GE AEM08LP Operating instructions

GEAppliances.com
0_
.I.J
-0
Safety Instructions ............. 2,s
Operating Instructions
Controls ........................... 4-6
Care and Cleaning
Air Filter .............................. 6
Outdoor Coils ......................... 6
Installation Instructions ...... 7-to
Troubleshooting Tips ............ 11
Normal Operating Sounds ............ 11
Consumer Support
Consumer Support .......... Back Cover
Ownership Registration for
Customers in Canada only ........ 13, 14
Warranty for Customers
in Canada ........................... 16
Warranty for Customers
in the USA ........................... 15
*ENERGY STAR® labeled product
AEL05
AEL06*
AEL08*
Climatiseur
Lo section franqaise commence 8 la page 17
Acondicionador
deaire
ENERGYSTAR
As an ENERGY STAR®partner, GEhas
determined that this product meets
the ENERGYSTAR®guidelines for
energy efficiency.
Write the model and serial numbers here:
Model #
Serial #
Find these numbers on a label on the sideof
the air conditioner.
Lo secci6n en espahol empieza en la pdgina 33
In Canada, contact us at:
www.GEAppliances.ca 49-7680 ii-i0GE

IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
Foryour safety, the information in this manual must be followed to minimize the risk of fire, electric
shock or personal injury.
SAFETYPRECAUTIONS
Use this appliance only for its intended
purpose as described in this Owner's
Manual.
This air conditioner must be properly
installed in accordance with the Installation
Instructions before it is used.
Never unplug your air conditioner by pulling
on the power cord. Always grip plug firmly
and pull straight out from the receptacle.
Replace immediately all electric service
cords that have become frayed or otherwise
damaged. A damaged power supply cord
must be replaced with a new power supply
cord obtained from the manufacturer and
not repaired. Do not use a cord that shows
cracks or abrasion damage along its length
or at either the plug or connector end.
Turn the unit OFFand unplug your air
conditioner before cleaning.
GEdoes not support any servicing of the
air conditioner. We strongly recommend
that you do not attempt to service the air
conditioner yourself.
For your safety...do not store or use
combustible materials, gasoline or other
flammable vapors or liquids in the vicinity
of this or any other appliance.
All air conditioners contain refrigerants,
which under federal law must be removed
prior to product disposal. If you are getting
rid of an old product with refrigerants, check
with the company handling disposal about
what to do.
If the receptacle does not match the plug,
the receptacle must be changed out by a
qualified electrician.
These R410A air conditioning systems
require contractors and technicians to
use tools, equipment and safety standards
approved for use with this refrigerant.
DO NOT use equipment certified for
R22 refrigerant only.
2
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove
the third (ground) prong from the power cord.
For personal safety, this appliance must be
properly grounded.
DO NOT use an adapter plug with this appliance.
The power cord of this appliance is equipped
with a 3-prong (grounding) plug which mates
with a standard 3-prong (grounding) wall outlet
to minimize the possibility of electric
shock hazard from this appliance.
Have the wall outlet and circuit checked by
a qualified electrician to make sure the outlet
is properly grounded.
Where a 2-prong wall outlet is encountered,
it isyour personal responsibility and obligation to
have it replaced with a properly grounded
3-prong wall outlet.
The air conditioner should always be plugged
into its own individual electrical outlet which has
a voltage rating that matches the rating plate.
Power cord includes a current interrupter device.
A test and reset button is provided on the plug
case. The device should be tested on a periodic
basis by first pressing the TESTbutton and
then the RESETbutton while plugged into the
outlet. If the TESTbutton does not trip or if the
RESETbutton will not stay engaged, discontinue
use of the air conditioner and contact a qualified
service technician.
This provides the best performance and also
prevents overloading house wiring circuits which
could cause a fire hazard from overheated wires.
See the Installation Instructions, Electrical
Requirements section for specific electrical
connection requirements.

WARNING!
USEOFEXTENSION CORD5
RISK OF FIRE. Could cause serious injury or
death.
,, DO NOT use an extension cord with this
Window Air Conditioner.
,, DO NOT use surge protectors or multi-outlet
adaptors with this Window Air Conditioner.
GEAppliances.com
READAND FOLLOW THISSAFETYINFORMATIONCAREFULLY.
SAVE THESE INSTRUCTIONS

