Welcome…
Welcome to a new era of aviation navigation. Once
again, Garmin has set new standards in features and
ease of use for the general aviation public. The GMX
200 Multi-Function Display provides a focal point for
integrating many of your navigation needs in an easy
to use and convenient package.
The GMX 200 presents a wealth of information
on its six-inch diagonal, 640x480 pixel, color display.
The many features are organized as distinct functions.
Each function allows varying degrees of customization.
The custom map function is customizable so you
can create a display for almost any configuration you
require. The other functions provide more limited
levels of customization.
The GMX 200 is capable of creating powerful over-
lay views where information from a variety of sources
can be presented simultaneously in proper relationship
to each other, thus greatly increasing situational aware-
ness for the pilot.
You can be confident in knowing that you are
the owner of the state-of-the-art in aviation and
navigation. The GMX 200 architecture is designed to
support full expansion for both software and hardware
enhancements. This flexibility protects your invest-
ment and allows for the ease of adding new features.
Our products are built to last and to allow the flexibil-
ity to meet your needs as they change in the future.
Accessories and Packing List
To obtain accessories for your GMX 200 please contact
your Garmin dealer.
Help us better support you by completing our on-line
registration form today! Registration ensures that you
will be notified of product updates and new products and
provides lost or stolen unit tracking. Please, have the serial
number of your GMX 200 handy, connect to our web site
(www.garmin.com) and look for our Product Registra-
tion link on the home page.
NOTE: The GMX 200 display lens is coated with a
special anti-reflective coating which is very sensi-
tive to skin oils, waxes, and abrasive cleaners. It is
very important to clean the lens using an eyeglass
cleaner that is specified as safe for anti-reflective
coatings and a clean, lint-free cloth.
Accessories, Packing List, & Welcome

v190-00607-02 Rev C
Introduction
About This Manual
This manual may be used as a summary, a refer-
ence, and a learning tool. Information is provided
about all of the functions available to the GMX 200.
Your specific installation may not include all of these
functions.
Take a few moments to familiarize yourself with
the various sections in this manual. The Getting
Started section gives an introduction to the controls,
basic operation, and organization of the functions in
your GMX 200. Be sure to read the Getting Started
section to learn the rules for using the GMX 200. The
Detailed Operation section (starting on page 15) is the
reference for each of the functions in the GMX 200.
Refer to the Detailed Operation section when you want
to get into the details on every function and option
along with step-by-step instructions.
Not every function is available in every installation.
Limitations
The Traffic function is not a collision avoid-
ance system. It is an aid to visual acquisition and
does not relieve the flight crew of their respon-
sibility to “see and avoid.” There are no evasive
aircraft maneuvers authorized, recommended,
or provided for as a result of displayed traffic
targets. Refer to the traffic sensor documentation
for additional information.
All pilots/operators are reminded that the airborne
equipment that displays other ADS-B equipped aircraft
and transponder equipped aircraft via TIS-B is for pilot
situational awareness and is not approved as a colli-
sion avoidance tool. Any deviation from an air traffic
control clearance based on cockpit information must
be approved by the controlling ATC facility prior to
Limitations
commencing the maneuver. Uncoordinated devia-
tions may place an aircraft in close proximity to other
aircraft under ATC control not seen on the airborne
equipment and may possibly result in the issuance of a
pilot deviation.
The Terrain function shows you the general terrain
elevations relative to your altitude and are advisory
in nature. Individual obstructions may be shown
if available in the database. Terrain is displayed
from database information and may therefore
contain errors. The Terrain function does not
relieve the flight crew of their responsibility to
“see and avoid.” Do not use this information for
navigation.
The moving map, weather information, and
other displayed information are meant to be aids to
situational awareness. The pilot should rely on the
appropriate primary means of navigation and consult
official and approved data sources prior to and during
each flight.
Refer to your airplane flight manual supplement
for more information.

