GE AEN08 Series and Operating instructions

0GEAppliances.com
0
0_
0_
Safety Instructions ...................z, 3
Operating Instructions .............4, s
Care and Cleaning
Air Filter .............................................................6
Outdoor Coils ..................................................6
Installation Instructions ......7-12
Troubleshooting Tips.................14
Normal Operating Sounds ....................14
Consumer Support
Consumer Support .................Back Cover
Ownership Registration for
Customers in Canada only ...........15, 16
Warranty for Customers
in Canada ......................................................17
Warranty for Customers
in the USA ....................................................18
AEN08*
Climatiseur
Lo section ffonqoise commence _ Io poge 19
Acondicionodor
deoire
Lo secci6n en espohol empiezo en Io pdgino 35
0_
*ENERGY STAR@ labeled product
ENERGYSTAR
As an ENERGYSTAR@partner, GE has
determined that this product meets
the ENERGYSTAR®guidelines for
energy efficiency.
Write the model and serial numbers here:
Model #
Serial #
Find these numbers on a label on the side of
the air conditioner.
49-7663 12-10 GE

IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
Foryour safety, the information in this manual must be followed to minimize the risk of fire, electric
shock or personal injury.
SAFETYPRECAUTIONS
Use this appliance only for its intended
purpose as described in this Owner's
Manual.
This air conditioner must be properly
installed in accordance with the Installation
Instructions before it is used.
Turn the unit OFFand unplug your air
conditioner before making any repairs
or cleaning.
NOTE: We strongly recommend that any
servicing be performed by a qualified
individual.
Never unplug your air conditioner by pulling
on the power cord. Always grip plug firmly
and pull straight out from the receptacle.
Replace immediately all electric service
cords that have become frayed or otherwise
damaged. A damaged power supply cord
must be replaced with a new power supply
cord obtained from the manufacturer and
not repaired. Do not use a cord that shows
cracks or abrasion damage along its length
or at either the plug or connector end.
If the receptacle does not match the plug,
the receptacle must be changed out by u
qualified electrician.
For your safety...do not store or use
combustible materials, gasoline or other
flammable vapors or liquids in the vicinity
of this or any other appliance.
Allair conditioners contain refrigerants,
which under federal law must be removed
prior to product disposal. If you are getting
rid of an old product with refrigerants, check
with the company handling disposal about
what to do.
These R410A air conditioning systems
require contractors and technicians to use
tools, equipment and safety standards
approved for use with this refrigerant.
DO NOT use equipment certified for R22
refrigerant only.
2
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove
the third (ground) prong from the power cord.
For personal safety, this appliance must be
properly grounded.
DO NOT use an adapter plug with this
appliance.
The power cord of this appliance is equipped
with o 3-prong (grounding) plug which mutes
with u standard 3-prong (grounding) wall outlet
to minimize the possibility of electric
shock hazard from this appliance.
Power cord includes u current interrupter device.
A test and reset button is provided on the plug
case. The device should be tested on u periodic
basis by first pressing the TESTbutton and then
the RESETbutton while plugged into the outlet. If
the TESTbutton does not trip
or if the RESETbutton will not stay engaged,
discontinue use of the air conditioner and
contact u qualified service technician.
Have the wall outlet and circuit checked by
a qualified electrician to make sure the outlet
is properly grounded.
Where a 2-prong wall outlet is encountered,
it isyour personal responsibility and obligation to
have it replaced with a properly grounded
3-prong wall outlet.
The air conditioner should always be plugged
into its own individual electrical outlet which has
a voltage rating that matches the rating plate.
This provides the best performance and also
prevents overloading house wiring circuits which
could cause a fire hazard from overheated wires.
See the Installation Instructions, Electrical
Requirements section for specific electrical
connection requirements.

