Nissindo WS-310 User manual

MANUAL
w w w . N i s s i n d o U S A . c o m
Congratulation &
Thank You for
Purchasing
Nissindo
Products!
WS-8215
(High Grade)
WS-6215
(Standard Grade)
WS-310
WS-310A
WS-312
WS-312A
Full Range Passive/Non-Powered
WS-310 10-inch WOOFER
WS-312 12-inch WOOFER
Full Range Active/Powered
WS-310A 10-inch WOOFER
WS-312A 12-inch WOOFER
OPERATING INSTRUCTIONS
Full Range Large Format
STANDARD GRADE FORMAT UNIT
WS-6215 Dual 15-inch WOOFER
WS-8215 Dual 15-inch WOOFER
HIGH GRADE PERFORMANCE UNIT

CONTENTS
INTRODUCTION............................................................................................................................................... 3
SYSTEM FEATURES........................................................................................................................................... 3
SAFETY INSTRUCTIONS.............................................................................................................................4~5
SYSTEM APPLICATIONS..................................................................................................................................6
• 2-way Full Range Passive/Non-Powered Speaker System Functioning...............................................7
• 2-way Full Range Active/Powered Speaker System Functioning........................................................... 8
• High Portability and High Power........................................................................................................................9
• 2-way Full Range Large format Speaker System Functioning................................................................10
• Speaker Connection.............................................................................................................................................11
• Multi-function Connection................................................................................................................................... 11
CONTROLS AND FUNCTIONS....................................................................................................................12
• Rear Panel Features. for WS-310/WS-312.................................................................................................. 12
• Rear Panel Features. for WS-310A/WS-312A............................................................................................12
• Rear Panel Features. for WS-6215...................................................................................................................13
• Rear Panel Features. for WS-8215...................................................................................................................13
SYSTEM SETUP GUIDELINES........................................................................................................................14
• Installation Setup for WS-310/WS-310A/WS-312/WS-312A..................................................14~16
• Installation Setup for WS-8215........................................................................................................................ 17
• Parts for Maintenance (WS-6215 & WS-8215)........................................................................................ 18
PHYSICAL DIMENSIONS........................................................................................................................19~20
SPECIFICATIONS............................................................................................................................................ 20
BLOCK DIAGRAM and SOUND RANGE COVERAGE for WS-6215 & WS-8215........................... 21
TROUBLESHOOTING..............................................................................................................................22~23
FINAL WORDS TO USER.............................................................................................................................. 23
WARRANTY.....................................................................................................................................................24
AGENCY REGULATORY NOTICES..............................................................................................................25
CONTACT INFORMATION...........................................................................................................................26
2
Safety
Applications
Set Up
Speaker
Features
Intro
Spec
Dimensions
Warranty
Final Words
Notices
Contact Us
Troubleshooting
Diagram

3
Intro
INTRODUCTION
Nissindo, which is registered with the U.S. Patent and
Trademark Office, is one of the most famous brand names
for Karaoke equipment in Asia. It is also very popular in the
North America markets. Now Nissindo takes great pride in
introducing three new revolutionary speaker series to the
consumers in North America: Full Range Passive
Non-Powered Speakers (WS-310 and WS-312), Full Range
Active/Powered Speakers (WS-310A and WS-312A) and
Full Range Large Format Speakers (WS-6215 and
WS-8215).
Each of these three speaker series has its own distinguished
features. Both Full Range Passive Non-Powered (WS-310
and WS-312) and Full Range Active/Powered Speakers
(WS-310A and WS-312A) are made of plastics. WS-310
and WS-310A have 10-inch woofers while WS-312 and
WS-312A have 12-inch woofers.
The Full Range Large Format Speakers (WS-6215 and
WS-8215) are made of quality wood (for instance,
WS-6215 is made of plywood and WS-8215 is made of
high grade MDF wood).
Both WS-6215 (Output power: 400 Watts @ 8 ohms) and
WS-8215 (Output power: 600 Watts @ 8 ohms) are
designed for strong bass power with two 15-inch woofers.
Therefore, they can be used for both outdoor and indoor
activities such as home party, outdoor wedding and social
events.
WS-6215 is also equipped with a special horn possessing
frequency response from 50Hz~20kHz while WS-8215 is
equipped with a special horn possessing frequency response
from 55Hz~18kHz. Therefore, these speakers can definitely
enhance your singing performance by mixing the vocal and
music together.
Features
SYSTEM FEATURES
2-WAY FULL RANGE PASSIVE/NON-POWERED
SPEAKERS: WS-310 & WS-312
• 1 x 10” (WS-310) or 1 x 12” (WS-312) high power
transducer with 50mm voice coil
• 1 x 1.3” (WS-310) or 1 x 1.7” (WS-312) diaphragm
compression driver
• 2way full range speaker
• High SPL and high sensitivity speaker
• 90°x 60°controlled coverage pattern
• Rotatable Horn
• Heavy duty protective grill
• Injection molded
• 2 x NL4 connector
• Cabinet design for FOH and Monitor use
• Suitable for use as a main system with or without sub
speaker augmentation
• Portable system (stand), or permanent installation (wall,
ceiling, under balcony)
2-WAY FULL RANGE ACTIVE/POWERED
SPEAKERS: WS-310A & WS-312A
• 1 x 10” (WS-310A) or 1 x 12” (WS-312A) high power
transducer with 50mm voice coil
• 1 x 1.7” (WS-310A) or 1 x 1.7” (WS-312A) diaphragm
compression driver
• 2way full range speaker
• High output SPL and high sensitivity speaker
• 90°x 60°controlled coverage pattern
• Rotatable Horn
• Built-in Bi-amp power amplifier module
• Master volume control
• Bass and Treble control
• XLR input and output connectors
• Switchable between Mic and Line input
• Heavy duty protective grill
• Injection molded
• 2 x XLR connector
• Cabinet design for FOH and Monitor use
• Suitable for use as a main system with or without sub
speaker augmentation
• Portable system (stand), or permanent installation (wall,
ceiling)
2-WAY FULL RANGE LARGE FORMAT SPEAKERS:
WS-6215 & WS-8215
• 2 x 15“ (WS-6215) or 2 x 15” (WS-8215) professional
woofer with big power low frequency transducer
• 1 x 1.7” (WS-6215) or 1 x 3” (WS-8215) compression
driver
• 2way full range speaker
• High SPL and high sensitivity speaker
• 60° x 40° width direction to get more widely enlarge
capability
• 12 hanging points powerful low frequency, rich elasticity.
nice vocal penetration
• Widely spread, natural vocal, rich performance
• With computer optimize simulated design to get better
frequency and phrase features
• Fit for many pro audio avenues main speaker. Such as
performance hall, show bar, Disco square, theater, hall
and church.
• Suitable for any big sound engineering project or enlarge,
repair listening of fluxion performance system

