Intelligent 2-in-1 Electric Hob
(Infrared + Induction)
智能2合1電能煮食爐
Model/型號：EC-2989
Installation & O erating Instructions
產品使用說明書

1
1、 Product Introduction-------------------------------------------------- 2
1.1 .Introduction of Product
1.2 .Function & Characteristics
2、 Installation Guideline-------------------------------------------------- 3-5
3、 Control Panel Instructions-------------------------------------------- 6
4、 O eration Method----------------------------------------------------- 7-9
4.1 .O eration Instructions
4.2 .Usable and Non-usable Cookware
4.3. Heating Power Distribution
5、 Safety Precautions----------------------------------------------------- 10
5.1 . Safety Notes
5.2 . Warning
6、 Daily Maintenance----------------------------------------------------- 11
7、 Product S ecification-------------------------------------------------- 11
8、 Trouble-Shooting Guideline------------------------------------------ 12-13
8.1 . Code Of Breakdown
8.2 . Trouble Shooting
CONTENTS

2
1、Product Introduction
1.1、Introduction Of Product：
Thank you for choosing Garwoods 2-in-1 Electric Hob. This roduct combines with two
different calefaction rinci les. The left zone is infrared cooker and the right zone is induction
cooker. It is controlled by the micro-com uter touching sensor control system. Please read
this o eration manual carefully before installing or using this roduct.
1.2 、Function Characteristics：
 Energy-efficient

The electric hob utilizes the brand-new calefaction rinci le. For the
art of the Infrared zone, it utilizes radiant heating element and the surface remains a
residual heat for short-time cooking without ower after cooking. It is energy-saving.
For another art of the Induction zone, it is also both time-saving & energy-efficient
because it directly heats u the bottom of the cookware and a heat transfer efficiency of
u to 90% is achieved.
 Multi-function

The electric hob utilizes newest micro-com uter chi rogram control.
It offers multi le scales for heating ower level regulation.
 Safety Environmental Friendly

Safety & Environmental Friendly of the roduct is on
our to riority. The electric hob contains a serious of safety system such as safety lock;
high tem erature indicator(Infrared art); overheat revention(Induction art);
cookware sensor (induction art) automatic shut-off when 2 hours not in use; and
auto-tem erature adjustment etc.
 Easy-to-clean Surface

Ceramic glass to anel is easy to clean. When the high
tem erature indicator is off and the surface is cool down after cooking, wi e it with a
dam cloth.

Notice : The surface at infrared zone is under a very high temperature condition
after cooking, please do not place any combustible materials on the surface and touch
the surface to avoid any risk of fire and getting burnt

 Touch Buttons Operation

Touch button design is easy for use.
 Intellectual Power

The electric hob ado ts intellectual ower distribution technology
and the s ecified ower can be distributed to each cooker zone by the micro-com uter
system.

3
2、Installation Guideline
★ Installation should be followed below requirements：

The walls on to of the working face and next to the installation of the electric hob must
be heat- roof.

The laminated boards and adhesive used for installation must be heat-resistant.

For any installation method, the air under the electric hob and behind the cooking range
should have enough s ace for cooling in order to ensure the safety of o erating the
electric hob.

Based on the rescribed dimensions, a square hole is o ened on the work table. Ensure
the distance between any side of the work table and the walls is

100mm.

Protect the o ening: If in contact with dam , the laminated boards used in marking the
work table will easily ex and more. It is required to stick varnish or s ecial adhesive onto
the edge of the o ening in order to revent any steam from condensation under the work
table.

For any condition of installation, the electric hob should have a good ventilation condition
with air inlet and air outlet not blocked.

Don’t lace other equi ments on the working face of the double cooking zones of the
electric hob and within the range of 30cm around the working face.

If choosing a table-to installation, ventilation hole shall be at least 100mm from wall
surface.

The electric hob must be com lied with a 13A ower outlet.
★ Ste s on Installation：
~ O en an installation hole on the workto of cabinet as er

illustration 1

.
(Note : The height shall be more than 100mm)
Cut out dimensions(unit/mm)

(W) 670 x (D) 350 x (H) 100

illustration 1

* If the installation hole on the work table is a new o en, it is recommended a de th
to 370mm and ut the electric cooker into the hole at front side so at to have a good
ventilation condition.

