GE ADT521PGF4WS User manual

Installation Instructions
Built-in Dishwasher
Ifyou have questions, call 800.GE.CARES(800.432.27371or visit our Website at: GEAppliances.com.
InCanada, please call 1.800.561.3344or visit www.geappliances.ca
BEFOREYOU BEGIN
Read these instructions completely and
carefully.
IM PORTANT - Observeallgoverningcodesand
ordinances.
. Note to Installer - Be sure to leave these instructions for the
consumer's and local inspector's use.
Note to Consumer - Keep these instructions with your
Owner's Manual for future reference.
Skill Level - Installation of this dishwasher requires
basic mechanical, electrical and plumbing skills. Proper
installation is the responsibility of the installer. Product
failure due to improper installation is not covered under
the GE Appliance Warranty. See warranty information.
Completion Time - 1 to 3 Hours. New installations require
more time than replacement installations.
IM PORTANT - The dishwasherMUST be installed
to allow for future removal from the enclosure if service is
required.
Care should be exercised when the appliance is installed or
removed, to reduce the likelihood of damage to the power
supply cord.
If you received a damaged dishwasher, you should immediately
contact your dealer or builder.
Optional Accessories - Seethe Owner's Manual for available
custom panel kits.
FOR YOUR SAFETY
Read and observe all CAUTIONSand WARNINGSshown
throughout these instructions. While performing
installations described in this booklet, gloves, safety glasses
or goggles should be worn.
READ CAREFULLY.
KEEP THESE INSTRUCTIONS.
Printedin the UnitedStates 3"1-3"1506-3 04-"13 GE

Installation Preparation
PARTS SUPPLIED
IN INSTALLATION PACKAGE:
. Junction box cover and #!0 hex-head screw
. Hose clamp
. Drain hose (approximately 78" long)
. Drain hose hanger
.2 #8-!8 hex head screws to secure brackets to washer
tub frame
.2 Plug buttons
.2 side trim pieces (some models)
.2 mounting brackets for wood countertops or side
cabinets
.2 #8-18 x 5/8" Phillips special head screws, to secure
dishwasher to underside of countertop or to side
cabinets
Literature, samples and/or coupons
Junction
Box Cover
?
#10
Hex-Head
Junction
Box Screw
112" long
Drain Hose Hanger
Hose Clamp
??
#8 Hex-Head Mounting
Bracket Screws
(onsome models)
Mounting
Brackets
Drain Hose
n
Plug Buttons
#8 Phillips
Special
Head Screws
5/8" long
MATERIALS YOU WILL NEED:
. Ferrule, compression nut and 90 ° elbow (3/8"NPT
external thread or dishwasher sA" GHT on one
end, opposite end sized to fit water supply)
Thread seal tape
. UL-listed wire nuts (3) Masking Tape
(if applicable)
Masking Tape
Materials Needed for
New InstaiJations:
. Air gap for drain hose, if required
. Waste tee for house plumbing, ifapplicable
. Electrical cable or power cord
Screw-type hose clamps
Strain relief for electrical connection
Hand shut-off valve (recommended)
Water line-3/8" minimum, copper tubing or
GEPart # WX28X326, flexible braided hose Air Gap
GPF12Ldrain hose (12' long),if needed
90° Elbow,
Ferrule and
Compression Nut
Hand
Shut-Off
Valve Seal Tape
(ifapplicable)
Waste Tee
Electrical Cable
(or Power Cord, if applicable)
Hose Clamps Strain Relief
Wire Nuts (3)
Hot Water Line
Optional
12' Drain Hose
GPF12L
TOOLS YOU WILL NEED:
. Phillips-head screwdriver
1/4" and 5/16" nutdriver
6"Adjustable wrench
Level
, Carpenters square
, Measuring tape
Safety glasses
Flashlight
Bucket to catch water when flushing the line
15/16" socket (optional for skid removal)
Gloves
Pliers
Phill2ad_
Screwdriver
15/16" Socket
For New Installations Only:
Tubing cutter
Drill and appropriate bits
Hole saw set
Flashlight
Gloves
Nutdriver
Pliers
Adjustable
Wrench
Bucket
Level
Carpenter's
Square
Tubing Cutter
Safety Glasses
Hole Saw Set
Measuring Tape

Installation Preparation
PREPARE DISHWASHER ENCLOSURE kWARNING:
Toreducethe riskofelectricshock,fire,or injury to persons,the
installermustensurethat the dishwasheriscompletelyenclosedat
thetime of installation.
33-1/2" to 3/4-3/4"
Underside of
Countertop
to Floor
Figure A
ThisWallArea
mustbe Free
of Pipesor
wires
£abinets
Square
and
Plumb
. The rough cabinet opening must be at least 2/4"deep, 2/4"
wide and approximately 34-1/2" high from floor to underside
of the countertop.
A ADVERTENCIA:
Parareducirelriesgode descargael@ctrica,incendioo lesionesa
personas,el instaladordebeasegurarsedeque el lavaplatosest@
completamentecerradoen el momentadela instalaci6n.
CLEARANCES:
• When installed into a corner,
allow 2" rain. clearance
between dishwasher and
adjacent cabinet, wall or other
appliances.Allow 28-5/8" rain.
clearance from the front
of the dishwasher for door
opening. Figure B.
Allow at least 6" between
dishwasher and range or
oven appliances. FigureB
The dishwasher must be installed so that drain hose is no
more than 12' in length for proper drainage.
The dishwasher must be fully enclosed on the top, sides and
back, and must not support any part of the enclosure.
L
JCountertop
/Clearancefor Door
Opening2"Minimum
DRAIN REQUIREMENTS
, Follow local codes and ordinances.
Do not exceed 12' distance to drain.
NOTE:Air gap must be used, if waste tee or disposer
connection is less than 18" above floor to prevent siphoning.
DETERMINE DRAIN METHOD
The type of drain installation depends on the following
questions.
. Do local codes or ordinances require an air gap?
. Iswaste tee less than 18" above floor?
If the answer to either question isYES,Method 1 MUST
be used.
. If the answers are NO,either method may be used.
CABINET PREPARATION
, Drill a 1-1/2" diameter hole in the cabinet wall within
the shaded areas shown in Figure A for the drain hose
connection. The hole should be smooth with no sharp edges.
IMPORTANT -When
connectingdrainlinetodisposer,
checktobesurethatdrainplughas
beenremoved.DISHWASHER WILL
NOT DRAIN IFPLUG ISLEFTINPLACE. 4 Remove
Drain
Plug
Figure C
Method I - Air Gap with Waste Tee or Disposer
Anair gap mustbe usedwhen requiredbylocalcodesand ordi-
nances.Theair gap must beinstalledaccordingto manufacturer's
instructions.
DrainHoseHanger
Figure D
_Hanger
L
Method 2 -"High Drain Loop" with Waste Tee or Disposer
\
Tip: Avoid unnecessary service call charges.
Always be sure disposer drain plug has been removed before
attaching dishwasher drain hose to the disposer.

