Garmin FUSION SIGNATURE Series User manual

SIGNATURE SERIES SUBWOOFER
INSTALLATION INSTRUCTIONS
Important Safety Information
WARNING
See the Important Safety and Product Information guide in the product box for product warnings and other
important information.
This device must be installed according to these instructions.
Disconnect the vessel's power supply before beginning to install this device.
CAUTION
Continuous exposure to sound pressure levels over 100dBA may cause permanent hearing loss. The volume
is typically too loud if you cannot hear people speaking around you. Limit the amount of time you listen at high
volume. If you experience ringing in your ears or muffled speech, stop listening and have your hearing checked.
To avoid possible personal injury, always wear safety goggles, ear protection, and a dust mask when drilling,
cutting, or sanding.
NOTICE
When drilling or cutting, always check what is on the opposite side of the surface to avoid damaging the vessel.
It is strongly recommended that you have your audio system installed by a professional installer to ensure
optimum performance.
You must read all installation instructions before beginning the installation. If you experience difficulty during
the installation, go to support.garmin.com for product support.
After installing an audio system, you should run the connected speakers and subwoofers at low to medium
volumes for the first few hours of use. This helps to improve the overall sound by gradually loosening up the
moving components of new speakers and subwoofers, such as the cone, spider, and surround.
GUID-D5444697-CFDC-4F43-AEA4-6835F0527D82 v2May 2022

Tools Needed
• Electric drill
• Drill bit (size varies based on surface material)
• Appropriate saw or utility knife to cut surface material
• Phillips screwdriver
• Wire strippers
• 12 AWG (3 through 4mm2) or larger marine-grade, fully-tinned copper speaker wire
You can purchase this wire from your Fusion® or Garmin® dealer:
◦010-12898-00: 7.62m (25ft.)
◦010-12898-10: 15.24m (50ft.)
◦010-12898-20: 100m (328 ft.)
• Solder and water-tight heat shrink tubing or water-tight, heat-shrink, butt-splice connectors (optional)
• Marine sealant (optional)
NOTE: For customized installations, additional tools and materials may be needed.
Mounting Considerations
NOTICE
When mounting the subwoofer in an area exposed to weather or water, you must mount the subwoofer on a
vertical surface. If you mount the subwoofer on a horizontal surface facing up, water can gather in and around
the subwoofer, causing damage over time.
If you intend to mount the subwoofer outside the boat, you must mount it in a location well above the waterline,
where it is not submerged or damaged by docks, pilings, or other pieces of equipment. When mounted correctly,
this subwoofer is rated for protection from the front of the speaker. Water exposure and damage to the rear
of the subwoofer voids the warranty. This includes situations when the subwoofer is mounted in a sealed
enclosure, especially if it is exposed to wash down. Using an enclosure with a port or vent exposed to the
outside environment may allow water to collect and damage the subwoofer.
You must turn off the audio system before making any connections to the source unit, amplifier, or speakers.
Failure to do so could result in permanent damage to the audio system.
You should protect all terminals and connections from grounding and from each other. Failure to do so could
result in permanent damage to the audio system and void the product warranty.
When selecting a mounting location for the subwoofer, observe these considerations:
• You must select mounting locations that provide sufficient clearance for the mounting depth of the
subwoofer as specified in the product specifications.
• You should select a flat mounting surface for the best seal.
• You should select a location where the surface material is thick enough to support the weight of the
subwoofer. It's important to note that when in use, the subwoofer exerts a pushing and pulling effect on the
surface, so if the material is thin, it can result in excess vibration and negatively affect the sound quality.
• You should protect the speaker wires from sharp objects and always use rubber grommets when wiring
through panels.
• To avoid interference with a magnetic compass, you should not mount the subwoofer closer to a compass
than the compass-safe distance value listed in the product specifications.
Selecting the correct mounting location optimizes the performance of the subwoofer. Fusion speakers are
designed to perform in the widest possible range of mounting locations, but the more you plan the installation,
the better the speakers' sound will be. For more information on subwoofer placement and specifications, go to
garmin.com/manuals/speaker_placement.
2

