GB Instruments GMT-19A User manual

Analog Multimeter
Owners Manual Model
• Read this owners manual thoroughly before
use and save.
Gardner
Bender
GMT-19A

GMT-19A
OHMS ADJUST
1000V DC/AC
500mA DC
MAX
O
H
M
S
1000
250
50
10
2.5
500m
50m
5m
1000
250
50
10
1.5V
AA
9V
X1K
X10
X1
DC10A
A
C
V
D
C
V
D
C
A
+
–
DC10A
V.Ω.A.
COM
20KΩ/V DC
8KΩ/V AC
1K 100
200
50
500
2K
000
AC
DC
50 100 150
200
250
10
20 30
40
246850
10
AC
dB
DC
dB
BAT
20
10
0
Ω
Ω
BAT
G
O
O
D
?
-80+6+12+16+18+20
+22
∞
R
E
P
L
A
C
E
5K
10 K
+14
O
H
M
S
O
H
M
S
2
1. Meter Functions
Function/
Range
Selector
Switch
Figure 1
Insulated
Test
Leads
Zero
Adjust
Screw
Input Jacks
1.0 Meter Functions
Zero
Ohms
Adjustment
1.0 Meter Functions
2.0 Specifications
2.1 For Your Safety
3.0 Operating Suggestions
3.1 Preliminary Adjustments
3.2 Internal Battery Condition
4.0 DC Voltage Measurement
4.1 Automotive Batteries
4.2 Alternators and Generators
4.3 Household Batteries
5.0 DC Milliamp Measurement
6.0 AC Voltage Measurement
6.1 Wall Receptacles
6.2 Appliance Receptacles
6.3 Circuit Breaker Panels
7.0 Resistance/Continuity Measurement
7.1 Extension Cords
7.2 Appliance Cords
7.3 Fuses
7.4 Switches
7.5 Heating Elements
7.6 Thermostats
8.0 Decibel Measurement
9.0 Battery and Fuse Replacement
1
Table of Contents

4
WARNING! Use extreme caution when using
this multimeter. Improper use of this tester can
result in severe damage to property, severe
personal injury or death. Follow all instructions and
suggestions in this operators manual as well as
observing normal electrical safety precautions. Do not
use this multimeter if you are unfamiliar with electrical
circuits and proper test procedures.
2.1 For Your Safety
1) WARNING! Use extreme caution when checking
electrical circuits.
2) WARNING! Do not stand in wet or damp work
areas when working with electricity. Wear
rubber soled boots or shoes.
3) WARNING! Do not apply more voltage or
current than the set range of the multimeter
will allow.
4) Do not touch the metal probes of the test leads when
making a measurement.
5) Replace worn test leads. Do not use test leads with
broken or tattered insulation.
6) Discharge a capacitor before measuring it.
7) Remove the test leads from the circuit being measured
as soon as the test is completed.
8) WARNING! Do not measure voltage when the
function/range switch is set on the resistance
(ohms) or the current (mA) settings. Never measure
current when the tester is set on the resistance range.
Never measure AC voltage when the tester is set on
DC voltage or DCmA/A. Setting the tester on the
incorrect function may burn out some of the internal
circuitry and may pose a safety hazard.
3
Ranges: 19 measuring ranges
DC Voltage: 2.5-10-50-250-1000 Volts
AC Voltage: 10-50-250-1000 Volts
DC Current 5-50-500 milliAmps (fused)
10 amps on a separate jack (unfused)
Resistance (ohms) Rx1 (resistance indicated multiplied by 1)
Rx10 (resistance indicated multiplied by 10)
Rx1K (resistance indicated multiplied by 1000)
10 Megohm Max
Continuity Buzzer: For audible continuity checks. Buzzer sounds at
less than 100 ohms.
Decibels: -8dB to +22dB on AC voltage ranges
Accuracy: DC voltage, Amps = 4% full scale of range
AC voltage = 5% full scale of range
Resistance = 4% full scale of range
Battery Test: 1.5 volt and 9 volt batteries
Sensitivity: 20,000 ohms per volt DC and 8000 ohms per
volt AC
Operating Temperature: 64°F – 77°F (18°C – 25°C)
Function/Range Switch: 6 Functions
20 Positions
19 Measuring ranges
Zero Ohms Adjustment Dial: Located on the front left side of the housing.
Adjustment dial is used to zero the needle
indicator on the ohms scale while shorting the test
leads together.
Mechanical Zero Located directly below the center of the scale,
Adjustment Screw: used to align needle on the zero settings for
accurate readings.
Mirrored Scale Plate: The mirror on the scale plate is used to line up the
needle with its reflection to improve the reading
accuracy by preventing parallax error.
Recessed Input Jacks: Negative (-) input jack for black test lead, positive
(+) input jack for red test lead. Separate jack for
10 Amp range.
Important:
Read this operators manual thoroughly before using this
multimeter. This manual is intended to provide basic
information regarding this multimeter and to describe
common test procedures which can be made with this unit.
Many types of appliance, machinery and other electrical
circuit measurements are not addressed in this manual and
should be handled by experienced service technicians.
2.0 Specifications