Installation Preparation
PREPARE ELECTRICAL WIRING
WARNING:
FORPERSONALSAFETY:Removehousefuseor opencircuit breaker
beforebeginninginstallation.Donot usean extensioncord or
adapter plugwith this appliance.
_//_/_ _'_ Alternate
/I
_ Receptacle
Location
\\
ADVERTENCIA:
PARASEGURIDADPERSONAL:Quiteelfusibleo abra el interruptor
de circuitosantesde comenzarla instalaci6n.Noutiliceun cable
de extensi6no unenchufeadaptador conesteartefacto.
Electrical Requirements
. Thisappliance must be supplied with !20V, 60 Hz.,and
connected to an individual properly grounded branch circuit,
protected by a 15- or 20-ampere circuit breaker or time-delay
fuse.
. Wiring must be 2 wire with ground and rated for 75°C(176%).
. If the electrical supply does not meet the above requirements,
call a licensed electrician before proceeding.
Grounding Instructions-Permanent Connection
This appliance must be connected to a grounded metal,
permanent wiring system, or an equipment-grounding
conductor must be run with the circuit conductors and be
connected to the equipment-grounding terminal or lead on
the appliance.
Grounding Instructions-Power Cord Models
This appliance must be grounded. In the event of a malfunction
or breakdown, grounding will reduce the risk of electric shock
by providing a path of least resistance for electric current.
This appliance is equipped with a cord having an equipment-
grounding conductor and a grounding plug. The plug must
be plugged into an appropriate outlet that is installed and
grounded in accordance with all local codes and ordinances.
AWARNING:
Theimproperconnectionof theequipmentgrounding conductor
can resultin a riskofelectricshock.Checkwith a qualified
electricianor servicerepresentativeifyou are indoubt that
the applianceisproperlygrounded.
Cabinet
Figure E White
For models equipped with power cord: Do not modify the plug
provided with the appliance; if it will not fit the outlet, have a
proper outlet installed by a qualified technician.
Cabinet Preparation & Wire Routing
. Thewiring may enter the opening from either side, rear or the
floor within the shaded area illustrated above in Figure Eand
defined in Figure A.
. Cut a 1-1/2" maximum diameter hole to admit the electrical
cable. Edgesof hole should be smooth and rounded.
Permanent wiring connections may pass through the same
hole as the drain hose and hot water line, if convenient. If
cabinet wall is metal, the hole edge must be covered with a
bushing.
NOTE:Power cords with plug must pass through a separate
hole.
Electrical Connection to Dishwasher
Electrical connection is on the right front of dishwasher.
. For permanent connections the cable must be routed as
shown in Figure E.Cable must extend a minimum of 24" from
the rear wall.
. For power cord connections, install a 3-prong grounding
type receptacle in the sink cabinet rear wall, 6" min. or 18"
maximum from the opening, 6" to 18" above the floor.
. Use WD06×lO020 Dishwasher Power Cord Kit.
A ADVERTENCIA:
Laconexi6ninadecuadadelconductordeconexi6na tierradel
equipamientopuedeprovocarun riesgodedescargael_ctrica.
Consultea unelectricistacalificadoorepresentantedeservicio
t_cnicositienedudassabrelacorrectaconexi6natierradelaparato.

Installation Preparation
PREPARE HOT WATER LINE
NOTE:GErecommends copper tubing for the water line, but if
you choose to useflexible hose, use GE'sW×28×326, flexible
braided hose.
. Thewater supply line (3/8" copper tubing or flexible braided
hose) may enter from either side, rear or floor within the
shaded area shown in Figure F.
. Thewater supply line may pass through the same hole as the
electrical cable and drain hose. Or,cut an additional 1-1/2"
diameter hole to accommodate the water line. If power cord
with plug is used, water line must not pass through power
cord hole.
ACAUTION:
Do not remove wood base until you are ready to install the
dishwasher. The dishwasher will tip over when the door is
opened if base isremoved.
PRECAUCION:
Noquite la base de madera hasta que est_ listo para instalar el
lavaplatos. Sisequita la base, el lavaplatos sevolcar6 cuando
se abra la puerta.
il Shut-off_
Hot
From
Cabinet
Cabinet
FigureF
2" From Floor
Water Line Connection
. If using a flexible braided supply hose, labelthe hose with the
installation date to use as reference. Flexible braided hoses
should be replaced in 5 years.
. Turn off the water supply.
. Install a hand shut-off valve in an accessible location, such
as under the sink. (Optional, but strongly recommended and
may be required by local codes.)
. Water connection is on the left side of the dishwasher. Install
the hot water inlet line, using no less than 3/8" copper tubing
or a flexible braided hose. Route the line as shown in Figure F
and extend forward at least 19" from rear wall.
. Adjust water heater for 120°F to 1/40°Ftemperature.
. Flush water line to clean out debris.
. The hot water supply line pressure must be 20-120 PSI.
Turn page to begin dishwasher installation,

