GE JKP44 User manual

Built-in Oven
Safety instructions.....................3 4
Operating Instructions, Tips
Aluminum Foil....................4, 12, 16, 19,21
Baking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-14
Broiling, Broiling Guide .......................20-22
Control Panel
...,..........................................6-8
Clock and Timer .........................................6, 7
Fan ...9, 10, 13, 14, 16, 18, 20,24,25,30
Features........................................................5, 6
Light; Bulb Replacement .......................9, 27
Preheating . . . . . . . . . . . . . . . . . . . . . . . . 11, 14, 16, 19, 22
Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17, 18,29
Roasting, Roasting Guide . . . . . . . . . . . . . . . . . . . 16-19
Roasting with the Probe . . . . . . . . . . . . . . . 17, 18
Self-Cleaning Instructions ..................23-26
Shelves .........................9, 11, 16,23,26,28
Timed Baking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 14
Problem Solver...............................30
Thermostat Adjustment–
Do It Yourself
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ......15
More questions ?.,.call
GE Answer Center@ 800.626.2000
Care and Cleaning ....................27-29
Broiler Pan and Grid ....................................27
Door Removal ...............................................28
Oven Shelves..................................2 3,26, 28
Probe .............................................................2 9
Self-Cleaning Instructions ..................23-26
Consumer Services .,,................3 1
Appliance Registration ..................................2
Important Phone Numbers........................3 1
Model and Serial Number Location ...........2
Removal of Packaging Tape ........................2
Warranty ........................................Back Cover
GE Appliances
Models: JKP44 JKP45
164D2966P125

HELP US HELP YOU...
Before using your oven,
read this guide carefully.
It is intended to help you operate and maintain
your new oven properly.
Keep it handy for answers to your questions.
If you don’t understand something or need more help, call:
GE Answer Center@
800.626.2000
24 hours a day, 7 days a week
How to Remove Packaging Tape
To assure no damage is done to the finish of the
product, the safest way to remove adhesive left from
packaging tape on new appliances is an application of
a household liquid dishwashing detergent, mineral oil
or cooking oil. Apply with a soft cloth and allow to
soak. Wipe dry and then apply an appliance polish to
thoroughly clean and protect the surface.
NOTE: The plastic tape must be removed from the
chrome trim on oven parts. It cannot be removed if it
is baked on.
Write down the model and
serial numbers.
You’ll find them on a label on the front of the
oven behind the oven door.
These numbers are also on the Consumer Product
Ownership Registration Card that came with your
oven. Before sending in this
card, please write these
numbers here:
Model Number
Serial Number
Use these numbers in any correspondence or service
calls concerning your oven.
If you received a damaged oven...
Immediately contact the dealer (or builder) that
sold you the oven.
Save time and money.
Before you request service...
Check the Problem Solver in the back of this guide.
–
It lists causes of minor operating problems that you
can correct yourself.
IF YOU NEED SERVICE...
To obtain service, see the Consumer Services page in
the back of this guide.
We’re proud of our service and want you to be
pleased. If for some reason you are not happy with the
service you receive, here are three steps to follow for
further help.
FIRST, contact the people who serviced your
appliance. Explain why you are not pleased.
In most cases, this will solve the problem.
NEXT, if you are
still not pleased, write all the
details—including your phone number—to:
Manager, Consumer Relations
GE Appliances
Appliance Park
Louisville, KY 40225
FINALLY,
if your problem is still not resolved, write:
Major Appliance Consumer Action Panel
20 North
Wacker Drive
Chicago, IL 60606
—
2

7
MPORTANT SAFETY INSTRUCTIONS
Read til instruction before using this appliance.
IMPORTANT SAFETY NOTICE
● The California Saf’e Drinking Water and Toxic
Enforcement Act
requires the Governor of
California to publish a list of substances known to
the state to cause birth defects or other
reproductive harm, and requires businesses to warn
customers of potential exposure to such substances.
● The fiberglass insulation in self-clean ovens
gives off a very small amount of carbon
monoxide during the cleaning cycle.
Exposure can be minimized by venting with an
open window or using a ventilation fan or hood.
When using electrical appliances, basic safety
precautions should be followed, including the
following:
● Have the installer show you the location
of the circuit breaker or fuse. Mark it for
easy reference.
● Use this appliance only for its intended use
-IS described in this guide.
~e sure your appliance is properly installed
and grounded
by a qualified technician in
accordance with the provided installation
instructions.
● Do not attempt to repair or replace any part of
your oven unless it is specifically recommended
in this guide.
All other servicing should be
referred to a qualified technician.
● Before performing any service, DISCONNECT
THE OVEN POWER SUPPLY AT THE
HOUSEHOLD DISTRIBUTION PANEL
BY REMOVING THE FUSE OR SWITCHING
OFF THE CIRCUIT BREAKER.
● Be sure the oven is securely installed in a
cabinet that is firmly attached to the house
structure. Never allow anyone to climb, sit,
stand or hang on the oven door.
● Do not leave children alone—children should
not be left alone or unattended in an area where an
appliance is in use. They should never be allowed
to sit or stand on any part of the appliance.
● Do not allow anyone to climb, stand or hang on
the
door. They could damage the oven or cause
severe personal injury.
● CAUTION: ITEMS OF INTEREST TO
CHILDREN SHOULD NOT BE STORED IN
CABINETS ABOVE AN OVEN. CHILDREN
CLIMBING ON THE OVEN TO REACH
ITEMS COULD BE SERIOUSLY
INJURED.