6
3.2 Check Condition of Internal Battery
Before making resistance or continuity tests, check the
condition of the internal battery. First turn the function/range
switch to the ohms Rx1 position. Short the test leads together
and the needle indicator should deflect to the right side of the
scale. Keep the test leads shorted together while
simultaneously turning the zero ohms adjustment dial until the
needle indicates zero at the right side of the ohms scale. If the
needle will not zero, replace the batteries with two new 1.5 volt
AA size batteries (see Battery Replacement).
1) Fully seat the test leads in the correct input jacks, (-) black
lead, (+) red lead.
5
1) Set the function/range switch to the proper position
before making a measurement. When the voltage or
current is not known, it MUST be determined that the
capacity of the selected range will handle the amount of
voltage or current in the circuit (see #3 under “For Your
Safety”). Always start with the highest range in the
function. If the voltage applied falls within the range of
a lower setting, reset the function/range switch to the
appropriate setting for greatest accuracy of reading.
2) Avoid placing the tester in areas where vibration, dust or
dirt are present. Do not store the tester in excessively
hot, humid or damp places. This tester is a sensitive
measuring device and should be treated with the same
regard as other electrical and electronic devices.
3) Using the tester in areas with high magnetic fields can
result in inaccurate readings. For greatest accuracy of
reading, lay the tester on a flat, non-metallic surface.
4) When the tester is not in use, keep the function/range
switch in the OFF position. This keeps the needle
indicator from deflecting or “bouncing” excessively.
5) When disconnecting the test leads from the unit, always
grasp the leads where the input jacks meet the tester
housing. Never pull the leads out of the jacks by the
insulated wire or transport the tester using the test leads
as a carrying strap.
6) Never immerse the tester in water or solvents. To clean
the housing use a damp cloth with a minimal amount of
mild soap.
7) If the resistance (ohms) function of the tester is not going
to be used for a week or more, remove the internal
battery to avoid potential leaks that may damage the unit.
3.1 Preliminary Adjustments
Fully seat the test leads in the correct input jacks. If
necessary, using a small flat tip screwdriver, slowly turn the
mechanical zero adjustment screw clockwise or counter-
clockwise until the needle indicator is directly over the three
black zeros at the left end of the scale.
DC
10
20
50
100
200
500
2K
5K
10K
6
8
1K
Resistance
(Ohms) Scale
DC Voltage &
Milliamps Scale
Common Markings for
both the AC & DC
Voltage Scales
AC Voltage Scale dB Scale for Transistor
Gain Measurement
}
4.0 DC Voltage Measurement
Reading the Scale
GMT-19A
OHMSADJUST
1000VDC/AC
500mADC
MAX
O
H
M
S
1000
250
50
10
2.5
500m
50m
5m
1000
250
50
10
1.5V
AA
9V
X1K
X10
X1
DC10A
A
C
V
D
C
V
D
C
A
+
–
DC10A
V.Ω.A.
COM
20KΩ/VDC
8KΩ/VAC
1K 100
200
50
500
2K
000
AC
DC
50 100 150
200
250
10
20 30
40
246850
10
AC
dB
DC
dB
BAT
20
10
0
Ω
Ω
BAT
G
O
O
D
?
-80+6+12+16+18+20
+22
∞
R
E
P
L
A
C
E
5K
10 K
+14
O
H
M
S
O
H
M
S
DC
Voltage
Scale
DC
Voltage
Range
Black Red
3.0 Operating Suggestions

