GE JB850 User manual

49-80701-2 10-14 GE
GEAppliances.com
Write the model and serial
numbers here:
Model # __________________
Serial #___________________
You can find them on a label
behind the door or drawer.
Printed in the United States
Printed on
Recycled Paper
For a Spanish version of this
manual, visit our Website at
GEAppliances.com.
Para consultar una version
en español de este manual
de instrucciones, visite
nuestro sitio de internet
GEAppliances.com.
JB850 - 30" Free-Standing Double Oven
JB870 - 30" Free-Standing Double Oven
PB950 - 30" Free-Standing Double Oven
Owner’s Manual
Ranges
Electric Free-Standing
Safety Information............2
Warranty.......................7
Assistance / Accessories.....8
Using The Range
Surface Units .....................9
Cookware for Radiant
GlassCooktop.................12
DoubleOvenControls...........13
SpecialFeatures................14
Oven Racks .....................15
Aluminum Foil and Oven Liners . . 16
Cookware.......................16
Cooking Modes .................17
Cooking Guide ..................18
Care and Cleaning
Cleaning the Range – Exterior . . . 20
Cleaning the Range – Interior....21
CleaningtheGlassCooktop......22
Maintenance....................24
Troubleshooting Tips .......26

249-80701-2
SAVE THESE INSTRUCTIONS
Read all safety instructions before using the product. Failure to follow these instructions may result in fire,
electrical shock, serious injury or death.
STATE OF CALIFORNIA PROPOSITION 65 WARNING
ANTI-TIP DEVICE
WARNING
The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to
publish a list of substances known to the state to cause cancer, birth defects or other reproductive harm,
and requires businesses to warn customers of potential exposure to such substances.
WARNING This product contains one or more chemical known to the State of California to
cause cancer, birth defects or other reproductive harm.
Self-clean ovens can cause low-level exposure to some of these substances, including carbon monoxide,
during the cleaning cycle. Exposure can be minimized by venting with an open window or using a
ventilation fan or hood.
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
SAFETY INFORMATION
To reduce the risk of tipping the range,
the range must be secured by a properly
installed anti-tip bracket. See installation
instructions shipped with the bracket for
complete details before attempting to install.
For Free-Standing and Slide-In Ranges
To check if the bracket is installed and
engaged properly, look underneath the
range to see that the rear leveling leg
is engaged in the bracket. On some models, the storage
drawer or kick panel can be removed for easy inspection.
If visual inspection is not possible, slide the range forward,
confirm the anti-tip bracket is securely attached to the floor
or wall, and slide the range back so the rear leveling leg is
under the anti-tip bracket.
If the range is pulled from the wall for any reason, always
repeat this procedure to verify the range is properly secured
by the anti-tip bracket.
Never completely remove the leveling legs or the range will
not be secured to the anti-tip device properly.
A child or adult can tip the range and be killed.
Verify the anti-tip bracket has been properly installed
and engaged.
Ensure the anti-tip bracket is re-engaged when the range
is moved.
Do not operate the range without the anti-tip bracket in
place and engaged.
Failure to follow these instructions can result in death or
serious burns to children or adults.
Tip-Over Hazard
WARNING
Anti-Tip
Bracket
Leveling Leg
Free-Standing and Slide-In Ranges

49-80701-2 3
SAVE THESE INSTRUCTIONS
SAFETY INFORMATION
Ŷ8VHWKLVDSSOLDQFHRQO\IRULWVLQWHQGHGSXUSRVH
as described in this Owner’s Manual.
Ŷ%HVXUH\RXUDSSOLDQFHLVSURSHUO\LQVWDOOHGDQG
grounded by a qualified installer in accordance
with the provided installation instructions.
Ŷ'RQRWDWWHPSWWRUHSDLURUUHSODFHDQ\SDUWRI
your range unless it is specifically recommended
in this manual. All other servicing should be
transferred to a qualified technician.
Ŷ%HIRUHSHUIRUPLQJDQ\VHUYLFHXQSOXJWKHUDQJH
or disconnect the power supply at the household
distribution panel by removing the fuse or
switching off the circuit breaker.
Ŷ'RQRWOHDYHFKLOGUHQDORQH²FKLOGUHQVKRXOGQRW
be left alone or unattended in an area where an
appliance is in use. They should never be allowed
to climb, sit or stand on any part of the appliance.
Ŷ CAUTION:Do not store items of
interest to children above a range or on the
EDFNJXDUGRIDUDQJH²FKLOGUHQFOLPELQJRQWKH
range to reach items could be seriously injured.
Ŷ8VHRQO\GU\SRWKROGHUV²PRLVWRUGDPSSRW
holders on hot surfaces may result in burns from
steam. Do not let pot holders touch hot surface
units or heating elements. Do not use a towel or
other bulky cloth in place of pot holders.
Ŷ 1HYHUXVH\RXUDSSOLDQFHIRUZDUPLQJRUKHDWLQJ
the room.
Ŷ 'RQRWWRXFKWKHVXUIDFHXQLWVWKHKHDWLQJ
elements or the interior surface of the oven.
These surfaces may be hot enough to burn
even though they are dark in color. During and
after use, do not touch, or let clothing or other
flammable materials contact the surface units,
areas nearby the surface units or any interior
area of the oven; allow sufficient time for cooling
first. Other surfaces of the appliance may
become hot enough to cause burns. Potentially
hot surfaces include the cooktop, areas facing
the cooktop, oven vent opening, surfaces near
the opening and crevices around the oven door.
Ŷ 'RQRWKHDWXQRSHQHGIRRGFRQWDLQHUV3UHVVXUH
could build up and the container could burst,
causing an injury.
Ŷ 'RQRWXVHDQ\W\SHRIIRLORUOLQHUWRFRYHUWKH
oven bottom or anywhere in the oven, except as
described in this manual. Oven liners can trap
heat or melt, resulting in damage to the product
and risk of shock, smoke or fire.
Ŷ $YRLGVFUDWFKLQJRULPSDFWLQJJODVVGRRUVFRRN
tops or control panels. Doing so may lead to
glass breakage. Do not cook on a product with
broken glass. Shock, fire or cuts may occur.
Ŷ &RRNPHDWDQGSRXOWU\WKRURXJKO\²PHDWWR
at least an internal temperature of 160°F and
poultry to at least an internal temperature of
180°F. Cooking to these temperatures usually
protects against foodborne illness.
GENERAL SAFETY INSTRUCTIONS
WARNING
ŶDo not store or use flammable materials in
an oven or near the cooktop, including paper,
plastic, pot holders, linens, wall coverings,
curtains, drapes and gasoline or other flammable
vapors and liquids.
Ŷ
Never wear loose-fitting or hanging garments while
using the appliance. These garments may ignite if
they contact hot surfaces causing severe burns.
ŶDo not let cooking grease or other flammable
materials accumulate in or near the range.
Grease in the oven or on the cooktop may ignite.
ŶClean ventilating hoods frequently. Grease
should not be allowed to accumulate on the hood
or filter.
KEEP FLAMMABLE MATERIALS AWAY FROM THE RANGE
Failure to do so may result in fire or personal injury.
WARNING