Dishwasher Installation
STEP 1:PREPARATION
Locate the items in the installation package:
, Screws
Junction box cover
,Drain hose and clamp
,Mounting brackets
,Trim pieces (on some models)
,Drain hose hanger
,Owner's Manual
,Product samples and/or coupons
STEP 2: CHECK DOOR BALANCE
, With dishwasher on the
wood base, check the
door balance by opening
and closing the door.
,Door isproperly balanced
if, when opened, it self
closes within 20°from
vertical, stays in position
from 20°to 70° and falls
fully open beyond 70°.
/
Door _
closes /
within /
20 ° /
/
/Door stays in
Position from _- _ _IL
20°to 70_ . -- -- "_
_Door falls fully ._
open beyond 70°_
,If necessary increase or decrease tension as shown. Latch
door and adjust both springs to the same tension setting to
correct balance.
Side View
Make sure
pulley cable
iswithin
pulley
shoulders
Figure G Front View
Tip: Make sure door opens and closes smoothly.
Check door opening and closing. If door does not open easily or
falls too quickly, check spring cable routing. The cable is held in
place by "shoulders" on the pulley. Check to be sure cable has
not slipped over the pulley shoulders and isrouted as shown.
STEP 3: REMOVE WOOD BASE,
INSTALL LEVELING LEGS
IMPORTANT - Do not kickoffwood bose!
Damage willoccur.
,Move the dishwasher close to the installation location and lay
it on its back.
,Remove the 4 leveling legs on the underside of the wood base
with a !5/16" socket wrench.
,Discard base.
Figure H
, Screw leveling legs back into the dishwasher frame,
approximately 1/2" from frame as shown.
STEP 4: REMOVE TOEKICK
,Removethe 2 toekick screws and toekick. Set aside for use in
Step 22.
Remove 2
FigureI Toekick Screws
STEP 5: POSITION SOUND BARRIER
Ion some models}
Skip this step if the sound
barrier is not assembled
to the dishwasher.
Lift the sound barrier and
tape to the door front with
masking tape. This will
hold the sound barrier up
and out of the way during
installation.
Sound Barrier
Bottom Front View
6

Dishwasher Installation
STEP 6: INSTALL 90 ° ELBOW
, Thread 90° elbow
onto the water valve.
Use thread seal tape Water Valve
for elbows with 3/8" Bracket
NPTexternal threads.
, Do not overtighten
elbow. Water valve
bracket could
bend or water valve Thread
fitting could break. Seal
, Position the end of Tape
the elbow to face the
rear of the dishwasher.
Front of Dishwasher
NPT
Elbow
Fill Hose
OR
Frontof dishwasher
STEP 8: POSITION WATER LINE
AND HOUSE WIRING
, Position water supply line and house wiring on the floor of
the opening to avoid interference with base of dishwasher
and components under dishwasher.
Line Wiring
Water Valve
Bracket \Figure M
\ Fill Hose
Figure K
STEP 7: INSTALL DRAIN HOSE TO DRAIN
LOOP
Connect drain loop end to drain hose using the screw clamp
as shown in the figure.
Figure L
STEP 9: INSTALL DRAIN HOSE,
THROUGH CABINET
, Position dishwasher in front of cabinet opening. Insert drain
hose into the hole in cabinet side. If a power cord is used,
guide the end through a separate hole.
Maximum Drain Hose
Length 10'
Blanket
Hose //
House
, Wiring
\
PowerCord
(IfUsed)
Figure N
Tip: Prevent unnecessary service call charges for fill, drain or
noise concerns.
Position utility lines sothey do not interfere with anything
under or behind the dishwasher.

Dishwasher Installation
STEP 10: SLIDE DISHWASHER THREE-FOURTHS
OF THE WAY INTO CABINET
IMPORTANT- oonotpushagainstfrontpanelwith
knees. Damage will occur.
, Grasp the sides of the front panel and slide dishwasher into
the opening a few inches at a time.
STEP 12: INSTALL MOUNTING BRACKETS
You will need the mounting brackets and 2 #8 hex-head screws
set aside in Step 1.
You must install the mounting brackets onto the dishwasher
tub frame top or sides prior to sliding the dishwasher into place
under the countertop.
Install mounting brackets on top if the underside of
countertop iswood or wood-like material that accepts screws:
IMPORTANT - Afterinstalling bracketsandbefore
closing the dishwasher door, adjust the brackets by bending
them up as needed, so that they do not contact the top of the
dishwasher door and cause damage.
Figure O
Do not push against
front door panel with
knee. Damage to the
door panel will occur.
. Asyou proceed, pull the drain hose through the opening
under the sink. Stop pushing when the dishwasher extends
about 6 inches forward of adjacent cabinets.
. Make sure drain hose isnot kinked under or behind the
dishwasher.
. Make certain the house wiring, drain line and water line do
not interfere with components under dishwasher.
STEP 11: INSTALL TRIM PIECES
{on some models)
Skip this step if trim is not supplied with the dishwasher.
Inthis step you will need the trim pieces set aside in Step 1.
. Position the trim pieces so the lips face toward the
dishwasher door.
. Select a trim piece and press it onto the left side tub flange.
Start with the top edge and press the trim piece completely
onto the tub flange as you move towards the bottom. Repeat
for the right side tub flange trim piece.
Figure P
If you would like to order the Trim Kitfrom GEService, please
call 800.GE.Cares and request part number WD08×10094 for
BB models or WD08×10096 for WW or CCmodels.
Top Mounting
#8 Bracket
Screw Bracket
DL_
tub frame Bend and break here
after installing if
counter has ashort
overhang.
, If you are installinc the dishwasher under a counter with a
short overhang, the countertop brackets may extend beyond
the edge of the counter. If this is the case, remove the excess
length by repeatedly bending the brackets at the front notch
only until they break.
Install mounting brackets on sides if the countertop is
granite or similar material that will not accept wood screws:
. Break off front portion of the tab with pliers at the location
shown.
. Position the left-hand side bracket as shown. Repeat with the
right bracket.
Side Mounting
Dishwasher
tub frame
#8 Bracket
Screw --_%. Bend and break
Jhere if necessary
Bracket