About the controls on the air conditioner.
Features and appearance will vary.
Lights next to the touch pads on the air conditioner control panel indicate the selected settings.
Dght indicates the unit
is in the temperature or
delay time Set mode.
Auto
m High _ Cool
m Med _ Energg Sorer
Low _ Fan Onlg
(on some models) Light indicates the
delay timer is set.
NOTE: The display always shows the
room temperature except when setting
the Set temperature or the Delay timer.
Light indicates the unit
is in the temperature or
delay time Set mode.
mAuto
mHigh mCool
m Med _ _nergy Savel
m LOW _ Fan Ontg
TemplDelag
cT?c,?
Dght indicates the [
delay timer is set. (on some models)
0
0
Delay 1-24hr
Delay timer __
Decrease
Mode select
Fan speed
Decrease
Temperature O--
set Increase
ond
Decrease
Air Conditioner Controls
Controls (onsome models)
Oower Pad
Turns air conditioner on and off.When turned
on,the display will show the room temperature.
ODisplay
Showsthe room temperature or time remaining
on the Delay timer. Showsthe Settemperature
while setting the temperature in Cool or Energy
Saver modes.The Setlight will turn on while
setting.
O
O
NOTE:Thedisplay will change to show the room
temperature after settings havebeen made.
Oemp Increase A/Decrease T Pads
Useto set temperature when in Coolor Energy
Saver mode.The Setlight will turn on while
setting.
Oelay Timer Increase A(+)/Decrease T(-)
Pads
Eachtouch of the Increase A/Decrease T
pads on the unit or the Increase +/ Decrease
- padson the remote control will set the delay
time when usingthe Delay 1-24hr timer.The
Setlight will turn on while setting.
Oan Speed Pads
Useto set the fan speedto Low, Meal,High
or Auto on the unit. NOTE:Onthe remote
control, usethe fan speed Increase +/
Decrease - pads to set the fan speeds to Low,
Mad or High. Usethe Auto pad to turn Auto
fan on.
Delay timer
Increase
Auto Fan on
Fan speed
Increase
Unit power
on/off
Remote Control
Mode Pad
Useto set the air conditioner to Cool, Energy
Saver or Fan Only mode.
Delay Pads
Delay ON-When the air conditioner isoff, it can
be set to automatically come on in i to 24 hours
at its previous mode and fan settings.
Delay OFF--When the air conditioner ison,
it can beset to automatically turn off in i to
24 hours.
How toset:
Pressthe Delay 1-24hr pad on the unit or on the
remote control. Eachtouch of the Increase A
/Decrease _'pads on the unit or the Increase
+/Decrease - pads on the remote control will
set the timer in 1-hour intervals.TheSetlight will
turn on while setting.
Toreview the remaining time on the Delay
1-24hr timer, pressthe Delay 1-24hr pad on the
unit or on the remote control. Usethe Increase
A/ DecreaseTpads on the unit or the
Increase +/Decrease - padson the remote
control to set a new time if desired.
Tocancel the timer, pressthe Delay 1-24hr pad
until the light on the Delay 1-24hr pad goes off.
4
Note: The default temperature reading on the display is degree Fahrenheit (°F). Tochange the display to
degree Celcius (°C),pressthe Temp Increase A and Temp Decrease T buttons together and hold for 3
seconds. Repeat the process to change back to degree Fahrenheit (°F)

Features and appearance will vary.
GEAppliances.com
High Low
Cool _ Cool
Low
Fan
0
OFF
MODE
MODE CONTROL 0
Coolest
l:
TEMP
71_ 2
2/))
_j4
TEM PERATU RE CONTROL
Controls(onsomemodels)
0Mode Control
High Cool and Low Cool provide coolingwith
different fan speeds.
Fansettings provide air circulation and filtering
without cooling.
NOTE:If you move the mode control from a cool
setting to OFFor to a fan setting,wait at least
3 minutes before switching back to a cool
setting.
O TEMP Control
TheTEMPcontrol isusedto maintain the room
temperature. Thecompressor will cycleon
and off to keepthe room at the same levelof
comfort. When you turn the knob to a higher
number, the indoor air will become cooler.Turn
the knob to a lower number and the indoor air
will become warmer.
Cooling Descriptions
For Normal Cooling-Select High Cool or Low
Coolwith the TEMPERATUREcontrol at midpoint.
For Maximum Cooling--Select High Cool with
the TEMPERATUREcontrol at the highest number
available on your knob.
For Quieter and Nighttime Cooling-Select Low
Cool with the TEMPERATUREcontrol at midpoint.

