Gateway 3100 Series User manual

SPECIFICATIONS
1
www.gateway.com
Gateway 3100/3600 Series
Notebook
Specifications are subject to change without notice or obligation.
Processor and Core Logic
Processor options ■One Intel®Celeron™ M CPU
-OR-
■One Mobile Intel®Pentium®M CPU
To determine your notebook’s processor, click Start, My Computer,
then click View System Information. The processor is listed.
Processor packaging 478-pin uFCPGA
Level 2 cache ■512 KB or 1 MB (Celeron M)
-OR-
■1 MB or 2 MB (Mobile Pentium M)
Chipset-Northbridge ■Intel 910GML (Celeron M)
-OR-
■Intel 915GM (Pentium M)
Chipset-Southbridge Intel ICH6-M
Processor side bus speed ■400 MHz (Celeron M)
-OR-
■400/533 MHz (Pentium M)
BIOS ■Phoenix BIOS
■8 MB Flash ROM
■SMBIOS 2.3 support
■Advanced Configuration and Power Interface 2.0 (ACPI 2.0)
support
■Wired for Management 2.0 (WfM 2.0)

2www.gateway.com
System memory
Memory type 400/533 MHz DDR2 SDRAM
Memory expansion options ■Two 200-pin industry standard DDR-SODIMM sockets
■Accepts two 400/533 MHz DDR2 SDRAM memory modules in
memory bay
■2 GB maximum system memory
■Dual channel
To determine your notebook’s memory, click Start, My Computer,
then click View System Information. The memory is listed.
Video
Graphics controller Intel Graphics Media Accelerator (GMA) 900
■2D hardware acceleration
■3D rendering acceleration
Video memory Shares system memory: 32, 64, or 128 MB
LCD panel 12.0-inch or 14.0-inch active matrix (TFT) LCD color display
Maximum panel resolution (12.0-inch): 1280 ×800
Maximum panel resolution (14.0-inch): 1280 ×768
Maximum color depth: 32-bit (16.7 million colors)
LCD supported video modes WXGA
LCD maximum refresh rate 60 Hz
Controls ■Brightness level selectable through FNkeys (up, down)
■Auto dim on battery and auto bright on AC power (selectable in
BIOS)
External video Supports dual display and dual view
External CRT resolutions Supports standard IBM VGA compatible modes
Maximum resolution: 2048 ×1536
Maximum color depth: 32-bit colors
External CRT maximum refresh rate 85 Hz

3
www.gateway.com
Audio
Sound support ■Conexant SmartAMCi Audio Modem Codec (AMC) CX20468-31
■AC ’97 Revision 2.3 Compliant
NOTE: This notebook does not support S/PDIF.
NOTE: This notebook does not have an internal microphone.
Volume controls ■Digital volume control toggle (press toggle in to mute the sound)
■Software control provided through Windows
Internal speakers ■Stereo speakers built into the sides of notebook
■1.0 W/4 ohm maximum output for each channel
Audio jacks ■Stereo headphone output
■Stereo microphone input
Communications
Modem features ■Conexant CX20493-21
■56K v.92 Soft Modem
■Uses the RJ-11 jack on the left side of the notebook
■Supports Wake on Ring from S3 power mode
Wired Ethernet interface features ■PCI-E 10/100/1000
■Integrated IEEE 802.3 (10/100/1000 BASE-TX) Ethernet interface
■Uses the RJ-45 jack on the rear of the notebook
■Supports Wake on LAN from S3 power mode
Wireless Ethernet interface features
(Factory installed option)
■Intel®PRO/Wireless IEEE 802.11b/g network card, Mini-PCI
(Pentium M models only)
-OR-
■Broadcom IEEE 802.11g network card, Mini-PCI (Celeron M
models only)
FN+F2 keyboard combination toggles wireless networking
Antenna: Uses factory-installed diversified internal antenna
Operating channels: 11 channels in the United States and Canada
Security: 128 and 64 bit WEP encryption, WPA, and WPA2
Operating Frequency: 2.4 GHz Direct Sequence Spread Spectrum
(IEEE 802.11b and IEEE 802.11g)
Maximum Data Rate
■54 Mbps (IEEE802.11g)
■11 Mbps (IEEE802.11b)

4www.gateway.com
Input/Output (I/O)
Keyboard ■U.S. English keyboard
■Full-sized 86-keys
■19 mm × 19 mm key pitch
■3.0 mm key travel
Pointing device ■Gateway EZ-Pad™ touchpad with vertical scroll
■2-button design
Status indicators FN+F1 keyboard combination turns status indicators on and off.
■AC power
■Wireless Ethernet
■Caps lock
■Num lock
■Hard drive access
■Power/battery charge
Input/Output (I/O) ports ■Three USB 2.0 (4-pin)
■IEEE 1394 (4-pin)
■V.92, 56K Modem (RJ-11)
■10/100/1000 Ethernet (RJ-45)
■External monitor (VGA)
■Stereo headphone output
■Stereo microphone input
■PC Card socket (one Type II)
■DC input
■Docking port
PCMCIA ■Accepts one Type II device
■TI PCI-7411 controller
NOTE: This notebook does not support Zoom Video.