Dishwasher Installation
STEP 13: PUSH DISHWASHER INTO
FINAL POSITION
, Check the tub insulation blanket, if equipped, to be sure it is
smoothly wrapped around the tub. It should not be "bunched
up" and it must not interfere with the door springs. If the
insulation is"bunched up" or interfering with the springs,
straighten and recenter the blanket prior to sliding the
dishwasher into its final position.
. Slide the dishwasher into the final position by pushing on the
sides of the door panel. Do not use a knee or push on the
center of the panel. If you do, damage to the panel will likely
result.
The dishwasher isin the final position when the edges of
the front panel are flush with the adjacent cabinets and the
dishwasher iscentered in the cabinet opening.
IMPORTANT - Before opening the dishwasher door,
be certain the edges of the dishwasher door panel are behind
the face of the adjacent cabinet and not up against the cabinet
face. Refer to Figure q).If the dishwasher door isopened
when the edge of the door isagainst the face of the cabinet,
dishwasher door damage and cabinet damage will occur.
, Open and close the dishwasher door to be sure it operates
smoothly, and does not rub on the adjacent cabinet.
STEP 14: LEVEL DISHWASHER
IMPORTANT - Dishwasher must be level for proper
dish rack operation, wash performance and door operation.
Thedishwasher must be leveled left to right and front to back.
This ensures the dish racks will not roll in or out on their own,
circulation water will flow to the pump inlet, and the door will
close without hitting the side of the tub.
, Remove the lower dish rack and place a level on the door and
lower rack track as shown in Figure R.
Adjust the level of the dishwasher by individually turning the 4
legs on the bottom of the dishwasher as illustrated in Figure S.
Thedishwasher isproperly leveled when the level indicator is
centered left to right and front to back. Also,the dishwasher
door should close without hitting the side of the tub.
Replace the lower rack.
_\\\\
Check
Level"
Front
to Buck Check
Level
Side
to Side
Figure R
Door
Fits and
Swings
Back
Behind
Cabinet
Frame
Alignment
Incorrect Alignment DoorCatches
will resultin door damage on CabinetFrame
Figure Q
Tip: Prevent unnecessary service charges for panel damage
or wash performance.
Check dishwasher alignment prior to opening dishwasher door
to prevent panel damage.
Hake sure utility lines are not trapped or crushed behind
dishwasher. Crushed lines will restrict water flow.
Figure S '\to Adjust /
Tip: Prevent unnecessary service charges. Verify dishwasher
is leveled.
Pull the dish racks half way out. They should stay put. Open
and close the door.The door should fit in the tub opening
without hitting the side of the tub. If the racks roll on their own,
or the door hits the side of tub, relevel the dishwasher.

Dishwasher Installation
STEP 15: POSITION DISHWASHER, SECURE
TO COUNTERTOP OR CABINET
Inthis step you will need the 2 Phillipsspecial head screws
from the screws set aside in Step 1.
The dishwasher must be secured to the countertop or the
cabinet sides. When the underside of the countertop is wood,
use Method 1.Use Method 2 when the underside of the
countertop is made of a material, such as granite, that will not
accept wood screws.
IMPORTANT - Preventdoorpaneland control
panel damage. Dishwasher must be positioned so the front
panel and control panel do not contact the adjacent cabinets
or countertop. Mounting screws must be driven straight and
flush. Protruding screw heads could scratch the door panel or
control panel and interfere with door operation.
Method 1
Secure dishwasher to underside of wood countertop.
. Recheck alignment of the dishwasher in the cabinet. Referto
Steps 13 and 1/4.Door panel and/or control panel must not
hit cabinets or countertop.
. Fasten the dishwasher to the underside of the countertop
with the 2 Phillips special head screws. Refer to Figure T.
Make certain screws are driven straight and flush to prevent
panel damage.
• Install plug buttons to the side of the tub well in the holes
provided.
Figure T
Brackets Wood Countertop
Method 2
Secure dishwasher to cabinet sides.
. Recheck alignment of the dishwasher in the cabinet. Refer to
Steps 13 and 1/4.Door panel and/or control panel must not
hit cabinets or countertop.
. Fasten the dishwasher to the adjacent cabinets with the 2
Phillips special head screws provided. Refer to Figure U. Make
certain screws are driven straight and flush to prevent panel
damage.
Install plug buttons to the side of the tub well in the holes
provided. Granite Countertop
/
/
/
Figure U
STEP 16: CONNECT WATER SUPPLY
Connect water supply line to 90° elbow.
If using a flexible braided hose connection:
Attach nut to 90° elbow using an adjustable wrench.
If using a copper tubing connection:
Slide compression nut, then ferrule over end of water line.
Insert water line into 90° elbow.
Slide ferrule against elbow and secure with compression nut.
IMPORTANT - Checktobesurethatdoorspring
and/ordoorspringcabledo notruborcontactthefillhoseor
water supply line.
Test by opening and
closing the door.
Reroute the water
supply lines if a
rubbing noise or
interference
occurs.
Hot Water
Supply Line
90° Elbow \ Compression
\ \ Nut
Ferrule
Figure V Bottom Left Side
STEP 17: CONNECT DRAIN LINE
The molded end of the drain hose will fit 5/8" through 1"
diameter inlet ports on the air gap, waste tee or disposer.
Determine size of inlet port.
Cut drain hose connector on the marked line, if required,
to fit the inlet port.
Figure W
Cutting Line
/
#
IMPORTANT: Do not cut corrugated
portion of hose
. If a longer drain hose is required and you did not purchase
drain hose GPF12L,add up to 66" length for o total of 14/4"
(12 feet) to the factory-installed hose. Use 5/8" or 7/8" inside
diameter hose and a coupler to connect
the 2 hose ends.
Secure the
connection
with hose
clamps. Coupler
Figure × Hose Clamp
Hose Clamp
NOTE: TOTAL DRAIN HOSE LENGTH MUST NOT EXCEED 12 FEET
FOR PROPER DRAIN OPERATION.
lO