8
GB #OX-100 anti-oxidant compound (available at your local
hardware store). Replace and tighten the terminal connectors.
Secondly, if the terminals and connectors are making good
contact, touch the test leads to the battery and vehicle
framework as described above (see fig. 2). Note the reading
of the tester. Get an assistant to turn on the headlights while
the test leads are making contact. The needle indicator should
drop a few volts. Should the needle indicator drop 5 volts or
more, the battery should be charged or possibly replaced if
the voltage drop is significant. The circuit may need to be
checked further for problems within the electrical system that
may be draining the battery.
4.2 Alternators and Generators
Set the function/range switch to the 50 DCV range. While the
engine is idling at normal operating speed, touch the black (-)
test lead to the metal framework of the vehicle, then touch the
red (+) test lead to the output terminal connector. The
alternator output cable is always the heaviest gauge cable
attached to the alternator (see fig. 3). The needle indicator
should read 12 volts or more. If the needle indicator moves
sporadically, the cable may need to be tightened. If the engine
is idling lower than is specified in the vehicle owners manual,
the voltage reading will be lower. If the output voltage is
significantly low, the alternator may require service
or replacement.
WARNING! When making automotive
measurements, observe safety precautions. Stay away from
the fan blades, belts and other moving parts of the engine.
Keep the multimeter and its leads away from moving parts.
Figure 3
7
2) Set the function/range switch to the appropriate DC
voltage range. If the voltage is unknown, use the highest
range. If the voltage applied falls within the range of a
lower setting, reset the function/range switch to the
appropriate setting for greatest accuracy of reading.
3) If the polarity of the circuit to be tested is known, touch
the black test lead to the neutral side. If the polarity is
unknown, touch the test leads to opposite sides of the
circuit. If the needle indicator deflects to the left of the
scale, reverse the test leads.
Use the chart below as a guide to reading DC
voltage measurements:
DCV Read and
Range Following Multiply
Setting Scale Reading By:
2.5 0-250 Divide Reading by 100
50 0-50 1
250 0-250 1
1000 0-10 100
Common DC Measurements
4.1 Automotive Batteries
Set the function/range switch to 50 DCV. First check the
quality of the battery terminal connector by touching the red
(+) test lead to the connector while touching the black (-) test
lead to any bare metal framework of the vehicle. The tester
should read 12 volts or higher on the 0-50 scale with all of the
vehicle accessories turned off. If the needle indicator moves
sporadically, this indicates a bad terminal connection. Remove
the terminal connectors and clean both terminals and
connectors thoroughly. For improved conductivity and
corrosion resistance, coat the terminals and connectors with
Figure 2

10
Common DC Milliamperage Measurements
It is important to point out that milliamps can also be
expressed as thousandths of an Ampere. Therefore 500
milliamps is 500 thousandths of one Amp or 1⁄2of one Amp.
The milliamperage function of your multimeter is commonly
used by electronics repair technicians and hobbyists to
troubleshoot various low voltage circuits. Although not
normally used for electrical troubleshooting around the home,
this function can be used to measure the milliamperage draw
of household items such as flashlights and other battery
operated devices that do not draw more than 500mA. In fig. 4,
the red (+) test lead is hooked up to the (+) terminal of the
lantern battery while the black (-) test lead is hooked up to the
bulb. The tester will indicate the milliamperage draw when the
flashlight switch is thrown in the ON position.
WARNING! Do not apply voltage to the
test leads while the tester is set in the milliamp
range. See #8 under For Your Safety.
DC 10Amp Measurement
A separate input jack is provided for measurement of DC
current up to 10 Amps. This range is not fused so it is
imperative that the circuit under test does not exceed 10
Amps. Additionally, this function is designed for intermittent
use only. Maximum contact of the test leads with the circuit
is 15 seconds, with a minimum intermission time of 30
seconds between tests. Set the function/range switch to the
10A range. Touch the test leads to the circuit in the same
manner as instructed in DC MILLIAMPERAGE
MEASUREMENT. Read the 0-10 scale.
9
4.3 Household Batteries
Household batteries can be tested in either one of two ways.
For a good/bad check, set the function/range switch to the
1.5V or 9V BAT setting depending on which type of battery is
to be tested. Plug the red test lead into the jack marked
“V. Ω.A.”. Touch the red (+) lead to the (+) terminal of the
battery and the black (-) lead to the (-) terminal of the battery.
Read the BAT scale at the very bottom of the scale plate. The
scale will indicate if the battery is good, questionable or should
be replaced. To more accurately measure the voltage value of
household batteries, set the function/range switch to 10 VDC
and touch the leads to the battery as before. Read the 0-10
scale to determine the condition of the battery.
1) Fully seat the test leads in the correct input jacks.
2) Set the function/range switch to the appropriate
DCmA setting.
3) Touch the test leads to the circuit in series (in line with the
circuit) so that the circuit current passes through the
multimeter in order to make the measurement. If the
needle indicator deflects to the left, reverse the test leads.
With a set range of 5mA, read the 0-50 scale and “drop”
the zeros. With a set range of 500mA read the 0-250
scale and multiply the readings by 2.
Figure 4
5.0 DC Milliamp Measurement
GMT-19A
OHMS ADJUST
1000VDC/AC
500mADC
MAX
O
H
M
S
1000
250
50
10
2.5
500m
50m
5m
1000
250
50
10
1.5V
AA
9V
X1K
X10
X1
DC10A
A
C
V
D
C
V
D
C
A
+
–
DC10A
V.Ω.A.
COM
20KΩ/V DC
8KΩ/V AC
1K 100
200
50
500
2K
000
AC
DC
50 100 150
200
250
10
20 30
40
246850
10
AC
dB
DC
dB
BAT
20
10
0
Ω
Ω
BAT
G
O
O
D
?
-80+6+12+16+18+20
+22
∞
R
E
P
L
A
C
E
5K
10 K
+14
O
H
M
S
O
H
M
S
DC Milliamp
Scale
DC Milliamp
Measurement
Black Red