5
www.gateway.com
Docking solution
Type Cabled port replicator
Docking supported ■Hot dock
■Warm dock
■Cold dock
Input/Output (I/O ports) ■Three USB 2.0 (4-pin)
■Stereo headphone output
■IEEE 1394 (4-pin)
■Parallel (printer)
■High-speed serial
■External monitor (VGA)
■Ethernet (RJ-45)
■DC input
■Docking cable
AC adapter ■19 VDC, 4.74A, 90 W output
■Automatically adjusts for 100 to 240 VAC, 50 to 60 Hz power
sources
■Two-prong design
Storage
Hard drive ■User removable
■2.5-inch diameter
■9.5 mm height
To find the hard drive capacity, click Start, then click My Computer.
Right-click the drive letter, then click Properties. The drive’s capacity
and available space appears. If the drive has multiple partitions (for
example, C: and D:), add the capacities of each partition to
determine the drive’s total capacity.
Memory card reader Supports the following card types:
■Memory Stick®
■Memory Stick Pro®
■MiniSD™
■MultiMediaCard™
■RS-MMC (Reduced Size MultiMediaCard™)
■Secure Digital™
Optical drive
(factory installed)
Available drives include:
■Combination DVD/CD-RW
■DVD±R/±RW drive
To determine the type of optical drive in your system, examine the
drive tray’s plastic cover. A DVD logo in combination with a CD-R/RW
logo indicates a DVD drive that also is a recordable/rewritable CD
drive, and a DVD+ReWritable logo in combination with a CD-R/RW
logo indicates a recordable/rewritable DVD drive that also is a
recordable/rewritable CD drive.

6www.gateway.com
Power
AC adapter ■19 VDC, 3.42A, 65 W output
■Automatically adjusts for 100 to 240 VAC, 50 to 60 Hz power
sources
■Two-prong design
Battery type ■Removable Lithium Ion battery pack
■Embedded controller inside to support SBS 1.1
Battery capacity 4-cell Li-Ion
■2.0 Ah
■14.8 V nominal
■29 Wh
6-cell Li-Ion
■4.4 Ah
■11.1 V nominal
■48 Wh
9-cell Li-Ion
■6.6 Ah
■11.1 V nominal
■72 Wh
12-cell Li-Ion
■6.6 Ah
■14.8 V nominal
■98 Wh
Battery life varies depending on configuration, programs, power
management settings, and features used. Recharge time varies,
depending on usage.
Power management ■Advanced Configuration and Power Interface 2.0 (ACPI 2.0)
support
■SMBIOS 2.3
■PC 2001 compliant
■CPU may support Intel®Speedstep™ technology
Controls Icon on taskbar shows battery charge as a percentage remaining
Power switch Supports Power On/Off, Standby/Resume, Hibernate using
Windows Setting, Shutdown
Lid switch LCD On/Off, Standby, Hibernate

7
www.gateway.com
Security
Passwords ■Power-on password (user/supervisor password set in BIOS)
■Hard drive password
Physical ■Main system memory compartment screw
■Hard drive kit screws
■Mini PCI bay screw
■Kensington®security slot on notebook back
System software
Operating system ■Microsoft®Windows®XP Professional
■Microsoft®Windows®XP Home Edition
System management ■SMBIOS 2.3 BIOS support
■Advanced Configuration and Power Interface 2.0 (ACPI 2.0)
support
■Support for Wake on LAN from S3 power mode
■Support for Intel®LANDesk®Client manager 6.0
■Wired for Management 2.0 (WfM 2.0) enabled
System compatibility ■PC2001 specification
■SMBIOS 2.3
■Windows Hardware Quality Labs (WHQL) certified
Quick boot Supported
Physical specifications
Dimensions ~13.00 ×9.7 ×1.24 in. (W ×D×H)
~330 ×246 ×31. mm (W ×D×H)
System weight ~4.99 lbs. (~2.26 kg)
Includes optical drive and battery
AC adapter weight ~8.0 ounces (~250 g)
Includes cord
Environment
Operating temperature 50°F to 90°F (10°C to 32°C)
Storage temperature 4°F to 140°F (-15°C to 60°C)
Operating humidity 20% to 80% relative humidity; no condensation
MAN 3100/3600 SER SPECS 6/05