About the controls onthe air conditioner.
Do Not Operate in Freezing Outdoor
Conditions
Thiscool-only air conditioner was not designed for
freezing outdoor conditions. It must not be used in
freezing outdoor conditions.
Remote Control
Toensure proper operation, aim the remote
control at the signal receiver on the air
conditioner.
Make sure nothing isbetween the air conditioner
and the remote control that could block the
signal.
Theremote control signal has a rangeof
up to 20 feet.
Make sure batteries are fresh and installed
correctly as indicated on the remote control.
Remotecontains a magnet allowing it to attach
to metal surfaces.
6
Cool Mode
Usethe Cool mode at Low, Med, High or Auto Fan
Speedfor cooling. Usethe Temperature increase A
/Decrease T padsto set the desired temperature
between 64% and 86% in !% increments.
An electronicthermostat isusedto maintain the room
temperature. Thecompressorwill cycleon and off
to keepthe room at the set levelof comfort.Setthe
thermostat at a lower number and the indoor air will
become cooler.Setthe thermostat at a higher number
and the indoor air willbecome warmer.
NOTE:If theair conditioner isoff and isthen turnedon
while setto aCoo/setting or if turnedfrom a fan setting
to a Coolsetting,it may takeapproximately 3minutes
for thecompressorto start and coolingto begin.
Cooling Descriptions
For Normal Cooling-Select the Cool mode and
High or Med fan with a middle set temperature.
For Maximum Cooling-Select the Cool mode
and High fan with a lower set temperature.
For Quieter and Nighttime Cooling-Select the
Cool mode and Low fan with a middle set
temperature.
Energy Saver Mode
Controlsthe fan.
ON--The fan will cycleon and off with the
compressor.This resultsin wider variations of room
temperature and humidity. Normally usedwhen the
room isunoccupied. NOTE:Thefan may continue to
run for a short time after the compressorcyclesoff.
OFF--Thefan runsall the time, while the compressor
cycles on and off.
Fan Only Mode
Usethe FanOnly Modeat Low, Medor Highfan
speedto provide air circulation and filtering without
cooling. Sincefan-only settings do not provide
cooling, a Settemperature cannot be entered.The
room temperature will appear
in the display.
NOTE:Auto FanSpeedcannot be used when in the
Fan Only Mode.
Auto Fan Speed
Setto Auto fan speedfor the fan speedto
automatically set to the speed needed to provide
optimum comfort settings with the set temperature.
If the room needsmore cooling, the fan speed
will automatically increase.If the room needs less
cooling, the fan speedwill automatically decrease.
NOTE:Auto FanSpeedcannot be used when in the
Fan Only Mode.
Power Outage Recovery Feature
Inthe case of a power outage or interruption, the
unit will automatically restart in the settings last
used after the power isrestored. Ifthe Delay 1-24hr
feature was set,it will resume countdown. You may
need to set a new time if desired.

Additional important information.
Air Direction
Usethe lever to adjust the air direction left and right
only.
GEAppliances.com
Care and cleaning of the air conditioner.
Grille and Case
Turn the air conditioner off and remove the plug from Toclean, usewater and a mild detergent. Do not use
the wall outlet before cleaning, bleach or abrasives.
Air Filter
Theair filter behind the front grille should be checked
and cleaned at least every 30 days or more often if
necessary.
Toremove:
Pullthe tab on the right sideof the unit untilthe filter
isout.
Toremove:
Openthe inlet grille by pulling downward on the tabs
at the top upper corners of the inletgrille untilthe
grille isin a 450position. Removethe filter.
Cleanthe filter with warm, soapy water. Rinseand let
the filter dry before replacing it. Do not clean the filter
in a dishwasher.
CAUTION: Noronerotetheair
conditioner without a filter becausedirt and lint will
clogit and reduceperformance. Tab
Outdoor Coils
Thecoils on the outdoor side ofthe air conditioner
should be checked regularly. If they are clogged with
dirt or soot,they may be professionallycleaned.
Tab
How
%to Insert the Batteries in the Remote Control
Removethe buttery cover by sliding it according
to the arrow direction.
Insert new batteries, making sure that the (+)
and (-)of battery are installed correctly.
Reuttachthe cover bysliding it back
into position.
NOTES:
Use2 "AAA"(1.5volt) alkaline batteries. Donot
userechargeable batteries.
Removethe batteriesfrom the remote control if
the system isnot going to be usedfor a long time.
Donot mix old and new batteries. Do not mix
alkaline,standard (carbon-zinc)or rechargeable
(ni-cad,ni-mh, etc) batteries.

