GE Monogram ZET2RM Manual

Dimensions and Installation Information (in inches)
Installation Flexibility
These ovens may be installed in combination with a Monogram
warming drawer.
Note: Cabinets installed adjacent to wall ovens must have an
adhesion spec of at least a 194°F temperature rating.
Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Specification Created 4/07 130182
ZET2RM
GE Monogram®30” Built-In Double Oven
KW Rating
240V 8.6
208V 7.8
Breaker Size
240V 40 Amps
208V 40 Amps
Listed by
Underwriters
Laboratories
28-1/2" Min.
28-5/8" Max.
51-13/16"
Min.
51-15/16"
Max.
12"
Locate Junction Box 47"
Above Cutout Floor, Within 5"
of Right Rear Wall
30"
52-7/8"
23-1/4"
Recessed
Depth
29-3/4"
23-1/2"
Min.
28-1/2" Min.
28-5/8" Max.
51-13/16"
Min.
51-15/16"
Max.
12"
Locate Junction Box 47"
Above Cutout Floor, Within 5"
of Right Rear Wall
30"
52-7/8"
23-1/4"
Recessed
Depth
29-3/4"
23-1/2"
Min.
The solid bottom or runners must be level with the bottom of the
cutout, or the bottom trim may not install correctly and could
interfere with the door opening. If the cabinet does not have a
solid bottom, two braces or runners must be installed level with
the bottom of the cutout to support the weight of the oven. The
runners and braces must support 375lbs. (90 kg).
NOTE: Install the
oven only with
specific models
listed on the label
located on top of
the oven.
Anti-Tip Block
Against Rear
Wall Per
Warming
Drawer
Requirement
2 (5.1 cm)
Min.
1 (2.5 cm) Min. Above Toekick
Per Warming
Drawer
Requirement

Features and Benefits
• Electronic Touchscreen with Proximity
Sensor - Provides easy, intuitive access
to oven functions and options
• Halogen Light Columns - On the oven walls
provide brilliant task lighting for each
rack position
• Exclusive Self-Cleaning, Full-Extension Oven
Racks - Glide in and out smoothly on stainless
steel ball bearings, and are designed to be left
in the oven during the self-clean cycle
• 4.4 Cu. Ft. Capacity (Each Oven) - Easily
accommodates even the largest meals
• True Hidden Bake Element - Concealed beneath
the oven floor, allowing additional capacity and
improved cleanability
• Reverse-Air Convection System - Uses an
innovative fan that reverses direction for optimal
air and heat circulation, providing even cooking
and multi-rack baking capability
• Six-Element Design - Two bake, two broil and
two convection elements provide precise cooking
control, with fast preheating
• 208V Performance Compensation - Utilizes the
six-element design to boost power in reduced-
voltage installations
• Signature Tubular Handles - Are smooth, sleek
and easy to grasp
• Hand-Finished Edges - Reflect the meticulous
quality and craftsmanship for which Monogram
products are renowned
• Two Broil Elements with Reflector Shield - Offer
intense, dual-zone broiling
• Large Viewing Window - Allows you to view your
culinary work in progress
• Model ZET2RMSS – Stainless steel
ZET2RMSS
Specification Created 4/07 130182
ZET2RM
GE Monogram®30” Built-In Double Oven
