GE Monogram ZET1 User manual

1
30”(76.2 cm) Built-In
Wall Oven
Installation
Instructions ZET1, ZET2
If you have questions, call 1.800.GE.CARES or visit our website at:
ge.com
Before You Begin
Read these instructions carefully and completely.
•IMPORTANT—Save these
instructions for local inspector’s use.
•IMPORTANT—Observe all
governing codes and ordinances.
• Note to Installer—Be sure to leave these
instructions with the consumer.
• Note to Consumer—Keep these
instructions for future reference.
• Proper installation is the responsibility
of the installer and product failure due
to improper installation is NOT covered
under warranty.
• NOTE—This appliance must be properly
grounded.
•ATTENTION INSTALLER
All electric wall ovens must be hard wired
(direct wired) into an approved junction
box. A plug and receptacle is NOT permitted
on these products.
Materials Needed
Strain Relief Clamp
for 1/2”conduit Junction Box
Wire Nuts
36”(91 cm)
of String
31-10649-3 11-07 JR
Parts Included
Metal Bottom
Trim Assembly Tools Needed
1/8”Drill Bit and
Electric or Hand Drill Phillips Screwdriver
Adjustable Wrench
(Appearance may vary.)
(8-18 x .750 flat-head
Phillips wood screws)
(8A8 x .625 truss-head
Phillips wood screws)
3/4”Wood
Screws
5/8”Wood
Screws

2
Installation Instructions
IMPORTANT SAFETY INSTRUCTIONS
WARNING: The electrical
power to the oven supply line
must be shut off while line
connections are being made. Failure
to do so could result in serious injury
or death.
For Your Safety
• Be sure your oven is installed properly by
a qualified installer or service technician.
• Make sure the cabinets and wall coverings
around the oven can withstand the
temperatures (up to 200°F [93.3°C])
generated by the oven.
• Be sure the oven is securely installed in a
cabinet that is firmly attached to the house
structure. Weight on the oven door could
cause the oven to tip and result in injury.
Never allow anyone to climb, sit, stand or
hang on the oven door.
Rating plate is located on the oven side trim,
side front frame or lower front frame.
We recommend you have the electrical
wiring and hookup of your oven connected by a
qualified electrician. After installation, have the
electrician show you where your main oven
disconnect is located.
Check with your local utilities for electrical
codes which apply in your area. Failure to wire
your oven according to governing codes could
result in a hazardous condition. If there are no
local codes, your oven must be wired and fused
to meet the requirements of the National
Electrical Code, ANSI/NFPA No. 70–Latest
Edition. You can get a copy by writing:
National Fire Protection Association
Batterymarch Park
Quincy, MA 02269
Effective January 1, 1996, the National
Electrical Code requires that new, but not
existing, construction utilize a four-conductor
connection to an electric oven. When installing
an electric oven in new construction, a mobile
home, recreational vehicle or an area where
local codes prohibit grounding through the
neutral conductor, follow the instructions in
the section on NEW CONSTRUCTION AND
FOUR-CONDUCTOR BRANCH CIRCUIT
CONNECTION.
You must use a three-wire, single-phase A.C.
208Y/120 Volt or 240/120 Volt, 60 hertz
electrical system. If you connect to aluminum
wiring, properly installed connectors approved
for use with aluminum wiring must be used.
Rating Plate
Location
Electrical
Requirements (cont.)
Electrical
Requirements
This appliance must be supplied with the
proper voltage and frequency and connected
to an individual, properly grounded branch
circuit, protected by a circuit breaker or fuse.
See the rating plate located on the oven frame
to determine the rating of the product. Use
the chart below to determine the minimum
recommended dedicated circuit protection.
Recommended
KW Rating KW Rating Circuit Size
240V 208V (Dedicated)
≤4.8 KW ≤4.1 KW 20 Amp
4.9 KW–7.2 KW 4.3 KW–6.2 KW 30 Amp
7.3 KW–9.6 KW 6.3 KW–8.3 KW 40 Amp
9.7 KW–12.0 KW 8.4 KW–10.4 KW 50 Amp

3
Installation Instructions
Pre-Installation Checklist
To Remove the Door (if necessary)
NOTE: The oven door is very heavy. Be sure
you have a firm grip before lifting the oven
door off the hinges. Use caution once the
door is removed. Do not lay the door on its
handle. This could cause dents or scratches.
Place the oven on a table or platform
even with the cutout opening. (Platform
must support 175 lbs. [79 kg] single,
350 lbs. [159 kg] double.)
Remove the bottom trim from the top
of the oven. It will be installed at the
end of the installation process. The
trim is wrapped separately and taped
to the top of the unit.
Place hands on both sides
of the door, and close the
oven door to the removal
position, which is most of
the way closed.
Lift door up and out
until the hinge arms
clear the slots.
Hinge Clears Slot
Removal Position
Door removal is not a requirement for
installation of the product, but is an
added convenience. To remove the door:
Open the oven door as far as it will go.
Push both hinge
locks down toward
the door frame,
to the unlocked
position. This may
require a flat-blade
screwdriver.
DO NOT LIFT THE DOOR
BY THE HANDLE!
Hinge
Unlocked
Position
Hinge
Slot
Hinge
Arm
Hinge
Unlocked
Position
Hinge
Slot
Hinge
Arm
Remove packaging materials.
Check behind hinges and under
false bottom. Remove labels on the
outside of the door, plastic on trims
and panel, all tape around the oven,
and any shipping screws securing
the oven to the base pad.
ALL INSTALLATION INFORMATION
ON THE FOLLOWING PAGES IS TO
BE USED FOR SINGLE AND DOUBLE
OVEN INSTALLATION!
Oven Racks
Literature
Pack
Broiler Pan
and Grid