4
~ In front of the cabinet, o en an air inlet with more than 100cm2 under the location of the
electric hob as er

illustration II

. If the cabinet is not sealed, the air inlet may not be o ened
so as to ensure heat elimination.

illustration II

~ Before ut the electric hob into the hole, an water- roof ty e is ro erly a lied on the
bottom of front anel of the electric hob as er

illustration III

. If the old size of the hole is
large than the current size of cutting hole, a double side ty e can be used to fix the movement
between the electric hob and workto .

illustration III


5
~ Put the electric hob into hole. Insert lug of ower line into corres onding socket. The
electric hob can be used after ower connection as er

illustration IV

.

illustration IV

~ If the electric hob is installed above an oven, fix an insulation art at least 150mm under the
electric hob as er

illustration V

. Also, o en an air inlet with more than 100cm2 under
the location of the electric hob to ensure ventilation and o eration in good conditions
 
 !"#

6
3、Control Panel Instruction

Cooking Zone


Control Panel

11 10 9 8 7 6 5 4 3 2 1
1…On/Off 2…On/Off Indicator
3…Plus Key –Timer 4…touchSlider bar – Power
5…Minus Key – Timer 6…LED Digital Indicator
7…High Tem erature Indicator 8…Timer Key
(A ly for Infrared Cooker Only)
9…Time Indicator 10…Lock Key
11…Lock Indicator

7
4、Operation Method
4.1、Operation Instructions：
 Power Connection

After ower connection, buzzer will make a short sound and the
electric hob kee s at the stand-by mode. LED digit will show (- - - - ).
 On switching

Place cookware on heating zone (Pls. refer to Usable and Non-usable
Cookware), by ressing the “ON/OFF” key, buzzer will make a short sound and the
on/off indicator will be on. LED digit will show the re-set ower level “4”.
 Power Level Alteration

At the ower function, touch the sliderbar from left to right
side to increase the ower level or decrease the ower level from right to left side. LED
digit shows set ower level.
(Note : This electric hob ado ts intellectual ower distribution technology. When the ower
level of a cooking zone is increased and total ower level exceeds s ecified value, the
micro-com uter system will automatically decrease ower level of another cooking zone so
as to assure total ower is under s ecified value.)
 Selecting Timer

By ressing
$
Timer
%
key, the time indicator will be on. At the time, by
ressing
$&%
Or
$'%
key to set the required time. The o erational setting range is
between 1 min. and 3 hrs 59 min. (Dis lay form in
(
hrs : mins
)
) After setting, the LED
will show the required time. When set time is reached, buzzer will make a long sound
and the electric hob sto s heating. To cancel time setting, set the timing to “ZERO”.
 Lock Function

By ressing the
$
Lock
%
key, buzzer will make a short sound and a red dot
will be on. At this time, all keys will be locked in order to avoid mis-o eration. By
ressing
$
Lock
%
key 3 min. again, buzzer will make a short sound and a red dot will be off.
The electric hob will be locked automatically after 15 seconds when switching off. For
restarting the electric hob, by ressing the
$
Lock
%
key 3 min. again, buzzer will make a
short sound and the red dot will be off, then by ressing the
$
ON/OFF
%
key to enter the
normal cooking mode by other function keys.
 High Temperature Indicator

After cooking, the
$
High tem erature indicator
%
will be
on and flicker, that means the tem erature on the heating zone is over 70
*
c. At this time,
the heating zone is under a very high tem erature condition, lease do not attem t to
lace any combustible materials on the heating zone and touch the heating zone to
avoid any risk of fire and getting burnt.
+
 Off Switching

During heating, by ressing
$
ON/OFF
%
key to switch off.

8
4.2、Usable and Non-usable Cookware：
1. Please refer to below information to select a suitable cookware cater for all delicious
cuisine by the infrared cooker.
 Most of materials for a flat bottom cookware are suitable for use of the infrared cooker,
such as stainless steel ot, iron ot, aluminum ot, ceramic ot and glass ot etc. The
diameter of the flat bottom cookware is within 12-24 cm. For a good effect, it is
recommended for an around 22 cm in diameter and de ends on the thickness of the
cookware at the flat bottom.
 It is normal that feeling hot from the heating zone if the flat bottom cookware does not
cover the circle on the heating zone because it will release far infrared rays when cooking.
2. Please refer to below information to select a suitable cookware cater for all delicious
cuisine by the induction cooker.
Usable Cookware Non-usable Cookware

Materials

Iron, cast iron, stainless steel
and enamel cookware.