WARNING!
USEOF EXTENSION CORDS
RISK OF FIRE. Could couse serious injury or
death.
•DO NOT use an extension cord with this
Window Air Conditioner.
•DO NOT use surge protectors or multi-outlet
adaptors with this Window Air Conditioner.
GEAppliances.com
READAND FOLLOWTHISSAFETYINFORMATIONCAREFULLY.
SAVE THESE INSTRUCTIONS

About the controlson the air conditioner
Features and appearance will vary.
Lights next to the touch pads on the air conditioner control panel indicate the selected settings.
The display always shows
the room temperature
except when setting the
Set temperature or the
Delay timer.
Light indicates the unit
is in the temperature or
delay time Set mode.
Lig : indicates the delay timer is set.
Air Conditioner Controls
Controls
O ower Pad O
Turns air conditioner on and off.When turned
on,the display will show the room temperature. Q
Display
Showsthe room temperature or time remaining
on the Delaytimer. Showsthe Settemperature
while setting the temperature in Cool or Energy
Saver modes.TheSet lightwill turn on while
setting.
NOTE:Thedisplay will change to show the room
temperature after settings havebeen made.
Torecallthe Settemperature, pressthe Temp
Increase Aor Decrease vpads.
Temp Increase A/Decreasev Pads
Useto set temperature when in Coolor Energy
Savermode. TheSetlight will turn on while
setting.
Delay Timer Increase A(+)/Decreasev(-)
Pads
Eachtouch of the Increase A/Decrease • pads
on the unit or the Increase + /Decrease - pads
on the remote control will set the delay time
when usingthe Delay 1-24hr timer (+).TheSet
light will turn on while setting.
O Fan Speed Pads
Useto set the fan speedto Low, Med, High
or Auto on the unit. NOTE:Onthe remote
control, usethe fan speed Increase + /
Decrease- pads to set the fan speedsto Low,
Medor High. Usethe Auto pod to turn Auto
fan on.
Mode Pad
Useto set the air conditioner to Cool, Energy
Saver or FanOnly mode.
Delay Pads
Delay ON--When the air conditioner isoff, it can
be set to automatically come on in 1 to 2/4hours
at its previous mode and fan settings.
Delay OFF--When the air conditioner ison,
it can beset to automatically turn off in J_to
2/4hours.
How to set:
Pressthe Delay 1-24hr pad on the unit or the
+ pad on the remote control. Eachtouch of the
Increase A/Decrease •pads on the unit or the
Increase + /Decrease - pads on the remote
control will set the timer in 1-hour intervals.The
Set lightwill turn on while setting.
Toreview the remaining time on the Delay
1-24hr timer, pressthe Delay 1-24hr pad on the
unit or the + pad on the remote control. Usethe
Increase A/Decrease •pads on the unit or the
Increase + /Decrease - pads on the remote
control to set a new time if desired.
Tocancel the timer, pressthe Delay
1-24hr pad until the light on the Delay 1-24hr
pad goesoff.
4
Power Outage Recovery Feature
Inthe case of a power outage or interruption, the
unit will automatically re-start in the settings last
used after the power isrestored. Ifthe Delay 1-24hr
feature was set,it will resume countdown. You may
need to set a new time if desired.