12
Common AC Voltage Measurements
6.1 Wall Receptacles
If the receptacle is controlled by a switch, make sure the
switch is ON. Set the function/range switch to 250 ACV.
Touch the test leads to the “hot”and “neutral”slots of the
receptacle (see fig. 5.) The needle indicator should read 120
VAC on the 0-250 scale. To test for proper grounding of the
receptacle, touch one test lead to the “hot”(narrow) side of
the receptacle, and the other test lead to the ground slot.
The tester should read 120 VAC as before. To test for proper
grounding of non- polarized receptacles (fig.6), alternately
touch the test leads between the receptacle slots and the
wall plate screw. The tester should indicate 120 VAC when
one test lead contacts the “hot”side of the receptacle. If
ground contact cannot be made on the wall plate screw,
remove the wall plate and touch the electrical box with the
test lead in the same manner as before. The tester should
read 120 VAC with one test lead touching the electrical box
and the other touching the live side of the receptacle. If not,
the receptacle is not properly grounded.
11
1 ) Fully seat the test leads in the correct input jacks.
2) Set the function/range switch to the appropriate AC
voltage range. If the voltage is unknown, use the highest
range. If the voltage applied falls within the range of a
lower setting, reset the function/range switch to the
appropriate setting for greatest accuracy of reading.
3) Touch the test leads to the circuit under test. With AC
voltage, the polarity of the test leads is not a factor.
Use the following chart below as a guide to reading AC
voltage measurements:
ACV Read and
Range Following Multiply
Setting Scale Reading By:
10 0-10 1
50 0-50 1
250 0-250 1
1000 0-10 100
6.0 AC Voltage Measurement
GMT-19A
OHMS ADJUST
1000VDC/AC
500mADC
MAX
O
H
M
S
1000
250
50
10
2.5
500m
50m
5m
1000
250
50
10
1.5V
AA
9V
X1K
X10
X1
DC10A
A
C
V
D
C
V
D
C
A
+
–
DC10A
V.Ω.A.
COM
20KΩ/V DC
8KΩ/V AC
1K 100
200
50
500
2K
000
AC
DC
50 100 150
200
250
10
20 30
40
246850
10
AC
dB
DC
dB
BAT
20
10
0
Ω
Ω
BAT
G
O
O
D
?
-80+6+12+16+18+20
+22
∞
R
E
P
L
A
C
E
5K
10 K
+14
O
H
M
S
O
H
M
S
GMT-19A
OHMSADJUST
1000VDC/AC
500mADC
MAX
O
H
M
S
1000
250
50
10
2.5
500m
50m
5m
1000
250
50
10
1.5V
AA
9V
X1K
X10
X1
DC10A
A
C
V
D
C
V
D
C
A
+
–
DC10A
V.Ω.A.
COM
20KΩ/VDC
8KΩ/VAC
1K 100
200
50
500
2K
000
AC
DC
50 100 150
200
250
10
20 30
40
246850
10
AC
dB
DC
dB
BAT
20
10
0
Ω
Ω
BAT
G
O
O
D
?
-80+6+12+16+18+20
+22
∞
R
E
P
L
A
C
E
5K
10 K
+14
O
H
M
S
O
H
M
S
5A 5B
Figure 5 Figure 6
AC Scale
in Red
(Use black
numbers on
top for scale.)
AC Voltage
Settings
Red
Black
Neutral Hot
Ground
10 Amp
Scale
Black
Red