vi 190-00607-02 Rev C
Introduction
Table of Contents
Table of Contents
Introduction.............................................................. i
History of Revisions ................................................................ i
Ordering Information ............................................................. i
End User License Agreement (“EULA”) ..................................ii
Accessories and Packing List..................................................iv
Welcome…...........................................................................iv
About This Manual.................................................................v
Limitations .............................................................................v
Getting Started ....................................................... 1
Functions .............................................................................. 1
GMX 200 Function List .................................................... 1
Display .................................................................................. 3
Message Flag................................................................... 3
Controls................................................................................ 4
Power On ....................................................................... 4
Power.............................................................................. 4
Brightness ....................................................................... 4
Rotary Knob .................................................................... 4
Function (FN) Key ............................................................ 4
MENU/ENT ...................................................................... 5
Menu Item ...................................................................... 5
Data Card ............................................................................. 5
Annunciations....................................................................... 6
Advisory Flags.................................................................. 6
ADS-B Traffic ................................................................... 6
TAS/TCAD/TIS-A Traffic .................................................... 6
Radar .............................................................................. 6
Terrain ............................................................................. 6
Lightning......................................................................... 6
ADS-B Status Annunciation ............................................. 6
Basic Operation..................................................................... 8
Start Up Screen ..................................................................... 8
Confirm Current Baro Correction........................................... 9
Function Selection................................................................. 9
Advisory Hot Key................................................................. 10
Normal Cruise Condition ............................................... 10
Viewing the Advisory..................................................... 10
Returning To Normal Condition ..................................... 10
Alert Hot Key ...................................................................... 10
Options Menu..................................................................... 10
Thumbnail Feature .............................................................. 11
Traffic on Thumbnail...................................................... 11
Terrain on the Thumbnail............................................... 11
Obstructions on the Thumbnail...................................... 11
Thumbnail Activation..................................................... 11
Traffic Information Services (TIS) .......................................... 12
Polar Navigation.................................................................. 12
Detailed Operation................................................15
Message Log (MSG) .....................................................................15
Custom Map (MAP).......................................................................16
Initial Zoom Level ................................................................ 16
Map Scale ........................................................................... 16
Auto Zoom.......................................................................... 16
Pan .................................................................................... 17
Info .................................................................................... 17
Info In Pan Mode................................................................. 17
Custom Map Menu Option Page 1...................................... 18
Flight Plan ........................................................................... 18
Map Orientation.................................................................. 18
Invert .................................................................................. 18
Nav Data............................................................................. 18
Load Chart (Optional).......................................................... 19
Custom Map Menu Option Page 2...................................... 19
Airports ......................................................................... 19
Hot Spots ...................................................................... 20
VORs................................................................................... 21
VOR Highlight ............................................................... 21
VOR OBS............................................................................. 21
ILS/Localizer Depiction .................................................. 22
Localizer Back Course Display ....................................... 22
NDBs .................................................................................. 22
Intersections........................................................................ 22
Airspace.............................................................................. 22
Custom Map Menu Option Page 3...................................... 23
Low Airways........................................................................ 23
High Airways....................................................................... 23
Water.................................................................................. 23
Roads.................................................................................. 23
Cities................................................................................... 23
Custom Map Menu Option Page 4...................................... 24
Boundaries.......................................................................... 24
Nexrad ................................................................................ 24
METARs............................................................................... 24
Lightning............................................................................. 24
Cell Move............................................................................ 24
Custom Map Menu Option Page 5...................................... 24
Airport Chart (ChartView) ................................................... 25
Terrain................................................................................. 25
Obstructions........................................................................ 26
Traffic.................................................................................. 26
Strikes ................................................................................ 26
IFR En Route (IFR) Chart Function ................................................27
SafeTaxi............................................................................... 27

vii190-00607-02 Rev C
Introduction
Hot Spots............................................................................ 27
IFR Option Page 1................................................................ 28
Flight Plan ........................................................................... 28
Map Orientation.................................................................. 28
Invert .................................................................................. 28
Nav Data............................................................................. 28