449-80701-2
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
SAFETY INFORMATION
ŶDo not use water on grease fires. Never pick up
a flaming pan. Turn the controls off. Smother a
flaming pan on a surface unit by covering the
pan completely with a well-fitting lid, cookie sheet
RUIODWWUD\8VHDPXOWLSXUSRVHGU\FKHPLFDORU
foam-type fire extinguisher.
ŶIf there is a fire in the oven during baking,
smother the fire by closing the oven door and
turning the oven off or by using a multi-purpose
dry chemical or foam-type fire extinguisher.
ŶIf there is a fire in the oven during self-clean, turn
the oven off and wait for the fire to go out. Do
not force the door open. Introduction of fresh air
at self-clean temperatures may lead to a burst
of flame from the oven. Failure to follow this
instruction may result in severe burns.
IN THE EVENT OF A FIRE, TAKE THE FOLLOWING
STEPS TO PREVENT INJURY AND FIRE SPREADING
WARNING
Ŷ Never leave the surface units unattended at
PHGLXPRUKLJKKHDWVHWWLQJV%RLORYHUVFDXVH
smoking and greasy spillovers that may catch
on fire.
ŶNever leave oil unattended while frying. If
allowed to heat beyond its smoking point, oil
may ignite resulting in fire that may spread
WRVXUURXQGLQJFDELQHWV8VHDGHHSIDW
thermometer whenever possible to monitor oil
temperature.
Ŷ
To avoid oil spillover and fire, use a minimum
amount of oil when shallow pan-frying and
avoid cooking frozen foods with excessive
amounts of ice.
Ŷ8VHSURSHUSDQVL]H²VHOHFWFRRNZDUHKDYLQJ
flat bottoms large enough to cover the surface
heating element. The use of undersized
cookware will expose a portion of the surface
unit to direct contact and may result in ignition
of clothing. Proper relationship of cookware to
surface unit will also improve efficiency.
ŶOnly certain types of glass, glass/ceramic,
earthenware or other glazed containers are
suitable for cooktop service; others may break
because of the sudden change in temperature.
ŶTo minimize the possibility of burns, ignition of
flammable materials and spillage, the handle of a
container should be turned toward the center of
the range without extending over nearby surface
units.
ŶWhen preparing flaming foods under a hood, turn
the fan on.
ŶIf power is lost to an electric cooktop while a
surface unit is ON, the surface unit will turn back
on as soon as power is restored. In the event of
power loss, failure to turn all surface unit knobs
to the OFF position may result in ignition of items
on or near the cooktop, leading to serious injury
or death.
COOKTOP SAFETY INSTRUCTIONS
WARNING
SAVE THESE INSTRUCTIONS

49-80701-2 5
ŶStand away from the range when opening the
oven door. Hot air or steam which escapes can
cause burns to hands, face and/or eyes.
ŶDo not use the oven if a heating element
develops a glowing spot during use or shows
other signs of damage. A glowing spot indicates
the heating element may fail and present a
potential burn, fire, or shock hazard. Turn the
oven off immediately and have the heating
element replaced by a qualified service
technician.
ŶKeep the oven vent unobstructed.
ŶKeep the oven free from grease buildup. Grease
in the oven may ignite.
ŶPlace oven racks in desired location while oven
is cool. If rack must be moved while oven is hot,
do not let pot holder contact hot heating element
in oven.
ŶWhen using cooking or roasting bags in the
oven, follow the manufacturer’s directions.
ŶPull the oven rack to the stop-lock position when
loading and unloading food from the oven. This
helps prevent burns from touching hot surfaces
of the door and oven walls.
ŶDo not leave items such as paper, cooking
utensils or food in the oven when not in use.
Items stored in an oven can ignite.
ŶNever place cooking utensils, pizza or baking
stones, or any type of foil or liner on the oven
floor. These items can trap heat or melt, resulting
in damage to the product and risk of shock,
smoke or fire.
OVEN SAFETY INSTRUCTIONS
WARNING
SAVE THESE INSTRUCTIONS
SAFETY INFORMATION
Ŷ8VHFDUHZKHQWRXFKLQJWKHFRRNWRS7KHJODVV
surface of the cooktop will retain heat after the
controls have been turned off.
ŶDo not cook on a broken cooktop. If glass
cooktop should break, cleaning solutions and
spillovers may penetrate the broken cooktop and
create a risk of electric shock. Contact a qualified
technician immediately.
ŶAvoid scratching the glass cooktop. The cooktop
can be scratched with items such as knives,
sharp instruments, rings or other jewelry, and
rivets on clothing.
ŶDo not place or store items that can melt or catch
fire on the glass cooktop, even when it is not
being used. If the cooktop is inadvertently turned
on, they may ignite. Heat from the cooktop or
oven vent after it is turned off may cause them to
ignite also.
Ŷ8VH&(5$0$%5<7(®ceramic Cooktop Cleaner
DQG&(5$0$%5<7(®Cleaning Pad to clean
the cooktop. Wait until the cooktop cools and
the indicator light goes out before cleaning. A
wet sponge or cloth on a hot surface can cause
steam burns. Some cleaners can produce
noxious fumes if applied to a hot surface.
NOTE: Sugar spills are an exception. They
should be scraped off while still hot using an oven
mitt and a scraper. See the Cleaning the glass
cooktop section for detailed instructions.
ŶRead and follow all instructions and warnings on
the cleaning cream label.
RADIANT COOKTOP SAFETY INSTRUCTIONS
WARNING

649-80701-2
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
SAFETY INFORMATION
SAVE THESE INSTRUCTIONS
The self-cleaning feature operates the oven at temperatures high enough to burn away food soils in the
oven. Follow these instructions for safe operation.
Ŷ 'RQRWWRXFKRYHQVXUIDFHVGXULQJVHOIFOHDQ
operation. Keep children away from the oven
during self-cleaning. Failure to follow these
instructions may cause burns.
Ŷ
%HIRUHRSHUDWLQJWKHVHOIFOHDQF\FOHUHPRYHSDQV
shiny metal oven racks and other utensils from the
oven. Only gray porcelain-coated oven racks may
be left in the oven. Do not use self-clean to clean
other parts, such as drip pans or bowls.
Ŷ %HIRUHRSHUDWLQJWKHVHOIFOHDQF\FOHZLSH
grease and food soils from the oven. Excessive
amount of grease may ignite leading to smoke
damage to your home.
Ŷ ,IWKHVHOIFOHDQLQJPRGHPDOIXQFWLRQVWXUQWKH
oven off and disconnect the power supply. Have
it serviced by a qualified technician.
Ŷ 'RQRWFOHDQWKHGRRUJDVNHW7KHGRRUJDVNHWLV
essential for a good seal. Care should be taken
not to rub, damage or move the gasket.
Ŷ 'RQRWXVHRYHQFOHDQHUV1RFRPPHUFLDORYHQ
cleaner or oven liner protective coating of any kind
should be used in or around any part of the oven.
SELF-CLEANING OVEN SAFETY INSTRUCTIONS
WARNING