● Do not store flammable materials in an oven.
● Never wear loose-fitting or hanging garments
while using the appliance. Be careful when
reaching for items stored in cabinets over the
oven. Flammable material could be ignited if
brought in contact with hot heating elements
and may cause severe burns.
● Use only dry pot holders—moist or
damp pot holders on hot surfaces may
result in burns from steam.
Do not let pot holders touch the hot heating
elements. Do not use a towel or other bulky cloth.
Such cloths can catch fire on a hot heating element.
● Always keep dish towels, dish cloths, pot
holders and other linens a safe distance
from
your oven.
● Always keep wooden and plastic utensils
and canned food a safe distance away from
your oven.
● Teach children not to play with the controls or
any other part of the oven.
● Always keep combustible wall coverings,
curtains or drapes a safe distance from
your oven.
* For your safety, never use your appliance for
warming or heating the room.
“ DO NOT STORE OR USE COMBUSTIBLE
MATERIALS, GASOLINE OR OTHER
FLAMMABLE VAPORS AND LIQUIDS
IN THE VICINITY OF THIS OR ANY
OTHER APPLIANCE.
● Do not let cooking grease or other flammable
materials accumulate in or near the oven.
3

r onnue~
-
~PORTANT SAFETY INSTRUCTIONS
* Do not use water on grease fires.
Smother fire or flame or use a multi-
purpose dry chemical or foam-type
fire extinguisher.
Flame in the oven can be smothered completely
by closing the oven door and turning the oven off
or by using a dry multi-purpose. chemical or foam-
type fire extinguisher.
● Never leave the oven door open when you are
not watching the oven.
● Do not touch the heating elements or the
interior surface of oven. These surfaces may be
hot enough to burn even though they are dark in
color. During and after use, do not touch, or let
clothing or other flammable materials contact the
areas nearby or any interior area of the oven;
allow sufficient time for cooling first.
Potentially hot surfaces include the oven vent
opening, surfaces near the opening, crevices
around the oven door, the edges of the door
window and metal trim parts above the door.
Remember: The inside surface of the oven may
be hot when the door is opened.
● When cooking pork, follow the directions
exactly and always cook the meat to an internal
temperature of at least 170°F. This assures that, in
the remote possibility that trichina may be present
in the meat, it will be killed and the meat will be
safe to eat.
Oven
● Stand away from the oven when opening the
door. Hot air or steam which escapes can cause
burns to hands, face antior eyes.
c Do not heat unopened food containers.
Pressure could build up and the container could
burst, causing an injury.
.-
● Keep the oven vent ducts
&
i.. .>, .-
unobstructed.
● Keep the oven free from grease butidup.
● Place the oven she~ in desired position while
the oven is cool. If the shelves must be handled
when hot, do not let pot holders contact the
heating elements.
● Pulling out the shelf to the shelf stop is a
convenience in lifting heavy foods. It is also
a precaution against burns from touching hot
surfaces of the door or oven walls.
● When using cooking or roasting bags in the
oven, follow the manufacturer’s directions.
● Do not use your oven to dry newspapers.
If overheated, they can catch fire.
● Do not leave paper products, cooking utensils
or food in the oven when not in use.
● Do not use aluminum foil to line the oven
bottom, except as suggested in this guide.
Improper installation of aluminum foil may result
in a risk of electric shock or fire.
● After broiling, always take the broiler pan out of
the oven
and clean it. Leftover grease in the broiler
can catch fire next time you use the pan.
● Never leave jars or cans of fat drippings on or
near your oven.
Self-Cleaning Oven
—
● Do not clean the oven door gasket. The door
gasket is essential for a good seal. Care should be
taken not to rub, damage or move the gasket.
● Do not use oven cleaners. No commercial oven
cleaner or oven liner protective coating of any kind
should be used in or around any part of the oven.
Residue from oven cleaners will damage the inside
of the oven when the self-clean cycle is used.
● Before self-cleaning the oven, remove the
broiler pan, rack and other cookware.
● Clean only parts listed in this LTse and
Care Guide.
● Be sure to wipe up excess spillage before starting
the self-cleaning operation.
● If the self-cleaning mode malfunctions, turn
the oven off and disconnect the power supply.
Have it serviced by a qualified technician.
SAVE THESE
INSTRUCTIONS
● Do not use the oven for a storage area. Items
stored in an oven can ignite.
4

FEATURES OF YOUR OVEN
Ill
-
Ill -
IIlmllv/u ~
~
Explained
Feature Index on page
1 Lift-OffOven Doors
~~
with Broil Stop Position
2 Broil Element 20,27
3 Oven Door Gasket 4,23,28
4 Model and Serial
2
Number Location
5 Oven Vent
4
6 Automatic Oven Door lJatch
23-25
7 Oven Control, Clock and Timer 6-8
8 Oven Light Pad Lets y’oLl turn
9
on the inside oven lights when
the door is closed.
9 C,rille
~~
JKP44
JKP45
Feature Index
10 Oven Interior Light
Comes on automatically when
either door is
open.
11 Probe Receptacle
(upper oven only)
12 Oven Shelf Supports
Shelf positions for cooking are
suggested in the Baking, Roastin&
and Broiling sections.
13 Oven Shelves with Stop-Locks
14 Bake Element May be lifted
gently for wiping the oven floor.
15
Broiler Pan and Rack
Do not clean in self-cleaning oven.