!
I
Iti structi as Air Conditio
r_ Questions? Call 800.GE.CARES {800.432.2737) or Visit our Website at: GEAppliances.com
In Canada, call 1.800.561.3344 or visit www.GEAppliances.ca
r
1
BEFORE YOU BEGIN
Read these instructions completely
and carefully.
• IMPORTANT -Savetheseinstructions
for local inspector's use.
• IMPORTANT - Observe all governing
codes and ordinances.
• Note to Installer- Be sure to leave these
instructions with the Consumer.
• Note to Consumer - Keep these instructions for
future reference.
• Skill level - Installation of this appliance requires
basic mechanical skills.
• Completion time - Approximately 1 hour
. We recommend that two people install this
product.
. Proper installation is the responsibility of the
installer.
Product failure due to improper installation is not
covered under the Warranty.
You MUST use all supplied parts and use proper
installation procedures as described in these
instructions when installing this air conditioner.
ELECTRICAL REQUIREMENTS
Some models require a 115/120-volt AC,
60-Hz grounded outlet protected with a
15-amp time-delay fuse or circuit breaker.
The 3-prong grounding plug minimizes the
possibility of electric shock hazard. If the wall outlet
you plan to use is only a 2-prong outlet, it isyour
responsibility to have it replaced with a properly
grounded 3-prong wall outlet.
Some models require 230/208-volt AC,
protected with a time-delay fuse or circuit
breaker. These models should be installed
on their own single branch circuit for best
performance and to prevent overloading
house or apartment wiring circuits, which
could cause a possible fire hazard from
overheating wires.
CAUTION:
Do not, under any circumstances, cut or remove
the third {ground) prong from the power cord.
Do not change the plug on the power cord
of this air conditioner.
Aluminum house wiring may present special
problems--consult a qualified electrician.
TOOLS YOU WILL NEED
Phillips head screwdriver
Flat-blade screwdriver
Pencil Ruler or tape measure
Level Scissorsor knife
Power cord includes a current interrupter
device. A test and reset button is provided on the
plug case. The device should be tested on a periodic
basis by first pressing the TESTbutton and then the
RESETbutton while plugged into the outlet. If the
TESTbutton does not trip or
if the RESETbutton will not stay engaged, discontinue
use of the air conditioner and contact a qualified
service technician.

Installation Instructions
PARTS INCLUDED
(Appearance may vary)
Top mo_
Air
conditioner
_e window
al
FOamgOp_
Left
accordion
panel _
Top mo'_
seal strip
Right
accordion
panel
/
Type A (4) Type B(6) Window locking
bracket (1)

Installation Instructions
WINDOW REQUIREMENTS
, Theseinstructions are for a standard double-hung
window. You will need to modify them for other types
of windows.
. The air conditioner can be installed without the
accordion panels if needed to fit in a narrow
window. See the window opening dimensions.
. All supporting parts must be secured
to firm wood, masonry or metal.
. The electrical outlet must be within reach of the
power cord.
. Follow the dimensions in the table and illustration
for your model.
Models A B
AEL05 12 1/2" min. 23"-38"
AEL06 13 1/2" min. 22 1/2"-38 1/8"
AEL08
A
B
(With accordion panels)
[] STORM WINDOW REQUIREMENTS
A storm window frame will not allow the air
conditioner to tilt toward the outside, and will keep it
from draining properly.
To adjust for this, attach a piece of wood to the sill.
WOOD PIECES
WIDTH: 2"
LENGTH:Long enough to fit inside the window
frame.
THICKNESS: To determine the thickness, place a
piece of wood on the sill to make it 1/2" higher
than the top of the storm window frame or the vinyl
frame.
Attach securely with nails or screws provided by the
installer.
1/2" higher
than storm
window
frame
Storm window
frame
1/2" higher
than vinylframe
_ (onsomewindows)
,, _ Wood
-r_ Vinylframe I !
[] ATTACH THE TOP MOUNTING RAIL
SEAL STRIP
(Some models may have the seal strip already
attached to the top mounting rail. If applicable,
skip this step.)
Remove the backing from the top mounting rail
seal strip and attach the seal strip to the bottom
of the top mounting rail, along the front edge.
Topmountingrail
Remove
backing
from seal
strip
FRONT VIEW Top mounting rail
I
Sealstrip
10
[_ PREPARE THE AIR CONDITIONER
[] Install the top mounting rail with 4 Type A
screws from the outside of the case.
Topmounting rail
Bottom mountingrail
r_ Hold the accordion panel in one hand and
gently pull back to free the open end.

Installation Instructions
[]
©
PREPARE THE AIR CONDITIONER
(cont.)
Slide the free end of the accordion panel into
the side panel rails. Slide the panel down. Be
sure to leave enough space to slip the top
and bottom of the frame into the rails on the
cabinet.
NOTE: There is a right and a left accordion
panel. Be sure to use the proper panel for each
side.
[] Slide the left and right accordion panels into
the top and bottom mounting rails.
Top mounting rail Top ight
Top left
Bottom mounting rail
ITI PREPARE THE WINDOW
Cut the window sash seal to the proper length.
Peel off the backing and attach the seal to the
underside of the window sash.
%
rfl
B]
%
©
INSTALL THE AIR CONDITIONER IN
THE WINDOW
Place the air conditioner on the sill with the
bottom mounting rail against its back edge.
Center it and close the window securely behind
the top mounting rail. It should be level or
slightly tilted to the outside. Use a level; about
a 1/3 bubble will be the correct case slant to the
outside. /I
Type B screws
Extend the left and right accordion panels to
the vertical window sashes and attach, through
the holes in the panels, with 5 Type B screws,
as appropriate.
INSTALL SUPPORT BRACKET AND
FOAM TOP WINDOW GASKET
CAUTION:
To prevent broken
glass or damage to
windows, on vinyl or other
similarly constructed
windows, attach the
window locking bracket to
the window side jamb with
one Type B screw.
Vinyl
Wood
Cut the foam top window gasket to the window
width.
Stuff the foam
between the glass
and the window
to prevent air and
insects from getting
into the room.
NOTE: If the gasket supplied does not fit your
window, obtain appropriate material locally to
provide a proper installation seal.
11