49-80701-2 7
GE Electric Range Warranty
GEAppliances.com
All warranty service is provided by our Factory Service Centers, or an authorized Customer Care®technician.
To schedule service, on-line, visit us at www.geappliances.com/service_and_support/, or call 800.GE.CARES
(800.432.2737). Please have serial number and model number available when calling for service.
Servicing your appliance may require the use of the onboard data port for diagnostics. This gives a GE factory
service technician the ability to quickly diagnose any issues with your appliance and helps GE improve its products
by providing GE with information on your appliance. If you do not want your appliance data to be sent to GE, please
advise your technician not to submit the data to GE at the time of service.
For the period of one year from the date of the original purchase. GE will provide any part of the range which fails due
to a defect in materials or workmanship. During this limited one-year warranty, GE will also provide, free of charge, all
labor and in-home service to replace the defective part.
What GE will not cover:
ŶService trips to your home to teach you how to use
the product.
ŶImproper installation, delivery or maintenance.
ŶFailure of the product if it is abused, misused,
modified or used for other than the intended purpose
or used commercially.
ŶDamage to the glass cooktop caused by use of
cleaners other than the recommended cleaning
creams and pads.
ŶDamage to the glass cooktop caused by hardened
spills of sugary materials or melted plastic that
are not cleaned according to the directions in the
Owner's Manual.
ŶReplacement of house fuses or resetting of circuit
breakers.
ŶDamage to the product caused by accident, fire,
floods or acts of God.
ŶIncidental or consequential damage caused by
possible defects with this appliance.
ŶDamage caused after delivery.
ŶProduct not accessible to provide required service.
ŶService to repair or replace light bulbs, except for
LED lamps.
EXCLUSION OF IMPLIED WARRANTIES
<RXUVROHDQGH[FOXVLYHUHPHG\LVSURGXFWUHSDLUDVSURYLGHGLQWKLV/LPLWHG:DUUDQW\$Q\LPSOLHGZDUUDQWLHV
including the implied warranties of merchantability or fitness for a particular purpose, are limited to one year or the
shortest period allowed by law.
This warranty is extended to the original purchaser and any succeeding owner for products purchased for home use
ZLWKLQWKH86$,IWKHSURGXFWLVORFDWHGLQDQDUHDZKHUHVHUYLFHE\D*($XWKRUL]HG6HUYLFHULVQRWDYDLODEOH\RX
may be responsible for a trip charge or you may be required to bring the product to an Authorized GE Service location
for service. In Alaska, the warranty excludes the cost of shipping or service calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty gives you
specific legal rights, and you may also have other rights which vary from state to state. To know what your legal rights
are, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: General Electric Company. Louisville, KY 40225
Extended Warranties: Purchase a GE extended warranty and learn about special discounts that are available while
\RXUZDUUDQW\LVVWLOOLQHIIHFW<RXFDQSXUFKDVHLWRQOLQHDQ\WLPH
www.geappliances.com/service_and_support/shop-for-extended-service-plans.htm
or call 800.626.2224 during normal business hours. GE Consumer Home Services will still be there after your
warranty expires.
Register Your Appliance: Register your new appliance on-line at your convenience!
www.geappliances.com/service_and_support/register/
Timely product registration will allow for enhanced communication and prompt service under the terms of your warranty,
VKRXOGWKHQHHGDULVH<RXPD\DOVRPDLOLQWKHSUHSULQWHGUHJLVWUDWLRQFDUGLQFOXGHGLQWKHSDFNLQJPDWHULDO
Staple your receipt here. Proof of the original purchase date is needed to obtain service under the warranty.
WARRANTY
Thank You! ... for your purchase of a GE Brand appliance.

849-80701-2
Have a question or need assistance with your appliance?
ASSISTANCE / ACCESSORIES
Schedule Service: Expert GE repair service is only one
step away from your door. Get on-line and schedule your
service at www.geappliances.com/service_and_support/
Or call 800.GE.CARES (800.432.2737) during normal
business hours.
Parts and Accessories: Individuals qualified to service
their own appliances can have parts or accessories sent
directly to their homes (VISA, MasterCard and Discover
cards are accepted).Order on-line today, 24 hours
every day or by phone at 800.626.2002 during normal
business hours.
Instructions contained in this manual cover procedures
to be performed by any user. Other servicing generally
should be referred to qualified service personnel. Caution
must be exercised, since improper servicing may cause
unsafe operation.
Real Life Design Studio: *(VXSSRUWVWKH8QLYHUVDO
Design concept of products, services and environments
that can be used by people of all ages, sizes and
capabilities. We recognize the need to design for a wide
range of physical and mental abilities and impairments.
)RUGHWDLOVRI*(¶V8QLYHUVDO'HVLJQDSSOLFDWLRQV
including kitchen design ideas for people with disabilities,
check out our Website today. For the hearing impaired,
please call 800.TDD.GEAC (800.833.4322).
Contact Us: If you are not satisfied with the service you
receive from GE, contact us on our Website with all the
details including your phone number, or write to:
General Manager, Customer Relations
GE Appliances, Appliance Park Louisville, KY 40225
Try the GE Appliances Website (www.geappliances.com/service_and_support/) 24 hours a day, any day of the
year! For greater convenience and faster service, you can now download Owner’s Manuals, order parts or even
schedule service on-line.
Accessories
Looking For Something More?
GE offers a variety of accessories to improve your cooking and maintenance experiences!
To place an order visit us online at:
www.GEApplianceParts.com86RUwww.GEAppliances.ca (Canada)
or call 800.626.200286800.661.1616 (Canada)
The following products and more are available:
How to Remove Protective Shipping Film and Packaging Tape
Carefully grasp a corner of the protective shipping film
with your fingers and slowly peel it from the appliance
surface. Do not use any sharp items to remove the film.
Remove all of the film before using the appliance for the
first time.
To assure no damage is done to the finish of the
product, the safest way to remove the adhesive from
packaging tape on new appliances is an application of
a household liquid dishwashing detergent. Apply with a
soft cloth and allow to soak.
NOTE: The adhesive must be removed from all parts. It
cannot be removed if it is baked on.
Accessories
 6PDOO%URLOHU3DQô´[ó´[ò´ :%;86'*&DQDGD
 /DUJH%URLOHU3DQô´[ó´[ò´ :%;86'*&DQDGD
 ;/%URLOHU3DQ´[ó´[ó´ :%;861RWDYDLODEOHLQ&DQDGD
Parts
Oven racks Part numbers vary by model
Oven elements Part numbers vary by model
Light bulbs Part numbers vary by model
Cleaning Supplies
 &LWUX6KLQH6WDLQOHVV6WHHO:LSHV :;;
 &(5$0$%5<7(®6WDLQOHVV6WHHO$SSOLDQFH&OHDQHU 30;
 &(5$0$%5<7(®&OHDQLQJ3DGVIRU&HUDPLF&RRNWRSV :;;
&(5$0$%5<7(®&HUDPLF&RRNWRS&OHDQHU :;;
 &(5$0$%5<7(®&HUDPLF&RRNWRS6FUDSHU :;;
 .LW.LWLQFOXGHVFUHDPDQGFRRNWRSVFUDSHU :%;27
7KHODUJHEURLOHUSDQGRHVQRWILWLQ´´UDQJHV
7KH;/EURLOHUSDQGRHVQRWILWLQ´ZDOORYHQV´GURSLQVRU´´UDQJH

