1
Installing the Batteries
The Rino operates on three “AA” batteries (not
included), which are located in the back of the unit.
Rechargeable Alkaline, NiM , NiCad or Lithium batteries
(see Reference Manual for setting battery type) may also be
used. Stored data will not be lost when
the batteries are removed.
To install batteries:
1. Remove the battery cover on the back of the unit.
Turn the D-ring 1/4 turn counter-clockwise & pull
away clockwise.
. Insert batteries observing the polarity. A polarity
reference can be found moulded in the unit housing.
The negative (-) battery terminal always orients clos-
est to the spring.
3. Reinstall the battery cover by inserting the bottom
hinge clip and closing the cover. Turn the D-ring 1/4
turn clockwise.
Important Note:
When replacing batteries, use only
new or fully recharged batteries
and do not mix Alkaline, NiMH,
NiCad or Lithium batteries
Rechargeable batteries may
typically display less capacity
than Alkaline batteries
Remove the batteries from the
unit if you don’t plan to use it
for several months
Follow the battery manufactur-
er’s instructions for proper care
and disposal of used batteries
Extensive use of backlighting
and/or WAAS will signifi cantly
reduce battery life
Quick Start
Battery
Installation
190-00259-01_0B.indd 1 9/19/2002, 3:15:21 PM

Quick Start
Unit Overview
PAGE/QUIT button:
• Press to cycle through main pages.
• Used to quit or escape menu items.
POWER button:
• Press and hold to turn the unit On/Off.
• Press to adjust contrast and backlighting
CALL button:
• Press to send out Call Tone.
• Will send position when released (if enabled).
TALK button:
• Press and hold to talk.
• Will send position when released (if enabled).
VOLUME (V) button:
• Press to pop up volume control.
ZOOM/MAP (Z) button:
• From Map Page, press to pop up Zoom control.
• From any other page, press to display Map Page
and press again to pop up Zoom control.
MICROPHONE:
• old unit 3-4 inches away when talking.
LCD DISPLAY
CLICK STICKTM
• Press in to enter highlighted
options and to confi rm messages.
• Move Up/Down or Right/Left to move through
lists, highlight fi elds, on-screen buttons, icons,
enter data or move the map panning arrow.
• Press in and hold to display Shortcut Menu.
SPEAKER
190-00259-01_0B.indd 2 9/19/2002, 3:15:35 PM

3
2-WAY FRS/GMRS ANTENNA
HEADSET CONNECTOR WEATHERCAP
EXTERNAL POWER AND
DATA CONNECTOR WEATHERCAP
GPS ANTENNA
BATTERY COMPARTMENT COVER
BELT CLIP CONNECTOR MOUNT
BATTERY COMPARTMENT D-RING
MOUNT ALIGNMENT NOTCHES
Unit Overview
Quick Start
190-00259-01_0B.indd 3 9/19/2002, 3:15:41 PM

4
Quick Start
Display Backlighting and Contrast Set Up
If lighting conditions make it hard for you to see the
display screen, you can adjust the contrast or turn on the
backlight.
To turn on the backlighting:
1. Briefly press and release the POWER button from
any page on the unit to display the Backlight and
Contrast adjustment. Press either the POWER
button or Up or Down on the LI K STI K to turn
the Backlight either On or Off. The backlight will
remain on until the set timeout period is completed
or the POWER button is pressed again.
The unit is factory set to timeout 15 seconds after
the last button press. A light bulb symbol will
appear on the top Status Bar when the backlight is
On.
To adjust the screen contrast:
1. Briefly press and release the POWER button from
any page on the unit to display the Backlight and
Contrast adjustment. Move the LI K STI K to Left
(Lighter) or Right (Darker) to adjust the contrast.
Backlighting
and
ontrast
Backlight/Contrast
Adjustment Window
Backlight On/Off Contrast Adjustment
Backlight ‘On’ symbol