16 Probe (upper oven only)
Explained
on page
9,27
17,
18
9, 11, 16,
26,28
9, 11, 16,
23,26,28
27
20–23. 27
—

FEATURES OF YOUR OVEN CONTROL
UPPER OVEN
QQ
no
BAKE
CLEAR
A
OFF
LOWER OVEN
eQ
on
CLEAR
BAKE
OFF
A
NOTE: The oven has controls for the upper oven
and the lower oven. Be sure to set the correct
control. Pads on the left side of the panel are for
the upper oven. Pads on the right side of the panel
are for the lower oven. The TIMER ON/OFF,
COOK TIME, STOP TIME, INCREASE and
DECREASE pads can be used for either oven.
1. BAKE.
Press this pad to select the bake function.
2. CLEAWOFF. Press this pad to cancel all oven
operations except the clock and timer.
3.
DISPLAY. Shows the operations you have
selected, the time of day and the cooking or
cleaning status.
4. INCREASE. Short taps to this pad increase the
time or the temperature by small amounts. Press
and
hold the pad to increase the time or the
temperature by larger amounts.
5. BROIL. Press this pad to select the broil function.
6. OVEN LIGHTS. Press to turn the oven lights
on or off.
7. AUTO SELF CLEAN. Press this pad to select the
self-cleaning function. See the Operating the Self-
Cleaning Oven section.
8. DECREASE. Short taps to this pad decrease the
time or the temperature by small amounts. Press
and hold the pad to decrease the time or the
temperature by larger amounts.
9. STOP TIME. Use this pad along with the
COOK TIME or AUTO SELF CLEAN pad to set
the oven to stop automatically at a time you select.
10. COOK TIME. Press this pad for the Timed
–
Baking operation.
11. CLOCK. To set the clock, first press the CLOCK
pad. Then press the INCREASE or DECREASE
pad to change the time of day. Press the CLOCK
pad
to start.
12. TIMER ON/OFF. Press this pad to select the
timer function. The timer does not control oven
operations. The timer can time LIp to 9 hOUr~ and
55 minutes.
To set the timer, first press the TIMER ON/OFF
pad. Then press the INCREASE or DECREASE
pad to change the time.
To cancel the timer, press and hold the
TIMER ON/OFF pad until the word “TIMER”
disappears from the display.
13. PROBE. (upper oven only) Press this pad when
using the
prbbe to cook f~od.
If “F- and a number” flash in the display and
the oven control signals, this indicates function
error code. Press the CLEAWOFF pad. Allow
the oven to cool for one hour. Put the oven back
into operation.
If function error code repeats,
disconnect power
to the oven and call for service.
—
6
——

OVEN CONTROL, CLOCK Am TMER
M
ck To Set the Clock
The clock must be set for the automatic oven timing
D
1. Press the CLOCK pad.
functions to work properly. The time of day cannot be
CLOCK
changed during a Timed Baking or Self-Cleaning
A
cycle.
A
2. Press the INCREASE or DECREASE
pad to set the time of day.
@
v
@
3. Press the CLOCK pad to start.
Timer To Set the Timer
The timer is a minute timer only.
D
1. Press the TIMER ON/OFF pad.
The timer does not control oven operations.
TIMER
ON/OFF
The maximum setting on the timer is 9 hours and
A
55 minutes. 2. Press the INCREASE or DECREASE pad to set the
amount of time on the timer.
The timer will start automatically within a few seconds
of releasing the INCREASE or DECREASE pad. The
timer, as you are setting it, will display seconds until
one minute is reached. Then it will display minutes
and seconds until 60 minutes is reached.
After 60 minutes, it will display hours (“HR” now
appears in the display) and minutes until the
maximum time of 9 hours and 55 minutes is reached.
To Reset the Timer To Cancel the Timer
If “TIMER” is displayed, press the INCREASE or Press and hold the TIMER ON/OFF
pad until the
DECREASE pad until the desired time is reached. word “TIMER” disappears from the display.
If “TIMER” is not displayed, press the TIMER
ON/OFF pad first. then
follow the instructions above
to set the timer.
End of Cycle Tone
Power Outage
The End of Cycle tone is a series of three beeps After a power outage, when power is restored, the
followed by one beep every six seconds. If you would
display will flash and time shown will no longer be
like to remove the
signal that beeps every six seconds,
correct-for example, after a 5-minute power
press and hold the CLEAR/OFF pad for
10 seconds.
interruption the clock will be 5 minutes slow. The
To return the signal that beeps every six seconds, display flashes until the clock is set.
\s and hold the CLEAR/OFF pud for 10 seconds.
All other functions that were in operation when the
power went
out will have to be programmed again.
7

OVEN CONTROL, CLOCK AND TIMER
(continued)
Display Messages
Programmed information can be displayed at any time
● If “clean” appears in the display, DOOR flashes
by pressing the pad of the operation you want to see. and the oven control signals, you set the self-clean
For example, you can display the current time of day
cycle and did not shut the door.
while the timer is counting down by pressing the
“ If “LOCK” only appears in the display, the
CLOCK pad. The selected function is displayed on
oven door is in the locked position. BAKE,
the left
side of the panel for the upper oven and the BROIL and COOK TIME cannot be set if the
right side of the panel for the lower oven.
door is in the locked position.
INCREASE and DECREASE Pad Speed
You can change the speed of the INCREASE and
DECREASE pads.