49-80701-2 9
USING THE RANGE: Surface Units
Surface Units
FIRE HAZARD: Never leave the range unattended with the cooktop on medium or high
settings. Keep flammable items away from the cooktop. Turn off all controls when done
cooking. Failure to follow these instructions can result in fire, serious injury or death.
WARNING
Throughout this manual, features and appearance may vary from your model.
How to Set
Push the knob in and turn in either direction to the
setting you want.
A surface ON indicator light will glow when any surface
unit is on
For glass cooktop surfaces:
AHOT COOKTOP indicator light will:
Ŷcome on when the unit is hot to the touch.
Ŷstay on even after the unit is turned off.
Ŷstay on until the unit is cooled to
DSSUR[LPDWHO\)
Dual and Triple Surface Units and Control Knobs (on some models)
The surface unit has 2 or 3 cooking sizes to select from so you can match the size of the unit to the size of the
cookware you are using.
At both OFF and HI the control clicks
into position. You may hear slight
clicking sounds during cooking,
indicating the control is maintaining
your desired setting.
Be sure you turn the control knob to
OFF when you finish cooking.
Models with a Dual-Ring surface
element only Models with a Tri-Ring surface
element only.
Melt setting (on some models) will
melt chocolate or butter.

10 49-80701-2
Surface Units (Cont.)
USING THE RANGE: Surface Units
Throughout this manual, features and appearance may vary from your model.
Using the Bridge Zone (on some models)
To use the bridge zone, adjust the knobs for the Left rear
and Left front elements to create one large area for even
cooking.
Using the Warming Zone
FOOD POISON HAZARD:%DFWHULDPD\JURZLQIRRGDW
temperatures below 140°F.
Always start with hot food. Do not use warm setting to
heat cold food.
Do not use warm setting for more than
2 hours.
The WARMING ZONE, located in the back center of
the glass surface, will keep hot, cooked food at serving
temperature. Always start with hot food. Do not use to
heat cold food. Placing uncooked or cold food on the
WARMING ZONE could result in foodborne illness.
Turn the control knob to the ON position.
For best results, all foods on the WARMING ZONE
should be covered with a lid or aluminum foil. When
warming pastries or breads, the cover should be vented
to allow moisture to escape.
The initial temperature, type and amount of food, type of
pan, and the time held will affect the quality of the food.
Always use pot holders or oven mitts when removing
food from the WARMING ZONE, since cookware and
plates will be hot.
NOTE: The surface warmer will not glow red like the
cooking elements.
Models with a bridge Zone only.
WARNING

49-80701-2 11
Home Canning Tips
%HVXUHWKHFDQQHULVFHQWHUHGRYHUWKHVXUIDFHXQLW
Make sure the canner is flat on the bottom.
To prevent burns from steam or heat, use caution when
canning.
8VHUHFLSHVDQGSURFHGXUHVIURPUHSXWDEOHVRXUFHV
7KHVHDUHDYDLODEOHIURPPDQXIDFWXUHUVVXFKDV%DOO®
and Kerr®and the Department of Agriculture Extension
Service.
)ODWERWWRPHGFDQQHUVDUHUHFRPPHQGHG8VHRIZDWHU
bath canners with rippled bottoms may extend the time
required to bring the water to a boil.
Temperature Limiter on Radiant Glass Cooktops
Every radiant surface unit has a temperature limiter.
The temperature limiter protects the glass cooktop from
getting too hot.
The temperature limiter may cycle the surface units off
for a time if:
Ŷ WKHSDQERLOVGU\
Ŷ WKHSDQERWWRPLVQRWIODW
Ŷ WKHSDQLVRIIFHQWHU
Ŷ WKHUHLVQRSDQRQWKHXQLW
For Models With a Radiant Glass Cooktop
The radiant cooktop features heating units beneath a
smooth glass surface.
NOTE: A slight odor is normal when a new cooktop is
used for the first time. It is caused by the heating of new
parts and insulating materials and will disappear in a
short time.
NOTE: On models with light-colored glass cooktops, it is
normal for the cooking zones to change color when hot
or cooling down. This is temporary and will disappear as
the glass cools to room temperature.
The surface unit will cycle on and off to maintain your
selected control setting.
It is safe to place hot cookware on the glass surface
even when the cooktop is cool.
Even after the surface units are turned off, the glass
cooktop retains enough heat to continue cooking. To
avoid overcooking, remove pans from the surface units
when the food is cooked. Avoid placing anything on the
surface unit until it has cooled completely.
Ŷ :DWHUVWDLQVPLQHUDOGHSRVLWVDUHUHPRYDEOHXVLQJ
the cleaning cream or full-strength white vinegar.
Ŷ 8VHRIZLQGRZFOHDQHUPD\OHDYHDQLULGHVFHQWILOPRQ
the cooktop. The cleaning cream will remove this film.
Ŷ 'RQ¶WVWRUHKHDY\LWHPVDERYHWKHFRRNWRS,IWKH\
drop onto the cooktop, they can cause damage.
Ŷ 'RQRWXVHWKHVXUIDFHDVDFXWWLQJERDUG
USING THE RANGE: Surface Units
Surface Units (Cont.)
Never cook directly on the glass.
Always use cookware.
Always place the pan in the center of
the surface unit you are cooking on.
Do not slide cookware across the cooktop
EHFDXVHLWFDQVFUDWFKWKHJODVV³WKHJODVV
is scratch-resistant, not scratch proof.