GEAppliances.com
Cool Mode
Usethe Cool mode at Low, Med, High or Auto Fan
Speedfor cooling. Usethe Temperature Increase •
/Decrease • padsto set the desiredtemperature
between 64°F and 86°F in 1% increments.
An electronicthermostat isusedto maintain the room
temperature. Thecompressorwill cycleon
and off to keepthe room at the set levelof comfort.
Setthe thermostat at a lowernumber and the indoor
air will become cooler.Setthe thermostat at a higher
number and the indoor air will become warmer.
NOTE: If the air conditioner is off and is then turned on
while set to a Cool setting or if turned from a fan
setting to a Cool setting, it may take approximately
3 minutes for the compressor to start and cooling to
begin.
Cooling Descriptions
ForNormal Cooling-Select the Cool mode and
High or Mealfan with a middle set temperature.
For Maximum Cooling-Select the Cool mode
and High fan with a lower set temperature.
For Quieter & Nighttime Cooling-Select the
Cool mode and Lowfan with a middle set
temperature.
Do Not Operate in Freezing Outdoor Conditions
Thiscool-only air conditioner was not designed for
freezing outdoor conditions. It must not be usedin
freezing outdoor conditions.
Energy Saver Mode
Controlsthe fan.
ON--The fan will cycle on and off with the
compressor. This results in wider variations of room
temperature and humidity. Normally used when the
room is unoccupied. NOTE: The fan may continue to
run for a short time after the compressor cycles off.
OFF--The fan runs all the time, while the compressor
cycles on and off.
Fan Only Mode
Use the Fan Only Mode at Low, Med or High fan
speed to provide air circulation and filtering without
cooling. Since fan only settings do not provide cooling,
a Set temperature cannot be entered. The room
temperature will appear in the display.
NOTE:Auto FanSpeedcannot be usedwhen in the
Fan Only Mode.
Auto Fan Speed
Setto Auto fan speedfor the fan speedto
automatically set to the speed needed to provide
optimum comfort settings with the set temperature.
If the room needsmore cooling, the fan speed
will automatically increase.Ifthe room needs less
cooling, the fan speedwill automatically decrease.
NOTE:Auto FanSpeedcannot be used when in the
Fen Only Mode.
Air Direction
Usethe leversto adjust the air direction left and right.
Fingertip pressureon the louverbanks adjuststhe air
direction up or down.
Remote Control
Toensure proper operation, aim the remote
control at the signal receiver on the air
conditioner.
Hake sure nothing isbetween the air conditioner
and the remote control that could block the
signal.
Theremote control signal has o range of
up to 20 feet.
Make sure batteries are fresh and installed
correctly as indicated on the remote control.
Remotecontains o magnet allowing itto attach
to metal surfaces.

Care and cleaning of the air conditioner.
Grille and Case
Turnthe air conditioner off and remove the plug from Toclean, usewater and a mild detergent. Donot use
the wall outlet before cleaning, bleach or abrasives.
Air Filter
Theair filter behind the front grille should be checked
and cleaned at least every 30 days or
more often if necessary.
Toremove:
Open the inlet grille by pulling downward on the tabs
at the top upper corners ofthe inlet grille until the
grille is in a 85° position. Removethe filter.
Cleanthe filter with warm, soapy water. Rinseand let
the filter dry before replacing it. Donot cleanthe filter
in a dishwasher.
-&CAUTION: NOTo erotetheair
conditioner without o filter becousedirt and lint will
clog it and reduceperformance.
Outdoor Coils
Thecoils on the outdoor sideof the air conditioner
should be checked regularly. Ifthey are clogged with
dirt or soot,they may be professionallycleaned.
How to Insert the Batteries in the Remote Control
[_ emove the battery cover by sliding it according
to the arrow direction.
2_ Insert new batteries, making surethat the (+)
and (-) of battery are installed correctly.
-3] eattach the cover by sliding it back
into position.
NOTES:
Use 2 "AAA"(1.5volt)alkaline batteries. Do not
use rechargeable batteries.
Removethe batteriesfrom the remote control if
the system isnot going to be usedfor a long time.
Do not mix old and new batteries. Donot mix
alkaline,standard (carbon-zinc)or rechargeable
(ni-cad,ni-mh, etc) batteries.
6