4
NO GOOD
ABNORMALITY
• If the power cord or plug becomes frayed or damaged,
or if there is a sudden loss of sound during use of the
device, or if any unusual smells or smoke should appear to
be caused by it, immediately turn off the power switch,
disconnect the electric plug from the outlet, and have the
device inspected by qualified Nissindo service personnel.
• If this device should be dropped or damaged, immediately
turn off the power switch, disconnect the electric plug from
the outlet, and have the device inspected by qualified
Nissindo service personnel.
LOCATION
• Always consult qualified Nissindo service personnel if the
device installation requires construction work, and make
sure to observe the following precautions.
• Choose mounting hardware and an installation location
that can support the weight of the device.
• Avoid locations that are exposed to constant vibration.
• Inspect the device periodically.
• When transporting or moving the device, always use two
or more person. Attempting to lift the device by yourself
may damage your back, result in other injury, or cause
damage to the device itself.
• Before moving the device, remove all connected cables.
• Do not use the device in a confined, poorly-ventilated
location. If this device is to be used in a small space
other than an EIA-standard rack, make sure that there is
adequate space between the device and surrounding
walls or other devices; at least 30cm at the sides, 30cm
Safety
SAFETY INSTRUCTIONS
We will not notify you any errors or changes in this manual in
advance. If there are any errors and changes in this manual,
we will make the corrections in a timely manner. The
corrections and changes will be appeared in our website.
Therefore, please visit our website at www.NissindoUSA.com
frequently to find out the most updated information, corrections
on errors and changes in this manual. You may also contact
us at toll free at 1-800-318-2218.
CAUTIONS FOR INSTALLATION
POWER SUPPLY / POWER CORD
• Only use the voltage specified as correct for the device.
The required voltage is printed on the name plate of the
device.
• Use only the included power cord.
• Do not place the power cord near heat sources such as
heaters or radiators, and do not excessively bend or
otherwise damage the cord, place heavy objects on it, or
place it in a position where anyone could walk on, trip
over, or roll anything over it.
• Remove the electric plug from the outlet when the device is
not to be used for extended periods of time, or during
electrical storms.
• When removing the electric plug from the device or an
outlet, always hold the plug itself and not the cord. Pulling
by the cord can damage it.
DO NOT OPEN
• Do not open the device or attempt to disassemble the
internal parts or modify them in any way. The device
contains no user-serviceable parts. If it should appear to
be malfunctioning, discontinue use immediately and have
it inspected by qualified Nissindo service personnel.
WATER WARNING
• Do not expose the device to rain, use it near water or in
damp or wet conditions, or place containers on it containing
liquids which might spill into an openings.
• Never insert or remove an electric plug with wet hands.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT
REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS
INSIDE REFER SERVICING TO QUALIFIED PERSONNEL

5
behind and 30cm above. Inadequate ventilation can
result in overheating, possibly causing damage to the
device(s), or even fire.
• Do not use the speaker’s handles for suspended installation.
Doing so can result in damage or injury.
• Do no expose the device to excessive dust or vibrations,
or extreme cold or heat (such as in direct sunlight, near a
heater, or in a car during the day) to prevent the possibility
of panel disfiguration or damage to the internal
components.
• Do not place the device in an unstable position where it
might accidentally fall over.
CONNECTIONS
• Before connecting the device to other devices, turn of the
power for all devices. Before turning the power on or off
for all devices, set all volume levels to minimum.
CAUTION
• When turning on the AC power in your audio system,
always turn on the device LAST, to avoid speaker damage.
When turning the power off, the device should be turned
off FIRST for the same reason.
• Do not insert your fingers or hands in any gaps or
openings on the device (ports, etc.).
• Avoid inserting or dropping foreign objects (paper, plastic,
metal, etc.) into any gaps or openings on the device
(ports, etc.) If this happens, turn off the power immediately
and unplug the power cord from the AC outlet. Then
have the device inspected by qualified Nissindo service
personnel.
• Do not use the device for a long period of time at a high
or uncomfortable volume level, since this can cause
permanent hearing loss. If you experience any hearing
loss or ringing in the ears, consult a physician.
• Do not operate the device if the sound is distorting.
Prolonged use in this condition could cause overheating
and result in fire.
• Do not rest your weight on the device or place heavy
objects on it, and avoid use excessive force on the buttons,
switches or connectors.
GETTING STARTED
WIRING
IMPORTANT: Make sure all equipment is turned off before
making any connections.
For speaker connections, use a high-quality speaker wire with
polarity coding. The side of the wire with a ridge or other
coding is usually considered positive polarity.
If desired, consult Nissindo technical support for
speaker wire and connection options.
The speakers have coded terminals that accept a variety or
wire connectors.
To ensure proper polarity, connect each + terminal on the
back of the amplifier or receiver to the respective + (red)
terminal on each speaker. Connect the – (black) terminals in
a similar way. See the owner’s guides that were included
with your amplifier, receiver and television to confirm connec-
tion procedures.
IMPORTANT: Do not reverse polarities (i.e., + to – or – to +)
when making connections. Doing so will cause poor
imaging and diminished bass response.
ADJUSTING
Check the speakers for playback, first by setting the system
volume control to a minimum level, and then by applying
power to your audio system. Play a favorite music or video
segment and increase the system volume control to a comfort-
able level.
You should hear balanced audio reproduction across
the entire frequency spectrum. If not, check all wiring
connections or consult the authorized dealer from whom you
purchased the system for more help.
The amount of bass you hear and the stereo-image quality
will be affected by a number of different factors, including the
room’s size and shape, the construction materials used to
build the room, the listener’s position relative to the speakers,
and the position of the speakers in the room.
Listen to a variety of music selections and note the bass level.
If there is too much bass, move the speakers away from
nearby walls. Conversely, if you place the speakers closer to
the walls, there will be more bass output.
CARING
Each enclosure has a finish that does not require any routine
maintenance. When needed, use a soft cloth to remove any
fingerprints or dust from the enclosure or grille.
NOTE
NOTE

6
OUTPUT INPUT
2+
1+
2–1–
TO
AMPLIFIER
Connector Panel
OUTPUT INPUT
2+
1+
2–1–
TO
AMPLIFIER
FULL
RANGE
BI-AMP
LF
HF
Connector Panel on Multi-Way Systems
OUTPUT INPUT
PASSIVE BI-AMPLING
INPUT PASSIVE OUTPUT
2+ 2+
2– 2–
1+ 1+
1– 1–
SUB
WOOFER
INPUT BI-AMPLING OUTPUT
2+ 2+
2– 2–
1+ 1+
1– 1–
SUB
WOOFER
Connector Panel on Subwoofers
EXAMPLE OF SPEAKON CONNECTOR
There are two groups on the speakon connectors: Group 1
(+1, –1) and Group 2 (+2, –2) as indicated in the diagram. In
order to use it, your speaker must have multi-functions (i.e.
enable two sources of signal for input). If your speaker does
not have multi-functions, it would not work with the Group 2
for connection. Please refer to the following diagram for
connection.
Applications
SYSTEM APPLICATIONS
Speakon Outputs
The upper Speakon jack has both Channel 1 and
Channel 2 outputs, so it is especially useful for parallel,
bi-amp, or BRIDGE mono operation. The other Speakon
carries only Channel 2's output. See the illustrations at
above.
SPEAKON Y CONNECTORS
INPUT OUTPUT
L
O
C
K
L
O
C
K
TO CHANNEL 2
SPEAKER
TO CHANNEL 1
SPEAKER
2–
1–
1+ 2+
REFERENCE CONNECT
8
4
2
+
–
8
4
2
–
+
SPEAKON CONNECTORS
INPUT OUTPUT
L
O
C
K
L
O
C
K
SOURCE
(from active/powered)
BRIDGE
2–
1–
1+ 2+
REFERENCE CONNECT
8
4
2
+
–
Source (INPUT) comes from the output source of the
active/powered speaker while the bridge (OUTPUT)
connects to the passive/non-powered speaker.
A speakon cable is required to connect the “OUTPUT”
of the acive/powered speaker to the “INPUT” of the
passive/non--powered speaker. Please order the speakon
cable from our authorized dealers.
NOTE