While the oven is off and the time of day shows in the
display, press and hold the INCREASE and
DECREASE pads and the TIMER ON/OFF pad at the
same time for 2 or 3 seconds. A number from
I to 5
will replace “0:00” in the display. The slowest is 1
and 5 is fastest. Use the INCREASE or DECREASE
pad to change, then press the CLEAR/OFF pad to
return to time of day display.
—
Child Lockout Feature
Your built-in oven has a provision for locking the
oven control to prevent the oven from being turned on
accidentally.
To lock the oven control, press and hold the
INCREASE and DECREASE pad and the STOP
TIME pad at the same time for two seconds. The
word “OFF”
will appear and then disappear in the
display and the oven control will be locked. During
lockout, the word “OFF” will appear momentarily
each time a cooking function pad is touched.
To unlock the oven control, repeat the above
procedure. The word “OFF” will appear in the display
and then disappear after two seconds.
—
8

USING YOUR OVEN
ore Using Your Oven
1. Look at the controls. Be sure yOLI understand
how to set them properly.
2. Check the oven interior. Look
at the shelves.
Take a practice run at removing and replacing
them properly to give sure, sturdy support.
3. Read over the information and tips that follow.
4. Keep this guide handy so you can refer to it.
especially during the
firs{ weeks of using your
new oven.
NOTF;:
● You may notice a “burning” or “oily.> smell the
first few times yOLI turn your oven on. This is
normal in a new oven and will disappear in a short
time. To speed the process, set a self-clean cycle for
a minimum of 3 hours. See the Operating the Self-
Cleaning Oven section.
● A fan may automatically turn on and off to cool
internal parts. This is normal and the fan may
continue to run even after the oven is turned off.
Oven Shelves
The shelves are designed with stop-locks so that
To remove a shelf from
! i
when placed correctly on the shelf supports, they
the oven, pull the shelf
dg
t
, <: >,-”:~
will stop before coming completely out from the
toward you, tilt the front
d
oven, and will not tilt when you are removing food
end upward and pull the
from them or placing food on them.
When placing the cookware on a shelf, pLIll the
=~;~j[[~jjn +%
To replace, place the
shelf out to the bump on the shelf support. Place
the cookware on the shelf, then slide the shelf back
into the oven. This
will eliminate reaching into the
~Jven.
of the shelf] facing up and toward the rear of the
oven. Tilt up the front and push the shelf toward the
back of the oven until it goes past the bump on the
shelf support. Then lower the front of the shelf and
push it all the way back.
Shelf Positions
The o~,en has 4 shelf supports identified in this
illustration as A (bottom), B, C
and D (top).
Shelf positions for cooking are suggested in the
Baking. Rousting and Broiling sections.
Oven Lights
m
Both of the Iighls come on automatically when either oven
~~#~~s door is opened.
Use the pad on the control panel to turn the
lights on ~nd oft
when the doors are closed.
9

r- ‘- ‘“-------”-----”-”-’”-”””””-’--
““”’”-”-”
BAKING
NOTE: The oven has controls for the upper oven Your
o\cn temperature is ct~nlr(>llcd kcry accuratel>
and the lower oven. Be sure to set the correct
using an olen c(ln(rol systcnl. 1( is rccomtnendcd (hat
control. Pads on the left side of the panel are for
yfou operate [ht: t)~en l’~~r a nutnbcr ot’ wcc’ks using the
the upper oven. Pads on the right side of the panel
tilnc :i\en on recipes as a guide to bcctlnl{? fatnil iar
are for the lower oven. The TIMER ON/OFF,
with your new’ olJen. s perti)rtnance. [f yoLI think an
COOK TIME, STOP TIME, INCREASE and
actjustment is neccssar-y. see [he AcijLIst the {)ven
DECRE.4SE pad can be used for either oven. Thermostat section in
ihis guide. It lists easy 1>(J [r
~~~(}-.sc~f’ instructions on how to adjust the thermostat.
NOTE: When the oven is hot, the front of the oven
gets
hot tc)o.
How to Set Your Oven for Baking
To avoid possible burns, place the shelves in the
o
3. Press the CLEAR/OFF pad when the
correct position before you turn the oven on.
CLEAR
baking is finished and then remove the
1. Press the BAKE pad.
OFF
❑
food from the oven.
BAKE
NOTE: A fan tn~y automatically turn on and off t(}
&
cool internal parts. This is normal and the fan may
fi
2. Press the INCREASE or DECRE.4SE continue to run even
after the oven is turned off.
u)
@
pad. The last oven temperature used
appears in the display. Continue
pressing until the desired temperature
v
@
is displayed
The oven will start autornatica]ly.
The word “ON’. and “100°” will be
displayed. As the oven heats up. the
display will show the changing
temperatures. When the oven reaches the
temperature
you set a tone will sound.
To change the oven temperature during the
Bake cycle,
press the BAKE pad and then
the INCREASE or DECREASE pad to get the
new temperature.
—
—
10

, en Shelves
Arrange the oven
shell or shelves in
the desired locations
while the oven is
coo]. The correct
shelf position
depends
on the kind
of food and the
browning desired.
As
a general rule,
olacc most foods in
,
the middle of the oven, on either shelf position
B or C. See the
chart for suggested shelf positions.
Type of Food Shelf Position
I Angelfoodcake I A
I
I Biscuits or muffins
I B orC
\
Cookies or cupcakes
B 01’ C
Brownies B or C
Layer cakes B or C
Bundt or pound cakes A or B
Pies or pie shells B or C
Frozen pies A (on cookie sheet)
Casseroles B or C
Roasting A or B
Preheating
Preheating is neeessary for good results when baking Preheat the oven if the recipe calls for it. Preheat
.-kes, cookies, pastry and breads. For most casseroles means bringing the
o~ren up to the specified
roasts, preheating is not necessary. For ovens
temperature before putting the food in the oven.
