hammer
CAUTION: Tubing will crush if over-tightened.
Step 1: Motor Carrier Assembly
A. Slide bottom braces on axle using large holes as
shown.
B. Slide Upright support tube on axle using large holes
as shown.
Step 2:
A. Place plastic washer on axle.
B. Place wheel on axle as shown.
C. Secure with pin. **Bend pin to secure in place**
D. Place caps on wheels. Gently tap into place with
hammer.
Step 3:
Place tank tie straps on upright supports as shown.
Step 4:
Attach plastic block to each end of upright support by
aligning holes. Insert 4 bolts (2 7/8” long) and tighten
fasteners.
NOTE: Top of block should be even with ends of
upright tubes as shown.
Plastic Washer
Bend pin
Cap
Upright Support Tube
Bottom Brace
Axl
e

Assembly Instructions for:
31600 Motor Carrier
PO Box 8, 644 2nd Street
St. Paul Park, MN 55071
Form 12.121
Phone: [phone]
E-mail: [email protected]
On the Web: www.garelick.com
Revision Date: 08/07
Page 2
Step 5: Handle Assembly
Insert handles into short bottom U tube.
Align holes in assembly so that the handles will
point AWAY from each other and insert bolts.
NOTE: DO NOT add fasteners yet.
NOTE: Rigidity of cart is obtained through the following
assemblies; some force will be needed to align certain
holes.
Step 6:
Slide handles assembly into upright support assembly.
Insert bolts in bottom brace and finger tighten
fasteners.
NOTE: Handles will rest on outsides of upright support
tubes. Make sure plastic block is facing up as shown.
Step 7:
Align holes to fasten handles to upright support. (May
need to turn assembly “up-side-down”)
Insert bolt and finger tighten fasteners.
Bolts
Handles
Short U Tube
Block
Handle Assembly
Bottom Brace
Locknut
Locknut
Bolt

Assembly Instructions for:
31600 Motor Carrier
PO Box 8, 644 2nd Street
St. Paul Park, MN 55071
Form 12.121
Phone: [phone]
E-mail: [email protected]
On the Web: www.garelick.com
Revision Date: 08/07
Page 3
Step 8:
Attach handle brace (tube with rounded ends) across
top. Insert bolts and finger tighten fasteners.
Drape tank tie straps over wood block so loops are
above holes.
Step 9:
Position tank holder U tube as shown.
NOTE: Place tank holder on inside of main upright
tube. U opens out facing forward.
Insert bolts and finger tighten fasteners.
***Step 10: Tighten all fasteners on carrier.***
Finished Assembly:
Maintenance:
Periodically lubricate wheels and polish** aluminum to
ensure a long life.
NOTE: Recommended for motors 1-30 h.p./130 lbs.
**EEz-In marine polish, Model 65010, available.
Fasten
Fasten
Strap