14
scale. If the needle will not zero, replace the internal
batteries with two new 1.5 volt AA size batteries (see
Battery Replacement) .
3) Touch the test leads to the resistance or non-energized
circuit to be measured. Measure the value of the reading
on the ohms scale and multiply the reading by 1000. If
you’re making basic continuity tests, the needle indicator
should move all the way to the right side of the ohms
scale if continuity exists.
Note: When switching the unit back and forth from ohms to
other functions, always zero the needle indicator before
taking another reading. Failure to zero the needle before
taking resistance/continuity measurements will result in
inaccurate readings.
Continuity Buzzer Setting
For quick, audible continuity checks, turn the function/range
switch to the setting. If the circuit under test has a
resistance of 100 ohms or less, the internal buzzer will sound
when the test leads are touched to the circuit. This makes
continuity checks quick and easy. Note: The needle indicator
will not indicate resistance values when the tester is in the
mode. Do not operate the continuity buzzer continuously
as this will discharge the internal batteries.
13
6.2 Appliance Receptacles
Set the function/range switch to 250 VAC. Touch the test
leads to the receptacle slots. The tester should read 240 VAC
between the two “hot”sides of the receptacle, and 120 VAC
between the neutral slot and either of the two “hot”sides
(see fig. 7).
6.3 Circuit Breaker Panel
To test for defective circuit breakers, set the function/range
switch to the 250 VAC or 600 VAC settings. Touch one test lead
to the neutral (buss) terminal strip of the breaker panel and the
other test lead to the terminal on the circuit breaker (see fig. 8).
The tester should read 120 VAC on the 0-250 scale.
For resistance and circuit continuity testing with power OFF
1) Fully seat the test leads in the input jacks.
2) Set the function/range switch to the Rx1K position and
short the test leads together. Using the zero ohms
adjustment dial, slowly turn the dial until the needle
indicator reads -0- ohms at the right end of the ohms
Figure 7
Figure 8
7.0 Resistance/Continuity Measurement
GMT-19A
OHMS ADJUST
1000VDC/AC
500mADC
MAX
O
H
M
S
1000
250
50
10
2.5
500m
50m
5m
1000
250
50
10
1.5V
AA
9V
X1K
X10
X1
DC10A
A
C
V
D
C
V
D
C
A
+
–
DC10A
V.Ω.A.
COM
20KΩ/V DC
8KΩ/V AC
1K 100
200
50
500
2K
000
AC
DC
50 100 150
200
250
10
20 30
40
246850
10
AC
dB
DC
dB
BAT
20
10
0
Ω
Ω
BAT
G
O
O
D
?
-80+6+12+16+18+20
+22
∞
R
E
P
L
A
C
E
5K
10 K
+14
O
H
M
S
O
H
M
S
Resistance
(Ohms) Scale
Top Green
Scale
Zero Ohms
Adjustment
Dial
Black Red
Resistance
(Ohms)
Setting
Audible
Continuity

