GE 19204 User manual

GE Model 19204/19218
www.jascoproducts.com
Wired Push Button
This button is not recommended for use on systems which exceed 16 volts.
Included hardware:
(2) 3x20mm screws
Installation
Push buttons are typically mounted at the same height above the door sill as the
door knob or handle (between 36” and 44” above the sill).
Taking out the back cover of the push button:
1. Locate the two door chime wires emanating from the existing door chime
circuit.
2. Test the door chime by touching the two wires together, completing the circuit.
If the door chime does not sound, check the chime transformer or chime.
3. Turn off power.
4. Attach one wire to each of the screw terminals on the back of the button.
5. Mount the button in the desired location with two (2) screws provided. Install
according to applicable local electrical codes.
6. Close the back cover.

Ratings: 16 V Maximum
! Warning
Risk of electric shock
. Turn off power before replacing switch
Rick of fire
. Do not exceed electrical ratings
For technical support contact Jasco Products Company at 1-800-654-8483
or www.jascoproducts.com
Made in China
is a trademark of
General Electric Company
and is used under license to
Jasco Products Company LLC,
311 N.W. 122nd Street,
Oklahoma City, OK 73114.
www.jascoproducts.com
Rev. 1-07 19216