12 49-80701-2
Cookware for Radiant Glass Cooktop
USING THE RANGE: Cookware for Radiant Glass Cooktop
The following information will help you choose cookware which will give good performance on glass cooktops.
NOTE: Follow all cookware manufacturer’s recommendations when using any type of cookware on the ceramic cooktop.
Stainless Steel:
recommended
Aluminum:
heavy weight recommended
Good conductivity. Aluminum residues
sometimes appear as scratches on the
cooktop but can be removed if cleaned
LPPHGLDWHO\%HFDXVHRILWVORZPHOWLQJ
point, thin weight aluminum should not
be used.
Copper Bottom:
recommended
Copper may leave residues which can
appear as scratches. The residues can
be removed, as long as the cooktop
is cleaned immediately. However, do
not let these pots boil dry. Overheated
metal can bond to glass cooktops. An
overheated copper bottom pot will leave
a residue that will permanently stain the
cooktop if not removed immediately.
Porcelain Enamel on Cast Iron:
recommended if bottom of pan is coated
Porcelain Enamel on Steel:
not recommended
Heating empty pans can cause
permanent damage to cooktop glass.
The enamel can melt and bond to the
ceramic cooktop.
Glass-ceramic:
not recommended
Poor performance. Will scratch the
surface.
Stoneware:
not recommended
Poor performance. May scratch the
surface.
Cast Iron:
QRWUHFRPPHQGHG²XQOHVVGHVLJQHG
specifically for glass cooktops
Poor conductivity and slow to absorb
heat. Will scratch the cooktop surface.
Check pans for flat bottoms by using
a straight edge.
Pans with rounded, curved, ridged or
warped bottoms are not recommended.
Do not place wet pans on the glass cooktop.
Do not use woks with support rings on the
glass cooktop.
Use flat-bottomed woks on the glass cooktop.
For Best Results
Ŷ 3ODFHRQO\GU\SDQVRQWKHVXUIDFHHOHPHQWV'RQRW
place lids on the surface elements, particularly wet
lids. Wet pans and lids may stick to the surface when
cool.
Ŷ 'RQRWXVHZRNVWKDWKDYHVXSSRUWULQJV7KLVW\SHRI
wok will not heat on glass surface elements.
Ŷ :HUHFRPPHQGWKDW\RXXVHRQO\DIODWERWWRPHG
wok. They are available at your local retail store. The
bottom of the wok should have the same diameter as
the surface element to ensure proper contact.
Ŷ 6RPHVSHFLDOFRRNLQJSURFHGXUHVUHTXLUHVSHFLILF
cookware such as pressure cookers or deep-fat
fryers. All cookware must have flat bottoms and be
the correct size.

49-80701-2 13
1. Upper Oven and Lower Oven: Designates
which oven the controls will operate.
2. Convection Cooking Modes (on some
models): Convection cooking modes use
increased air circulation to improve performance.
7KHW\SHRIEHQHILWGHSHQGVRQWKHPRGH<RXU
oven has the following convection cooking modes:
&RQYHFWLRQ%DNHDQG&RQYHFWLRQ5RDVW6HHWKH
Cooking Modes section for more information.
3. Traditional Cooking Modes: <RXURYHQKDV
WKHIROORZLQJWUDGLWLRQDOFRRNLQJPRGHV%DNH%URLO
Hi/Lo and Warm. See the Cooking Modes section
for more information.
4. Self Clean: See the Cleaning the Oven section
for important information about using this mode.
5. Start: Must be pressed to start any cooking,
cleaning, or timed function.
6. Cancel/Off: Cancels ALL oven operations except
the clock and timer.
7. Clock: Sets the oven clock time. Press the Set
Clock or 9and 0SDGVDQGKROGIRUVHFRQGV8VH
the number pads to program the clock. Press Start
to save the time.
8. Timer: Works as a countdown timer. Press the
Timer pad and the number pads to program the
time in hours and minutes. Press the Start pad.
If the oven is on, it will not turn off when the timer
countdown is complete. To turn the timer off press
the Timer pad.
9. Delay Time: Delays when the oven will turn
RQ8VHWKLVWRVHWDWLPHZKHQ\RXZDQWWKHRYHQ
to start. Press the Delay Time pad and use the
number pads to program the time of day for the
oven to turn on then press Start. Press the desired
cooking mode and temperature then press Start.
A Cook Time may also be programmed if desired.
Follow the directions under Cook Time for setting
WKLVIHDWXUH7KLVFDQRQO\EHXVHGZLWK%DNH
&RQYHFWLRQ%DNH&RQYHFWLRQ5RDVWDQG6HOI&OHDQ
NOTE: When using the Delay Time feature, foods
WKDWVSRLOHDVLO\²VXFKDVPLONHJJVILVKVWXIILQJV
SRXOWU\DQGSRUN²VKRXOGQRWEHDOORZHGWRVLWIRU
more than 1 hour before or after cooking. Room
temperature promotes the growth of harmful
EDFWHULD%HVXUHWKDWWKHRYHQOLJKWLVRIIEHFDXVH
heat from the bulb will speed harmful bacteria
growth.
10. Cook Time: Counts down cooking time and turns
off the oven when the cooking time is complete.
Press the Cook Time pad, use the number pads
to program a cooking time in hours and minutes,
then press Start.7KLVFDQRQO\EHXVHGZLWK%DNH
&RQYHFWLRQ%DNHDQG&RQYHFWLRQ5RDVW
11. Oven Light(s): Turns the oven light(s) on or off
in both ovens. Note that lights in both ovens will not
turn on if the door is opened while the other oven is
in a clean mode.
12. Lock Controls: Locks out the control so that
pressing the pads does not activate the controls.
Press and hold the Lock Controls pad for three
seconds to lock or unlock the control. Cancel/Off is
always active, even when the control is locked.
USING THE RANGE: Double Oven Controls
DoubleOven Controls
15 581
2
3
3
46 7 64 99
10 101112