Without a preheat indicator light or tone, preheat 10 To preheat, set the oven at the correct
temperature—-
rninutes. After the oven is preheated, place the food selecting a higher temperature does not shorten
in the oven as quickly as possible to prevent heat preheat time.
from escaping.
Baking Pans Pan Placement
Use the proper baking pan. The type of finish on the
pan determines the amount of browning that will occur.
● Dark, roLlgh or du]l pans absorb heat resulting in a
browner, crisper crust. Use this type for pies.
* Shiny, bright and smooth pans reflect heat, resulting
in a lighter, more delicate browning.
Cakes and
cookies require this type of pan.
● Glass baking dishes also absorb heat. When bakin&
in glass baking dishes, the temperature may need to
be reduced by 25°F.
● 1 f you are using dark non-stick pans, you may find
that you need to reduce the oven temperature 25°F.
to prevent overbrowning.
For
e~en cooking and proper browning, there must be
enough room for air circulation in the oven. Baking
results will be better if baking pans are centered as
mllcll as possible rather than being placed to the front
or to the back of the oven.
Pans should
not touch each other or the walls of the
oven. Allow 1- to I Yj-inch space between pans as
well as from the back of the oven, the door and the
sides. If you need to use two shelves, stagger the pans
so one is not directly above the other.
11

BAKING
(continued)
Baking Guides
When using prepared baking mixes, follow package recipe or instructions
for the best baking results.
Cookies
When baking cookies, flat cookie sheets (without
sides) produce better-looking cookies. Cookies baked
in a
jelly roll pan (short sides all around) may have
darker edges and pale or
light browning may occur.
Do not use a cookie sheet so large that it touches the
walls or the door of the oven. Never entirely cover a
shelf with a cookie sheet.
For best results. use only one cookie sheet in the oven
at a time.
.—
Pies Cakes
For best results, bake pies in dark, rough or dull pans When baking cakes, warped or bent pans will cause
to produce a browner, crisper crust. Frozen pies in foil uneven baking results and poorly shaped products.
pans should be placed on an aluminum cookie sheet A cake baked in a pan larger than the recipe
—
for baking since the shiny foil pan reflects heat away recommends will usually be crisper, thinner and drier
from the pie crust; the cookie sheet helps retain it. than it should be. If baked in a pan smaller than
recommended, it may be undercooked and batter may
overflow. Check the recipe to make sure the pan size
used is the one recommended.
Aluminum Foil
Never entirely cover a shelf with aluminum foil.
This will disturb the heat circulation and result in poor
baking. A smaller sheet of foil maybe used to catch a
spillover by placing it on a lower shelf several inches
below the food.
Don’t Peek
Set the timer for the estimated cooking time and do DO NOT open the door to check until the
not open
the door to look at your food. Most recipes minimum time. Opening the oven door frequently
provide minimum and maximum baking times such during cooking allows heat to escape and makes
as “bake 30-40 minutes. ” baking times longer. Your baking results may also
be affected.
—
12

TIMED BA~NG
wto Time Bake
The control allows you to turn the oven on or off
NOTE: Before beginning make sure the oven clock
automatically at specific times that you set. Examples shows the correct
time of day.
of immediate Start (oven turns on now and you set it
n
To set the clock, first press the CLOCK
to turn off automatically) and
Delay Start and Stop
(setting the oven to turn on automatically at a
later time
~LOCK pad. Press the INCREASE or DECREASE
and turn off at a preset Stop Time) will be described.
A
pad until correct time of day is displayed.
Press the CLOCK pad to start.
● You will not be able to use Timed Baking in one
oven and Self-Cleaning in the other.
● You will not be able to use Timed Baking in both
ovens at the same time.
How to Set Immediate Start and Automatic Stop
To avoid possible burns, place the shelves in the The oven will start automatically. The word “ON”
correct position before you turn the oven on. and “lOO
O
.’ will be displayed. The Cook Time will
The oven will turn
on immediately and cook for a
begin to count down. As the oven heats up, the
selected length of time. At the end of Cook Time, display will
shows the changing temperature.
the oven will turn off automatically. When the oven reaches the temperature you set,
~
1. Press the COOK TIME pad. a tone will sound. The oven will continue to cook
~;$:
NOTE: If your recipe requires preheating, for the programmed amount of time, then shut off
automatically.
A
you may need to add additional time to
the length of the Cook Time.
o
5. Press the CLEAWOFF pad to clear the
2. Press the INCREASE pad until the desired length
CLEAR
display if necessary. Remove the food
OFF
from the oven. Remember, even though
of baking time appears in the display. the oven shuts off automatically, foods
n
3. Press the BAKE pad.
continue cooking after the controls are off.
BAKE
NOTE:
A
● Foods that spoil easily, such as milk, eggs, fish,
A
4. Press the INCREASE or DECREASE
stuftings, poultry and pork, should not be allowed to
pad until the desired temperature is
sit for more than one hour before or after cooking.
@
displayed. An attention tone will sound Room temperature promotes the growth of harmful
if step
3 is not done.
bacteria. Be sure that the oven light is off because heat
v
from the bulb will speed harmful bactetia growth.