Installation
Instructions Air Conditioner
-_ uestions? Call 800.GE.CARES (800.432.2737) or visit our Website at: GEAppliances.comIn Canada, call 1.800.561.3344 or visit www.GEAppliances.ca I
BEFORE YOU BEGIN
Read these instructions completely
and carefully.
•IMPORTANT - Savetheseinstructions
forlocalinspector'suse
• IMPORTANT - Observeallgoverning
codes and ordinances
• Note to Installer- Be sure to leave these
instructions with the Consumer.
• Note to Consumer - Keep these instructions for
future reference.
• Skill level- Installation of this appliance requires
basic mechanical skills.
• Completion time - Approximately 1 hour
• We recommend that two people install
this product.
• Proper installation is the responsibility
of the installer.
Product failure due to improper installation is not
covered under the Warranty.
You MUST use all supplied ports and use proper
installation procedures as described in these
instructions, and any separate kit instructions,
when installing this air conditioner.
ELECTRICAL REQUIREMENTS
Some models require a 115/120-volt AC,
60 Hz grounded outlet protected with a
15-amp time delay fuse or circuit breaker.
The 3-prong grounding plug minimizes the possibility
of electric shock hazard. If the wall outlet you plan to
use is only a 2-prong outlet,
it isyour responsibility to hove it replaced with
o properly grounded 3-prong wall outlet.
©Some models require 230/208-volt AC,
protected with a time delay fuse or circuit
breaker. These models should be installed
on their own single branch circuit for best
performance and to prevent overloading
house or apartment wiring circuits, which
could cause a possible fire hazard from
overheating wires.
-- CAUTION:
Do not, under any circumstances, cut or remove
the third (ground) prong from the power cord.
Do not change the plug on the power cord
of this air conditioner.
Aluminum house wiring may present special
problems--consult a qualified electrician.
If the sill support bolts do not contact the
window sill, or if you have a window without
a sill, you must order accessory kit RAK87
to properly install this air conditioner. Call
800.626.2002 or visit GEAppliances.com.
TOOLS YOU WILL NEED
Phillips head screwdriver
AdJustable wrench
Fiat-blade screwdriver
Pencil Ruleror tope measure
Level Scissors or knife
Power cord includes acurrent interrupter
device. A test and reset button is provided on the
plug case. The device should be tested on a periodic
basis by first pressing the TESTbutton and then the
RESETbutton while plugged into the outlet. If the
TESTbutton does not trip or
if the RESETbutton will not stay engaged, discontinue
use of the air conditioner and contact a qualified
service technician.

Installation Instructions
PARTS INCLUDED
(appearance may vary)
Foam top
window gasket
Window sash seal
(thin, adhesive-backed)
Left accordion
panel
Top mounting rail
TopmeO_
Right
accordion
panel
Window locking
Type A(6) Type B (5) Type C(5) Type D (2) bracket (1)

Installation Instructions
[] WINDOW REQUIREMENTS
• These instructions are for a standard
double-hung window. You will need to modify
them for other types of windows.
CAUTION: Ifthesillsupport
bolts do not contact the window sill, or
if you hove u window without u sill, you
must order accessory kit RAK87 to
properly install this air conditioner.
Cull 800.626.2002 or visit GEAppliunces.com.
The air conditioner can be installed without
the accordion panels if needed to fit in a
narrow window. See the window opening
dimensions.
All supporting parts must be secured
to firm wood, masonry or metal.
The electrical outlet must be within reach of
the power cord.
IB==t] I
14.5" min.
22.6" to 38.1"
(With accordion panels)
t" I
IY1STORM WINDOW REQUIREMENTS
A storm window frame will not allow the air
conditioner to tilt toward the outside, and will keep
it from draining properly. To adjust for this, attach
a piece of wood to the sill.
WOOD PIECES -
WIDTH: 2"
LENGTH: Long enough to fit inside the window
frame.
THICKNESS: To determine the thickness, place a
piece of wood on the sill to make it 1/2" higher
than the top of the storm window frame or the
vinyl frame.
Attach securely with nails or screws provided
by the installer.
1/2" higher
than storm
window
frame
Storm window
frame
1/2" higher
than vinyl frame
___ _ (on some windows)
L- S Wood
-r v Vinyl frame I I
I_ REMOVE THE AIR CONDITIONER
FROM THE CASE
I'_ Remove and save the 2 screws from the lower
sides of the front grille.
%
FRONT
Grasp the lower corners of the grille while
pressing in on the case sides with your finger
tips. Pull out to release and lift it up.
NOTE: Do not pull the bottom edge toward you
more than 3" or you may damage the tabs of
the grille. t t
FRONT
El When the front grille is removed the control
panel will still be attached by a harness. Turn
the grille around so you can see the back
side of the grille. Remove the three screws to
separate the control panel housing from the
grille.
rDl Remove the ground screw from each side of
the case. Keep them in a safe location.
NOTE: Be sure to save these screws. You will
need them later in the installation.
FRONT