14 49-80701-2
Special Features
USING THE RANGE: Special Features
There are several different special features on your range. To change the settings of these special features:
Ŷ 3UHVVWKHBake and Broil pads at the same time and hold for three seconds.
Ŷ ³6)´ZLOODSSHDULQWKHGLVSOD\
Ŷ 6HOHFWWKHIHDWXUH\RXZDQWWRFKDQJH
Ŷ :KHQWKHFKDQJHKDVEHHQPDGHSUHVVWKHStart key to save the change and return to the time of day.
Adjust the Oven Temperature
This feature allows the oven baking and convection baking
WHPSHUDWXUHWREHDGMXVWHGXSWR)KRWWHURUGRZQ
WR)FRROHU8VHWKLVIHDWXUHLI\RXEHOLHYH\RXURYHQ
temperature is too hot or too cold and wish to change it.
7KLVDGMXVWPHQWDIIHFWV%DNHDQG&RQYHFWLRQ%DNHPRGHV
No other cooking modes are affected.
Press the Upper Oven Bake pad or Lower Oven Bake pad
corresponding to the oven to be adjusted. Press the Bake
pad again to enter the temperature adjustment mode. A
QXPEHUEHWZHHQDQGZLOOGLVSOD\8VHWKHQXPEHU
pads to set the desired temperature adjustment and use the
Bake pad to change between negative and positive. Press
the Start pad to save the temperature adjustment.
End of Timer Signals
This is the tone that signals the end of a timer. The tone
can be continuous (Con bEEP) or one repeating beep
(bEEP). A continuous setting will continue to sound a tone
until a button on the control is pressed. Press the Broil pad
to view the current setting and then to change the setting.
Fahrenheit or Celsius Temperature Display
The oven control is set to use Fahrenheit temperatures
(F), but you can change it to use Celsius temperatures (C).
Press the number 6and 8pads at the same time to view
the current setting, press again to change the setting.
Clock Display
This feature specifies how the time of day will be displayed
RULIQRWLPHRIGD\ZLOOEHGLVSOD\HG<RXFDQVHOHFWD
standard 12-hour clock (12 H), 24-hour military time display
(24 H), or no clock displayed (oFF). Press the Clock pad to
view the current setting, press again to change the setting.
Auto Recipe Conversion
:KHQXVLQJ&RQYHFWLRQ%DNHFRRNLQJ$XWR5HFLSH
Conversion will automatically convert the regular baking
temperatures entered to convection bake cooking
temperatures when turned on. Note that this option does
not convert convection bake cooking times, it only converts
temperatures. Press the Convection Bake pad to view the
conversion settings, press again to toggle between On (Con
On) and Off (Con oFF).
Sound Volume
This feature allows the oven tone volume to be adjusted
between high (HI bEEP HI), medium (Std bEEP Std),
low (Lo bEEP Lo) and off (oFF bEEP oFF). Press the
number 1and 5pads at the same time to view the current
setting or to change the setting. The control will sound the
oven tone at the new volume level each time the sound
level is changed.
12-hour auto shut-off and Sabbath
2SWLRQVIRUWKLVIHDWXUHDUH³6+GQ´³QR6+GQ´DQG
³6$EE$W+´
12-hour auto shut-off turns off the oven after 12 hours of
continuous operations.
Sabbath mode disables the oven lights all sounds (the
control will not beep when a button is pressed), Convection,
%URLO:DUP&RRN7LPH7LPHU&ORFNDQG'HOD\7LPH
IXQFWLRQV6DEEDWKPRGHFDQRQO\EHXVHGZLWK%DNH
This feature conforms to the Star-K Jewish Sabbath
requirements.
NOTE: The oven light comes on automatically (on some
models) when the door is opened and goes off when the
door is closed. The bulb may be removed. See the Oven
Light Replacement section. On models with a light switch
on the control panel, the oven light may be turned on and
left on.
Press the Delay Time pad to view the current setting and
then to change the setting.
Press the Delay Time pad to view the current setting and
then to change the setting.
7RXVH6DEEDWKPRGHVHOHFW³6$EE$W+´DQGSUHVVStart.
A]will appear in the display and the clock will not display.
Note that if you have a double oven, when you place the
control into Sabbath mode, both ovens are now in Sabbath
mode and available for cooking.
Once in Sabbath mode, at any time you can press Bake,
use the number pads to enter a temperature between
170°)DQG°F, and press Start. No sound will be given
when the keys are pressed. At a random time between
30 seconds and 1 minute, ][, will appear in the display
indicating the oven is running. Note that both ovens of a
double oven can be used in Sabbath mode. Each oven can
be programmed to a different temperature and each oven
must be programmed separately.
If you need to adjust the temperature, press Bake, use the
number pads to enter a new temperature between 170°F
DQG°F, and press Start.
To exit Sabbath mode, make sure that the oven is turned
off. To turn the oven off, press Cancel/Off. The oven will
immediately turn off and ][ will change to ]indicating that
the oven has turned off. Press and hold the Bake and Broil
pads for 3 seconds to enter special features then press
Delay Time until either "12 Shdn" or "no Shdn" is in the
display and press Start.
NOTE: If power outage occurs during Sabbath mode the
unit will remain in Sabbath mode but off when power is
restored.
If you wish to use the Cook Time feature (if available) to
bake in the oven and then have the oven automatically
turn off, you will need to press the Cook Time pad, enter a
cooking time duration, and press Start. Then enter special
features to start Sabbath mode as detailed above.

49-80701-2 15
Recommended rack positions for various types of
foods are provided in the Cooking Guide. Adjusting
rack position is one way to impact cooking results. For
example, if you would prefer darker tops on cakes,
muffins, or cookies, try moving food one rack position
higher. If you find foods are too brown on top try moving
them down next time.
When baking with multiple pans and on multiple racks,
HQVXUHWKHUHLVDWOHDVWòEHWZHHQSDQVWRDOORZ
sufficient space for air to flow.
<RXU2YHQPD\KDYHH[WHQVLRQUDFNVDQGRUWUDGLWLRQDO
flat racks.
To avoid possible burns, place the racks in the desired
position before you turn the oven on.
Extension Racks
Always pull the rack out by its upper front rail to its fully
open position, when placing or removing cookware.
If extension racks are difficult to extend, lubricate the
racks with the graphite lubricant provided with your
oven. Remove the rack from the oven, remove debris in
the side tracks with a paper towel, shake the graphite
lubricant and place 4 small drops on the two bottom
tracks of the left and right sides. Open and close the
rack several times to distribute the lubricant.
To order additional graphite lubricant, read the
Assistance and Accessories section at the beginning of
the manual.
To Remove An Extension Rack:
1. Make sure the rack is pushed all the way into the
oven so that side paddles on the rack disengage from
the oven support.
2. Slide the rack toward you to the bump (stop position)
on the rack support.
3. Firmly grasp both sides of the rack frame and the
sliding rack, tilt the front end up and pull it out.
To Replace An Extension Rack:
1. Firmly grasp both sides of the rack frame and the
sliding rack.
2. Place the curved end of the rack (stop-locks) onto the
oven supports, tilt up the front of the rack and push it
in as far as it will go.
If extension racks are difficult to replace or remove, wipe
the oven rack supports with cooking oil. Do not wipe oil
on the rack slides.
To Lubricate the Paddle:
Shake lubricant and apply to the moving parts of the
paddle mechanisms as shown.
The number of rack positions may vary by model.
Upper Front
Rail
Fully Open Position
Grasp here
USING THE RANGE: Oven Racks
Oven Racks

16 49-80701-2
USING THE RANGE: Aluminum Foil and Oven Liners /Cookware
Cookware
Cookware Guidelines
The material, finish, and size of cookware affect baking
performance.
Dark, coated and dull pans absorb heat more readily
than light, shiny pans. Pans that absorb heat more
readily can result in a browner, crisper, and thicker crust.
If using dark and coated cookware check food earlier
than minimum cook time. If undesirable results are
obtained with this type of cookware consider reducing
RYHQWHPSHUDWXUHE\)QH[WWLPH
Shiny pans can produce more evenly cooked baked
goods such as cakes and cookies.
Glass and ceramic pans heat slowly but retain heat well.
These types of pans work well for dishes such as pies
and custards.
Air insulated pans heat slowly and can reduce bottom
browning.
Keep cookware clean to promote even heating.
CAUTION: Do not use any type of foil or oven liner to cover the oven bottom. These items can trap
heat or melt, resulting in damage to the product and risk of shock, smoke or fire. Damage from improper use
of these items is not covered by the product warranty.
Foil may be used to catch spills by placing a sheet on a lower rack, several inches below the food. Do not use more
IRLOWKDQQHFHVVDU\DQGQHYHUHQWLUHO\FRYHUDQRYHQUDFNZLWKDOXPLQXPIRLO.HHSIRLODWOHDVW´IURPRYHQZDOOV
to prevent poor heat circulation.
Aluminum Foil and Oven Liners