Troubleshooting Tips __ GEAppliances.com
Possible Causes What To Do
The air conditioner _Make surethe air conditioner plug ispushed
does not start is unplugged, completely into the outlet.
Thefuse is blown/circuit • Checkthe house fuse/circuit breaker box and replace
breaker istripped, the fuse or reset the breaker.
Power failure. _Theunit will automatically restart in the settings last
used after the power isrestored.
There isa protective time delay (approximately
3 minutes) to prevent tripping of the compressor
overload. For this reason, the unit may not start
normal cooling for 3 minutes after it is turned
back on.
The current interrupter * Pressthe RESETbutton located on the power cord plug.
device is tripped. * If the RESETbutton will not stay engaged, discontinue
use of the air conditioner and contact a qualified
service technician.
Air conditioner does Airflow is restricted. * Hake surethere are no curtains, blindsor furniture
not cool as it should blocking the front of the air conditioner.
Thetamp control may * On models with touch pads: Inthe Cool mode, pressthe
not be set correctly. Decrease T pad.
On models with control knobs,turn the temperature
knob to a higher number.
The air filter isdirty. * Cleanthe filter at leastevery 30 days.
Seethe Careand Cleaningsection.
The room may have been hot. . When the air conditioner isfirst turned on,you need
to allow time for the room to cool down.
Cold air isescaping. • Checkfor open furnace registersand cold air returns.
Cooling coils have iced up. . See "Air conditioner freezing up" below.
Air conditioner
freezing up Ice blocks the air flow and stops the air conditioner
from cooling the room.
On models with control knobs,set the mode control at
High Fan or High Coolwith the Tamp at 1 or 2.
On models with touch pads, set the controls at High Fan
or High Coo/and set the thermostat to a higher
temperature.
Theremote control The batteries are inserted . Checkthe position of the batteries.They should be
is not working incorrectly, inserted inthe opposite (+)and (-)direction.
The batteries may be dead. * Replacethe batteries.
Water drips outside Hot, humid weather. * Thisisnormal.
Water drips indoors The air conditioner is not . Forproper water disposal,make sure the air conditioner
tilted to the outside, slants slightlyfrom the case front to the rear.
Water collects in Moisture removed from air _Thisisnormal for a short period in areaswith little
basepan and drains into base pan. humidity; normal for a longer period in very humid areas.
Normal Operating Sounds
12
iiiiiiiiiiii_iii
Youmay hear a pinging noisecaused by
water being picked up and thrown against the
condenser on rainy days or when the humidity
is high.This designfeature helpsremove
moisture and improve efficiency.
Youmay hear the thermostat clickwhen the
compressor cycles on and off.
Water will collect in the basepan during
high humidity or on rainy days.Thewater
may overflow and drip from the outdoor side
of the unit.
Thefan may run even when the compressor
does not.

Notes
13

Notes
14

GEAir Conditioner-One-Year Limited Warranty. (Forcustomers in theU.S.A.)
original purchase
We Will Replace:
Replacement unit for any product which fails due to (] defect in m(]teriols or workmanship.
The replacement unit iswarranted for the remainder ofyour product's original one-year
warranty period.
Return the product to the retail location where it
was purchased.
Customer instruction. This owner's manual provides
information regarding operating instructions and
user controls.
Improper installation, delivery or maintenance. Ifyou
have an installation problem, or ifthe air conditioner is
of improper cooling capacity, contact your dealer or
installer. You are responsible for providing adequate
electrical, plumbing and other connecting facilities.
Failure of the product resulting from modifications to
the product or due to unreasonable use, including failure
to provide reasonable and necessary maintenance.
Replacement of house fuses or resetting of circuit
breakers.
Failure due to corrosion on models not corrosion-
protected.
Damage to the product caused by improper power
supply voltage, accident, fire, floods or acts of God.
Incidental or consequential damage caused by possible
defects with this air conditioner.
Damage caused after delivery.
EXCLUSION OF IMPLIED WARRANTIES--Your sole and exclusive remedy is product replacement
as provided in this Limited Warranty. Any implied warranties, including the implied warranties of
merchantability or fitness for a particular purpose, are limited to one year or the shortest period
allowed by law.
This warranty is extended to the original purchaser and any succeeding owner for products purchased for
home use within the USA.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty
gives you specific legal rights, and you may also have other rights which vary from state to state. To know
what your legal rights are, consult your local or state consumer affairs office or your state's Attorney General.
Exclusion of implied warranties: Except where prohibited or restricted by law, there are no warranties,
whether express, oral or statutory which extend beyond the description on the face hereof, including
specifically the implied warranties of merchantability or fitness for a particular purpose.
Warrantor: General Electric Company. Louisville, KY 40225
15