16
Should it be determined that the cord is not the source of the
problem, the appliance may need to be disassembled in order
to pinpoint the problem. Refer to the owners manual of the
appliance. The manufacturer of the appliance may require that
the appliance be serviced only by a qualified repair technician.
7.3 Fuses
Note: With the power OFF, always remove a fuse from its
socket before testing it. With cartridge fuses, touch the test
leads to each end of the fuse (see fig. 10). If the fuse is good,
the needle indicator will move to -0- ohms, or if the continuity
buzzer is being used it should sound. If not, replace the fuse.
On plug-type fuses, touch the the test leads on the bottom
contact and the other on the threaded metal contact (see fig.
11). On time-delay/tamper-proof fuses, the other metal contact
is at the top of the ceramic threads.
7.4 Switches
Cut off the power source to the switch. If necessary, remove
the switch from whatever it’s mounted to. Turn the switch to
the ON position and touch the test leads to the switches
terminals (see fig. 12). If the switch is good, the needle
indicator will move to -0- ohms, or if the continuity buzzer is
being used it should sound. If not, replace the switch. On
other than two-way SPST (single pole, single throw)
switches such as three-way light switches or double pole
double throw (ON-OFF-ON) switches, in each ON position
you will need to alternate the test leads between the
switches terminals to determine which two terminals control
that ON position.
15
Common Resistance and
Continuity Measurements
Continuity tests are probably the most frequently performed
electrical troubleshooting procedures around the home.
ALWAYS REMEMBER THAT CONTINUITY CHECKS ARE
TO BE MADE WITH THE POWER TO THE CIRCUIT
TURNED OFF. Polarity of the test leads is not a factor in
making continuity checks.
7.1 Extension Cords
Unplug the cord. Set the function/range switch to the Rx1K
position. Touch one of the test leads to one of the metal prong
ends of the cord, and insert the other test lead in either one of
the receptacle slots on the other end of the cord, making sure
the test lead is making good contact with the receptacle (see
fig. 9). If the needle indicator does not move to -0- ohms, or if
the continuity buzzer is being used and does not sound, insert
the test lead into the other receptacle slot, again making sure
of good contact. If the needle indicator does not move to -0-
ohms, or if the continuity buzzer is being used and does not
sound, the cord should be replaced.
7.2 Appliance Cords
Unplug the appliance from its power source. Turn its power
switch to the ON position. Touch the test leads to the metal
prong ends of the cord. The tester should indicate a low
resistance value. If not, flex the cord while the leads are still in
contact with the metal prongs. If the needle indicator moves
sporadically, or if the continuity buzzer does not sound, while
the cord flexes, there may be a broken conductor in the cord.
If the needle indicator does not move at all, or the buzzer does
not sound, there may be an open circuit in the appliance.
Figure 11Figure 10
Figure 9

17
7.5 Heating Elements
Household appliances such as coffee makers and water
heaters contain heating elements which may require
troubleshooting. When making continuity checks on heating
elements, disconnect the element(s) from the circuit(s) that
supply it/them. Touch the test leads, one on each end of the
element and observe the needle indicator. The reading should
indicate low ohms. If the needle indicator doesn’t move, or if
the continuity buzzer is being used and does not sound, the
heating element is broken. If the element(s) show that
continuity exists, test for continuity of the circuit(s) that feed
the element(s) .
7.6 Thermostats
Make sure the thermostat control is in the OFF position.
Remove the thermostat cover. Touch the test leads to the
contact points on the thermostat. The needle indicator should
move to read -0- ohms, or if the continuity buzzer is being
used, it should sound. If not, either one of the contacts may be
loose or broken.
The decibel feature of this multimeter is for transistor gain
measurement in electronic circuits and should not be
confused with audio decibels. This function is used primarily
by electronics technicians to measure the power gain in
transistors, and is rarely encountered in home
project applications.
1) Fully seat the test leads in the correct input jacks.
2) Set the function/range switch to any one of the AC voltage
ranges and read the decibel measurement on the bottom
(red) scale of the faceplate. Based on the AC voltage
8.0 Decibel Measurement
Figure 12 range you selected, you will need to compute the actual
measurement by using the decibel conversion chart
located at the bottom right of the faceplate.
Important: For absolute decibel measurements, circuit
impedance must be at least 600 ohms. -0- decibels = 1
milliwatt in a 600 ohm impedance (equivalent to 0.775 volts
across 600 ohms).
1) Remove the screws in the battery/fuse cover and carefully
separate from the front.
2) Note the polarity of the batteries when removing them
from their compartments and replace.
3) Use GB catalog number GF-0306 .5 Amp/250 Volt
replacement fuses.
4) Carefully replace the battery/fuse cover and tighten the
screws. Do not overtighten the screws as this may strip
the threads in the tester housing.
Order Form
Learn more about using multimeters with "How To Use Your
Multitester For Electrical Testing and Troubleshooting". A
160-page guide to using analog and digital multimeters. Only
available in English. Contains nine chapters of easy to
understand instructions on basic household, automotive
electrical and electronic circuit testing. Packed with
illustrations. Paperback bound. Available wherever
multimeters are sold or:
For customers within the US, send check or money
order for $15.23 per copy ($13.23 plus $2.00 per
copy shipping and handling) to:
Gardner Bender
P.O. Box 3241
Milwaukee, WI 53201-3241
Name
Address
City State Zip
Qty. Ordered
Please print clearly.
9.0 Battery and Fuse Replacement

Gardner
Bender
www.gardnerbender.com
PO Box 3241 •Milwaukee, WI 53201-3241 •414-352-4160
6615 Ordan Drive •Mississauga, Ontario L5T 1X2 •905-564-5749
Rev. A