Label................................................................................... 29
IFR Option Page 2................................................................ 29
Low Airways........................................................................ 29
High Airways....................................................................... 29
Airport Chart (Jepp ChartView) ........................................... 29
Load Chart.......................................................................... 30
VFR Chart (VFR) Function .............................................................31
SafeTaxi............................................................................... 31
Hot Spots............................................................................ 31
Flight Plan ........................................................................... 32
Map Orientation.................................................................. 32
Invert .................................................................................. 32
Nav Data............................................................................. 32
Label................................................................................... 32
Split Screen (SPLIT) Function........................................................33
TAS / TCAD Traffic (TRAF) Function ..............................................34
Traffic Depiction .................................................................. 34
Symbology .......................................................................... 34
Alert Hot Key ...................................................................... 34
Traffic Alert Pop-Up............................................................. 34
Vert Smart Key (TAS) ........................................................... 35
Traffic Status Indicators ....................................................... 35
Off Scale........................................................................ 35
Standby (TAS) ................................................................ 35
Test (TAS)....................................................................... 35
Not Displayed ................................................................ 35
TAS Fail.......................................................................... 35
TAS Data Fail ................................................................. 35
TAS Data Time-Out........................................................ 35
No Bearing Advisories.......................................................... 35
TAS Menu Options .............................................................. 35
Traffic Alert Mode (Pop-Up/Prompt) ............................... 35
Standby Mode............................................................... 35
Self-Test......................................................................... 35
TCAD 9900B Menu Options................................................ 36
Altitude Option (Relative/Pressure) ................................. 36
Filter.............................................................................. 36
Volume.......................................................................... 36
Approach Mode ............................................................ 36
Mute Duration............................................................... 36
Shield ............................................................................ 36
Shield Heights ............................................................... 36
Shield Ranges ................................................................ 36
TCAD 9900BX Menu Options.............................................. 36
Altitude Option (Relative/Pressure) ................................. 36
Filter.............................................................................. 36
Volume.......................................................................... 36
Approach Mode ............................................................ 36
Ground/Flight Mode ...................................................... 36
ADS-B Traffic (TRAF) Function ......................................................37
Traffic Description ............................................................... 38
TIS-B Traffic ................................................................... 39
TIS-B Limitations ............................................................ 40
Degraded Target............................................................ 41
Target Color .................................................................. 41
Surface Targets ............................................................. 41
Traffic Altitude Values .................................................... 41
Ident ............................................................................. 41
Operation...................................................................... 41
Traffic Option Page 1........................................................... 42
Transmit Status ................................................................... 42
ADS-B Broadcast Mode Control........................................... 42
Broadcast FID................................................................. 42
Broadcast VFR................................................................ 42
Enter Code (ADS-B Air Traffic Source).................................. 42
Set 1200 ............................................................................. 43
Services............................................................................... 43
Traffic Menu Option Page 2................................................. 43
Time ................................................................................... 43
Traffic Altitude Filter ............................................................ 43
Altitude Option (Relative/Absolute) .................................... 44
Flight Plan ........................................................................... 44
Traffic Map Orientation ...................................................... 44
Traffic Menu Option Page 3................................................. 44
Display Mode ...................................................................... 44
Graphic Display ............................................................. 44
Text Display ................................................................... 44
Enter FID ............................................................................. 45
Label................................................................................... 45
TIS-A Traffic (TRAF) Function .......................................................45
Traffic Depiction .................................................................. 46
TIS-A Menu Options............................................................ 46
Alert Hot Key (TA Prompt) ............................................. 46
Traffic Alert Pop-Up (TA Popup) ..................................... 46
Operate/Standby .......................................................... 47
Symbology .......................................................................... 47
Traffic Status Indicators ....................................................... 47
Flight Plan (FPL) Function.............................................................48
METARs............................................................................... 48
Terrain (TER) Function ..................................................................50
Table of Contents

viii 190-00607-02 Rev C
Introduction
Table of Contents
Internal GMX 200-Based Terrain.......................................... 50
Obstructions........................................................................ 50
Terrain Option Page............................................................. 51
Flight Plan ........................................................................... 51
TRK Up Arc/TRK Up 360...................................................... 51
Set Barometer (Pressure Altitude only) ................................. 51
TER Data Flag...................................................................... 52
External TAWS-Based Terrain Display ................................... 52
TAWS Pop-Up Modes .......................................................... 52
UAT Flight Information Service (FIS) Function .............................53
Text Display ......................................................................... 54