49-80701-2 17
<RXUQHZRYHQKDVDYDULHW\RIFRRNLQJPRGHVWRKHOS\RXJHWWKHEHVWUHVXOWV7KHVHPRGHVDUHGHVFULEHGEHORZ
Refer to the Cooking Guide section for recommendations for specific foods. Remember, your new oven may perform
differently than the oven it is replacing.
Baking and Roasting Modes
Select a mode for baking and roasting based on the
type and quantity of food you are preparing. When
preparing baked goods such as cakes, cookies, and
pastries always preheat the oven first. Follow recipe
recommendations for food placement. If no guidelines
are provided, center food in the oven.
Bake
The bake mode is intended for single rack cooking. This
mode uses heat primarily from the lower element but
also from the upper element to cook food. To use this
mode press the Bake pad, enter a temperature, and
then press Start. Preheating is generally recommended
when using this mode.
Convection Bake Multi Rack
7KH&RQYHFWLRQ%DNH0XOWL5DFNPRGHLVLQWHQGHG
for baking on multiple racks at the same time. This
mode uses heat primarily from the rear element, when
available, but also heat from the upper and lower
elements, along with air movement from the convection
IDQWRHQKDQFHFRRNLQJHYHQQHVV<RXURYHQLV
equipped with Auto Recipe Conversion, so it is not
necessary to convert the temperature when using this
PRGH%DNLQJWLPHPLJKWEHVOLJKWO\ORQJHUIRUPXOWLSOH
racks than what would be expected for a single rack. To
use this mode press the Convection Bake pad, enter a
temperature, and then press Start. Always preheat when
using this mode.
Convection Roast
The Convection Roast mode is intended for roasting
whole cuts of meat on a single rack. This mode uses
heat from the lower, upper, and rear elements, when
available, along with air movement from the convection
fan to improve browning and reduce cooking time. It
is not necessary to convert temperature. Check food
earlier than the recipe suggested time when using this
mode or use a meat probe. To use this mode press the
Convection Roast pad, enter a temperature, and then
press Start. It is not necessary to preheat when using
this mode.
Broiling Modes
%URLOLQJLVDYDLODEOHLQERWKRYHQV)RUEHWWHUEURLOLQJ
the lower oven is recommended. When broiling in the
upper oven, the door should remain CLOSED. When
broiling in the lower oven, the door should remain OPEN.
0RQLWRUIRRGFORVHO\ZKLOHEURLOLQJ8VHFDXWLRQZKHQ
broiling on upper rack positions as placing food closer to
the broil element increases smoking, spattering, and the
possibility of fats igniting. For best performance center
food below the broil heating element. Broiling on rack
position 7 in the lower oven is not recommended.
Try broiling foods that you would normally grill. Adjust
rack positions to adjust the intensity of the heat to the
food. Place foods closer to the broil element when a
seared surface and rare interior is desired. Thicker foods
and foods that need to be cooked through should be
broiled on a rack position farther from the broiler or by
XVLQJ%URLO/R
Broil Hi
7KH%URLO+LPRGHXVHVLQWHQVHKHDWIURPWKHXSSHU
HOHPHQWWRVHDUIRRGV8VH%URLO+LIRUWKLQQHUFXWVRI
meat and/or foods you prefer less done on the interior.
To use this mode press the Broil pad once and then
press Start. It is not necessary to preheat when using
this mode.
Broil Lo
7KH%URLO/RPRGHXVHVOHVVLQWHQVHKHDWIURPWKHXSSHU
element to cook food thoroughly while also producing
VXUIDFHEURZQLQJ8VH%URLO/RIRUWKLFNHUFXWVRIPHDW
and/or foods that you would like cooked all the way
through. To use this mode press the Broil pad twice and
then press Start. It is not necessary to preheat when
using this mode.
Warm
Warm mode is designed to keep hot food hot, it is not
intended to heat cold food. To use this mode, press the
Warm pad then press Start. Preheating is not required.
Cover foods that need to remain moist and do not
cover foods that should be crisp. It is recommended,
for food quality, that food not be kept warm for more
than 2 hours.
USING THE RANGE: Cooking Modes
Cooking Modes

18 49-80701-2
FOOD TYPE RECOMMENDED
MODE(S) RECOMMENDED RACK POSITION(S) ADDITIONAL SUGGESTIONS
Baked Goods
Layer cakes, sheet cakes,
bundt cakes, muffins, quick
breads on a Single Rack %DNH 48VHVKLQ\FRRNZDUH
Layer cakes* on Multiple
Racks %DNH DQG Ensure adequate airflow (see illustration below).
Chiffon cakes (angel food) %DNH 18VHVKLQ\FRRNZDUH
Cookies, biscuits, scones
on a Single Rack %DNH 48VHVKLQ\FRRNZDUH
Cookies, biscuits, scones
on Multiple Racks %DNH &RQYHFWLRQ%DNHLIDYDLODEOH
DQG
2, 4, and 6 (3 rack
recommended only for
&RQYHFWLRQ%DNH
Ensure adequate airflow.
Beef & Pork
Hamburgers %URLO+L 6.HHSWKHGRRURSHQZKHQEURLOLQJLQWKHORZHURYHQ8VHDEURLOSDQPRYH food down for more doneness/less searing. Watch food closely when broiling.
For best performance center food below the broil heating element.
Steaks & Chops %URLO+L 6.HHSWKHGRRURSHQZKHQEURLOLQJLQWKHORZHURYHQ8VHDEURLOSDQPRYH food down for more doneness/less searing. Watch food closely when broiling.
For best performance center food below the broil heating element.
Roasts %DNH
Convection Roast (if available) 3 or 4 8VHDORZVLGHGSDQVXFKDVDEURLOSDQ3UHKHDWLQJLVQRWQHFHVVDU\
Poultry
Whole chicken %DNH
Convection Roast (if available) 3 or 4 8VHDORZVLGHGSDQVXFKDVDEURLOSDQ
%RQHLQFKLFNHQEUHDVWV
legs, thighs
%URLO+L 2,IEUHDGHGRUFRDWHGLQVDXFHDYRLG%URLO+LPRGHV%URLOVNLQVLGHGRZQILUVW
Watch food closely when broiling. Keep the door open when broiling in the
lower oven. For best performance when broiling, center food below the broil
heating element.
%URLO/R
%DNH 2 or 3
%RQHOHVVFKLFNHQEUHDVWV %URLO/R
%DNH 2 or 3
Keep the door open when broiling in the lower oven. Move food down for
more doneness/less searing and up for greater searing/browning when
broiling. For best performance when broiling, center food below the broil
heating element.
Whole turkey %DNH
Convection Roast (if available) 1 or 2 8VHDORZVLGHGSDQVXFKDVDEURLOSDQ
7XUNH\%UHDVW %DNH
Convection Roast (if available) 2 or 3 8VHDORZVLGHGSDQVXFKDVDEURLOSDQ
Fish %URLO/R 6 (1/2 inch thick or less)
!LQFK
Keep the door open when broiling in the lower oven. Watch food closely when
broiling. For best performance center food below the broil heating element.
Casseroles %DNH 3 or 4
Frozen Convenience Foods
Pizza, french fries, tator
tots, chicken nuggets,
appetizers on a Single Rack %DNH 3 or 4 8VHVKLQ\FRRNZDUH
Pizza, french fries, tator
tots, chicken nuggets,
appetizers on Multiple
Racks
%DNH
&RQYHFWLRQ%DNHLIDYDLODEOH DQG 8VHVKLQ\FRRNZDUH
*When baking four cake layers at a time, use racks 3
DQG. Place the pans as shown so that one pan is not
directly above another.
Cook food thoroughly to help protect against food
borne illness. Minimum safe food temperature
recommendations for food safety can be found at
www.IsItDoneYet.gov. Make sure to use a food
thermometer to take food temperatures.
Rack position for baking 4 layer cakes.
Cooking Guide
USING THE RANGE: Cooking Guide
Lower Oven for Double Oven Models