PORTABLE SYSTEM
ON
POWE R
OFF PR OF ES SIO NA L PO WE R AMP LI FIE R MA -1 20 0 G2
PROTE CT
PEAK
SIGNA L
–0
–
8
–2–24
–4–20
–6–18
–8–16
–10–14 –12
CH 1
–0
–
8
–2–24
–4–20
–6–18
–8–16
–10–14 –12
CH 2
ON
POWE R
OFF PR OF ES SIO NA L PO WE R AMP LI FIE R MA -2 00 0
PROTE CT
PEAK
SIGNA L
–0
–
8
–2–24
–4–20
–6–18
–8–16
–10–14 –12
CH 1
–0
–
8
–2–24
–4–20
–6–18
–8–16
–10–14 –12
CH 2
TM
POWER
RF
AF
CHAN.
5 10 15 20 25 30 35 40
-30 -25 -20 -15 -10 -5 0 PEAK
CH 002 MUTE
RF
AF
CHAN.
5 10 15 20 25 30 35 40
-30 -25 -20 -15 -10 -5 0 PEAK
CH 004 MUTE
SET SET
ANTENNA-BVOLUME
DUAL CHANNEL RECEIVER
RECEIVER - A LCDANTENNA-A VOLUME RECEIVER - B LCD
64 SELECTABLE WIRELESS S YSTEM
UHF
7
WS-310/WS-312
2-WAY FULL RANGE PASSIVE/NON-POWERED SPEAKER SYSTEM FUNCTIONING
Recommended System Setup:
We recommend using two amplifiers to connect to two separate
speakers (i.e. one amplifier connects to a Hi and Mid frequency
speaker and the other amplifier connects to the other Low Bass
speaker) in order to control the different sound frequency on the
speakers. It has an advantage over a parallel connection where
only one amplifier is used to connect to two separate speakers
(i.e. one Hi and Mid frequency speaker and one Low Bass
speaker) in connection to produce mono sound only.
Wall
PASSIVE/NON-POWERED SPEAKERS
WS-310 & WS-312
FROM POWER AMPLIFIER MA-1200 G2
CONNECT TO SPEAKON INPUT
LARGE FORMAT SPEAKER
WS-8215 (High Grade)
LARGE FORMAT SPEAKER
WS-8215 (High Grade)
Wall
PASSIVE/NON-POWERED SPEAKERS
WS-310 & WS-312
FROM POWER AMPLIFIER MA-1200 G2
CONNECT TO SPEAKON INPUT
WS-310 WS-312
Hi/Mid
0% 100%
80%
Low
0% 100%
60%
FREQUENCIES
Hi/Mid
0% 100%
70%
Low
0% 100%
80%
FREQUENCIES
POWER AMPLIFIER
MA-2000
POWER AMPLIFIER
MA-1200 G2

8
2-WAY FULL RANGE ACTIVE/POWERED SPEAKER SYSTEM FUNCTIONING
The diagram indicates that signals from the sources (i.e.
mixer, iPod or MP3) to the active/powered speaker
through the powered subwoofer, which acts as a bridge
for bringing signal, are limited in output from the
active/powered speaker.
To increase the output from the active/powered speaker,
you need to use a passive/non-powered speaker (instead
of an active/powered speaker) and add a power
amplifier to drive the system. In this case, both the
powered subwoofer and the passive/non-powered
speaker are controlled separately by a mixer and a
power amplifier respectively. Therefore, the bass and the
full range sound are totally separately.
CLIP
LINE
MIC
LINE MIC INPUT OUTPUT
VOLUME BASS TREBLE
WARNING: DO NOT SUSPEND OVERHEAD
PLEASE FOLLOW THE INSTRUCTIONS
SUPPLIED WITH THE LOUDSPEAKER
ACTIVE 2-WAY FULL RANGE
ELECTRONIC COMPENSATION SPEAKER
WS-312A
POWER: 300W+100W
CALIFORNIA, UNITED STATES OF AMERICA
E-MAIL: [email protected]
WWW.NISSINDOUSA.COM
ENGINEERED AND DESIGN IN U.S.A.
CODE: 050310
SERIAL N O.:
SPECIFICATIONS:
Speaker Type: Build-in amplifier 2-way full range speaker
Input Impendance: 8 ohms
Power Handling Capacity: 300W (Bass)+100W (Tweeter)
Max Sound Level: 118 dB (1m/1w)
Frequency Response: 50Hz-18kHz
Drivers: LF: 12” woofer HF: 90°x60° SCWG horn/compression driver
ON
OFF
USE ON LY WITH A 250 V FUSE
115V/60Hz
230V/50Hz
NOTE
The equipment shown in the
above diagram such as TV, iPhone,
wired microphone and PC is not
included.
ACTIVE/POWERED
SPEAKER: WS-312A
PC
iPhone / iPod
VIDEO
CHARGER
AUDIO INPUT to AUX
This cable is from Apple
part # MB129LL
AT&T 9:42AM 88%
Entertainmen t Auto Priority
Wireless HD Vid eo
Connection Set u p
Speaker
Music
Customer Care
Mail
Vocal
Project Wireless
LyriPS on TV
Free Resources
Stat
Pro Sound
Group sing KTV
Technical Suppor t
S A I S
BASS POWERED SUBWOOFER
OUTPUT TO SUBWOOFER INPUT
ACTIVE/POWERED
SPEAKER: WS-310A
WIRED MIC.
CLIP
VOLUME BASS TREBLE
LINE
MIC
LINE MIC
INPUT OUTPUT
ON OFF
USE ON LY WITH A 250 V FUSE
115V/60Hz
230V/50Hz
CALIFORNIA, UNITED STATES OF AMERICA
E-MAIL: [email protected]
WWW.NISSINDOUSA.COM
ENGINEERED AND DESIGN IN U.S.A.
SER IA L NO.:
ACTIVE 2-WAY FULL RANGE
ELECTRONIC COMPENSATION SPEAKER
WS-310A
POWER: 100W+50W
NOTE
The rear panels of
WS-310A (10-inch woofer) and
WS-312A (12-inch woofer) have
the same features.
NOTE
When using the active/powered speaker for full range
coverage, the output is limited. If the output is not high enough,
you need to change it to a non-powered speaker and also add
a power amplifier to the system.
WS-310A WS-312A
Hi/Mid
0% 100%
80%
Low
0% 100%
60%
FREQUENCIES
Hi/Mid
0% 100%
70%
Low
0% 100%
80%
FREQUENCIES
WS-312A REAR PANEL
WS-310A REAR PANEL
WS-310A/WS-312A