GE Air Conditioner--One-Year Limited Warranty. Forcustomers in Canada)
_Will Replace:
We
I
One Replacement unit for Gny product which fails due to a defect in materials or workmanship.
From the date ofthe The replacement unit iswarranted for the remainder of your product's original one-year
Origind purchase I warranty period.
Return the product to the retail location where it
was purchased.
Customer instruction. This owner's manual provides
information regarding operating instructions and
user controls.
Improper installation, delivery or maintenance. Ifyou
have an installation problem, or ifthe air conditioner is
of improper cooling capacity, contact your dealer or
installer. You are responsible for providing adequate
electrical, plumbing and other connecting facilities.
Failure of the product resulting from modifications to
the product or due to unreasonable use, including failure
to provide reasonable and necessary maintenance.
iiiiiiiiiiii_iii
Replacement of house fuses or resetting of circuit
breakers.
Failure due to corrosion on models not corrosion-
protected.
Damage to the product caused by improper power
supply voltage, accident, fire, floods or acts of God.
Incidental or consequential damage caused by possible
defects with this air conditioner.
Damage caused after delivery.
EXCLUSION OF IMPLIED WARRANTIES-Your sole and exclusive remedy is product replacement as provided
in this Limited Warranty. Any implied warranties, including the implied warranties of merchantability or
fitness for a particular purpose, are limited to one year or the shortest period allowed by law.
This warranty is extended ta the original purchaser and any succeeding owner far products purchased in Canada
for home use within Canada.
Some provinces do nat allow the exclusion or limitation of incidental or consequential damages, so the above
exclusion may not apply toyou. This warranty gives yau specific legal rights, and you may also have other rights
which vary from province to province. To know what your legal rights are in your province, consult your local or
provincial consumer affairs office.
Exclusion of implied warranties: Except where prohibited or restricted by law, there are no warranties,
whether express, oral ar statutory which extend beyond the description an the face hereof, including
specifically the implied warranties of merchantability or fitness for a particular purpose.
Warranton Mabe Canada inc.,
Burlington, Ontario
16

Consignes de sGcurit6 ............. 18,19
Consignes d'utifisation
Commandes .......................... 20-22
Entretien et nettoyage
Filtre (_air ................................ 22
Serpentins extGrieurs ..................... 22
Instructions de montage .......... 23-26
Conseils de d_pannage .............. 27
Bruits normaux de fonctionnement ........ 27
Assistance _la clientele
Assistance 5 la clientele ................... 32
Garantie .................................. 31
Enregistrement du titre
de propriGt6 ........................... 29, 30
AEL05
AEL06*
AEL08*
*Produits homologuGs ENERGYSTAR@
ENERGYSTAR
Entant que partenaire d'ENERGYSTAR@,GEa
dGtermin6 que ce produit 6tait conforme aux
exigences d'efficacit6 6nergGtique d'ENERGY
STAR@.
Inscrivez ici les numGros de module et de sGrie :
NumGro de module :
NumGro de SGrie:
Vous trouverez ces numGros sur 1'Gtiquette
apposGe sur le cGt6 du climatiseur.
Au Canada, visitez-nous au :
www.electromenagersge.ca
17

