Gateway M505 User manual

www.gateway.com
Specifications for the
Gateway M505 Notebook
Specifications are subject to change without notice or obligation.
Processor and Core Logic
Processor options Mobile Intel®Pentium™ Processor-M CPU
To determine your notebook’s processor speed, click
Start, My Computer, then click View System
Information. The processor is listed.
Processor packaging Intel uFCPGA
Level 2 cache 1 MB
Core logic Intel®855PM, ICH4M
Processor side bus speed 400 MHz Processor System Bus
BIOS ■Phoenix Note BIOS Release 6
■512 KB Flash ROM
■SMBIOS 2.3 support
■Advanced Configuration and Power Interface 1.0b and
2.0 (ACPI 1.0b and 2.0) support
System memory
Memory type 266/333 MHz DDR SDRAM
Memory expansion options ■Two 200-pin industry standard DDR-SODIMM sockets
■Accepts two PC-266/333 DDR SDRAM memory
modules
■2048 MB maximum system memory
■No on-board memory
To determine your notebook’s memory, click Start, My
Computer, then click View System Information. The
memory is listed.
Video
Graphics controller ATI®Mobility™ Radeon™ 9600 high-performance
graphics chipset
Video memory 64 MB frame buffer

2www.gateway.com
LCD display panel 15.4-inch 16:10 WXGA (Wide eXtended Graphic Array)
widescreen TFT LCD panel
Maximum panel resolution: 1280 ×800 (WXGA)
Maximum color depth: 32-bit (16.7 million colors)
LCD supported video modes WXGA
LCD maximum refresh rate 60 Hz
Controls ■Brightness level selectable through FNkeys (up, down)
■Auto dim on battery
■Auto bright on AC power
External video Supports dual display and extended desktop
External CRT resolutions Supports standard IBM VGA compatible modes
Maximum resolution: 2048 ×1536
Maximum color depth: 32-bit (16.7 million colors)
External CRT maximum refresh rate 75 Hz
TV out (S-Video) jack Supports NTSC/PAL connection to standard TV monitors
with S-Video jack
IEEE 1394 ■One 6-pin connector and one 4-pin connector
■100/200/400mbps
■Supports video and audio capture
■Software included for motion and still-frame capture
Audio
Audio chipset Realtek ALC655 AC97 rev 2.3 audio codec
Sound support SoundBlaster Pro, MIDI, Windows Sound System
compatible, MP3, WMA
Volume controls ■Volume control buttons on palm rest
■Software control provided through Windows
Internal speakers ■Stereo speakers built into palm rest
■Subwoofer built into bottom of notebook
Internal microphone Omni-directional, low impedance
Audio jacks ■Combination stereo headphone output and S/PDIF line
output
■Stereo line input
■Monophonic microphone input

3
Specifications for the Gateway M505 Notebook
www.gateway.com
Communications
Modem features ■Agere integrated V.90/56K data/fax modem
■Uses the RJ-11 jack on the back of the notebook
■Supports Wake on Ring from S3 power mode
10/100 Mbps Ethernet interface
features
■Realtek RTL8139 Integrated IEEE 802.3 (10/100)
Ethernet interface
■Uses the RJ-45 jack on the back of the notebook
■Supports Wake on LAN from S3 power mode
Wireless Ethernet interface features ■Intel®IEEE 802.11b network card embedded in the
notebook
-OR-
■Intel®PRO/Wireless IEEE 802.11b/g network card
embedded in the notebook
Antenna: Uses factory-installed internal antenna
assembly
Operating channels: 11 selectable channels
Security: 128 and 64 bit WEP encryption
Operating Frequency: 2.4GHz Direct Sequence
Spread Spectrum
Maximum Data Rate: 11 Mbps
Input/Output (I/O)
Keyboard ■U.S. English keyboard
■Full-sized 84-keys
■19 mm × 19 mm key pitch
■2.7 mm keystroke
Pointing device ■Gateway EZ-Pad™touchpad
■Synaptics driver
■2-button design
Multifunction buttons Five “hot keys” that turn on and off wireless Ethernet
emitter, and launch e-mail, Web browser, and two
programs selected by the user

4www.gateway.com
Status indicators Above keyboard
■Wireless Ethernet
■Power
■Standby
■Hard disk/Optical disc access
■Battery status
■Caps lock
■PA D l o c k
On LCD panel
■Wireless Ethernet
■Power
■Standby
Input/Output (I/O) ports ■Three USB 2.0 (4-pin)
■Parallel (bi-directional, EPP, ECP)
■IEEE 1394 (4-pin)
■IEEE 1394 (6-pin)
■V.90, 56K Modem (RJ-11)
■10/100 Ethernet (RJ-45)
■External monitor (VGA)
■S-Video TV out
■Combination stereo headphone output and S/PDIF line
output
■Stereo line input
■Monophonic microphone input
■PC Card socket (one Type II)
■DC input
PCMCIA/CardBus ■Texas Instruments PCI4510 controller
■Accepts one Type II device
NOTE: This notebook does not support Zoom Video.
Storage
Hard drive controller Intel 82801 DBM Ultra ATA
Hard drive ■User removable
■2.5-inch diameter
■9.5 mm height
To find the hard drive capacity, click Start, then click My
Computer. Right-click the drive letter, then click
Properties. The drive’s capacity and available space
appears. If the drive has multiple partitions (for example,
C: and D:), add the capacities of each partition to
determine the drive’s total capacity.
Super I/O controller SMSC™LPC47N227

5
Specifications for the Gateway M505 Notebook
www.gateway.com
Memory card reader Supports Secure Digital™
Combination DVD-RW/CD-RW or
DVD/CD-RW
Slot-loading
Power
Intelligent charger Supports dynamic charge current to achieve the best
charge performance
AC adapter ■19 VDC, 3.16A, 60 W output
■Automatically adjusts for 100 to 240 VAC, 50 to 60 Hz
power sources
■Three-wire design
Battery type ■Removable Lithium Ion battery pack
■Embedded controller inside to support smart battery
Battery capacity 8-cell Li-Ion
■4400 Ah
■14.8 V nominal
■65.12 Wh
Battery life varies depending on configuration, programs,
power management settings, and features used.
Recharge time varies, depending on usage.
Power management
Controls Icon on taskbar shows battery charge as a percentage
remaining
Power switch Power On/Off, Suspend/Resume, or Hibernate
Lid switch LCD On/Off, Suspend/Resume, or Hibernate
Security
Passwords ■Power-on password (2-level password support)
■Hard drive password
Physical ■System memory compartment screws
■Hard drive kit screw
■Kensington®security slot on notebook sides
System software
Operating system ■Microsoft®Windows®XP Professional
■Microsoft®Windows®XP Home Edition

6www.gateway.com
System compatibility ■PC2001 specification
■Advanced Configuration and Power Interface 2.0
(ACPI 2.0) or later
■SMBIOS 2.3
■Windows Hardware Quality Labs (WHQL) certified
Quick boot Supported
Physical specifications
Dimensions ~1.38 ×13.93 ×10.04 in. (H ×W×D)
~35 ×354 ×255 mm (H ×W×D)
System weight ~7.1 lbs.
~3.2 kg
Includes battery
AC adapter weight ~1 lbs
~0.45 kg
Includes cord
Environment
Operating temperature 41°F to 95°F (5°C to 35°C)
Storage temperature 14°F to 149°F (-10°C to 65°C)
Operating humidity 20% to 80% relative humidity; no condensation
Storage humidity 20% to 80% relative humidity; no condensation
MAN SYS M505 SPEC R1 03/04