@
The words “TIME BAKE” and “COOK
TIME” will be displayed along with the
● A fan may automatically turn on and off to cool
oven temperature that you set and the internal parts. This is normal, and the fan may
Cook Time that you entered. continue to run after the oven is turned off.
(c(lntirlllec[ next JTage)
13

TIMED BAKING
(continued)
How to Set Delay Start and Automatic Stop
Quick Reminder:
1.
Press the COOK TIME pad.
2. Press the INCREASE/DECREASE pad to set
the length of baking time.
3. Press the STOP TIME pad.
4. Press the INCREASE/DECREASE pad until
the desired Stop Time appears in the display.
5. Press the BAKE pad.
6. Press the INCREASE/DECREASE pad to
select an oven temperature.
To avoid possible burns, place the shelves in the
correct position before you turn the oven on.
You can set the oven control to delay-start the oven,
cook for a specific length of time and then turn off
automatically.
❑
1. Press the COOK TIME pad.
::;:
NOTE: If your recipe requires
A
preheating, you may need to add
additional time to the Cook Time.
2. Press the INCREASE pad until the desired length
of baking time appears in the display.
n
3. Press the STOP TIME pad. “STOP
STOP
TIME” and the earliest Stop Time you
TIME
A
can set appear in the display.
The control automatically sets the Stop Time by
adding the Cook Time to the time of day. For
example, the time of day is
2:00 and the Cook
Time is 3 hours. Adding 3 hours to the time of day
equals
5:00.
4. Change the Stop Time by pressing the
INCREASE pad until the desired Stop Time
appears in the display. The words “DELAY TIMED
BAKE” and “STOP
TIME’7 appear in the display.
❑
5. Press the BAKE pad.
BAKE
A
A
6. Press the INCREASE or
DECREASE pad until the desired
@
temperature is displayed.
v
The oven will turn on automatically. The
@
word “ON” and” 100°” will be displayed.
The Cook Time will begin to count down.
As the oven heats up, the display will show
the changing temperature. The oven will
continue to cook for the programmed
time and shut off automatically.
At the end of Timed Bake, the display
will show
“OHR:OO COOK TIME” and
the oven will turn off. The end of cycle
tone will sound.
o
7. Press the CLEAWOF’F pad to clear
CLEAR
the display if necessary. Remove the
OFF
food from the oven. Remember, even
though the oven shuts off automatically,
foods continue cooking after the controls
are off.
—
NOTE:
● Foods that spoil easily, such as milk, eggs, fish,
stuffings, poultry and pork, should not be allowed to
sit for more than one hour before or after cooking.
Room temperature promotes the growth of harmful
bacteria. Be sure the oven light is
off. because heat
from the bulb will speed harmful bacteria growth.
● A fan may automatically turn on and off to cool
internal parts. This is normal, and the fan may
continue to run after the oven is turned off.
14

ADJUST THE OVEN THEWOSTAT—
DO ZT YOURSELF!
You may find that your new oven cooks differently
than the one it replaced. We recommend that you
use your new oven for a few weeks to become more
familiar with it, following the times given in your
recipes as a guide.
If you think your new oven is too hot or too cold,
you can adjust the temperature yourself.
If you
think it is too hot, adjust the thermostat to make it
cooler. If you think it is too cool, adjust the thermostat
to make it hotter.
We do not recommend the use of inexpensive
thermometers, such as those found in grocery stores,
to check the temperature setting of your new oven.
These thermometers may vary
2040 degrees.
To Adjust the Temperature:
NOTE: The thermostats in the upper and lower
ovens need to be adjusted separately.
n
1. Press the BAKE pad for the oven
BAKE
in which you want to adjust the
A
temperature.
2. Select an oven temperature between
500°F.
and 550°F.
3. Immediately, before “ON” is displayed, press and
hold the BAKE pad for about 4 seconds. The time
display will change to the oven adjustment display.
A
4. The oven temperature can be adjusted
up to (+) 35°F. hotter or (–) 35°F. cooler.
@
Use the INCREASE or DECREASE pad
to select the desired change in the display.
-
o
5. When you have made the adjustment,
CLEAR
press the CLEAWOFF pad to go back to
OFF
the time of day display. Use your oven as
you would normally.
NOTE: This adjustment will not affect the broiling or
the self-cleaning temperatures. It will be retained in
memory after a power failure.

ROASTING
NOTE: The oven has controls for the upper oven and the lower oven.
Be sure to set the correct control. Pads on the left side of the panel are
for the upper oven. Pads on the right side of the panel are for the lower
oven. The TIMER ON/OFF, COOK TIME, STOP TIME, INCREASE
and DECREASE pads can be used for either oven.
Roasting is cooking by dry heat. Tender meat or
poultry can be roasted uncovered in your oven.
Roasting temperatures, which should be
low and
steady, keep spattering to a minimum.
Roasting is really a baking procedure used for meats.
Therefore, the oven controls are set for Baking or
Timed Baking. (You may hear a slight clicking sound,
indicating the oven is working properly. ) Timed
Baking will turn the oven on and off automatically.
Most meats continue to cook slightly while standing,
after being removed from the oven. The standing time
recommended for roasts is 10 to 20 minutes. This
allows roasts to firm up and makes them easier to
carve. The internal temperature will rise about 5° to
IO°F.; to compensate for the temperature rise, if
desired, remove the roast from oven sooner (at 5° to
IO°F. less than the temperature in the Roasting Guide).
Remember that food will continue to cook in the
hot
oven and therefore should be removed when the
desired internal temperature has been reached.