Materials

Cookware made of
ottery,
aluminum, glass, co er or bronze.

Shape and size

The diameter more than
120mm (4.5 inches) are recommended.

Shape and size

The bottom diameter of
the cookware is less than 120mm (4.5
inches). And, the cookware with curved
bottom, with concave bottom (the concave
de th
,
4mm) or with legs (the
height
,
4mm).

Sorts of suitable cookware

Stainless
steel kettle, iron tray, bottom an, iron ot,
iron tray, enamel ot etc.

Sorts of un
-
suitable cookware

Co er,
bronze and aluminum ot, glass ot,
ottery ot, bronze an etc.

 It is normal that sound
$
ze..ze..
%
from the cookware when heating.
  !"#
3. The cookware is laced in the center of the circle at the heating zone.

9
4.3、Heating Power Distribution：
When two single zones are o erating in the same time, the total ower level is u to 7.
However, the ower of one single zone will reduce automatically when the other zone is
being cooking so as to maintain the total ower level will not exceed 7.
Infrared Zone
Induction Zone
Level
Power
Level
Power
7
2
3
00W
0
0W
6
2000W
1
600W
5
1
7
00W
2
1000W
4
1400W
3
1400W
3
1
1
00W
4
1600W
2
8
00W
5
1800W
1
4
00W
6
2200W
0
0W
7
2800W

10
5、Safety Precautions
5.1 Safety Notes：
 No other objects then cookware to be laced on the calefaction area.
 Do not insert any objects like iron wire etc. into the vent in order to revent any electric
shock.
 Do not ut anything to block the air outlet
-
 Do not heat u uno ened tins of food on the heating zone as ressure will build u in the
tin and it can ex lode, which in turn could result in injury and scalding or damage.
 Do not use the electric hob in a high tem erature environment. Kee it far away from
fire.
 Always kee children away from the electric hob.
 Kee a distance between the water su ly and the electric hob, to revent any electric
shock and interference or malfunction on function of the electric hob.
 Water or lliquid on the control anel will affect interference or malfunction on function of
the electric hob.
5.2、Warning：
 The electric hob must not be installed over any metal work to or electrical a liances
such as dishwasher, oven, and fridge etc.
 Do not lace metallic objects such as knives, forks, scoo s or s oons on the electric hob,
calefaction area in order to revent any danger caused by high tem erature
 The late of the electric hob is hot after cooking; do not touch the heating area by hand
until the high tem erature indictor is off or the glass surface has cooled down.
 If ower wire is broken, you must shut off the ower su ly immediately and contact our
After Sales Service rofessional to change the broken wire. User does not allow re airing
by yourself, otherwise the maintenance of the electric hob will be invalid.
 Do not smash the glass surface, switch off the electric hob when the glass surface is
cracked.

11
6、Daily Maintenance
 Clean the electric hob only when it has cooled down.
 Do not ut any tinder of acid or alkaline materials near the electric hob in order to avoid
the electric circuits inside the stove from the erosive damages of acidity and alkali which
can affect the life s an of the electric hob.
 Never use a steam cleaner or aggressive or abrasive detergent to clean the electric hob.
 Do not wash the electric hob directly with water.
 When cleaning the ceramic surface, wi e all coarse soiling off using a dam soft cloth
and a ly a few dro s of ro rietary-cleaning agent for ceramic surfaces.
 Do not let the bottom of the electric hob rubs the glass surface of the working area so as
to revent lacerating. (The laceration of the glass surface of the working area does not
affect the normal o eration of the electric hob).
 The air inlet should be cleaned regularly in order to have a good ventilation
condition.
 Be sure to remove stains from the bottom of cookware. Otherwise, the stains will be
scorched and stuck on the to late.
7、Product Specification
Description Intelligent 2-in-1 Electric Hob
Model EC-2989
Power Supply AC220-240V/50Hz
Total Rated Power 2800W
Overall Dimension(W x D x H) 750 x 450 x 65 mm
Net Weight 10 Kg