Mounting the Subwoofer
Before mounting the subwoofer, you must choose a location following the guidelines above.
1Trim the template and make sure it fits in the selected location.
2Orient the template so the Fusion logo is level.
3Secure the template to the selected location.
4Using a jigsaw or rotary tool, cut the mounting surface along the inside of the line on the template.
5Place the subwoofer in the cutout to test the fit.
6If necessary, use a file and sandpaper to refine the size of the cutout.
7After the subwoofer fits correctly in the cutout, ensure the mounting holes on the subwoofer line up with the
pilot holes on the template.
8If the mounting holes do not line up, mark the new hole locations.
9Using an appropriately sized drill bit for the mounting surface and screw type, drill the holes.
NOTICE
Do not drill the pilot holes through the holes on the subwoofer. Drilling through the subwoofer may damage
it.
10 Remove the template from the mounting surface.
11 Route speaker wire (not included) from the source to the subwoofer location (Speaker Wiring, page4).
NOTE: Avoid routing the speaker wire near sources of electrical interference.
12 For LED models, route the appropriate wire from the speaker location to the location of the LED controller or
the battery (LED Wiring, page4).
13 Connect the speaker wires to the included wiring harness while observing polarity.
14 For LED models, connect the LED wires to the included wiring harness.
15 Connect the wiring harnesses to the appropriate connectors on the subwoofer.
16 Place the subwoofer in the cutout.
17 Secure the subwoofer to the mounting surface using the included screws.
NOTE: Some versions of the sports model subwoofer include plastic washers you should install on the
screws to protect the paint.
NOTE: Do not over tighten the screws, especially if the mounting surface is not flat.
For a Classic model subwoofer, attach the grille (Attaching the Grille to the Classic Model Subwoofer, page4).
3

Attaching the Grille to the Classic Model Subwoofer
NOTE: This feature is available only on the Classic model subwoofer.
1With the subwoofer mounted, hold the grille with the Fusion logo at the bottom, at the 6 o'clock position.
2Turn the grille counter-clockwise about 10°, so the Fusion logo is at the 5 o'clock position.
3Place the grille on the rim of the subwoofer.
4Twist the grille clockwise to secure it.
Speaker Wiring
When connecting the subwoofer to your amplifier, observe these considerations.
• The wires on the speaker are terminated using a connector, and you should use the provided wiring harness
when connecting the speaker wires to the amplifier.
• Speaker wire is not included. You should use 12 AWG (3 through 4mm2) or larger speaker wire to connect
the wiring harness to the amplifier.
• You should use a water-tight connection method when connecting speaker wire to the wiring harness.
You can use this table to identify the polarity of the wires on the provided harness.
Lead color Polarity
White Positive (+)
White with a black stripe Negative (-)
LED Wiring
NOTICE
Using certain LED colors on the speakers, such as red and green, may violate the laws, regulations, and
standards related to the use and/or operation of marine navigation lights. It is the user's responsibility to
comply with any such applicable laws, regulations, and standards. Garmin is not responsible for any fines,
penalties, citations, or damages that may be incurred due to any such lack of compliance.
It is recommended to install a Fusion CRGBW Wireless Remote Control module with this speaker to turn the
LEDs on and off, change the colors, and create lighting effects. See your Fusion dealer or garmin.com for more
information.
The LED wires on the speaker are terminated using a connector, and you should use the provided wiring harness
when connecting the LED wires to a CRGBW Wireless Remote Control module or power source.
NOTE: LEDs are not available on all models.
4

Connecting the LED Wires Directly
If you do not install the recommended remote control, you can set the static color of the LEDs by connecting
the color LED wires from the harness to the negative (-) terminal of a 12Vdc power source. You can splice the
negative (-) wire to multiple LED wires to customize the LED color and tone. You must connect the black LED
wire from the harness to the positive (+) terminal of the same power source to complete the circuit.
The LED wires on the subwoofer are terminated using a connector, and you should use the provided harness
when connecting the LED wires directly to power.
You should use 20AWG (0.5 through 0.75mm2) or thicker wire to connect the LED wires from the harness to
the battery.
You must connect the positive (+) wire (black) for all of the speaker LEDs through a 3A fuse near the
power-source. You should also connect the positive (+) power wire to the power source through an isolator
switch or circuit breaker to turn the LEDs on and off. You can use the same isolator or circuit breaker controlling
the power supply to your stereo, which allows you to turn the LEDs and the stereo on and off at the same time.
You should use a water-tight connection method when connecting wire to the LED wiring harness.
1Connect the black wire on the LED harness to the positive (+) terminal of the power source .
NOTICE
To avoid damage to the speakers or the vessel, you must connect this wire through a 3A fuse near the
power source.
2Connect the negative (-) wire from the same power source to one or more color wires on the LED harness
according to the preferred LED color.
NOTICE
You must insulate any unused LED wires on the harness to avoid causing a short circuit.
LED Color LED Harness Wire Color
Red Red
Green Green
Blue Blue
Yellow Red and green
Magenta Red and blue
Cyan Blue and green
Cool white Turquoise
Warm white Yellow
NOTE: You can connect the cool white or warm white wire to change the tone of any LED color combination.
3Connect the harness to the speaker.
5