Viewing Text.................................................................. 54
Clearing Text FIS Messages ............................................ 54
Sorting Text FIS Messages .............................................. 54
GDL 69/69A Flight Information Service (FIS) Function ................55
Weather Product Zoom Scale .............................................. 55
Temporary Flight Restrictions (TFRs) ..................................... 55
NEXRAD Description............................................................ 56
NEXRAD Abnormalities.................................................. 56
NEXRAD Limitations ...................................................... 56
NEXRAD Intensity .......................................................... 56
Current ............................................................................... 57
NEXRAD ........................................................................ 57
METARs ......................................................................... 58
Lightning....................................................................... 58
Cell Movement.............................................................. 58
Cloud Tops .................................................................... 59
Echo Tops ...................................................................... 60
Winds Aloft ................................................................... 60
Winds Aloft Altitude...................................................... 60
TFR Label....................................................................... 61
GDL 69/69A FIS Current Menu Page 3........................... 61
Label ............................................................................. 61
Flight Plan ..................................................................... 61
Legend .......................................................................... 61
Map Detail .................................................................... 62
Map Orientation............................................................ 62
Product Times................................................................ 63
Forecast .............................................................................. 63
Surface Analysis............................................................. 64
City ............................................................................... 65
Forecast Time ................................................................ 65
SIGMET ......................................................................... 65
AIRMET ......................................................................... 65
GDL 69/69A FIS Forecast Menu Page 2 .......................... 66
Freezing Levels............................................................... 66
County .......................................................................... 66
Cyclone ......................................................................... 66
TFR Label....................................................................... 66
Label ............................................................................. 66
GDL 69/69A FIS Forecast Menu Page 3 .......................... 66
Flight Plan ..................................................................... 67
Legend .......................................................................... 67
Map Detail .................................................................... 67
Map Orientation............................................................ 67
Text ..................................................................................... 68
Selecting Categories and Messages ............................... 68
Sorting METAR, TAF, and TFR Text Messages .................. 69
View.............................................................................. 69
Temporary Flight Restrictions (TFRs)................................ 69
Status.................................................................................. 70
Product Status ............................................................... 70
Diagnostics.................................................................... 70
Activation...................................................................... 71
Activating XM Radio Services............................................... 71
Gather Information........................................................ 71
XM Satellite Radio Activation ....................................... 72
Lightning Strikes (LT) Function .....................................................73
Lightning Menu Page 1 ....................................................... 73
Flight Plan ........................................................................... 73
Display View (360/120) ....................................................... 73
Lightning............................................................................. 73
Strike............................................................................. 74
Cell ............................................................................... 74
Heading Stabilization........................................................... 74
System Data........................................................................ 74
Lightning Menu Page 2 ....................................................... 74
Demo.................................................................................. 74
Self-Test .............................................................................. 74
Noise Monitor ..................................................................... 75
Strike Test............................................................................ 75
Antenna Change Message .................................................. 75
FliteChart (CHART) Function (Optional)........................................76
Data Card...................................................................... 76
FliteChart Function.............................................................. 76
Menu Items......................................................................... 78
Search ID....................................................................... 78
Select Airport ................................................................ 79
Select Chart................................................................... 79
ChartView (CHART) Function (Optional).......................................80
Overview............................................................................. 80
Chart Data Source............................................................... 81
Data Card...................................................................... 81
Chart Geo-Referencing ................................................. 81
Hot Spots ...................................................................... 81
Chart Overlay in the Custom/IFR Map.................................. 81

ix190-00607-02 Rev C
Introduction
Selecting the Airport...................................................... 81
Loading the Approach Chart.......................................... 82
Viewing the Chart as an Overlay.......................................... 83
Display of Coverage Area............................................... 83
Chart Zooming .............................................................. 83
Chart Panning ............................................................... 83
Chart Orientation .......................................................... 83
Chart Info...................................................................... 83
ChartView Function............................................................. 84
Menu Items......................................................................... 85
Search ID....................................................................... 85
Select Airport ................................................................ 86
Select Chart................................................................... 86
View Loaded ................................................................. 86
Load to Map.................................................................. 86
Airport Surface Charts......................................................... 87
Viewing Surface Charts ................................................. 87
Operational Considerations ................................................. 88
When to Load a Chart ................................................... 88