Dishwasher Installation
STEP 17: CONNECT DRAIN LINE (Cont.)
. Connect drain line to air gap, waste tee or disposer
using the previously determined method. Secure hose
with a screw-type clamp.
Method 1 - Air gap with waste tee or disposer
Waste Tee Installation Disposer Installation
Figure Y
Method 2 - "High drain loop" with waste tee or disposer
With this method you will need the drain hose hanger set aside
in Step 1.
Fasten drain hose to underside of countertop with the provided
hanger.
__ Drain Hos,e Hanger
WasteTeeInstallation
Figure Z DisposerInstallation
IMPORTANT - When connecting drain line to
disposer, check to be sure that drain plug has been removed.
DISHWASHERWILL NOTDRAINIF PLUGISLEFTIN PLACE.
4 Remove
Drain
Plug
Tip: Avoid unnecessary service call charges for a no drain
complaint.
Make sure excess drain hose has been pulled through
the cabinet opening. This will prevent excess hose in the
dishwasher cavity from becoming kinked or crushed by the
dishwasher.
STEP 18: CONNECT POWER SUPPLY
Ifa power cord with plug is already installed proceed to
Step 19.
AWARNING:
If house wiring is not 2-wire with ground, a ground must be
provided by the installer. When house wiring is aluminum, be sure
to useUL-Listedanti-oxidantcompoundand aluminum-to-copper
connectors.
A ADVERTENCIA:
Sielcableadodom@sticonocuentaconuncablede 2hiloscon
conexi6natierra,un instaladordeberealizarunaconexi6na tierra.
Cuandoelcableadodom@sticoesdealuminio,asegOresedeusar
uncompuestoantioxidanteyconectoresdealuminioa cobre
aprobadosparUL
In this step you will need the junction box cover and the
#10 Hex head screw from the screws set aside in Step 1.
. Secure house wiring to the back of the junction box with a
strain relief.
. Locate the 3 dishwasher wires, (white, black and green) with
the stripped ends coming out of the ACjumper. Use ULlisted
wire nuts of appropriate size to connect incoming ground to
green, white to white and black to black.
. Install the junction box cover using #10 hex head screw.
Check to be sure that wires are not pinched under the cover.
. Hake sure that the junction box cover is resting on the
mounting bracket.
NOTE:Do not remove the
Junction Box Bracket.
Ground
White AC
Ground
Screw
Figure AA
Black
11

Dishwasher Installation
STEP 19:PRETEST CHECKLIST
Reviewthislistafterinstallingyourdishwashertoavoid
chargesfora servicecallthatisnotcoveredbyyour
warra nty.
,Check to be sure power is OFF.
,Open door and remove all foam and paper packaging.
,Locate the Owner's Manual set aside in Step 1.
,Read the Owner's Manual for operating instructions.
,Check door opening and closing. If door does not open and
close freely, check for proper routing of spring cable over
pulley. If door drops or closes when released, adjust spring
tension. See Step 2,
. Check to be sure that wiring is secure under the dishwasher,
not pinched or in contact with door springs or other
components. See Step 18.
, Check door alignment with tub. If door hits tub, level
dishwasher. SeeStep 1/4.
,Pull lower rack out, about halfway. Checkto be sure it does
not roll back or forward on the door. If the rack moves, adjust
leveling legs. SeeStep 1/4.
,Check door alignment with cabinet. If door hits cabinet,
reposition dishwasher. See Step 13.
,Check that door spring does not contact water line,fill hose,
wiring or other components. See Step 15.
,Verify water supply and drain lines are not kinked or in
contact with other components. Contact with motor or
dishwasher frame could cause noise.
,Turn on the sink hot water faucet and verify water
temperature. Incoming water temperature must be between
120°Fand 140°F.A minimum of 120°Ftemperature is
required for best wash performance. See "Prepare Hot Water
Line,"page 5.
,Add 2 quarts of water to the bottom of the dishwasher to
lubricate the pump seal.
,Turn on water supply. Check for leaks.Tighten connections if
needed.
, Remove protective film if present from the control panel and
door.
STEP 20: DISHWASHER WET TEST
,Turn on power supply or plug power cord into outlet,
if equipped.
, Select a cycle to run and push the Start/Reset pad.
, Ensurethe door is latched. Dishwasher should start.
,Check to be sure that water enters the dishwasher. If water
does not enter the dishwasher, check to be sure that water
and power are turned on.
,Check for leaks under the dishwasher. If a leak isfound, turn
off power at the breaker, and then tighten water connections.
Restore power after leak is corrected.
,Check for leaks around the door.A leak around the door could
be caused by door rubbing or hitting against
adjacent cabinets. Reposition the dishwasher if necessary.
SeeStep 13.
Pressand hold the Start/Reset pad for 3 seconds to cancel
the cycle. The unit will begin to drain. Check drain lines. If
leaks are found, turn off power at the breaker and correct
plumbing as necessary. Restore power after corrections are
made. See Steps 7,9, 10 and 17.
,Open dishwasher door and make sure all of the water has
drained. If not, check that disposer plug has been removed
and/or air gap is not plugged. Also check drain hose to be
sure it is not kinked underneath or behind dishwasher. See
Step 17.
PressStart/Reset pad once again and run dishwasher
through another cycle. Check for leaks and correct if
required.
Repeat this step as necessary.
12