49-80701-2 19
FOOD TYPE RECOMMENDED
MODE(S) RECOMMENDED RACK POSITION(S) ADDITIONAL SUGGESTIONS
Baked Goods
Layer cakes, sheet cakes,
muffins, baked on Single Rack %DNH 18VHVKLQ\FRRNZDUH
Cookies, biscuits, scones on a
Single Rack %DNH 18VHVKLQ\FRRNZDUH
Beef & Pork
Hamburgers %URLO+L 1
Keep the door closed when broiling in the upper
RYHQ8VHDEURLOSDQPRYHIRRGGRZQIRUPRUH
doneness/less searing. Watch food closely when
broiling. For best performance center food below the
broil heating element.
Steaks & Chops %URLO+L 1
Keep the door closed when broiling in the upper
RYHQ8VHDEURLOSDQPRYHIRRGGRZQIRUPRUH
doneness/less searing. Watch food closely when
broiling. For best performance center food below the
broil heating element.
Poultry
%RQHLQFKLFNHQEUHDVWVOHJV
thighs %URLO/R %DNH 1
%URLOVNLQVLGHGRZQILUVW:DWFKIRRGFORVHO\ZKHQ
broiling. Keep the door closed when broiling in the
upper oven. For best performance when broiling,
center food below the broil heating element.
%RQHOHVVFKLFNHQEUHDVWV %URLO/R
%DNH 1Keep the door closed when broiling in the upper
oven. For best performance when broiling, center
food below the broil heating element.
Fish %URLO/R 1
Keep the door closed when broiling in the upper
oven. Watch food closely when broiling. For best
performance center food below the broil heating
element.
Frozen Convenience Foods
Pizza, french fries, tator tots,
chicken nuggets, appetizers
on a Single Rack %DNH 18VHVKLQ\FRRNZDUH
Upper Oven for Double Oven Models
USING THE RANGE: Cooking Guide
Cooking Guide (Cont.)
NOTE: For better broiling, the lower oven is recommended.

20 49-80701-2
Cleaning the Range – Exterior
CARE AND CLEANING: Cleaning the Range – Exterior
If your range is removed for cleaning, servicing or any reason, be
sure the anti-tip device is reengaged properly when the range is
replaced. Failure to take this precaution could result in tipping of the
range and can result in death or serious burns to children or adults.
WARNING
%HVXUHDOOFRQWUROVDUHRIIDQGDOOVXUIDFHVDUHFRROEHIRUHFOHDQLQJDQ\SDUWRIWKHUDQJH
Control Knobs
The control knobs may be removed for easier cleaning.
Make sure the knobs are in the OFF positions and pull
them straight off the stems for cleaning.
The knobs can be cleaned in a dishwasher or they may
also be washed with soap and water. Make sure the
inside of the knobs are dry before replacing.
Replace the knobs, in the OFF position to ensure proper
placement.
Control Lockout
If desired, the touch pads may be deactivated before
cleaning.
See Lock Controls in the Oven Controls section in this
manual.
Clean up splatters with a damp cloth.
<RXPD\DOVRXVHDJODVVFOHDQHU
Remove heavier soil with warm, soapy water. Do not use
abrasives of any kind.
Reactivate the touch pads after cleaning.
Control Panel
It’s a good idea to wipe the control panel after each use.
Clean with mild soap and water or vinegar and water,
rinse with clean water and polish dry with a soft cloth.
Do not use abrasive cleansers, strong liquid cleansers,
plastic scouring pads or oven cleaners on the control
SDQHO²WKH\ZLOOGDPDJHWKHILQLVK
Oven Exterior
Do not use oven cleaners, abrasive cleansers, strong
liquid cleansers, steel wool, plastic scouring pads, or
cleaning powders on the interior or exterior of the oven.
Clean with a mild soap and water or vinegar and water
solution. Rinse with clean water and dry with a soft cloth.
When cleaning surfaces, make sure that they are at
room temperature and not in direct sunlight.
If stain on the door vent trim is persistent, use a mild
abrasive cleaner and a sponge-scrubber for best results.
Spillage of marinades, fruit juices, tomato sauces and
basting liquids containing acids may cause discoloration
and should be wiped up immediately. Let hot surfaces
cool, then clean and rinse.
Painted Surfaces
Painted surfaces include the sides of the range and the
doors, and top of control panel. Clean these with soap and
water or a vinegar and water solution.
Do not use commercial oven cleaners, cleaning powders,
steel wool or harsh abrasives on any painted surface.
Stainless Steel Surfaces (on some models)
Do not use a steel wool pad; it will scratch the surface.
To clean the stainless steel surface, use warm sudsy
water or a stainless steel cleaner or polish. Always wipe
the surface in the direction of the grain. Follow the cleaner
instructions for cleaning the stainless steel surface.
To inquire about purchasing cleaning products including
stainless steel appliance cleaner or polish read the
Assistance and Accessories sections at the beginning of
this manual.
Porcelain Enamel Cooktop
The porcelain enamel finish is sturdy but breakable if
misused. This finish is acid-resistant. However, any acidic
foods spilled (such as fruit juices, tomato or vinegar)
should not be permitted to remain on the finish.
If acids spill on the cooktop while it is hot, use a dry paper
towel or cloth to wipe it up right away. When the surface
has cooled, wash with soap and water. Rinse well.
For other spills such as fat spatterings, wash with soap
and water or cleansing powders after the surface has
cooled. Rinse well. Polish with a dry cloth.