12
8、Trouble-shooting Guideline
8.1、Code Of Breakdown：
In case of im ro er installation or use, abnormal ower su ly or breakdown of the electric
hob, the LED digit on front anel will dis lay code of breakdown.
Infrared Cooker:-
Code of breakdown Root cause of breakdown
E4 Failure of heater tem erature sensor
E5 High ower voltage
E6 Low Power voltage
Induction Cooker:
Code of breakdown Root cause of breakdown
E0 Failure of Circuit
E1 Cookware not be sensed on the cooking zone
E2 High tem erature inside induction heater
E3 Failure of heater tem erature sensor
E4 Failure of IGBT tem erature sensor
E5 High ower voltage
E6 Low Power voltage

13
8.2、Trouble Shooting：
Garwoods’s electric hob has ado ted the most advanced micro-com uter ins ection and
control technology. Some henomena a eared in the course of working may not indicate
roblems to occur.
Please check the electric hob according to the follow s ecifications

Situation Reason Solution
Infrared Cooker:-
No ower for the light
indicators
The ower cord may not be
ro erly connected to ower
outlet
Check the ower cord if it has
been connected or not
Auto- ower off during
working of roduct
1. The inlet of fan is off.
2. The fan sto s working.
3. The surrounding
tem erature is too high.
Pls. check if there is some
heating device nearby.
4. The tem erature of the
stuff being heated rises
too high.
5. Errors of timer setting
1. Clean and remove the stuff
in the inlet of fan.
2. Ask hel from a
rofessional service
technician.
3. Im rove the ventilation.
4. Im rove the ventilation.
5. Power off and re-start the
roduct
Induction Cooker:-
The heater works for a while
and sto , indicating
.
E1
/
1. No cook ware ut on the
cooking zone
2. Non-usable cookware is
used
1. Put the cookware on the
cooking zone
2. Refer to
.
Usable and
Non-usable cookware
/
in
the o eration manual
The heater works for a while
and sto s, indicating
.
E2
/
.
1.
The inlet of fan is off.
2.
The fan sto s working.
3.
The surrounding
tem erature is too high.
Pls. check if there is some
heating device nearby.
4.
The tem erature of the
stuff being heated rises
too high.
5.
The outlet ventilation is
off.
1. Clean and remove the
stuff in the inlet.
2. Ask hel from a
rofessional service
technician.
3. Im rove the ventilation.
4. Remove the cause for
fry heating and continue
to use the electric hob
after the calefaction
area is cooling down.
5. Ins ect the outlet
ventilation condition.
The heater works for a while
and sto , indicating
.
E3
/
or
.
E4
/
.
The tem erature sensor
breakdown.
Ask hel from a rofessional
service technician.

14
一、 產品簡介---------------------------------------------------------------- 15
I . 產品介紹
II . 性能特點
二、 產品安裝說明--------------------------------------------------------- 16-18
三、 控制面板說明----------------------------------------------------------- 19
四、 產品操作說明----------------------------------------------------------- 20-22
I . 操作說明
II . 鍋具的選擇與使用
III. 火力功率及功率 配說明
五、使用注意事項--------------------------------------------------------- 23
I . 安全注意事項
II . 警告
六、日常 養注意事項--------------------------------------------------- 24
七、產品規格--------------------------------------------------------------- 24
八、維修指南--------------------------------------------------------------- 25-26
I . 錯誤代碼
II . 簡易故障的判別和排除
目錄

15
一、產品簡介
I、產品介紹
多謝選購Garwoods 2合1電能煮食爐。本產品採用兩種不同加熱原理，左爐區為電
陶爐及右爐區為電磁爐，由先進微電腦控制，輕觸式操作，安全耐用，適合各種
不同的烹飪需求，是現代家庭廚房的理想之選。請在安裝及使用本產品之前閱讀
本說明書。
II、性能特點
 節能效益： 本產品應用全新加熱原理。電陶爐部份採用紅外綫加熱，高熱
效率，節能環保。在使用烹調食物過程中，更可因應情况下截
斷電源利用爐面產生餘下的高温而作短暫烹煮，以達到節省燃
料之效果。而電磁爐部份，同樣是節能環保。因為電磁爐直接
傳熱至鍋具底部，而且熱效率高達
012
。
 齊全功能： 本產品採用最新微電腦晶片程式操作，具有多段火力功率調
節，方便實用。
 環保安全： 本產品在設計上充 考慮使用者的安全及環境保護。爐設有
安全功能，如安全鎖、餘温警告指示燈(電陶爐部份)、過熱保
護裝置(電磁爐部份) 、鍋具檢知功能(電磁爐部份) 、2小時靜
止操作及自動調温功能等。
 容易清潔： 高級耐熱微晶玻璃面板、易潔耐用。烹調後，待餘温警告指
示燈熄滅及玻璃面板冷卻，才可進行清潔。
3456789:;<=>?@ABCDEFG>HIJK LMNOP
QRST?@>UVWXYZ[\]^_
 輕觸式操作： 輕觸式設計，只需要用手指輕輕觸摸玻璃控制面板上功能鍵
即可，簡便易用。
 智能功 ： 本產品採用智能功率 配技術。由微電腦根據用戶使 用狀
况，將規定的總功率 配到每個爐頭。