1. Place the shelf
in A or B position.
No preheating is
necessarv.
2. Check the weight of
the meat. Place it
fat side up (or for
poultry breast-side-
up) on a roasting
b
grid in a shallow
pan. The melting fat will baste the meat. Select
a
pan as close to the size of the meat as possible.
(The broiler pan with grid is a good pan for this.)
NOTE: A fan may automatically turn on and off to
cool internal parts. This is normal and the fan may
continue to run even after the oven is turned off.
❑
3. Press the BAKE pad.
BAKE
A
4. Press the INCREASE or DECREASE
Q
pad until the desired temperature
is displayed.
L~
1>
v
The oven will start automatically.
@
The word “ON” and “100°” will be
displayed. As the oven heats up, the
display will show the changing
temperature. When the oven reaches
set temperature a tone will
sound.
o
5. Press the CLEAWOFF pad when
CLEAR
roasting is finished and then remove
OFF
the food from the oven.
the
—
To change the oven temperature during
roasting,
press the BAKE pad and then the
INCREASE or DECREASE pad to get the new
temperature.
—
Use of Aluminum Foil
You can use aluminum foil to line the broiler pan.
Thi:j makes clean-up easier when using the pan for
marinating, cooking with fruits, cooking heavily
cured meats or basting food during cooking. Press
the foil tightly around the inside of the pan.
16

ROASTING WITH THE PROBE
See the Ro~\tmg Guide
w
rrect Placement of the Temperature Probe
The oven has a probe in the upper oven only.
A temperature probe has been provided
for use in
your new oven. This probe is designed to withstand
high temperatures. Temperature probes provided with
other products, such
as those used for microwave
ovens, may not be designed to withstand high
temperatures. Use of probes other than the one
provided with this product may result in damage to
the probe.
Never leave your probe inside the oven during a
self-
cleaning cycle.
For many foods, especially roasts and poultry, internal
food temperature is the best test for doneness. The
temperature probe takes the guesswork out of roasting
by cooking foods to the exact doneness you want.
When the internal temperature of the food reaches the
temperature you set, the oven automatically shuts off.
The temperature probe has a skewer-like probe at one
end and a plug at the other end that goes into a
receptacle on the oven wall.
Use the handles of the probe and plug when inserting
and removing from meat and wall receptacle. Do not
use tongs to
pull on the cable when removing the
probe—they might damage it. TO AVOID
BREAKING THE PROBE, MAKE SURE FOOD IS
COMPLETELY DEFROSTED BEFORE
INSERTING.
Cable
I
Probe
Plug
\
(appearance may vay)
Handles
After preparing the meat and placing it on a roasting
pan rack, follow these steps for proper probe
-ement.
bay the
probe on the
outside of the
meat along the top
or side and mark
with your finger
where the edge of
the meat comes to
on the probe. The
~oint should rest in
2. Insert the
probe into the
meat up to the
point marked off
with your finger.
It should not
touch bone, fat or
gristle. No more
than two inches
of the probe, not c’outlting the
h(mdle, should be left
exposed outside the meat.
,
the center of the thickest meaty part of the roast.
Ham or Lamb
Casseroles or Fish
Insert the probe into the cut end, Insert the probe into the center of
meatiest part of ham or lamb dishes such as meat loaf or
.nout a bone. For bone-in ham casseroles. When cooking fish,
or lamb, insert the probe into the insert the probe from just above
center of the lowest large muscle the
gill into the meatiest area,
or joint. parallel to the backbone.
Poultry
Insert the probe into the meatiest
part of the inner thigh from below
and parallel to the leg of a whole
turkey.
(continued rtext ~7atqe)
17

I
ROASTING WITH THE PROBE
(continued)
How to Set the Oven When Using the Temperature Probe
The display will flash “PROBE” and the oven
control will signal if the probe is inserted into
the outlet, but the oven is not programmed for
the probe.
1.
Insert the probe
into the meat.
2.
PILIg the probe &+ ‘\.
into the outlet
3
- -%U
:.;,(; $;:.: ‘-
on the oven
/ ‘A
!:$i:?
wall. Make
~“
~
sure it’s pushed ‘~
s
all the way in. . %-—. -
Close the
[ \\
oven door.
D
3. Press the BAKE pad.
BAKE
A
A
4. Press the INCREASE or DECREASE
@
pad. The last oven temperature used
appears in the display. Continue pressing
until the desired oven temperature is
v
@
displayed.
❑
5. Press the PROBE UPPER OVEN pad.
PROBE
UPPER OVEN
A
A
6. Press the INCREASE or DECREASE
@
pad until the desired internal probe
temperature is displayed.
-
The oven will start automatically. The words
“BAKE ON” and the roasting temperature you
set will be in the display.
After a few seconds, the words “LO PROBE” will
replace the roasting temperature in the display.
After the internal temperature of the meat reaches
10O°F., the changing internal temperature will be
shown in the display.
o
7. When the internal temperature of meat
CLEAR
reaches the temperature you have set,
OFF
the probe and the oven turn off and the
oven control signals. To stop the signal,
press the
CLEAWOFF pad. Use hot
pads to remove the probe from the
food. Do not use tongs to pull on
it–they might damage it.
CAUTION: To prevent possible burns, do not
unplug the probe from the outlet until the oven has
cooled. Do not store the probe in
the oven.
NOTE:
● You will not be able to use the probe in the upper
oven during timed oven operations. This is because
,
with the probe you are cooking by temperature
rather than time.
