GE Monogram ZBD3500ZZWW User instructions

Monogram.
™
ZBD3500ZZWW - GE Monogram Dishwasher with PermaTuf®Interior
Dimensions and Specifications (in inches)
Design Information: Designed for versatility, these dishwashers adapt
to virtually any installation. This dishwasher is supplied as a white
model. Optional trim kits allow door and access panels to be replaced
with custom panels of wood or other material to match cabinetry
or other appliances. GPF400S Trim Kit is also available for a stainless
steel appearance.
To achieve a custom flush appearance, standard 24" base cabinets
should be moved forward by use of spacer blocks.
Optional Kits:
• GPF425 Trim Kit-Provides for the installation of 1/4" thick custom door
and access panels.
• GPF475 Trim Kit-Provides for the installation of 3/4" thick custom door
and access panels.
• GPF400S Trim Kit-Provides stainless steel door and access panel.
• GPF400B, GPF400W Trim Kits-Black or White color change or
replacement door and access panel.
• GPF600B, GPF600W Trim Kits-Black or White replacement door only.
• GPF700B, GPF700W Trim Kits-Black or White replacement access
panel only.
• GPF100 Heavy Spring Kit-Heavy duty springs for door panels weighing
4 to 8 pounds. This spring kit is included with the GPF475 and
GPF400S.
• GPF53 Mounting Kit-Special brackets for installing dishwasher
beneath countertops of stone or other materials which will not
accept screws.
Additional Specifications: A 120 Volt, 60 Hz power supply is required.
An individual properly grounded branch circuit protected by a 15 or 20
amp circuit breaker or time delay fuse is recommended. Install a 3-prong
electrical receptacle at least 6" above the floor and within 18" of the
right or left adjacent cabinet wall. Wiring must enter the cutout in
shaded area shown. A double, side-by-side installation requires two
separate circuits.
The hot water line must enter the cutout in the shaded area from the
right, left, rear or through the floor. The water line should be 3/8" O.D.
copper or 1/2" O.D. plastic. Installation of an easily accessible hand
shut-off valve is strongly recommended.
The dishwasher should be placed no more than 10 feet from the sink for
proper drainage.
For a corner installation, allow 2” clearance between dishwasher and
adjacent cabinet or wall.
24"
4"
4 1/2"
34" Min.
35" Max.
Toekick
24 3/4"
25"
(Including 1/4"
Rear Insulation)
3 1/4"
Plumbing and Electric Services
Must Enter Inside This Area
6"
24"
Min.
ThisWallArea
mustbeFreeof
Pipesorwires
34-1/2"±1/4"
Underside of
Countertop
to Floor 4"
24"
Min.
5" 5"
4"
Cabinets
Square
and Plumb
For answers to your Monogram,®
GE Profile Performance Series,™
GE Profile™or GE appliance questions, call
GE Answer Center®service, 800.626.2000.
Created 11/98
R
Listed by
Underwriters
Laboratories

Monogram.
™
ZBD3500ZZWW - GE Monogram Dishwasher with PermaTuf®Interior
Dimensions and Specifications (in inches)
1/4" Custom Panels The GPF425 Trim Kit provides for
the installation of 1/4" thick custom door and access
panels.
3/4" Custom Panels: The GPF425 Trim Kit provides
for the installation of 3/4" thick custom door and
access panels with a typical 4" high toekick.
• The custom panels should be constructed in the
same manner as cabinet doors. Cut edges can be seen
and must be finished for the best appearance.
• This kit includes GPF100 heavy duty spring kit for
panels that weigh 4 to 8 pounds.
• Rout the bottom edge of the door panel on the
appearance side 1/2" deep and 1-1/2" high
resulting in 1/4” thickness.
Note: The custom wood access panel should evenly
match the bottom of adjacent cabinets. Adjustments
made to the leveling legs to obtain correct height
can affect the vertical dimension (height) of the
access panel.
GPF400S Trim Kit: Provides stainless steel door and
access panels and matching stainless trim.
1/4" Thick
Door Panel
23-9/16"
3-11/16"
19-3/4"
1/4" Thick Access Panel
1-1/2"
3/4"
1/2"
19-7/8"
23-5/8"
3/4" Thick Panel
Appearance Side
A*
23-5/8"
3/4" Thick Access Panel
1/4" Custom Door and Access Panel
Dimensions Using GPF425 Trim Kit
3/4" Custom Door and Access Panel
Dimensions Using GPF475 Trim Kit
3/4" Custom Access Panel Dimensions
Using GPF475 Trim Kit
* 3-3/4” min., 4-1/4” max.for typical 4” toekicks
For answers to your Monogram,®
GE Profile Performance Series,™
GE Profile™or GE appliance questions, call
GE Answer Center®service, 800.626.2000.
Created 11/98
R
Listed by
Underwriters
Laboratories

Monogram.
™
Created 11/98
ZBD3500ZZWW - GE Monogram Dishwasher with PermaTuf®Interior
Monogram
SENSING
NORMAL
CleanSensor
POTS
LOAD SELECTIONS
STATUS OPTIONS
2 4 8
PANS CHINA
CRYSTAL RINSE
RESET
START
&HOLD POWER
PRESOAK HITEMP
RINSE HEATED
DRY LOCK
(2TIMES)
DELAY
START
GLASSES
WASHING
RINSING
DRYING
CLEAN
Features and Benefits
• Sound Insulation Package
• PermaTuf®Tub
• QuickClean Solid-State Electronic Controls
• Cycle Selections: Pots & Pans Cycle, Normal
Wash, China/Crystal,
• Glasses and Rinse & Hold
• Power Pre-Soak
• Cycle Auto Memory
• Cycle Status Indicators
• Three-Level Wash System
• Water Temp Options Include Norm and Boost
• CleanSensor Technology
• Lower Wash Arm
• Triple Filtration System
• Super Nylon Upper Rack
• Nylon Lower Rack with Fold-Down Tines
• Split Silverware Basket with Cell Covers
• Adjustable Utility Shelves
• Convection Drying
• Heated Dry On/Off
• Rinse Aid Dispenser
• Electronic Child Lock-Out
• 2/4/8-Hour Delay Start Option
• ZBD3500ZZWW - White on white
• ZBD3500ZZBB- Black on black