9
POWER
0W 1000W
Average
300W
SOUND COVERAGE
0FT 100FT
Average
50FT
SOUND COVERAGE
0FT 100FT
Average
80FT
POWER
0W 1000W
Average
700W
Floor
Wall Wall
PERFORMER
PORTABLE
SYSTEM
PASSIVE/NON-POWERED PASSIVE/NON-POWERED
ACTIVE/POWERED
MONITOR
PC
AT&T 9:42AM 88%
Entertainment Auto Pri ority
Wireless HD Video
Connection Set up
Speaker
Music
Customer Care
Mail
Vocal
Project Wireless
LyriPS on TV
FreeRes ources
Stat
ProSo und
Group sing KTV
Technical Support
S A I S
iPhone / iPod
VIDEO
AUDIO INPUT to AUX
CHARGER
ACTIVE/POWERED
WIRED MIC.
OUTPUT TO SUBWOOFER INPUT
HIGH PORTABILITY
This speaker is designed for high portability. They are very
easy to carry. You may also use the flight cases to carry
audio equipment to go everywhere with these speakers for
rental and any purposes.
When using the active/powered speaker for full range
coverage, the output is limited. If the output is not high
enough, you need to change it to a non-powered speaker
and also add a power amplifier to the system.
HIGH POWER
This speaker series have two types of speakers:
active/powered speaker and passive/non-powered speaker.
When using the active/powered speaker alone, the output
power is limited to 300 watts. For more than 300 watts in
output, two passive/non-powered speakers and a
high-power amplifier are required to generate higher power
as high as 1,000 watts. Therefore, it would produce much
higher power.
ON
POWER
OFF PROFE SSION AL POWE R AMPLIF IER MA- 1200 G2
PROTECT
PEAK
SIGNAL
–0
–
8
–2–24
–4–20
–6–18
–8–16
–10–14 –12
CH1
–0
–
8
–2–24
–4–20
–6–18
–8–16
–10–14 –12
CH2
ON
POWER
OFF PROFE SSION AL POWE R AMPLIF IER MA- 2000
PROTECT
PEAK
SIGNAL
–0
–
8
–2–24
–4–20
–6–18
–8–16
–10–14 –12
CH1
–0
–
8
–2–24
–4–20
–6–18
–8–16
–10–14 –12
CH2
TM
POWER
RF
AF
CHAN.
5 10 15 20 25 30 35 40
-30 -25 -20 -15 -10 -5 0 PEAK
CH 002 MUTE
RF
AF
CHAN.
5 10 15 20 25 30 35 40
-30 -25 -20 -15 -10 -5 0 PEAK
CH 004 MUTE
SET SET
ANTENNA-BVOLUME
DUALCHANNEL RECEIVER
RECEIVER- A LCDANTENNA-A VOLUME RECEIVER- B LCD
64SELECTABLE WIRELESS SYSTEM
UHF
If you want a high bass, you
need to add a power
subwoofer of various sizes (i.e.
12-inch, 15-inch, 18-inch and
20-inch power subwoofer).

10
For large sound format coverage, you need to use a
passive/non-powered speaker and add a power amplifier to
drive four speakers WS-310 (10-inch woofer) for high and
mid frequencies. Therefore, it is easy to control the stereo
system setup.
2-WAY FULL RANGE LARGE FORMAT SPEAKER SYSTEM FUNCTIONING
www.nissindousa.com Comments? E-mail: [e-mail]
Nissindo All Rights Reserved. Engineered And Design In U.S.A.
Manufacture Code: 36027800
WS-8215
[Large Format Speaker]
SERIAL NO.
360100627800
FREQUENCY: 55Hz ~ 18kHz
POWER (RMS): 300W ~ 600W
SENSITIVITY (1W/1m): 100dB
IMPEDANCE: 8 ohms
NET WEIGHT: 103.6 Lbs / 47 kg
FROM POWER AMPLIFIER MA-2000
CONNECT TO SPEAKON INPUT
WS-6215/WS-8215
WS-6215 REAR PANELWS-8215 REAR PANEL
To add one more power amplifier to drive two speakers
WS-6215 or WS-8215 (dual 15-inch woofers) for low
frequency. Therefore, it is easy to control the stereo bass for
large sound format coverage.
Hi/Mid
0% 100%
30%
0% 100%
80%
Low
FREQUENCIES
Hi/Mid
0% 100%
50%
Low
0% 100%
90%
FREQUENCIES
WS-6215
(Standard Grade)
WS-8215
(High Grade)
CTRLR OUT
L
R
MONO
LINE IN 5-6
L
R
L
R
2-TRACK IN/OUT
L
R
MONO
LINE IN 7-8
L
R
PHONE
1 2 3 4
STEREO AUX RETURN AUX SEND LEFT RIGHT MAIN OUT
LR
1 2 345-6 7-8 EFFECT
DELAY
10
0dB
10
15
20
25
30
40
60
+10
+7
+2
0
-2
-4
-7
+4
-10
-20
+48 V POWER
MAIN MIX
PHONE LEVEL
+48 V
LLEVEL R
PFL
2TK
+4
-10
GAIN
LINE IN
MIC
+4
-10
GAIN
LINE IN
MIC
+4
-10
GAIN
LINE IN
MIC
+4
-10
GAIN
LINE IN
MIC
TYPE OUTTYPE IN
5
100
2TK TO MIX
EFF TO MIX
UP
DOWN
RL/MONO
HIGH
12KHz
MID
2.5KHz
LOW
80Hz
EQ
10
0
10
20
25
30
40
45
dB MUTE
PEAK
SING
0
+15-15 0
+15-15
RL
PAN
0
+15-15
AUX/
EFF
5
100
HIGH
12KHz
MID
2.5KHz
LOW
80Hz
EQ
10
0
10
20
25
30
40
45
dB MUTE
PEAK
SING
0
+15-15 0
+15-15
RL
PAN
0
+15-15
AUX/
EFF
5
100
HIGH
12KHz
MID
2.5KHz
LOW
80Hz
EQ
10
0
10
20
25
30
40
45
dB MUTE
PEAK
SING
0
+15-15 0
+15-15
RL
PAN
0
+15-15
AUX/
EFF
5
100
HIGH
12KHz
MID
2.5KHz
LOW
80Hz
EQ
10
0
10
20
25
30
40
45
dB MUTE
PEAK
SING
0
+15-15 0
+15-15
RL
PAN
0
+15-15
AUX/
EFF
5
100
HIGH
12KHz
MID
2.5KHz
LOW
80Hz
EQ
10
0
10
20
25
30
40
45
dB MUTE
SING
0
+15-15 0
+15-15
RL
PAN
0
+15-15
AUX/
EFF
5
100
HIGH
12KHz
MID
2.5KHz
LOW
80Hz
EQ
10
0
10
20
25
30
40
45
dB MUTE
SING
0
+15-15 0
+15-15
RL
PAN
0
+15-15
AUX/
EFF
5
100
AUX
SEND
5
100
AUX
RET
5
100
EFF
SEND
5
100
REPEAT
5
100
10
0
10
20
25
30
40
45
dB
POWERED MIXER
PASSIVE/NON-POWERED
SPEAKER WS-310
LARGE FORMAT
SPEAKER WS-8215
(High Grade)
PASSIVE/NON-POWERED
SPEAKER WS-310
LARGE FORMAT
SPEAKER WS-8215
(High Grade)
FROM POWER AMPLIFIER MA-1200 G2
CONNECT TO SPEAKON INPUT
PORTABLE SYSTEM
POWER
Professional Power Amplifier: MA-1200 G2
-0
-
8
-2-21
-4-20
-6-18
-8-16
-10-14 -12
CH 1
-0
-
8
-2-21
-4-20
-6-18
-8-16
-10-14 -12
CH 2
BR I D G E
PROTECT
C L I P
SIGNAL
POWER
Professional Power Amplifier: MA-2000
-0
-
8
-2-21
-4-20
-6-18
-8-16
-10-14 -12
CH 1
-0
-
8
-2-21
-4-20
-6-18
-8-16
-10-14 -12
CH 2
BR I D G E
PROTECT
C L I P
SIGNAL
TM
POWER
RF
AF
CHAN.
5 10 15 20 25 30 35 40
-30 -25 -20 -15 -10 -5 0 PEAK
CH 002 MUTE
RF
AF
CHAN.
5 10 15 20 25 30 35 40
-30 -25 -20 -15 -10 -5 0 PEAK
CH 004 MUTE
SET SET
ANTENNA-BVOLUME
DUAL CHANNEL RECEIVER
RECEIVER - A LCDANTENNA-A VOLUME RECEIVER - B LCD
64SEL ECTABLE WIRELESS SYSTEM
UHF
POWER AMPLIFIER
MA-1200 G2
POWER AMPLIFIER
MA-2000
Only WS-8215 High Grade
Performance Unit provides the
anti-shock rubber feet. Therefore, it
can produce high power. Also,
only the WS-8215 can be
suspended.
The WS-6215 can only be placed
on the ground. It is a standard
grade format unit.