16
二、產品安裝說明
★安裝須遵守以下說明要求：
1、 工作枱面及靠近電能煮食爐的牆壁必須是耐熱的。
2、 用於安裝電能煮食爐與廚櫃的層板和膠黏劑必須是耐熱的。
3、 在任何安裝方式中，應確保爐具底下及爐面後側能徹底散熱，以確保安
全。
4、 按規定尺寸在枱面上開一個安裝孔，同時確保任何一面距牆面距離至少
100mm。
5、 安裝孔防水保護：若與濕氣接觸，製作廚櫃所用的層板相對容易脹，在
開口邊緣塗上透明漆或專用膠黏劑，可防止水氣滲入造成篜氣在廚櫃枱面
下產生冷凝。
6、 在各種安裝條件下，電能煮食爐都需要良好的通風，要確保進氣口和出氣
口不會被堵塞。
7、 電能煮食爐爐面四周及爐面垂直上方300mm的範圍內不要設置其它設備。
8、 如選擇座檯式安裝時，亦須確保排風口距離牆壁至少100mm。
9、 使用此型號電能煮食爐時必須配備13安培獨立開關掣或固定接線座。
★安裝步驟
1. 在需安裝電能煮食爐的廚櫃枱上按照【安裝圖 一】尺寸開一安裝孔
（注意：高度距離枱面需超過100mm）。
開孔尺吋(單位/mm)：(闊) 670 x (深) 350 x (高) 100
【安裝圖 一】
* 如屬新枱面開孔，開孔深度可開至370亳米，並將電能煮食爐緊貼枱面前方放進
孔內以預留背部較多散熱空間。

17
2. 在櫥櫃前側電能煮食爐放位置的下方開出一個大於100c㎡的進風口如【安裝
圖二】 以確保電能煮食爐有足夠的散熱，如果櫥櫃不是密封式的，可以不
開此口，但電能煮食爐下方不可有任何雜物堵窒通風。
【安裝圖 二】
3. 安裝電能煮食爐在櫥櫃枱面前，必須將隨爐具所附的防水膠條如【安裝圖 三】，
貼在面板下方的四邊。如原枱面開孔大於本產品開孔尺吋，應使用雙面貼貼
在底盤四邊，以固定爐具與枱面而避免產生移動。
【安裝圖 三】

18
4. 將貼好防水膠條的電能煮食爐放入枱面開孔中如【安裝圖 四】，然後將電源
線插頭插入對應的插座中，通電即可正常使用。
【安裝圖 四】
5. 如安裝電能煮食爐在烤箱上方時，櫥櫃內電能煮食爐與烤箱中必須加裝一個
隔熱板如【安裝圖 五】隔熱板與電能煮食爐底部至少有150mm的距離：電
能煮食爐安裝位置的前側必須開出一個大於100c㎡的進風口以確保電能煮食
爐與烤箱能夠有足夠的通風。
【安裝圖 五】
六、鍋具的選擇與使用

19
三、控制面板說明

加熱區


功能鍵

11 10 9 8 7 6 5 4 3 2 1
`
開關鍵
`
開關指示燈
`
調高鍵 -
a
定時
b `
輕觸滑動操控條碼- (
cdb
`
調低鍵 -
a
定時
b `
LED數碼顯示區
`
餘温警告指示燈
aef#ghijb `
定時鍵
`
定時指示燈
k`
安全鎖鍵
`
安全鎖指示燈