● You can use the timer even though you cannot use
timed oven operations.
● A fan may automatically turn on and off to cool
internal parts. This is normal and the fan may
continue to run even after the oven is turned off.
To change the oven temperature during the
–
Roast cycle, press the BAKE pad and then
the INCREASE or DECREASE pad to get the
new temperature.
18

~~estions and Answers
Q. Is it necessary to check for doneness with a
meat thermometer?
A.
Checking the finished internal temperature at the
completion of cooking time is recommended.
Temperatures are shown in the Roasting Guide.
For roasts over 8 lbs. check with thermometer at
half-hour intervals after half the cooking time
has passed.
Q. Why is my roast crumbling when I try to
carve it?
A.
Roasts are easier to slice if allowed to cool 10 to
20 minutes after removing them from the oven.
Be sure
to cut across the grain of the meat.
Q. Do I need to preheat my oven each time I cook a
roast or poultry?
A.
It is not necessary to preheat your oven.
Q.
When buying a roast, are there any special tips
that would help me cook it more evenly?
A. Yes.
Buy a roast as even in thickness as possible,
or buy rolled roasts.
Q. Can I seal the sides of my foil “tent” when
roasting a turkey?
A.
Sealing the foil will steam the meat. Leaving it
unsealed allows the air to circulate and brown
the meat.
ROASTING GU~E
Frozen Roasts
Frozen roasts of beef, pork, lamb, etc., can be started Make sure poultry is thawed before roasting.
without thawing, but allow 10 to 25 minutes per Unthawed poultry often does not cook evenly.
~und additional time ( 10 minutes per pound for Some commercial frozen poultry can be cooked
;ts under 5 pounds, more time for larger roasts). successfully without thawing. Follow the directions
given on the package label.
Type
Meat
Tender cuts; rib, high quality sirloin
tip, rump or top round~
Lamb leg or bone-in shoulder+
Veal shoulder, leg or loint
Pork loin, rib or shouldert
Ham, precooked
Poultry
Chicken or Duck
Chicken pieces
Turkev
Oven
temperature
325°
325°
325°
325°
325°
325°
350°
3~50
Doneness
Rare:
Medium:
Well Done:
Rare:
Medium:
Well Done:
Well Done:
Well Done:
To Warm:
Well Done:
Well Done:
Well Done:
Approximate Roasting Time
in Minutes per Pound
3 to 5
lbs.
6 to 8 lbs.
24-33 18-22
35-39 22-29
404530-35
21-25
20-23
25-30 24-28
30-35
28–33
35-45
3040
3545
3040
17–20 minutes per pound (any weight
3 to 5 lbs.
Over 5 Ibs.
3540
30-35
3540
10 to 15 lbs.
Over 15 lbs
18-25 15-20
Internal
temperature ‘F.
1400–1500*
150°-1600
170°–1850
140°–1500*
150°-1600
170°-1850
170°–1800
170°-1800
115”–I 25°
185°–1900
185°-1900
In thigh:
185°-1900
~For boneless rolled roasts over 6 inches thick, add 5 to 10 minutes per pound to times given above.
*The ~T,s, Departn~ent of Agri~u]ture says “Rare beef is popular, b~lt vou should know that cooking it to only 140°F. means
some food poisoning organisms may survive.” (Source: Safe Food Book. Your Kitchen Guide. USDA Rev. June 1985.)
19

NOTE: The oven has controls for the upper oven
and the lower oven. Be sure to set the correct
control. Pads on the left side of the panel are for
the upper oven. Pads on the right side of the panel
are for the lower oven. The TIMER ON/OFF,
COOK TIME, STOP TIME, INCREASE and
DECREASE pads can be used for either oven.
1.
If the meat has fat or gristle around the edge,
cut vertical slashes through both about 2“ apart.
If desired, the fat may be trimmed, leaving a layer
about 1/8” thick.
2. Place the meat on the broiler grid in the broiler pan
Always use the grid so the fat drips into the broiler
pan; otherwise the juices
may become hot enough
to
catch on fire.
3. Position the shelf on the recommended shelf
position as suggested in the Broiling Guide.
Most broiling is done on C position, but if your
oven is connected to 208 volts, you may wish to
use a higher position.
4. Leave the door open
to the broil stop
position. The door
stays open by itself,
yet
the proper
temperature is
maintained in the oven.
Broiling is cooking food by intense radiant heat from
the upper broil element in the oven. You can broil in
upper or lower oven. Most fish and tender cuts of
meat can be broiled. Follow these directions to keep
spattering and smoking
to a minimum.
Turn the food using tongs only once during broiling.
Time the foods for the first side according to the
Broiling Guide.
Turn the food. then use the times given for the second
side as a guide to the preferred doneness.
NOTE: A fan may automatically turn on and off to
cool internal parts. This is normal and the fan may
continue to run even after the oven is turned off.
HI= ~5. Press the BROIL pad. Preheating
❑
B:o~
the elements is not necessary. (See
A-
the Comments column in the
Broiling Guide.)
NOTE: If the broil pad does not work, the probe
might be connected. Remove the probe.
6. Press the INCREASE pad for HI Broil or
press the DECREASE pad for LO Broil.
Q
—
To change from HI Broil to LO Broil, press the
BROIL pad then tap the DECREASE pad once.
o
7. When broiling is finished, press the
CLEAR
CLEAR/OFF pad. Serve the food
OFF immediately, and leave the pan outside
the oven to cool during the meal for
easiest cleaning.
—
20