11
SPEAKER CONNECTION
www.nissindousa.comComments? E-mail: supp [email protected]
NissindoAll Rights Reserved. Engineered An d Design In U.S.A.
ManufactureCode: 36027800
WS-8215
[Full-Range Loud speaker]
SERIALNO.
360100627800
FREQUENCY:55Hz~ 18kHz
POWER(RMS):300W ~ 600W
SENSITIVITY(1W/1m):100dB
IMPEDANCE:4ohms
NETWEIGHT:103.6 Lbs / 47 kg
www.nissindousa.com Comments? E-mail: [e-mail]
Nissindo All Rights Reserved. Engineered And Design In U.S.A.
Manufacture Code: 36027800
WS-8215
[Large Format Speaker]
SERIAL NO.
360100627800
FREQUENCY: 55Hz ~ 18kHz
POWER (RMS): 300W ~ 600W
SENSITIVITY (1W/1m): 100dB
IMPEDANCE: 8 ohms
NET WEIGHT: 103.6 Lbs / 47 kg
CTRLR OUT
L
R
MONO
LINE IN 5-6
L
R
L
R
2-TRACK IN/OUT
L
R
MONO
LINE IN 7-8
L
R
PHONE
1 2 3 4
STEREO AUX RETURN AUX SEND LEFT RIGHT MAIN OUT
LR
1 2 345-6 7-8 EFFECT
DELAY
10
0dB
10
15
20
25
30
40
60
+10
+7
+2
0
-2
-4
-7
+4
-10
-20
+48 V POWER
MAIN MIX
PHONE LEVEL
+48 V
LLEVEL R
PFL
2TK
+4
-10
GAIN
LINE IN
MIC
+4
-10
GAIN
LINE IN
MIC
+4
-10
GAIN
LINE IN
MIC
+4
-10
GAIN
LINE IN
MIC
TYPE OUTTYPE IN
5
100
2TK TO MIX
EFF TO MIX
UP
DOWN
RL/MONO
HIGH
12KHz
MID
2.5KHz
LOW
80Hz
EQ
10
0
10
20
25
30
40
45
dB MUTE
PEAK
SING
0
+15-15 0
+15-15
RL
PAN
0
+15-15
AUX/
EFF
5
100
HIGH
12KHz
MID
2.5KHz
LOW
80Hz
EQ
10
0
10
20
25
30
40
45
dB MUTE
PEAK
SING
0
+15-15 0
+15-15
RL
PAN
0
+15-15
AUX/
EFF
5
100
HIGH
12KHz
MID
2.5KHz
LOW
80Hz
EQ
10
0
10
20
25
30
40
45
dB MUTE
PEAK
SING
0
+15-15 0
+15-15
RL
PAN
0
+15-15
AUX/
EFF
5
100
HIGH
12KHz
MID
2.5KHz
LOW
80Hz
EQ
10
0
10
20
25
30
40
45
dB MUTE
PEAK
SING
0
+15-15 0
+15-15
RL
PAN
0
+15-15
AUX/
EFF
5
100
HIGH
12KHz
MID
2.5KHz
LOW
80Hz
EQ
10
0
10
20
25
30
40
45
dB MUTE
SING
0
+15-15 0
+15-15
RL
PAN
0
+15-15
AUX/
EFF
5
100
HIGH
12KHz
MID
2.5KHz
LOW
80Hz
EQ
10
0
10
20
25
30
40
45
dB MUTE
SING
0
+15-15 0
+15-15
RL
PAN
0
+15-15
AUX/
EFF
5
100
AUX
SEND
5
100
AUX
RET
5
100
EFF
SEND
5
100
REPEAT
5
100
10
0
10
20
25
30
40
45
dB
POWERED MIXER
SOURCE 2
SOURCE 1
ELECTRONIC KEYBOARD
www.nissindousa.comComments? E-mail: supp [email protected]
NissindoAll Rights Reserved. Engineered An d Design In U.S.A.
ManufactureCode: 36027800
WS-8215
[Full-Range Loud speaker]
SERIALNO.
360100627800
FREQUENCY:55Hz~ 18kHz
POWER(RMS):300W ~ 600W
SENSITIVITY(1W/1m):100dB
IMPEDANCE:4ohms
NETWEIGHT:103.6 Lbs / 47 kg
www.nissindousa.com Comments? E-mail: [e-mail]
Nissindo All Rights Reserved. Engineered And Design In U.S.A.
Manufacture Code: 36027800
WS-8215
[Large Format Speaker]
SERIAL NO.
360100627800
FREQUENCY: 55Hz ~ 18kHz
POWER (RMS): 300W ~ 600W
SENSITIVITY (1W/1m): 100dB
IMPEDANCE: 8 ohms
NET WEIGHT: 103.6 Lbs / 47 kg
POWER AMPLIFIER MA-1200 G2
HI FREQUENCY RESPONSE WS-310
This diagram indicates a mono connection where the power
amplifier is connected to the dual 15-inch woofer speakers,
and bridges to other high-frequency speakers.
Under the mono connection, both spealers produce the same
level of frquencies (i.e. high. mid and low). If you want to
adjust the bass to a different level from the sub-woofer, you
need stereo connection.
MULTI-FUNCTION CONNECTION
There are two sources for connection in the rear of the
speaker: INPUT and OUTPUT as indicated in the diagram.
The INPUT is connected to the powered mixer. The output is
connected to other sources such as electronic keyboard. In
this case, two sources would become input since it has a
MULTI-FUNCTION CONNECTION. If the master volume of
the speaker reaches the maximum level, it will automatically
shut off in five seconds and then back to function again.
Therefore, you must adjust the speaker master volume to a
normal level. In this case, we highly recommend you adding
two 15-inch woofer speakers and also increase more output
power in your power amplifier or music source.