Dishwasher Installation
STEP 21: POSITION SOUND BARRIER
AND INSULATION
{on some models)
Skip this step if the sound barrier is not assembled to the
dishwasher.
. Locate the sound insulation package inside the dishwasher.
, Locate the control box.
Control
Box
, Peeloff the paper from the insulation.
, Apply the insulation to the underside of the control box and
flush with its front face as shown.
Insulation shown adhered to bottom edge of the control
box, flush with the front face, and correctly placed along
dishwasher bottom.
, Remove the masking tape from the sound barrier, and door
front. Re-position the sound barrier over the sound insulation.
Sound
Burrier
L
STEP 22: REPLACE TOEKICK
. Place toekick against the legs of the dishwasher.
Screws
Figure CC
Align the toekick with the bottom edge and make sure it is
against the floor.
Insert and tighten the 2 toekick attachment screws. The
toekick should stay in contact with the floor.
When reinstalling the toe kick on models with a sound barrier,
ensure that the bottom edge of the rubberized flap isflush
with the floor. Any excess material should be tucked up
behind the outer door. Donot allow excess rubberized flap to
lay on the floor. If any excess is not tucked completely behind
the outer door, it will bunch up between the door and toe kick
and impede proper opening and closing of the door. This will
be noticeable because the door will not stay fully open and
will spring up.
Tip: Reduce sound from under the dishwasher.
Hake sure toekick is against floor.
STEP 23: LITERATURE
, Besure to leave complete literature package, these
Installation Instructions and product samples and/or coupons
with the consumer.
13

Notes
14

Notes
15

SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
GEAppliances
General Electric Company
Louisville, Kentucky/40225
GEAppliances.com © 2013 General Electric Company

Appareils m@nagers
Directivesd'instailation
Lave-vaisselleencastr@
Pourtoute question, composez le 1.800.561.3344 ou visitez notre site Web:
www.electromenagersge.ca
AVANT DE COMMENCER
Veuillez lira attentivement toutes lesdirectives
qui suivent.
IMPORTANT - Observeztouslescodeset
ordonnances en vigueur.
. Note 6 I'instellateur - Veuillez laisser les pr6sentes directives
au consommateur pour I'inspecteur local.
. Note au consommateur - Veuillez conserver les pr6sentes
directives avec votre Manuel d'utilisation pour consultation
ult6rieure.
. Comp_tences requises - L'installation de ce lave-vaisselle
exige des comp6tences de base en m6canique, en 61ectricit_
et en plomberie. L'installateur est responsable de la qualit_
de I'instellation. Toute d@failJancedu produit ettribuable
6 une installation ined@uate n'est pus couverte par la
garantie de GE.Reportez-vous a la garantie du produit.
. Dur@ede I'installation - Entre 1 et 3 heures. L'installation
d'un nouveau lave-vaisselle exige plus de temps qua
le remplacement d'un ancien mo@le.
IMPORTANT - Le lave-vaisselle DOIT_tre install6 de
mani_re 6 ce qu'il puisse _tre sorti de son emplacement si des
r@arations sont n6cessaires.
II importe d'user de prudence Iorsque I'appareil est install6
ou d@lac6 afin de pr6venir I'endommagement du cordon
d'alimentation.
Si le lave-vaisselle que vous avez request endommag6,
communiquez imm6diatement avec votre d6taillant ou
I'entrepreneur en construction.
Accessoires facultatifs - Reportez-vous au Hanuel d'utilisation
pour conndtre les ensembles pour panneau d6coratif
personnalis6 offerts.
POURVOTRES CUR T
Veuillez lira et observer toutes les raises en garde
(ATTENTION et AVERTISSEMENT} donn_es dens les pr_sentes
directives. Pour effectuer I'instellation d_crite dans les
pr_sentes directives, il faut porter des gents et des lunettes
de s_curit_.
VEUILLEZ LIRE ATTENTIVEMENT
ET CONSERVER CES DIRECTIVES.
Imprimd auxEtats-Unis 31-31506-3 04-13 GE