J
IMPORTANTES CONSIGNES DE SECURITE.
VEUILLEZ LIRE TOUTES LES CONSIGNES AVANT UTILISATION.
AA VERTISSEIVlENT!
Pour votre sdcuritd, les informations contenues dans ce manuel doivent _tre suivies afin de minimiser
les risques d'incendie, de chocs dlectriques ou de blessures corporelles.
18
CONSIGNES DE SECURITE
N'utilisez cet appareil qu'aux fins pr6vues
d6crites dans le manuel d'utilisation.
Ce climatiseur doit _tre correctement
install6 conform6ment aux Instructions
d'lnstallation avant route utilisation.
Ne d6branchezjamais votre climatiseur en
tirant sur le cordon d'alimentation. Prenez
toujours fermement la fiche en main et tirez
pour la sortir de la prise.
Remplacez imm6diatement tout cordon
61ectrique us6 ou endommag6. Un
cordon d'alimentation endommag6 doit
@re remplac6 par un nouveau cordon
d'alimentation obtenu du fabricant. Ne
r6parez pas le cordon endommag6. N'utilisez
pas un cordon fissur6 ou pr6sentant des
dommages dus aux frottements soit sur
sa Iongueur ou aux extr6mit6s du c6t6
de la fiche ou du raccord.
Eteignez votre climatiseur et d6branchez-le
avant de le nettoyer.
GE n'offre pas de service d'entretien pour les
climatiseurs. Nous vous recommandons de
ne pas essayer d'effectuer I'entretien
de votre climatiseur vous-m@me.
BRANCHEMENTS 4LLECTRI@UES
Ne coupez pas ou n'enlevez pas, sous aucun
prdtexte, la troisiSme broche de mise 8 la terre
du cordon d'alimentation. Pour des raisons
de s_curitd, cet appareil doit 8tre correctement
mis 8 la terre.
N'utilisez PA5 d'adaptateur avec cet appareiL
Le cordon d'alimentation de cet appareil
est 6quip6 d'une fiche 6 trois broches (pour une
mise 6 la terre) qui s'adapte 6 la prise
de courant standard 6 3 broches (pour une mise
6 la terre) pour minimiser les risques
de chocs 61ectriques par cet appareil.
Le cordon d'alimentation est 6quip6 dun
dispositif d'interruption du courant. Un bouton
d'essai et de r6enclenchement est fourni
sur le battier de la prise. Vous devez tester le
m6canisme r6guli@ement en appuyant d'abord
sur le bouton TEST(essai) puis sur le bouton
RESET(r6enclenchement)Iorsque I'appareil est
branch6. Si le bouton TEST(essai) ne bascule
pas ou si le bouton RESET(r6enclenchement)
ne reste pas enclench6, cessez d'utiliser votre
climatiseur
et appelez un technicien de service qualifi6.
Pour votre s6curit6, ne stockez pas et
n'utilisez pas de mat6riaux combustibles,
d'essence ou d'autres vapeurs et liquides
inflammables dans les parages de cet
appareil ou de tout autre appareil.
Tousles climatiseurs contiennent des
fluides frigorig_nes qui, conform6ment, 6 la
16gislation f6d@ale doivent @re retir6s avant
la mise au rebut de I'appareil. Si vous mettez
au rebus un ancien appareil contenant des
fluides frigorig_nes, v@ifiez la proc6dure 6
suivre aupr_s de la compagnie responsable
de 1'61imination.
Si la prise de courant est d'un format
diff@ent de la fiche, cette prise doit @tre
chang6e par un 61ectricien qualifi6.
Ces syst@mes de climatisation R410A
n6cessitent que les entrepreneurs et
techniciens adoptent des outils, du mat@iel
et des normes de s6curit6 approuv6s pour
utilisation avec ce r6frig@ant. N'utilisez pas
de mat@iel certifi6 pour le r6frig@ant R22
uniquement.
Faites v@ifier la prise murale et le circuit
61ectrique par un 61ectricien qualifi6 pour
s'assurer que le syst@meest correctement
mis 6 la terre.
Dans le cas d'une prise biphas6e,
I'installateur a la responsabilit6 et I'obligation
de la remplacer par une prise triphas6e
correctement mise 6 la terre.
Le climatiseur doit toujours @trebranch6
6 sa propre prise 61ectrique d'une tension
nominale correspondant 6 celle indiqu6e
sur sa plaque signal@ique.
Ceci permet d'obtenir un meilleur rendement
du climatiseur et 6vite de surcharger les circuits
61ectriques du domicile qui risque d'occasionner
un incendie en surchauffant.
Consultez les Consignes d'lnstallations, dans
la section Exigences Electriques pour les
exigences de branchements 61ectriques
particuliers.

VERTISSEMENT !
UTILISATION DE RALLONGES
RISQUED'INCENDIE. Peut occasionner des
blessures graves ou la mort.
•NE PASutiliser de rallonge avec ce climatiseur.
• NE PASutiliser de parasurtenseur ou
d'adaptateur 5 prisesmultiples avecce
climatiseur.
www.electromenagersge.ca
LISEZETSUIVEZSOIGNEUSEMENTCESCONSIGNESDE
f f
SECURITE.
CONSERVEZ CESINSTRUCTIONS
19