12
Rear View
CLIP
LINE
MIC
LINE MIC INPUT OUTPUT
VOLUME BASS TREBLE
WARNIN G: DO NOT SUSP END OVERH EAD
PLEASE F OLLOW T HE INST RUCTIO NS
SUPPLI ED WITH THE LO UDSPEAK ER
ACTIV E 2-WAY FUL L RANGE
ELECTRONIC COMPENSATION SPEAKER
CALIFORNIA,UNITED STATES OF AMERICA
E-MAIL: su pport@n issindo usa.com
WWW.NISSINDOUSA.COM
ENGINEEREDAND DESIGN IN U.S.A.
CODE: 0503 10
SERIAL NO. :
SPECIFICATIONS:
Speaker Ty pe: Build -in ampli fier 2-wa y full rang e speaker
Input Impe ndance: 8 o hms
Power Hand ling Capa city: 300 W (Bass)+ 100W (Twe eter)
Max Sound Le vel: 118 dB ( 1m/1w)
Frequenc y Respons e: 50Hz-1 8kHz
Drivers: L F: 12” woof er HF: 90°x 60° SCWG ho rn/comp ression d river
ON
OFF
USEONLY WITH A 25 0V FUSE
115V/60Hz
230V/50Hz
Rear View
Speaker
CONTROLS AND FUNCTIONS
SPEAKER HANDLE
SPEAKER INPUT TERMINAL (Speakon)
SPEAKER OUTPUT TERMINAL (Speakon)
1
2
3
REAR PANEL: features are available for full range passive/non-powered speaker model WS-310 and WS-312
REAR PANEL: features are available for full range active/powered speaker model WS-310A and WS-312A
Front View
1
32
Front View
SPEAKER HANDLE
VOLUME CONTROL
CLIP INDICATOR
MICROPHONE INPUT SIGNAL INDICATOR
LINE INPUT SIGNAL INDICATOR
LINE/MICROPHONE SELECTOR
115V/230V VOLTAGE INPUT SELECTOR
POWER ON/OFF SWITCH
BASS CONTROL
TREBLE CONTROL
LINE/MICROPHONE OUTPUT
LINE/MICROPHONE INPUT
CONNECT THIS TO 120V 60Hz AC WITH THE
SUPPLIED POWER CORD
1
2
3
4
5
6
7
8
9
10
11
12
13
CLI P
VOLUME BASS TREBLE
LINE
MIC
LINE MI C
INPUT OUTPUT
ON OFF
USE ONLY W ITH A 250V FU SE
115V/60Hz
230V/50Hz
CAL IFO RNI A, UN ITE D STA TES O F AME RIC A
E-MAIL: [email protected]
WWW.NISSINDOUSA.COM
ENG INE ERE D AND D ESI GN IN U .S. A.
SER IAL N O.:
ACT IV E 2-W AY F ULL R AN GE
ELECTRONIC COMPENSATION SPEAKER
WS-310A
POWER: 100W+50W
13
10
11
9
12
7
8
4
5
6
3
2
WS-310A
CLI P
LINE
MIC
LINE MI C INPUT OUTPUT
VOLUME BASS TREBLE
WARNING: DO NOT SUSPEND OVERHEAD
PLEASE FOLLOW THE INSTRUCTIONS
SUPPLIED WITH THE LOUDSPEAKER
ACTIVE 2-WAY FULL RANGE
ELECTRONIC COMPENSATION SPEAKER
WS-312A
POWER: 300W+100W
CALIFORNIA, UNITED STATES OF AMERICA
E-MAIL: [email protected]
WWW.NISSINDOUSA.COM
ENGINEERED AND DESIGN IN U.S.A.
CODE: 050310
SER IA L NO. :
SPECIFICATIONS:
Speaker Type: Build-in amplifier 2-way full range speaker
Input Impendance: 8 ohms
Power Handling Capacity: 300W (Bass)+100W (Tweeter)
Max Sound Level: 118 dB (1m/1w)
Frequency Response: 50Hz-18kHz
Drivers: LF: 12” woofer HF: 90°x60° SCWG horn/compression driver
ON
OFF
USE ONL Y WITH A 250V F USE
115V/60Hz
230V/50Hz
10
11
13
7
8
4
5
6
3
29
12
WS-312A
1
WS-310/WS-312WS-310A/WS-312A

WS-6215WS-8215
13
REAR PANEL: features are available for full range large format speaker model WS-6215 (Standard Grade)
REAR PANEL: features are available for full range large format speaker model WS-8215 (High Grade)
Bottom View
4
www.nissindousa.comComments? E-mail: supp [email protected]
NissindoAll Rights Reserved. Engineered An d Design In U.S.A.
ManufactureCode: 36027800
WS-8215
[Full-Range Loud speaker]
SERIALNO.
360100627800
FREQUENCY:55Hz~ 18kHz
POWER(RMS):300W ~ 600W
SENSITIVITY(1W/1m):100dB
IMPEDANCE:4ohms
NETWEIGHT:103.6 Lbs / 47 kg
Rear View
www.nissindousa.com Comments? E-mail: [e-mail]
Nissindo All Rights Reserved. Engineered And Design In U.S.A.
Manufacture Code: 36027800
WS-8215
[Large Format Speaker]
SERIAL NO.
360100627800
FREQUENCY: 55Hz ~ 18kHz
POWER (RMS): 300W ~ 600W
SENSITIVITY (1W/1m): 100dB
IMPEDANCE: 8 ohms
NET WEIGHT: 103.6 Lbs / 47 kg
1
2
3
Front View
SPEAKER HANDLE
SPEAKER OUTPUT TERMINAL (Speakon)
SPEAKER INPUT TERMINAL (Speakon)
RUBBER FEET: for anti-shock, so the speaker can produce strong bass. Only
WS-8215 High Grade Performance Unit provides the anti-shock rubber.
1
2
3
4
Rear View
1
SPEAKER HANDLE
SPEAKER OUTPUT TERMINAL (Speakon)
SPEAKER INPUT/OUTPUT 1/4 TERMINAL
RUBBER FEET
1
2
3
4
Bottom View
4
Front View
32
Standard Grade Format Unit
400 Watts @ 8 ohms
800 Watts @ 4 ohms
High Grade Performance Unit
600 Watts @ 8 ohms
1200 Watts @ 4 ohms

