JVM1850BH/CH/SH/WH – GE Spacemaker®Over-the-Range Microwave Oven
Dimensions (in inches)
For answers to your Monogram,®GE Profile™or
GE®appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.
R
Listed by
Underwriters
Laboratories
Note: Requires 120V grounded outlet. Electrical receptacle must be located in
cabinet above Spacemaker microwave oven. No additional wiring, venting or
cabinet rebuilding necessary in many cases. Complete detailed, easy-to-follow
installation instructions and convenient full-size templates are packed with
the Spacemaker microwave oven.
Important Information: When installing the Spacemaker microwave oven
over a range, allow minimum of 2" from bottom of Spacemaker microwave
oven to top of range backguard to allow for removal of light covers.
Ventilation Options: The Spacemaker microwave ovens are designed for
adaptation to the following three types of ventilation:
•Outside exhaust (vertical –as shown)
•Outside exhaust (horizontal)
•Recirculating (non-vented ductless –see Filter Kit drawing)
Installation Information: This information is not intended to be used for
installing unit described. Before installing, consult installation instructions
packed with product/kit for current dimensional data.
21-3/4"
Door open
16-13/32
66" MIN.
Mounting
height
from
floor
30"
MIN.
width
required
12"
MIN.
Exhaust outlet
connects to
3-1/4" X 10" duct
15-1/4
16
29-7/8
Specification Created 10/03
340105

GE Appliances
JVM1850BH/CH/SH/WH –GE Spacemaker®Over-the-Range Microwave Oven
Specification Created 10/03
340105
R
Listed by
Underwriters
Laboratories
For answers to your Monogram,®GE Profile™or
GE®appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.
Optional Accessories (Available at additional cost)
HOOD EXHAUST DUCT: Outside ventilation requires a HOOD EXHAUST DUCT. Read the following carefully.
EXHAUST CONNECTION: The hood exhaust has been designed to mate with a standard 3-1/4" x 10"
rectangular duct. If a round duct is required, a rectangular-to-round transition adaptor must be used.
Do not use less than a 6”diameter duct
REAR EXHAUST: If a rear or horizontal exhaust is to be used, care should be taken to align exhaust with space
between studs, or wall should be prepared at the time it is constructed by leaving enough space between the
wall studs to accommodate exhaust.
MAXIMUM DUCT LENGTH: For satisfactory air movement, the total duct length of 3-1/4" x 10" rectangular or
6" diameter round duct should not exceed 140 equivalent feet.
ELBOWS, TRANSITIONS,WALL AND ROOF CAPS, etc., present additional resistance to airflow and are
equivalent to a section of straight duct which is longer than their actual physical size. When calculating the total
duct length, add the equivalent length of all transitions and adaptors plus the lengths of all straight duct sections.
The chart below shows the approximate feet of equivalent length of some typical ducts.
Duct Equivalent Feet
A. Rectangular-To-round 5 ft.
Transition Adaptor
B. Wall Cap 40 ft.
C. 90°Elbow 10 ft.
D. 45°Elbow 5 ft.
E. 90°Elbow 25 ft.
F. 45°Elbow 5 ft.
G. Roof Cap 24 ft.
Filter Kits
JX81B–Recirculating
Charcoal Filter Kit
To be used when the
Spacemaker microwave
oven cannot be vented
to the outside.
Filler Panel Kits
JX52WH–White
JX52BL–Black
When replacing a 36" or 42"
range hood, this kit fills in the
additional width to provide a
custom built-in appearance.
For installation between
cabinets only; not for
end-of-cabinet installation.
Each kit contains two 3"-wide
filler panels.

GE Appliances
JVM1850BH/CH/SH/WH –GE Spacemaker®Over-the-Range Microwave Oven
ONETOUCH SENSOR
BEVERAGE
VEGETABLES
POPCORN REHEAT
POTATO
ADD
30 SEC.
POWER
LEVEL
123
456
789
0
EXPRESSCOOK EXPRESSCOOK EXPRESSCOOK
EXPRESSCOOK EXPRESSCOOK EXPRESSCOOK
TIME
COOK
AUTO/TIME
DEFROST
1 lb QUICK
DEFROST
CLEAR
OFF START
PAUSE
CLOCK
AM/FM
DELAY
START
VENT FAN
BOOST SURFACE
LIGHT
VENT FAN
OPTIONS
HELP
TIMER
TURNTABLE REMEMBER
Spacemaker XL1800
Features and Benefits
•1.8 cu. ft. capacity –1100 Watts (IEC-705 test procedure)
•Circuwave™1100 cooking system –Patented system provides more power for faster more
evening cooking results.
•Sensor cooking controls –Automatically adjust the time and power for perfect cooking results.
•Convenience cooking controls –Allows cooking and reheating at the touch of a button.
•1-lb. Quick Defrost –Evenly defrosts a pound meat, poultry or fish in a fraction of the
usual time, without precooking or turning the food.
•14-1/4" recessed turntable –Large enough to handle 5-qt. casserole dishes and can easily
be removed for cleaning.
•Three-speed, 300-CFM vortex venting vystem –Quickly removes smoke and steam from
the cooktop.
•Model JVM1850WH –White on white
•Model JVM1850BH –Black on black
•Model JVM1850CH –Bisque on bisque
•Model JVM1850SH –Stainless steel