Pr6paration pour I'installation
PIt CESFOURNIES DANS UEMBALLAGE:
, Couverclede la bottedejonction etvis 6 t6te
hexagonalen° 10
, Collier
, Boyaudevidange (198cm/78 po de long)
, Supportde twau devidange)
, 2vis(3t6te hexagonaleno 8-18 pourfixer lessupports
au cadredela cuvedu lave-vaisselle
, 2 Boutonsde bouchon
, 2 Moulureslat6rales(certainsmod61es)
, 2supportsde montage pour comptoirs ou armoires
lat6ralesen bois
, 2vis(3t6te sp6cialePhillipsn°8-18 x !5,8 mm
(5/8po)pourfixer lelave-vaisselleau dessous
du comptoirou armoireslat6rales
, Documentation,#chantillonset(ou)bans
\
Couvercle de la
boTte de jonction
et vis 6t_te
hexogonole n°10
Support de tuyou
de vidange
?
Vis 6t_te
hexagonale n° 10
de 12,7 mm {1/2 po)
de long pour boTte
dejonction
(sur certoins modules)
Collier
??
Vis 6t@te hexagonole
n° 8 pour support de
montage
Supports de
montage
MATI RIEL NI CESSAIRE:
, Coudede 90°,bague et#crou(_compression(filetageexterneNPT
de 9,5mm (3/8po)ou 19,! mm [5/4 po]filet pour tuyau d'arrosage
dejardin pour lave-vaisselle5 uneextr#mit# etI'autreextr#mit#
conquepour leraccordement 5 laconduite d'alimentation eneau)
, Rubanpourjoints filet#s
, Connecteursvissableshomologu#sUL(3)
,Ruban-cache Ruban-cache
Pour une nouvelle installation: (s'il y a lieu)
, Coupureanti-refoulement pour leboyaude vidange,sin#cessaire
, RaccordenTpour la plomberiede la r#sidence,s'ilya lieu
, C_ble#lectriqueoucordon d'alimentation
, Colliers5 vissansfin
, Bagueanti-traction pour leraccordement 61ectrique
, Robinetd'arr6t(recommand6)
, Conduited'alimentationen eau - twau en cuivred'aumains
9,5mm (5/8po)ou un boyauflexibletress6noW×18×326 de GE
, BoyaudevidangeGPF12L(5.66m/!2 pide long),sin6cessaire
©
Coude de 90°,
bogue et _crou
a compression
?
Roccord en T
Robinet Rubon pour
d'orr_t joints filet_s
(sill y a lieu)
CSble _lectrique (ou cordon
d'alimentation, s'il y a lieu)
Coupure
Colliers avis sans fin
Bogue anti-traction
onti-refoulement
Boyaudevidange
n
Boutons de
bouchon
Visa t_te
sp_ciole
Phillips n°8
de 15,8 mm
(5/8 po) de long
Connecteurs
vissables {3)
Conduited'eou
chaude
Boyau de vidange
facultotif GPF12L
de 3.66 m (12 pi)
OUTILS NI CESSAIRES:
, TournevisPhillips
, Tourne-6crousde6,3mm (1/4po)et
de 7,9mm (5/16po)
, CI65 molette de 15,2cm (6po)
, Niveau
, Equerrede charpentier
, Ruban5 mesurer
, Lunettesdes_curit#
, Lampedepoche
, Seaupour recueillirI'eauIorsdu rinqage
de laconduited'eau
, CI_5 douillede 23,8mm (15/16po)
(facultatif- pour enleverlabasede bois)
, Gants
, Pince
, Pour une nouvelle installation:
, Coupe-tubes
, Perceuseetforetsappropri#s
, Jeude scies-cloche
Phillips
CI_ 6 douille de
23,8 mm (15116 po)
Lampe de poche
Gants
Tou
de 6,3 mm 11/4 po)
et de 7,9 mm (5/16 po)
Pince
CI6 6molette
de 15,2 cm
(6 po)
Seou
Niveou
Coupe-tubes
I_querre de
charpentier
Ruban 6 mesurer

Preparation pour I'installation
PRI_PARATION DE L'OUVERTURE DANS
LESARMOIRES
33-1/2 po to 34-3/4 po
du dessous du
Lemur du fond
doit _tre exempt
de tuyaux ou
de ills
AVERTISSEMENT:
Pourr_duirelesrisquesde choc_lectrique,d'incendieou de
blessures,I'installateurdoits'assurerque lelave-vaisselleest
compl_tementencastr_au momentdeI'installation.
Lelave-vaisselle doit _tre install6 de faqon 6 ce que le boyau
de vidange mesure au maximum 3.66 m_tres (12 pieds) pour
assurer une vidange ad6quate.
Ledessus, lesc6t6s et I'arri_re du lave-vaisselle doivent
_tre compl_tement dissimul6s 6 I'int@ieur de I'ouverture.
Lelave-vaisselle ne doit soutenir aucune pattie de la
structure des armoires.
comptoir au
plancher
Figure A
61,0 cm
(24 po) min.
Armoires (3
1'6querre et
_d'aplomb
. L'ouverture dons les armoires doit mesurer au moins
61,0 cm (24 po) de largeur et de profondeur, et environ
87,6 cm (34-!/2 po) de hauteur 6 partir du plancher
jusqu'au-dessous du comptoir.
DI_GAGEMENTS:
. Dans le cos d'une
installation duns un
coin, veuillez pr@oir un
d6gagement d'au moins
5,1 cm (2 po) entre le Iove-
vaisselle et lesarmoires, le
mur ou un 61ectrom6nager
adjacent. Veuillez pr6voir
un d6gagement d'au moins
72 cm (28-3/8 po)a I'avant
du lave-vaisselle pour
I'ouverture de la porte.
Reportez-vous (_la Figure B.-
. Laisserun espaced'au moins -
!5,2 cm (6po)entreleIove-
vaisselle,la cuisini@eou autres
appareilsavecfour.
Comptoir
72#1283,8pol
7/ S,1 cm(2 po) minimum pourI'ouverture de la porte
Figure B
EXIGENCES RELATIVES AU SYSTEME
DE VIDANGE
. Veuillezobserver lesordonnonces et lescodes Iocauxen vigueur.
. Leboyau de vidange doitavoir une Iongueur maximale de
3.66m_tres (!2 pieds).
REHARQUE:IIfaut installerune coupure anti-refoulement sile
raccord au broyeura d6chetsou au raccord enTsetrouve a moins
de 46 cm (18po)au-dessusdu plancher (]fin d'@iter un siphonage.
CHOI× DE LA MI_THODE DE VIDANGE
Letype d'installation de vidange d6pend desconditions suivantes.
. Lesordonnances ou codes Iocauxen vigueurexigent-ils
une coupureanti-refoulement?
. Leraccorclen Tsetrouve-t-il (_moins de 46 cm (18po)
du plancher?
Sivous r6pondez OUl6 I'uneou I'autre de ces questions,
vous DEVEZutiliser la m_thode n° 1.
. Sivous r_pondez NON,vous pouvezemployer I'uneou I'autre
desm@hodes.
PR(=PARATION DES ARMOIRES
. Percezun trou de 3,8cm (1-1/2po)de diam_tre densk] paroi de
I'armoirequi setrouve dans la partie ombr6ede I(] FigureApour
leboyau de vidange.Assurez-vousque I'orificene pr6sente pas
d'ar@esvives.
IMPORTANT - Lorsquevous
bronchezleboyoude vidongea un
broyeur(_d6chets,ossurez-vousd'enlever
lebouchondevidonge.LELAVE-VAISSELLE
4 nlevezle
bouchon
de vidange
NE POURRA PASSEVIDER SIVOUS LAISSEZLEBOUCHON EN PLACE,
Figure C
H_thode n° 1 - Coupure anti-refoutement avec raccord en T ou
broyeur 6 d_chets
IIfaut installer une coupure anti-refoulement Iorsqu'elle est exig_e par
les ordonnances et les codes Iocaux en vigueur. Cette coupure anti-
refoulement doit _tre install_e conform_ment aux directives donn_es
par le fabricant.
Crochet pour boyau de vidange j,M9 Crochet pour boyau t vidange
Iql /(C_l I82cm F
/ pl III [ _llS2; _°1/
m,n. III I .V cd.?t /
118po)min _ (18po)_ L
Figure D
M@thode n° 2 - Boucle de vidange @lev@eavec raccord en T ou
broyeur a d@chets
Conseil: Pour @viterdes frois de r(_poration inutiles.
Assurez-vous d'enlever le bouchon de vidange du broyeur a
d6chets ovont d'y broncher le boyou devidonge du Iove-voisselle.3