Ceiling
14
CLIP
LINE
MIC
LINE MIC INPUT OUTPUT
VOLUME BASS TREB LE
WARNING: DO N OT SUSPEN D OVERHEA D
PLEASE FOLL OW THE INST RUCTION S
SUPPLIED WI TH THE LOUDSPEAKER
ACTIVE2-WAY FULL RANGE
ELECTRONICCOMPENSATION SPEAKER
CALIFORNIA, U NITED STA TES OF AMER ICA
E-MAIL: suppo rt@niss indousa .com
WWW.NISSIND OUSA.COM
ENGINEERED AN D DESIGN IN U .S.A.
CODE: 050310
SERIAL NO.:
SPECIFICATIONS:
Speaker Type: B uild-in a mplifie r 2-way ful l range spe aker
Input Impenda nce: 8 ohms
Power Handlin g Capacit y: 300W (Ba ss)+100 W (Tweete r)
MaxSo und Level : 118 dB (1m/ 1w)
Frequency Res ponse: 50 Hz-18kH z
Drivers: LF: 12 ” woofer HF : 90°x60° S CWG horn/ compres sion driv er
ON
OFF
USEONLYWITH A 2 50V FUSE
115V/60Hz
230V/50Hz
360° COVERAGE
SYSTEM SETUP GUIDELINES: INSTALLATION SETUP
Set Up
Ceiling
ANCHOR SHACKLE THREADED CHAIN
CONNECTOR
CARABINER-TYPE
SNAP HOOK
Examples of Useful Rigging Hardware
Safety Cable Style
LOOP ON ONE END, RETAINING WASHER ON ONE END
ONE WITH LOOP ON BOTH ENDS, TWO
CABLES WITH THREADED CHAIN CONNECTOR
ON ONE END AND LOOP ON THE OTHER END
EYE BOLT
NOTE
NOTE
1. MOUNTING THE SPEAKER TO THE CEILING
For an area of 3,000 square feet or more, you can group up
to six flying speakers together and suspend them into the
ceiling for spot sound to cover a greater distance.
To suspend the flying speakers onto the ceiling, you need the
parts and accessories (optional) as indicated in the diagram
below. To order these parts and accessories, please contact
our authorized dealers directly.
We highly recommend you hiring a professional audio
contractor to do the installation for safety purpose.
The structure of the ceiling must be strong enough to hold at
least 50 pounds.
Ceiling
WS-310/WS-312/WS-310A/WS-312A

15
PANEL WALL 2”X4” WOOD STUD
We recommend that the speakers be tiled at an angle, so
that it aims at audience’s ear level in order to achieve the best
accoustic quality.
NOTE
180° (ADJUSTABLE)
LEFT RIGHT
20 Feet
-6 dB
80 Degree
-6 dB
Wall
Wall
UP
DOWN
90°
(ADJUSTABLE)
1
2
NOTE
2. MOUNTING THE SPEAKER TO THE WALL
STEP : Place the wall mount panel on the wall and put
three or more screws to fasten it.
STEP : Then, put the speaker firmly onto the mount.
Adjust the speaker up and down for rotation at different
angles to achieve the maximum sound effect.
The structure of the wall must be strong enough to hold up to
100 pounds.
How to Adjust the Wall Mount (SL-001)
Adjust the wall mount left/right at 180 degree and up/down
at 90 degree for rotation at different angles to achieve the
best sound effect. Once you have set up the right position,
then you can use the screw to tight it up. Part Number:
SL-001 (Optional) for wall mount.
Mounting to Solid Wood or Wood Studs
In North America, most of the houses have 2”x4” wood studs
inside the panel walls. You may use stud finder to locate the
wood studs. Then, you can drive the screw into the wood
stud to mount the speaker bracket and hold it firmly.
12.5 inch
31.8 cm
9.8 inch
25 cm 3.2 inch
8 cm
11.2 inch
28.3 cm
1.4 inch / 3.5 cm5.5 inch / 14 cm
Dimensions: Wall Mount (SL-001)

16
Floor
WS-310, WS-310A,
WS-312, & WS-312A
SUBWOOFER
SPEAKER
MOUNTING
POLE
(Adjustable)
38 inch
96.5 cm
The speaker mounting pole as indicated in the diagram is
not included with any of our speaker models. You may order it
directly from our authorized dealers near you.
NOTE
LEFT SPEAKER
(Stand is not included)
RIGHT SPEAKER
(Stand is not included)
PORTABLE CASE
3. PLACING THE SPEAKER ON THE FLOOR TO
MONITOR SINGING
This WS-310, WS-312, WS-310A, & WS-312A speakers
can be placed on the floor to perform the vocal monitoring
function for live singing experience. It can also be used for
business conference, coffee shop and church, etc.
5. PLACING THE SPEAKERS ON THE SPEAKER
MOUNTING POLE (Adjustable)
Part Number: AM91 (Optional)
6. STORE THE SPEAKER INSIDE A PORTABLE
CASE
A speaker can be placed and stored inside a portable case
as indicated in the diagram on the below, which would
make it easy to carry to any places with a portable case.
4. PLACING THE SPEAKERS ON THE PORTABLE
STAND
The speakers can be mounted on to the optional portable
stand, (see figure below). Make sure that the mounting system
(hardware, stand, etc.) is capable of supporting four times the
weight (approximately 25 lbs per speaker) of the speakers.
Part Number: AMS001B (Optional).

1. MOUNTING THE SPEAKER TO THE CEILING
For an area of 3,000 square feet or more, you can group up
to six flying speakers together and suspend them into the
ceiling for spot sound to cover a greater distance.
To suspend the flying speakers onto the ceiling, you need the
parts and accessories (optional) as indicated in the diagram
below. To order these parts and accessories, please contact
our authorized dealers directly.
Suspension is only available with WS-8215 High Grade
Performance Unit. The WS-6215 is a standard grade format
unit without suspension.
We highly recommend you hiring a professional audio
contractor to do the installation for safety purpose.
The structure of the ceiling must be strong enough to hold at
least 50 pounds.
17
www.nissindousa.comComments? E-mail: support @nissindousa.com
NissindoAllRights Rese rved. Engineered And Design In U.S. A.
ManufactureCode: 36027800
WS-8215
[Full-Range Loudsp eaker]
SERIALNO.
360100627800
FREQUENCY:55Hz~ 18kHz
POWER(RMS):300W ~ 600W
SENSITIVITY(1W/1m):100dB
IMPEDANCE:4ohms
NETWEIGHT:103.6Lb s / 47k g
360° COVERAGE
Safety Cable Style
LOOP ON ONE END, RETAINING WASHER ON ONE END
ONE WITH LOOP ON BOTH ENDS, TWO
CABLES WITH ANCHOR SHACKLE ON ONE
END AND LOOP ON THE OTHER END
Ceiling
Ceiling
ANCHOR SHACKLE THREADED CHAIN
CONNECTOR
CARABINER-TYPE
SNAP HOOK
Examples of Useful Rigging Hardware & Brackets
BRACKET
NOTE
NOTE
Ceiling
WS-8215