Flying an Approach........................................................ 88
Approach to Surface Map Transitions............................. 88
Chart NOTAMS.............................................................. 88
Important System Limitations......................................... 88
Invert Option ................................................................. 88
Hot Spots ...................................................................... 88
Typical Operational Scenario ................................................ 89
Typical Taxi Scenario....................................................... 89
Typical Take Off Scenario................................................ 89
Typical Approach Scenario ............................................. 89
Typical Landing Scenario ................................................ 89
Radar (RADAR) Function...............................................................90
Off Mode ...................................................................... 90
Standby/On Mode ........................................................ 90
Test Mode .................................................................... 91
Weather Mode ............................................................. 91
MAP Mode.................................................................... 91
Manual Gain (GWX 68 only).......................................... 91
Horizontal Mode ........................................................... 92
Vertical Mode (GWX 68 and ART2000/2100 only) ......... 92
Range Control ............................................................... 92
Tilt Control .................................................................... 92
Bearing Control (GWX 68/ART2000/2100 only) ............. 92
Gain Control.................................................................. 93
Hold Control.................................................................. 93
Cursor Pre-Select Operation (GWX 68 and ART2000/2100 only)
..................................................................................... 93
Sector Scan (GWX 68 only)............................................ 94
Radar Alert (GWX 68 only) ............................................ 94
Radar Setup Page................................................................ 94
Stabilization (STAB)........................................................ 94
Target Alert (GWX 68 only)............................................ 94
Garmin GWX 68 Radar Description ..................................... 97
Principles of Pulsed Airborne Weather Radar.................. 97
Radar Signal Attenuation............................................... 98
Radar Signal Reflectivity....................................................... 99
Precipitation .................................................................. 99
Ground Returns............................................................. 99
Angle of Incidence....................................................... 100
Operating DISTANCE ......................................................... 100
MAXIMUM PERMISSIBLE EXPOSURE LEVEL (MPEL) ............ 100
Antenna Tilt Setup at Cruise Altitude ................................ 101
Weather Mapping and Interpretation ................................ 102
Weather display Interpretation..................................... 102
Thunderstorms ............................................................ 102
Tornadoes.................................................................... 104
Hail ............................................................................. 104
XM Satellite Radio (XM) Function ..............................................105
Menu Page 1..................................................................... 106
Radio ID ...................................................................... 106
Save Preset .................................................................. 107
Last Channel ............................................................... 107
Menu Pages 2-4................................................................ 107
Volume ............................................................................. 108
Mute ........................................................................... 108
Channels........................................................................... 108
Categories......................................................................... 109
Direct Access..................................................................... 109
Activating XM Satellite Radio Services................................ 110
Gather Information...................................................... 110
XM Advisory Messages...................................................... 111
System (SYS) Function ................................................................112
System Nav Pages.............................................................. 112
Ownship Symbol ........................................................ 112
Lat/Lon Format ............................................................ 112
Set Baro Correction Units (Pressure Altitude Source only)112
Set Baro Correction (Pressure Altitude Source only) ...... 112
Display Latitude/Longitude Lines ................................. 112
Initial En Route Zoom Scale, Initial Ground Zoom Scale, and
Transition Speed..................................................... 113
Slave Zoom to GPS Zoom ............................................ 113
AutoLoad Electronic Charts.......................................... 114
Altitude Units .............................................................. 114
Map Detail .................................................................. 114
System Info Pages ............................................................. 114
System Information ..................................................... 114
Feature Information ..................................................... 115
Table of Contents

x 190-00607-02 Rev C
Introduction
Hardware Information ................................................. 115
Port Status................................................................... 115
Data Link Status ......................................................... 115
System Test Pages.............................................................. 115
Test Pattern 1 .............................................................. 116
Red, Green, Blue, White, and Black Test Patterns ......... 116
Test Pattern 2 .............................................................. 116
Troubleshooting..........................................................................117
GDL 69/69A FIS Legends ............................................................119
Sample GDL 69/69A FIS Displays................................................120
Specifications .............................................................................121
Physical Specifications ....................................................... 121
Power ............................................................................... 121
Environmental................................................................... 121
Care Information ........................................................................122
Cleaning the Unit.............................................................. 122
Contacting the Factory...................................................... 122
Glossary......................................................................................123
Abbreviations .............................................................................124
License and Registration Information........................................127
Contacting the Factory ..............................................................127
Software License Agreement ............................................. 127
Product Registration and Support...................................... 127
Limited Warranty ........................................................................128
Index...........................................................................................129

1190-00607-02 Rev C
Getting Started
GETTING STARTED
This section explains how to get started using the
GMX 200. Information in this section describes the
controls, data card, display, and basic operation. After
reading this section, go to the Detailed Operation sec-
tion for expanded explanations for each feature.