Installation Instructions
[] REMOVE THE AIR CONDITIONER
FROM THE CASE (CONT.)
%Slide the air conditioner from the case by
gripping the base pan handle and pulling
forward while bracing the case. Do not pull or
lift on the styrofoam discharge area
Do not
pull or
damage
to the
unit may
result
FRONT
I_l ATTACH THE TOP MOUNTING RAIL
SEAL STRIP
Remove the backing from the top mounting rail
seal strip and attach the seal strip to the bottom
of the top mounting rail, along the front edge.
Top mounting rail
_ emove
backing
from seal
strip
FRONTVIEW Top mounting rail
/
I................./...................!
Sealstrip
rsl INSTALL THE TOP MOUNTING RAIL
ONTO THE CASE
Attach the top mounting rail onto the top of the
case with 3 Type B screws.
B
screws
[] INSTALL THE
SIDE ACCORDION PANELS
[_Slide the left and right accordion panels into
the top and bottom mounting rails.
[_]Attach the accordion panels to the case using
3 Type A screws on each side.
Accordion
panel
Type A
screws
Top mounting rail
BACK
Bottom mounting rail
1-71PREPARE THE WINDOW
• Cut the window sash seal to the window
width and stick the adhesive side to the
bottom of the sash.
/Window sashseal
INSIDE
10

Installation Instructions
[] INSTALL THE CASE IN THE WINDOW
IA1 Open the window and mark the centerline of
the window sill.
[] Carefully place the case on the window stool
and align the center murk on the bottom front
with the centerline of the sill.
r_ Pull the window down behind the top mounting
rail.
NOTE: Do not shut the window so tightly that
movement of the accordion panels is
restricted.
rDl secure the case to the window sill by using 2
Type D screws.
INSTALL THE CASE IN THE WINDOW
ICONT.)
[] Pull the accordion panels to each window sash
track. Attach them on each side to the window
sash and the window sill using 4 Type C screws.
r91INSTALL SUPPORT BRACKET AND
FOAM TOP WINDOW GASKET
CAUTION:
To prevent broken glass or
damage to windows, on
vinyl or other similarly
constructed windows,
attach the support bracket
to the window side jam.
Vinyl
Attach the support bracket
with one Type C screw.
Wood
©
Cut the foam top window gasket to the window
width.
Stuff the foam
between the glass
and the window
to prevent air and
insects from getting
into the room.
NOTE: If the gasket supplied does not fit your
window, obtain appropriate material locally to
provide a proper installation seal.
11

Installation Instructions
%
©
INSTALL THE AIR CONDITIONER
IN THE CASE
Slide the air conditioner into the case by
the base pan. Do not push on the controls,
styrofoam air discharge housing or the finned
coils. Make sure the air conditioner is firmly
seated.
(5 i:
Do not presson
these areas-
damage to the unit
may result
Bose Pan
Replace the 2 ground screws removed earlier,
one on each side of the case.
IMPORTANT: The ground screws must be
reinstalled to ensure a proper ground.
: :¸!¸¸¸¸¸¸¸¸¸¸¸5¸¸
Reinstall the control to the panel housing
be replacing the three screws you removed
earlier.
J
install screws
i\
[] INSTALL THE AIR CONDITIONER
IN THE CASE(CONT.}
r_ Attach the front grille to the case by inserting
the tubs on the grille into the slots on the front
top of the case. Push the grille in.
[]
,.=_
Secure the front grille to the case by replacing
the 2 screws removed earlier. Press on the top
of the grille to help with side screw installation.
Connect power.
12