18
Floor
FRONT GRILL COVER
GREAT EXPANSION CABINET
WOOFER (LF)
WS-6215 (Standard Grade) Part Number: ED15010
WS-8215 (High Grade) Part Number: ED15050
HORN (HF) Part Number: ED-7-QDQ10
CROSSOVER
WS-6215 (Standard Grade) Part Number: CGSO15-10
WS-8215 (High Grade) Part Number: EDE0110-0023
1
2
3
5
4
2GREAT EXPANSION CABINET 1FRONT GRILL COVER
5CROSSOVER
WS-8215 (High Grade)
Part Number: EDE0110-0023
CROSSOVER
WS-6215 (Standard Grade)
Part Number: CGSO15-10
WS-8215 speaker is not designed to
place in the positions as indicated in
figure 1 and 2. If you want to position
the WS-8215 as indicated in figure 1
and 2, we recommend you to choose
different models with that particular
function. We also highly recommend
you to hire professional for installation.
This is for your own safety and
protection.
FIGURE 2FIGURE 1
2. PLACING THE SPEAKER ON THE FLOOR TO
MONITOR SINGING
This speaker can be placed on the floor to perform the vocal
monitoring function for live singing experience. It can also be
used for business conference, coffee shop and church, etc.
PARTS FOR MAINTENANCE (WS-6215 &
WS-8215)
For repair and maintenance, you can order the following
parts indicated with numbers below from our authorized
dealers. The following parts include:
Test 1
out +
Hi
Test 2
Input
EDE011O-0023
UL
R
(ph) 2OW15RJ
(ph) 2OW15RJ
(ph) 2OW8ROJ
(ph) 2OW8ROJ
IN+
HI-
HI+
C1
C2
C3
LOW+
R4 CGSO15-10
R1
T1
R5
R2
L1
L3
IN-
LOW-
LOW+
L2
MPT250
305J
(ph) 2OW2ORJ
4HORN (HF)
Part Number: ED-7-QDQ10
3WOOFER (LF)
WS-6215 (Standard Grade)
Part Number: ED15010
WS-8215 (High Grade)
Part Number: ED15050
FRONT VIEW BACK VIEW BACK VIEW
FRONT VIEW
Suspension is only
available with WS-8215
High Grade Performance
Unit. The WS-6215 is a
Standard Grade Format
Unit without suspension.

19
10.6 inch
27 cm
Back View
WS-312 / WS-312AWS-310 / WS-310A
WS-8215 (High Grade Performance Unit)WS-6215 (Standard Grade Format Unit)
18.3 inch
46.4 cm
12.6 inch
32.1 cm
Front View
18.3 inch
46.4 cm
12.6 inch
32.1 cm
Back View
24.4 inch
62 cm
16.3 inch
41.5 cm
12.6 inch
32.1 cm
12.6 inch
32.1 cm
Top View
Bottom View
24.4 inch
62 cm
15 inch
38.2 cm
Side View
18.3 inch
46.4 cm
12.6 inch
32.1 cm
Side View
15 inch
38.2 cm
16.3 inch
41.5 cm
Top View
Bottom View
19.9 inch
50.5 cm
10.6 inch
27 cm
21.3 inch
54 cm
Top View
Bottom View
19.9 inch
50.5 cm
Side View
21.3 inch
54 cm
Front View
42.5 inch
108 cm
10.6 inch
27 cm
www.nissindousa.comComments? E-mail: supp [email protected]
NissindoAll Rights Reserved. Engineered An d Design In U.S.A.
ManufactureCode: 36027800
WS-8215
[Full-Range Loud speaker]
SERIALNO.
360100627800
FREQUENCY:55Hz~ 18kHz
POWER(RMS):300W ~ 600W
SENSITIVITY(1W/1m):100dB
IMPEDANCE:4ohms
NETWEIGHT:103.6 Lbs / 47 kg
Back View
42.5 inch
108 cm
17.5 inch
44.5 cm
10.6 inch
27 cm
19.5 inch
49.5 cm
Top View
Bottom View
17.5 inch
44.5 cm
Side View
19.5 inch
49.5 cm
Front View
41.4 inch
104.5 cm
41.4 inch
104.5 cm
24.4 inch
62 cm
16.3 inch
41.5 cm
Back View
Front View
Only WS-8215
provides the
anti-shock
rubber feet

2-Way Full Range
“SPOT” RANGE Compression Driver
1.7” Diaphragm
Compression Driver
1.3” Diaphragm
Compression Driver
1.7” Diaphragm
Compression Driver
3” Diaphragm
Compression Driver
1.3” Diaphragm
Compression Driver
Horn Full Range
Passive Operation
20
PHYSICAL DIMENSIONS
Dimensions
WS-310 WS-312AWS-312 WS-6215
(Standard Grade)
WS-310A WS-8215
(High Grade)
PASSIVE/NON-POWER SPEAKER ACTIVE/POWERED SPEAKER
MODEL
NET WEIGHT
12.6×18.3×12.6 in
32.1×46.4×32.1 cm
14.8x21.1x14 in
37.5×53.5×35.5 cm
(each)
22 lbs / 10 Kg
(each)
26.5 lbs / 12 Kg
(each)
16.3×24.4×15 in
41.5×62×38.2 cm
18.3x26.8x17.1 in
46.5×68×43.5 cm
(each)
39.7 lbs / 18 Kg
(each)
44.1 lbs / 20 Kg
(each)
12.6×18.3×12.6 in
32.1×46.4×32.1 cm
14.8x21.1x14 in
37.5×53.5×35.5 cm
(each)
33.1 lbs / 15 kg
(each)
37.5 lbs / 17 kg
(each)
16.3×24.4×15 in
41.5×62×38.2 cm
18.3x26.8x17.1 in
46.5×68×43.5 cm
(each)
50.7 lbs / 23 kg
(each)
55.6 lbs / 25.2 kg
(each)
19.5x41.1x17.5 in
49.5×104.5×44.5cm
23.5x45x22 in
59.7×114.3×55.9 cm
(each)
74.6 lbs / 33.8 kg
(each)
85.8 lbs / 38.9 kg
(each)
21.3x42.5x19.9 in
54x108x50.5 cm
23.1×45.5×24.4 in
58.8×115.5×62 cm
(each)
103.6 lbs / 47 kg
(each)
111.6 lbs / 50.6 kg
(each)
SHIPPING WEIGHT
DIMENSIONS
(WXHXD)
PACKING
DIMENSIONS
(WXHXD)
LARGE FORMAT SPEAKER
FREQUENCY
RESPONSE
HIGHLIGHTED
FEATURES
SENSITIVITY
65Hz ~ 18kHz
95 dB
Lightweight for
ultimate portability
50Hz ~ 18kHz
97 dB
Lightweight for
ultimate portability
55Hz ~ 18kHz
95 dB
Lightweight for
ultimate portability
55Hz ~ 18kHz
97 dB
Lightweight for
ultimate portability
Light-weight and very
high-power
55Hz ~ 18kHz
100 dB
50Hz ~ 20kHz
95 dB
SPECIFICATIONS
Spec
ACTIVE/POWERED SPEAKER
MAX. POWER
HANDLING
SUPPORTED
FIXTURE
WOOFER
(Low Frequency)
CABINET TYPE
TYPE
MODEL
PASSIVE/NON-POWER SPEAKER LARGE FORMAT SPEAKER
Front
250 Watts
Construction Plastic
10” (1 unit)
Ceiling,
Wall Mount,
Floor Stand
300 Watts
Construction Plastic Construction Plastic Construction Plastic Wood MDF-Wood
12” (1 unit)
Ceiling,
Wall Mount,
Floor Stand
Ceiling,
Ground,
Floor Stand
100 Watts
10” (1 unit)
Ceiling,
Ground,
Floor Stand
Ground Ceiling, Ground
300 Watts
12” (1 unit) 15” (2 unit)15” (2 unit)
TWEETER
(High Frequency) 2-Way Full Range 2-Way Full Range 2-Way Full Range 2-Way Full Range 2-Way Full Range
Front
WS-8215
(High Grade)
Front
WS-6215
(Standard Grade)
Front
WS-312WS-310
Front
WS-312A
Front
WS-310A
High power level:
vocal and music with
powerful bass
400 Watts @ 8ohms
800 Watts @ 4ohms
600 Watts @ 8ohms
1200 Watts @ 4ohms