Wire Strain Relief
NOTICE
Failure to secure the wiring-harness connections can damage the speaker.
The wires connected to the speaker and the included wiring harness use Amphenol™ AT Series™ connectors, and
these connectors must be secured during installation to provide strain relief for the internal wire connections to
the speaker. You can secure these connections using various methods.
• You can use cable ties or other third-party fastening devices to secure the connection to an appropriate
location.
• You can use the various Amphenol A Series™ clips produced by Amphenol to secure the connection. You can
check with your local electronics or marine dealer, or go to the Amphenol-Sine website for more information.
Speaker Information
True-Marine™Products
True-Marine products are subjected to rigorous environmental testing under harsh marine conditions to surpass
industry guidelines for marine products.
Any product that bears the True-Marine stamp of assurance has been designed for simplicity of use and
combines advanced marine technologies to deliver an industry leading entertainment experience. All True-
Marine products are supported by the Fusion 3-year worldwide limited consumer warranty.
Cleaning the Subwoofer
NOTICE
Do not use harsh or solvent-based cleaners on the subwoofer. Using such cleaners may damage the product
and void the warranty.
When mounted correctly, this subwoofer is rated IP65 for protection in the harsh marine environment from the
front of the subwoofer. The subwoofer is not designed to withstand high pressure water spray, which may occur
when you wash down your vessel. Failure to carefully spray-clean the vessel may damage the product and void
the warranty.
1Clean all salt water and salt residue from the grille with a damp cloth soaked in fresh water.
2Use a mild detergent to remove a heavy buildup of salt or stains.
6

Specifications
10" Subwoofer
Max. power 600W
RMS power 300W
Frequency response From 30Hz to 2kHz
Sensitivity (1W/1m) 86dB
Impedance 4ohms
Nominal voice coil diameter 50mm
Min. mounting depth (clearance) 133mm (51/4in.)
Mounting diameter (clearance) 223mm (813/16in.)
Amplifier power-rating recommendation 50 to 400W RMS, playing music
Compass-safe distance 520cm (205in.)
12" Subwoofer
Max. power 1400W
RMS power 700W
Frequency response From 20Hz to 2kHz
Sensitivity (1W/1m) 86dB
Impedance 4ohms
Nominal voice coil diameter 100mm
Amplifier power-rating recommendation 200 to 1000W RMS, playing music
Min. mounting depth (clearance) 207mm (85/32in.)
Mounting diameter (clearance) 306mm (123/64in.)
Grille height from surface 50mm (2in.)
Compass-safe distance 460 cm (181in.)
All Models
LED Supply Voltage (LED models only) From 10.8 to 16 Vdc
LED Load Current at 14.4Vdc (max.) (LED models only) 300mA
Operating temperature range From 0 to 50°C (from 32 to 122°F)
Storage temperature range From -20 to 70°C (from -4 to 158°F)
Cone material Polypropylene cone with Santoprene rubber surround
Ingress protection rating IEC60529 IP651
Wiring harness connector type Audio: Amphenol AT Series ATP 2-way
LED: Amphenol AT Series AT 6-way
1 Protected from dust and water ingress.
7

Dimension Drawings
Side View
Measurement 10" Subwoofer 12" Subwoofer
130mm (51/8in.) 204mm (81/16in.)
220mm (821/32in.) 303mm (1115/16in.)
A Sports model subwoofer is shown, but the dimensions are the same for the Classic model.
8

Front View
Measurement 10" Subwoofer 12" Subwoofer
275mm (1013/16in.) 356mm (14in.)
247mm (93/4in.) 325mm (1213/16in.)
A Sports model subwoofer is shown, but the dimensions are the same for the Classic model.
Optimum Enclosure Recommendations
Specification 10" Subwoofer 12" Subwoofer
Sealed enclosure volume127L (0.95ft.3) ≥ 60L (2.12ft.3)
Ported (vented) enclosure volume245L (1.6ft.)3) 250L (8.83ft.)3)
Port diameter 104mm (4.1in.) 101.6mm (4in.)
Port length 265mm (107/16in.) 127mm (5in.)
1 Fully filled with absorption material.
2 Lined with absorption material.
9

物質宣言
部件名称 有毒有害物质或元素
铅 汞 镉 六价铬 多溴联苯 多溴二苯醚
塑料件
磁钢
金属连接件
金属结构件（T铁甲板）
电线
PC 混纺软件
本表格依据 SJ/T11364 的规定编制。
: 代表此种部件的所有均质材料中所含的该种有害物质均低于
(GB/T26572) 规定的限量
: 代表此种部件所用的均质材料中, 至少有一类材料其所含的有害物质高于
(GB/T26572) 规定的限量
* 该产品说明书应提供在环保使用期限和特殊标记的部分详细讲解产品的担保使用条件。
产品
連絡地址
委製銷售:台灣國際航電股份有限公司
聯絡地址:新北市汐止區樟樹二路 68 號
電 話:[phone]
客服專線:[phone]
© 2022 Garmin Ltd. or its subsidiaries
Garmin®, the Garmin logo, Fusion®, the Fusion logo, and True-Marine™ are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. These
trademarks may not be used without the express permission of Garmin.
Amphenol™ and Amphenol AT Series™ are trademarks of Amphenol Sine Systems. CURV® is a registered trademark of Propex Furnishing Solutions.
© 2022 Garmin Ltd. or its subsidiaries support.garmin.com