Troubleshooting Tips.
Possible Causes What To Do
Air conditioner " _ 'The air conditioner • Hake surethe air conditioner plug is pushed
does not start is unplugged, completely into the outlet.
The fuse is blown/circuit • Checkthe housefuse/circuit breaker box and replace
breaker istripped, the fuse or resetthe breaker.
Power failure. • The unit will automatically re-start in the settings last
usedafter the power isrestored.
•There is u protective time delay (approximately
3 minutes) to prevent tripping of the compressor
overload. Forthis reason, the unit may not start
normal cooling for 3 minutes after it isturned
back on.
The current interrupter • Pressthe RESETbutton located on the power cord plug.
device is tripped. • If the RESETbutton will not stay engaged, discontinue
use of the air conditioner and contact a qualified
service technician.
Air conditioner does Airflow is restricted. •Hake surethere are no curtains, blinds or furniture
not cool as itshould blocking the front of the air conditioner.
The tamp control may • On models with touch pads: Inthe Cool mode, pressthe
not be set correctly. Decrease • pad.
• On models with control knobs,turn the temperature
knob to a higher number.
The air filter isdirty. • Cleanthe filter at least every 30 days.
Seethe Careand Cleaningsection.
The room may hove been hot. • Whenthe air conditioner isfirst turned on,you need
to allow time for the room to cool down.
Coldair is escaping. • Checkfor open furnace registersand cold air returns.
Cooling coils hove iced up. • See "Air conditioner freezing up" below.
Air conditioner
freezing up Ice blocks the air flow and stops the air conditioner
from cooling the room.
• On models with control knobs,set the mode control at
High Fanor HighCoolwith the Temp at i or 2.
• On models with touch pads, setthe controls at High Fan
or HighCooland set the thermostat to a higher
temperature.
Theremote control The batteries ore inserted • Checkthe position of the batteries.Theyshould be
is not working incorrectly, inserted in the opposite (+)and (-) direction.
The batteries may be dead. • Replacethe batteries.
Water drips outside Hot, humid weather. • This isnormal.
Water drips indoors The air conditioner is not • Forproper water disposal,make surethe airconditioner
tilted to the outside, slantsslightly from the case front to the rear.
Water collects in Moisture removed from air •This isnormal for ashort period in areaswith little
basepan and drains into bose pan. humidity; normal for alonger period in very humid areas.
Normal Operating Sounds
You may hear o pinging noise caused by
water being picked up and thrown against the
condenser on rainy days or when the humidity
is high. This design feature helps remove
moisture and improve efficiency.
You may hear the thermostat click when the
compressor cycles on and off.
Water will collect in the bose pan during
high humidity or on rainy days.The water
may overflow and drip from the outdoor side
of the unit.
Thefan may run even when the compressor
does not.
13

Notes.
14

Notes.
15

Notes.
16

GEAir Conditioner-One-Vear Limited Warranty. tForcustomers intheU.S.A.I
All warranty service provided by our Factory Service Centers,
or an authorized Customer Care®technician. To schedule service,
visit us on-line at GEAppliances.com, or carl 800.GE.CARES
(800.432.2737).Have serial number and model number available
when calling for service.
Staple your receipt here.
Proof of the original purchase
date is needed to obtain
service under the warranty.
_ii _i_i_i/_ _i _i__ii_ i i? _!ii_I
OneYear
Fromthedate ofthe
originalpurchase
GEWill Replace:
Any part of the air conditioner which fails due to a defectin materials or workmanship.
During this limited one-year warranty, GEwill alsoprovide, free of charge, all labor and related
serviceto replacethe defectivepart.
Service trips to your home to teach you how to
use the product.
Improper installation, delivery or maintenance. If you
have an installation problem, or if the air conditioner
is of improper cooling capacity for the intended use,
contact your dealer or installer. You are responsible
for providing adequate electrical connecting facilities.
Failure ofthe product resulting from modifications to
the product or due to unreasonable use including failure
to provide reasonable and necessary maintenance.
In commercial locutions, labor necessary to move the
unit to a location where it isaccessible for service
by an individual technician.
Replacement of house fuses or resetting of circuit
breakers.
Failure due to corrosion on models not corrosion-
protected.
Damage to the product caused by improper power
supply voltage, accident, fire, floods or acts of God.
Incidental or consequential damage caused by possible
defects with this air conditioner.
Damage caused after delivery.
EXCLUSION OF IMPLIED WARRANTIES--Vour sole and exclusive remedy is product repair as provided in
this Limited Warranty. Any implied warranties, including the implied warranties of merchantability or
fitness for a particular purpose, are limited to one year or the shortest period allowed by law.
This warranty is extended to the original purchaser and any succeeding owner for products purchased for
home use within the USA. If the product is located in an area where service by a GE Authorized Servicer is
not available, you may be responsible for a trip charge oryou may be required to bring the product to an
Authorized GE Service location for service. In Alaska, the warranty excludes the cost of shipping or service
calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty
gives you specific legal rights, and you may also have other rights which vary from state to state. To know
what your legal rights are, consult your local or state consumer affairs office or your state's Attorney General.
Warrantor: General Electric Company. Louisville, KV 40225
Z7