Functions
The GMX 200 contains fourteen major separate
functions for the display of information. The func-
tion names are shown as “smart” keys at the bottom
of the display. The “smart” key is the combination of a
label above a triangle key at the bottom of the display.
The labels above the triangle keys change to reflect
the choices available to you for each function. Press
the FN key to show the available functions. Press
the “smart” key below the function label to go to the
desired function. While in each function, press the
MENU/ENT key to show the options for each func-
tion. The options are shown on the right side of the
display. Press the Menu Item key to manipulate the
options. Some options toggle on/off, while some are
tri-state (three choices) and others cycle through a
series of choices.
GMX 200 Function List
• MSG - Message Log
• MAP - Custom Map
• IFR - IFR Chart
• VFR - VFR Chart
• Split - Split Screen
• Traffic - TAS/TCAD/IHAS
• Traffic - ADS-B TRAF
• Traffic - TIS-A
• FPL - Flight Plan
• TER - Internal/TAWS Terrain
• FIS-B - Flight Information Service
(GDL 90 UAT)
• FIS - Flight Information Service
(GDL 69/69A)
• XM - XM Satellite Radio
• LT - Lightning Strikes
• CHART - FliteChart or ChartView
• RADAR - Weather Radar
• SYS - System Information
Functions

2 190-00607-02 Rev C
Getting Started
The Message Log displays information from the GMX 200 or reported to the GMX 200 by its external sen-
sors. A flashing MSG annunciator notifies you of a new message that should be viewed.
The Custom Map function allows you to completely customize the displayed map by overlaying selected
information. The Custom Map can become cluttered if you choose every option, so use discretion.
The IFR Chart function provides an IFR en route style map on the display.
The VFR Chart function provides a VFR sectional style map on the display.
The Split Screen function allows up to two of the other functions to be displayed side by side and an optional
vertical profile across the bottom of the display. The terrain and profile features are not available if altitude data is
not available or if a TAWS sensor is connected to the GMX 200.
The Traffic function (when installed) shows nearby traffic and details about each target.
The Flight Plan function provides details about your flight plan and each waypoint.
The Terrain function shows a color coded map of terrain elevation in relation to your altitude. An altitude
sensor or TAWS sensor is required to provide altitude data.
The Flight Information Services (FIS) function is capable of displaying text and graphic weather informa-
tion with GDL 90 UAT- and GDL 69/69A installations. A subscription for the services is required with the GDL
69/69A,
The Lightning (LT) function, when connected to the L3 WX500 Stormscope, displays lightning strike infor-
mation.
The Chart feature provides the capability to view Garmin FliteChart or Jeppesen Sanderson Inc. electronic
charts. Garmin’s FliteChart shows approach charts. Jeppesen Sanderson’s ChartView provides approach charts and
airport surface charts.
The XM function allows the reception of XM Satellite Radio entertainment broadcasts when the GDL 69A is
installed and a subscription to the XM Radio service is activated.
The Radar Function allows weather radar from the Garmin GWX 68, ART2000, ART2100, RS 811A, or RS
181A to be displayed.
The System Information function lets you set general preferences, show software version information, and test
the display.
Functions

3190-00607-02 Rev C
Getting Started
Display
The GMX 200 display provides text and graphic information to give a “picture” of your flight and surround-
ings. The display brightness may be set manually or allowed to automatically adjust to ambient light conditions.
At the bottom of the display, labels above the function keys change to show the different choices for each function
to allow access to commonly used actions. A typical Custom Map function display is shown below.
Controls
Message Flag
The Message flag will appear on the
lower left side of the display when a
new message is posted. Go to the Mes-
sage function to view the information
about the operation or status of the
GMX 200.