A propos des commandes du climatiseur.
LesfonctionsetI'aspectpeuventvorier,
Lest_moinslumineux8c6t_destouches8effleurementsurletableaudecommandesdu climotiseurindiquentlesr@lages@lectionn@,
Le t6moin indique que I'appareil
est en mode Programmation de
la temp6rature ou du d61ai.
Auto
m High m Coot
Ned m _nerg_ Saver
Le t6moin indique que
I'appareil est en mode
Programmation de la
temp@ature ou du d61ai.
i_I sF Aut° I Fan Only
I High i Cool _ Low i Fan Only
:Med I Energy S....
Tamp /Delay
Le [@'noin lumineux ____
modules) indique que la
minuterie est _
I
(sur certains modules)
NOTE: L'6cran affiche toujours la Le temoin lumineux
temp6rature de la piece sauf Iorsque indique qua la minutede
vous programmez la temp@ature ou la est programm_e
minuterie.
Dalai1-24hr
Reductiondu dalai
_ S@lectiondumode_!_ I ,
Reductionde _ _ _ P'_
lavitessedu _ I _yrt_ _._--
ventilateur _ I _ k_zJc/
Augmentation I_'B " _ power_)_
et R@ductionde _ I
la temp6rature
programmee
_ ugmentation
du delai
_ arche
automatiquedu
ventilateur
_____ Augmentationde la
vitessedu ventilateur
Hise en marchede I'appareilON/OFF
(marche/arr_t)
Commandes du Climatiseur
Commandes(surcertainsmodules) T616commande
O ouche d'alimentation
Metleclimatiseuren positiondemarche
oud'arr@t.L'6cranaffichelatemperature
dela pi@ceIorsqueI'appareilestmisenmarche.
Offichage
Affichelatemp@aturedela pieceouletempsrestant
avantla miseen marcheouI'arr@tdeI'appareil.
Affichelatemp@atureder_glageIors
dela programmationdelatemp@aturepourles
modesCoo/(refroidissement)ouEnergySaver
(economied'energie).Let_moinlumineuxSet
(programme)s'allumeIorsdur_glage.
REMARQUE:L'_cranafficheralatemp@ature
delapiece6 lafindesr_glages.
Touches Temp Increase (Augmentation
temperature) A/Decrease (R6duction
de la temperature) T
Sontutilis@spourprogrammerlatemp@aturedans
lesmodesCoo/ouEnergySaver.Let@moinlumineux
Sets'allumeIorsdur@glage.
TouchesDelayTimerIncrease(Augmentationdu
d_lai)A(+}/ Decrease(Diminutiondu d_lai)T(-)
Chaquefoisquevouseffleurezlestouches
Increaseb,/Decrease T surI'appareilou
lestouchesIncrease+/ Decrease- dela
t@l@commande,vousprogrammezladur@
dud@laiIorsdeI'utilisationde laminuterieDelay
1-24hr(d@laide1-2Oh).Let@moinlumineuxSet
s'allumeIorsdur@glage.
Touches devitesse du ventilateur
Sontutilis@spour@glerlavitesseduventilateur
deI'appareilsurLow(faible),Ned(moyenne),
High(elev@)ouAuto(automatique).RENARQUE:
Surlat@l@commande,utilisezlestouchesIncrease
+/ Decrease- pourr@glerlavitesseduventilateur
surLow,Ned,ouHigh. UtilisezlatoucheAutopour
O
O
allumer leventilateur en mode Auto.
Touche lode
Estutilis@pourprogrammerleclimatiseursurles
modesCoo/,EnergySaverou FanOnly(ventilateur
uniquement).
Touches de O_lai
DelayON(d61aidemiseenmarche)-Lorsque
leclimatiseurest6teint,ilpeut6treprogramm6pour
d6marrerautomatiquementdansund61ai
de ! 6 24heures6 sesr6glagespr6c6dents(mode,
vitesseduventilateur).
DelayOFF(d_laid'arr_d-Lorsqueleclimatiseurest
enfonctionnement,ilpeut6treprogramm_pour
s'arr6terautomatiquementdonsund_laide 16 24
heures.
Commentle programmer:
AppuyezsurlatoucheDelay1-24hr(D_laide 1
6 2/4heures)de I'appareilou delat@l@commande.
Chaquefoisquevouseffleurezlestouches
IncreaseA/Decrease • surI'appareilou
lestouchesIncrease+/ Decrease- dela
t_l_commande,vousprogrammezladur@du d_lai
parintervallede i heure.Let_moinlumineuxSet
s'allumeIorsdur_glage.
Pourconna_treletempsrestantsurla minuterie
Delay1-24hr,appuyezsurlatoucheDelay1-24hr
deI'appareiloudelat_l_commande.Utilisezles
touchesIncrease•/ Decrease• surI'appareil
ou lestouchesIncrease+/ Decrease- de la
t_l_commandepourprogrammerun nouveaud_lai
sin_cessaire.
Pourannularla minuterie,appuyezsurlatouche
Delay1-24hrjusqu'6cequelevoyantlumineuxsurla
toucheDelay1-24hrs'_teigne.
Remarque ".La lecture de temp6rature par d6faut s'affiche en degr6 Fahrenheit (°F).Pour modifier
I'affichage en degr6 Celcius (°C),appuyez simultan6ment sur les boutons d'augmentation Aou
d'abaissement Vde la temp6rature et maintenez-les enfonc6s pendant 3 secondes. R6p6tez la m6thode
pour effectuer un retour @I'affichage des degr6s Fahrenheit (°F).
20