GEAir Conditioner--One-Vear Limited Warranty. (For customers in the CanadaJ
All warranty service provided by our Factory Service Centers,
or an authorized Customer Care®technician. For service, call
1.800.561.3344.Please have serial number and model number
available when calling for service.
Staple your receipt here.
Proof of the original purchase
date is needed to obtain
service under the warranty.
Fromthedate ofthe
originalpurchaseiii
Mabe Will Replace:
Any part of the air conditioner which failsdue to a defectin materials or workmanship.
During this limited one-year warranty, Habe will also provide,free of charge, all labor and
relatedserviceto replacethe defectivepart.
Service trips to your home to teach you how to
use the product.
Improper installation, delivery or maintenance. If you
have an installation problem, or if the air conditioner
is of improper cooling capacity for the intended use,
contact your dealer or installer. You are responsible
for providing adequate electrical connecting facilities.
Failure ofthe product resulting from modifications to
the product or due to unreasonable use including failure
to provide reasonable and necessary maintenance.
In commercial locations, labor necessary to move the
unit to alocation where it isaccessible for service
by an individual technician.
Replacement of house fuses or resetting of circuit
breakers.
Failure due to corrosion on models not corrosion-
protected.
Damage to the product caused by improper power
supply voltage, accident,fire, floods or acts of God.
Incidental or consequential damage caused by possible
defects with this air conditioner.
Damage caused after delivery.
EXCLUSION OF IMPLIED WARRANTIES--Your sole and exclusive remedy is product repair as provided in
this Limited Warranty. Any implied warranties, including the implied warranties of merchantability or
fitness for a particular purpose, are limited to one year or the shortest period allowed by law.
This warranty is extended to the original purchaser and any succeeding owner for products purchased in
Canada for home use within Canada. In-home warranty service will be provided in areas where it is available
and deemed reasonable by Mabe to provide.
Some provinces do not allow the exclusion or limitation of incidental or consequential damages, so the above
exclusion may not apply to you. This warranty gives you specific legal rights, and you may also have other
rights which vary from province to province. To know what your legal rights are in your province, consult your
local or provincial consumer affairs office.
Warrantor'. Mabe Canada Inc.,
Burlington, Ontario
18

Consignes de sOcuritO .......... 20, 21
Consignes d'utilisation
ModUles dotds touches
•aeftleurement .................... 99, 93
Entretien et nettoyage
Filtre 'aair .......................... 24
Serpentins ext_rieurs ................. 24
Instructions de montage ........ 25-30
Conseils de ddpannage ............ 31
Bruits normaux de fonctionnement ..... 31
Assistance "ala client&le
Assistance 'a la clientble ................ 36
Garantie ............................ 35
Enregistrement du titre
de propriOt_ ..................... 33, 34
AEN08*
* Produits homologuds ENERGY STAR @
ENERGYSTAR
En rant que partenaire d'ENERGY
STAR ®,GE a dO.terminal que ce produit
dtait conforme aux exigences d'efficacitd
dnergO.tique d'ENERGY STAR ®.
Inscrivezici lesnumOrosdemodeleet desOrie
NumOrode modele•
NumOrode SOrie•
Vous trouverez ces numO.ros sur l'O.tiquette
apposOe sur le c6tO. du climatiseur.
Au Canada, visitez-nous au •
xs_s_u.electromenagersge.ca 19