4 190-00607-02 Rev C
Getting Started
Controls
Power On
The power switch is located in the upper right
corner of the GMX 200. Press the “+” rocker switch
to turn the power on. The GMX 200 will progress
through a series of startup screens. The final startup
screen shows System Information and the results of
the Self-Test.
Power
The power and display brightness are controlled by a
rocker switch.
Power Rocker Switch
Press both the “-” and “+” rocker switches and hold
them down for at least three seconds to turn the power
off.
Brightness
Press the “-” and “+” rocker switches individually
to adjust the display brightness manually. Press the
“-” and “+” rocker switches at the same time for one
to three seconds, then release them to have the GMX
200 set the brightness automatically based on current
lighting conditions.
Rotary Knob
The rotary knob on the lower right corner of the
GMX 200 is used to move the cursor in Pan mode and
to zoom in and out while viewing maps. The rotary
knob complements the action of the function keys
in some functions by pressing and turning the knob.
Arrows will appear above the function keys indicat-
ing the direction to turn the rotary knob for the same
effect. A round push button symbol (“o”) will appear
indicating that pressing the rotary knob will have the
same effect.
Data Card
Rotary Knob Rotary Knob / Function Keys
Arrows indicate rotary
knob direction
Round push-button sym-
bol indicates the function
affected when the rotary
knob is depressed
Function (FN) Key
The Function keys are made up of one dedicated
key on the lower left side of the display and the four
“smart” keys to the right of it. Press the function (FN)
key repeatedly to scroll through the available func-
tions. The functions will appear above the “smart”
function keys in turquoise.
“Smart” Function Keys
“Smart” Function Key Labels
Function Keys
Use the FN key to display a list of the main func-
tions, such as Map, IFR, Terrain, etc. Each time you
press the FN key you will step through the list of func-
tions. After you press one of the function “smart” keys
at the bottom of the display, the function keys change
to provide options to control the display related to the
current function, now in green. Change the function
keys back to the function list by pressing the FN key.

5190-00607-02 Rev C
Getting Started
Display
MENU/ENT
The MENU/ENT key is located on the bottom right
corner of the GMX 200. Press the MENU/ENT key to
show a menu of options to modify the display of the
current function. Press the MENU/ENT key to hide the
menu. If no action is taken, the menu will automati-
cally extinguish in 20 seconds.
MENU/ENT Key
Menu Item
The Menu Item keys are on the right side of the
GMX 200. Press the MENU/ENT key to see the options
for the current function. Press the Menu Item key
next to each option to scroll through the choices for
each option. Some options support tri-state or multiple
choices, such as in Map mode. When you select a tri-
state option, the option label will change with each key
press between filled cyan (active), filled white (interme-
diate), and black (inactive).
Menu Item Key Layout
Menu
Item
Labels
Menu
Item
Keys
Data Card
The Map databases and other information are
stored on a data card. The use of a data card allows
you to easily update information.
Only change the data card when the power is
turned off.
Only Garmin-approved datacards can be used.
Data Card and Slot
Handle your data card carefully. Do not touch the
connector edge of the data card. To eject the card,
press the card in until it “clicks” and then pull the card
straight out of the slot. Insert a data card by pushing
the card straight into the slot until it “clicks.” When
fully inserted, the data card will be flush and slightly
recessed into the bezel.
When contacting your dealer or the Garmin
customer service department, eject the data card and
write down the information shown on the label.

6 190-00607-02 Rev C
Getting Started
Annunciations
Advisory flags, data flags, and messages appear on
the display to give information about the status of the
GMX 200 or to provide operating information.
Advisory Flags
Annunciations will appear on the upper left side
of the display to provide advisories for Traffic, Terrain,
and Lightning. Advisory information is monitored and
displayed regardless of the selected function. Advisory
flags will flash for approximately 10 seconds when
they first appear and then turn solid while they are still
valid. Advisory icons will reduce in size if more than
two advisory conditions exist.
Advisory Flags
ADS-B Traffic
The Traffic advisory flag will appear on the left side
of the display when the GDL 90 reports a traffic alert.
This Traffic advisory is only available when the ADS-B
system with a UAT data link is installed and opera-
tional. Refer to the TIS Traffic section for a description
of TIS-A and TIS-B.