Preparation pour I'installation
PRE PARATION DU C#,BLAGE E LECTRIOUE
AVERTISSEMENT:
POURVOTRESECURITEPERSONNELLE:Enlevezlefusibleou
d@clenchezledisjoncteurau panneaude distributionprincipal
avant de commencerI'installation.N'utilisezpasune rallonge
@lectriqueou un adaptateur defiche aveccet appareil.
Alimentotion @lectrique
.Cet appareil doit _tre aliment6 par un courant de 120 Vet
60 Hz,et branch6 6 un circuit individuel correctement mis
6 la terre et prot6g_ par un disjoncteur de !5 ou 20 amperes
ou un fusible temporis6.
. Le c@ble61ectriquedoit poss6der deux fils, plus un fil de mise
6 la terre, et r6sister 6 une temp6rature nominale de 75 °C
(176 °F).
. Sivotre alimentation 61ectrique ne r6pond pas 6 ces
exigences, appelez un 61ectricien agr66 avant de poursuivre
I'installation.
Mise 6 la terre- Branchement permanent
Cet appareil doit _tre branch6 6 un r6seau _lectrique
permanent mis 6 la terre. Sinon, il faut installer un conducteur
de raise 6 la terre avecles conducteurs du circuit et le brancher
6 la borne de raise 6 la terre du r6seau ou au fil de raise 6 la
terre de I'appareil.
Mise 6 la terre - ModUles dot_s d'un cordon d'alimentotion
Cet appareil doit _tre mis 6 la terre. Encas de mauvais
fonctionnement ou de d6faillance, la raise6 la terre r6duira
les risques de choc 61ectrique en fournissant au courant
61ectrique un circuit de moindre r6sistance. Cet appareil est
dot6 d'un cordon d'alimentation poss_dant un conducteur
de raise 6 laterre et une fiche de raise 6 la terre. Lafiche
doit _tre branch6e clans une raise appropri6e, install6e et
raise 6 la terre en conformit6 avec tousles codes Iocaux et
ordonnances en vigueur.
A AVERTISSEMENT:
Un branchement inad_quat du conducteur de raise 6 la terre
peutpr@senterdesrisquesdechoc @lectrique.Sivousn'@tespas
certain que I'appareilestcorrectementmis6 laterre,consultez
unr@parateurou un @lectricienqualifi@.
_'/ /_- Autreemplacement _'\
/_ possiblepourla l \
_ i prisede courant i \I \
46 cm (18 po)
-- 46 cm i÷ la prise d_--_l
(18po) I c°urclr"tIS1
/1÷'-
15cm 16po) 15cm-_
"Trou de 3,8 cm
7,6cm (3po)
des armoires
Mise 6 la terre
Noir
Figure E Blanc
Dons le cos des modules dot_s d'un cordon d'alimentotion:
Ne modifiez pas la fiche fournie avec I'appareil; si vous ne
pouvez pas la brancher dans la prise de courant, faites installer
une prise de courant appropri6e par un technicien qualifi6.
Preparation des ormoires et cheminement des ills
. Lesfils peuvent entrer dans I'ouverture du c6t_ droit, du c6t_
gauche, de I'arri_re ou du plancher dans la pattie ombr6e de
la Figure Eet de la FigureA.
. Percez un trou de 3,8 cm (1-!/2 po) de diam_tre au maximum
pour le passage du cable 61ectrique.Le bard du trou doit
_tre lisse et arrondi. Lesfils 61ectriques pour le branchement
permanent peuvent passer par le m_me trou que le boyau
de vidange et la conduite d'eau chaude, si c'est plus pratique.
Si le trou est pratiqu6 dans une paroi en m6tal, les bards de
I'orifice doivent _tre recouverts d'un passe-fils pour prot6ger
les fils.
REMARQUE:Lecordon d'alimentation dot6 d'une fiche doit
passer par un autre trou.
Branchement _lectrique du lave-voisselle
Le branchement _lectrique s'effectue du c6t_ avant droit du
lave-vaisselle.
Dans lecas d'un branchement permanent, le c_ble doit _tre
achemin_ de la faqon indiqu_e 6 la Figure E.Lec_ble doit
avoir une Iongueur minimale de 61 cm (24 po) 6 partir du tour
arri_re.
Dans le cas d'un branchement avec un cordon d'alimentation,
installez une prise de courant raise 6 la terre 6 trois broches
sur la paroi de I'armoire adjacente, entre 15 cm (6 po) et
46 cm (18 po) de I'ouverture, et entre 15 cm (6 po) et 46 cm
(18 po) du plancher.
Utilisez WD06×10020 Trousse de cordon d'alimentation pour
lave-vaisselle.