IMPORTANTESCONSIGNESDESI CURITI .
VEUILLEZLIRETOUTESLESCONSIGNESAVANTUTILISATION.
2O
a,AVERTISSEMENT!
Pourvotre s0curit0,les informationscontenuesdanscemanueldoivent_tresuiviesafinde minimiser
lesrisquesd'incendie,de chocs01ectriquesoude blessurescorporelles.
CONSIGNESDESI CURITI
N'ufilisez cet appareil qu'aux fins pr&ues
dOcrites dans le manuel d'utilisation.
Ce climatiseur doit _tre correctement
install_ conform_ment aux Instructions
d'Installafion avant mute ufilisafion.
Ne ddbranchez,jamais votre climatiseur en
firant sur le cordon d'alimentafion. Prenez
tou,jours fermement la fiche en main et tirez
pour la sortir de la prise.
Remplacez immddiatement tout cordon
dlectrique usd ou endommagd. Un
cordon d'alimentation endommag_ dolt
_tre remplac_ pax un nouveau cordon
d'alimentation obmnu du l[abricant.
Ne rOparez pas le cordon endommagd.
N'ufilisez pas un cordon fissurd ou
prOsentant des dommages dus aux
frottements soit sur sa longueur ou aux
extrOmitds du c6td de la fiche ou du
raccord.
Si la prise de courant est d'un format
ditJ[>rent de la fiche, cette prise dolt _tre
changde pax un dlectricien qu'alifid.
BRANCHEMENTSI LECTRIQUES
Eteignez votre climatiseur et ddbranchez-le
avant d'et_ectuer des rdparafions ou de le
nettoyer.
REMARQUE: Nousvousrecommandonsde faire
effectuerla maintenancepar untechnicienquali%.
Pour votre s_curit_, ne stockez pas et
n'utilisez pas de mat_riaux combustibles,
d'essence ou d'autres vapeurs et liquides
imqammables dans les parages de cet
appareil ou de tout autre appareil.
Tousles climatiseurs contiennent des
fluides frigoriganes qui, conl[brm_ment, 'ala
l_gisladon f_d&ale doivent _tre retires avant
la mise au rebut de l'appareil. Si vous metmz
au rebus un ancien appareil contenant des
fluides frigorig&nes, v&ifiez la procddure 'a
suivre aupras de la compagnie responsable
de l'dliminafion.
Ces systames de climatisafion R410A
demandent clue les contracteurs et
les techniciens utilisent des outils, de
l'dquipement et des mesures de sdcuritd
homology& pour une utilisadon avec
frigorigane. N'UTILISEZ PAS un
dquipement cerdfid pour fluide R22
refrigerant only.
Necoupezpasou n'enlevezpas,sousaucunprOtexte,
la troisiemebrochede misea la terredu cordon
d'alimentation.Pourdesraisonsde sOcuritO,cetappareil
doit _trecorrectementmisa la terre.
N'utilisez PAS d'adaptateur avec cet appareil.
Le cordon d'alimentation de cet appareil
est _quip_ d'une fiche 'a trois broches (pour
une mise 'ala mrre) qui s'adapte 'ala prise
de courant standard 'a 3 broches (pour une
mise 'ala terre) pour minimiser les risques
de chocs _lectriques par cet appareil.
Le cordon d'alimentation est _quip_ d'un
dispositif d'intermpfion du courant. Un
bouton d'essai et de r_enclenchement est
fourni sur le boider de la prise. Vous devez
tester le m_canisme r_guli_rement en
appuyant d'abord sur le bouton TEST(essai)
puis sur le boumn RESET(r_enclenchement)
lorsque l'appareil est branch,. Si le bouton
TEST(essai) ne bascule pas ou si le bouton
RESET(r_enclenchement) ne reste pas
enclench_, cessez d'utiliser votre climatiseur
et appelez un technicien de serx,ice qualifi_.
Faites v_rifier la prise murale et le circuit
dlectrique par un dlectricien qualifid pour
s'assurer que le syst&me est correctement
mis 'a la terre.
Darts le cas d'une prise biphas_e,
l'installateur a la responsabilit_ et l'obligation
de la remplacer par une prise triphas_e
correctement mise 'a la terre.
Le climatiseur dolt mujours _tre branch_
•asa propre prise _lectrique d'une tension
nominale correspondant 'a celle indiqu_e
sur sa plaque signal_fique.
Ceci permet d'obtenir un meilleur rendement
du climatiseur et _x,ite de surcharger les
circuits _lectriques du domicile qui risque
d'occasionner un incendie en surchautfant.
Consultez les Consignes d'Installafions, dans
la section ExigencesElectriquespour les exigences
de branchements dlectriques particuliers.