TAS/TCAD/TIS-A Traffic
The Traffic Advisory/Alert will appear in amber
on the left side of the display when the traffic sensor
indicates an alerting condition. Refer to the TIS Traffic
section for a description of TIS-A and TIS-B.
Radar
The Radar Alert flag will appear when Target Alerts
are present on two consecutive sweeps within 10° of
your heading.
Terrain
The Terrain advisory flag will appear on the left
side of the display when the terrain surface or obstacle
altitude is within approximately 100 feet of your alti-
tude and within approximately two minutes of flight
in any direction.
Lightning
The Lightning advisory flag will show on the left
side of the display when the WX500 sends an indica-
tion that lightning has been detected within 50 NM of
your location. See the WX500 manual for details about
range and other capabilities.
Data Flags
Data flags appear on the left side of the display to
notify you when there is a loss of reported informa-
tion. The data usually displayed, such as lightning or
nearby terrain, may still exist, but may not be displayed
for technical reasons. For instance, when the amber
TRAF data flag appears it means that the GMX 200 is
not receiving Traffic information from the sensor. Any
existing traffic will not be displayed on the GMX 200.
All data flags are yellow unless otherwise indicated.
ADS-B Status Annunciation
When the GMX 200 Code Edit option is
enabled, an annunciation will appear in the
top left portion of the display to indicate the
Flight ID broadcast status and the current ADS-B code.
The top half will indicate the operation being used:
Broadcast FID (FID), Broadcast VFR (VFR), or Stand-By
(STBY). The bottom half will show the transponder code
that is being used. When a ADS-B code has not been
selected, the code in the bottom half will be replaced by
dashes.
Annunciations

7190-00607-02 Rev C
Getting Started
Annunciations
Data Flag Description
No valid position information is available from the source. Do not expect a valid position
representation on the maps.
No valid route (flight plan) is available from the external navigation source. Route (flight
plan) information will not be shown on the maps.
No valid altitude information is available from the external source. Altitude related func-
tions will not operate, such as terrain awareness.
No traffic information is received from the optional traffic sensor. Traffic will not be
displayed.
The GPS receiver in the GDL 90 UAT is not reporting a valid position. ADS-B broadcast
will not include a valid position report.
No valid lightning detection information is being received from the optional Stormscope
sensor. Strike and cell information will not be displayed.
Terrain coverage is not available for some part of the terrain advisory coverage area.
Terrain advisories may not be provided.
When connected to the SL30, indicates the SL30 is not available or valid. ILS, OBS, and
VORs will not be highlighted.
Indicates that radar status information is not available from the optional external radar
transmitter head. Radar related functionality may not be available.
(Green)
Indicates that the radar is ON and transmitting RF energy. Appropriate precautions
should be taken.
(Green Flashing)
Indicates that the radar is in Hold and is transmitting RF energy. Appropriate precau-
tions should be taken.
(Green)
Displayed when the GDL 90 is in Ident mode.
No valid terrain information is available from the optional external source.
No valid data link information is available from the optional external source.
All data flags are yellow, except as noted.

8 190-00607-02 Rev C
Getting Started
Data Flags
Basic Operation
Use the following items to get a basic feel for the
operation of the GMX 200. The basic steps for using
any of the separate functions of the GMX 200 are:
• Turn the power on.
• Adjust the brightness or leave in automatic
mode.
• Check that all tests pass on the Start Up
screen.
• Press the FN key to view available functions.
Each press of the FN key will step through
the lists of functions.
• Press the key below the function label to
select the desired function.
• Confirm or enter the current barometric pres-
sure (if prompted).
• Press the MENU/ENT key to display available
options.
• Press the Menu Item key next to the dis-
played option to choose desired capabili-
ties. Some options use multiple key presses
for different states for the option. Press the
MENU/ENT key again to extinguish the
option display.
• Refer to the Detailed Operation section for
more details on each function.
Start Up Screen
The Start Up screen is displayed while the
GMX 200 goes through its initialization and testing
routines. System information is shown that provides
the GMX 200 software, hardware, and database ver-
sions. The results of the self test are shown. A check
mark shows that the test passed. If any of the Self-Tests
fail (red “x”), contact your dealer or the factory.
Start Up Screen After Passing Tests.
Hardware version will vary depending on the
configuration you have.
