GE Profile Advantium PSB2201NSS User instructions

Specification Created 9/08 240441
Listed by
Underwriters
Laboratories
PSB2201NSS
GE Profile Advantium® 240 Wall Oven
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
cooking_tower_solid_floor.eps
C
L
(Must support 130 lbs.)
2 x 4’s or
equivalent
solid floor
Suitable
bracing
to support
runners
21-5/8"
over centerline
of cabinet
A=Allow 1" overlap of oven over top and bottom edges of cutout.
B=Allow 11/16"-3/4" for overlap ov oven over side edges of cutout.
Cabinet
Width
(inches)
W
Width
H
Height
D
Depth
(excluding
handle)
X
Cutout
Width
Y
Cutout
Height
Z
Cutout
Depth
(minimum)
PSB2200/1 without
accessory drawer 30 29-25/32 19-1/8 21-3/4 25-1/8 17-1/2 23-1/2
PSB2200/1 with
accessory drawer 30 29-25/32 22-1/4 21-3/4 25-1/8 to
28-1/2* 21 23-1/2
*For existing cutouts a maximum width of 28-1/2" is acceptable
A=Allow 1" overlap of oven over top and bottom edges of cutout.
B=Allow 11/16"-3/4" for overlap ov oven over side edges of cutout.
Note: Cabinets
installed adjacent
to wall ovens must
have an adhesion
spec of at least a
194°F temperature
rating.
Note: 2" minimum
between cutouts
when installed
above warming
drawer or single
wall oven.
Installation
Information:
Before installing,
consult installation
instructions packed
with product for current
dimensional data.
Cutout width
25-1/8"
30
Required
cutout location
36-3/4"
minimum
from floor
Junction
box
location
(240-Volt
models only)
A=Allow 1" overlap of oven over top and bottom
edges of cutout.
B=Allow 11/16"-3/4" for overlap ov oven over side
edges of cutout.
4-3/16
17-1/2"
Cutout height
AB
23-1/2"
Cutout depth
29-25/32"
19-1/32"
21-1/2"
Excluding
Handle
Advantium Wall Oven Dimensions (in inches)and
Cabinet Installation (in inches)
Note: Cabinets installed adjacent
to wall ovens must have an adhesion
spec of at least 194° F temperature rating.
Construct Solid
Bottom Min.
3/8" Plywood
Supported by
2 x 4 or 1 x 2
Runners, all
Four Sides.
(Must Support
150 lbs.)
Conduit
(48-1/2"
long)
adv_240_120_cooktower_dia.eps
1" Min. above toekick or adjust
to oven installation height
2" MIN between cutouts
2-1/2" MIN between cutouts
recommended—2" MIN required
9-1/4" cutout height
28-1/2" cutout width
Junction box location
AB
ABConstruct Solid Bottom
MIN 3/8" Plywood Supported by
2 x 4 or 1 x 2 Runners, all Four Sides.
(Must Support 150 lbs. for Advantium)
(Must Support 200 lbs. for Wall Oven)
4-3/16
D
Excluding
Handle
H
W
Conduit
(46" long)
Cabinet width
(240-volt models only)

Specification Created 9/08 240441
Listed by
Underwriters
Laboratories
PSB2201NSS
GE Profile Advantium® 240 Wall Oven
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Installation over a GE/Monogram
Warming Drawer:
30” 23-1/2”
25-1/4”
Min.
21” 2” Min.
(3” recommended)
Per warming
drawer
requirement
Construct
Solid Bottom
Min. 3/8”
Plywood
Supported
by 2x4 or 2x2
Runners all
Four Sides
5” min.
from floor
1” min.
above
toekick
Warming Drawer:
Construct Solid
Bottom Min.
3/8” Plywood
Supported by
2x4 or 2x2
Runners all
Four Sides
30” 23-1/2”
21”
2” Min.
Per Oven
Requirement
Per warming drawer requirement
2” Min.
(3” recommended)
25-1/4”
Min.
5” min.
from floor
1” min.
above
toekick
Prepare the opening
The Advantium 240V can be installed in combination with
other GE/Monogram appliances. Always follow each product's
Installation Instructions to compete the installation.
Single Advantium 240V Installation:
Order a 30" wide single oven cabinet or cut the opening in a wall
to the dimensions shown.
* For existing cutouts, a
maximum width of 28-1/2" is
acceptable. If the opening is
slightly wider, secure a furring
strip on each side of the
cutout for securing the oven.
• Always maintain 36-3/4"
minimum height from
the floor to the cutout in
any single or combined
installation.
• Allow 3/4" to 2-1/8" case trim
overlap on the sides and 7/8"
overlap on the bottom of
the opening for all models.
The amount of overlap on
the sides depends on the actual cutout width. Allow 1-1/4" case
trim overlap on the top for models PSB2200 and PSB2201 and for
models ZSC2200, ZSC2201 and ZSC2202.
• Oven overlaps will conceal cut edges on all sides of the opening.
Prepare the opening (cont.)
When installed over a single oven or a
warming drawer, allow at least 2" between
the two openings. This separation will
provide clearance for bottom overlap of the
Advantium 240V and the other appliance
overlaps.
Construct a solid oven floor of 3/8" min. thick
plywood supported by 2 x 4 or 2 x 2 runners
on all sides.
• the support must be level and rigidly
mounted, flush with the bottom edge of
the cutout.
* For existing cutouts, a maximum width of
28-1/2" is acceptable. If the opening is slightly
wider, secure a furring strip on each side of
the cutout for securing the oven.
Note: Additional clearances between the
cutouts may be required. Check to be sure the
oven supports above the Warming Drawer
location do not obstruct the required interior
depth and height. See Warming Drawer
installation instructions for details.
Installation over a GE/Monogram Oven
and Warming Drawer:
* For existing cutouts, a maximum width of
28-1/2" is acceptable. If the opening is slightly
wider, secure a furring strip on each side of
the cutout for securing the oven.
Note: Additional clearances between the
cutouts may be required. Check to be sure the
oven supports above the Warming Drawer
location do not obstruct the required interior
depth and height. See Warming Drawer
installation instructions for details.
CAUTION: For personal safety, the mounting
surface must be capable of supporting the
cabinet load, in addition to the added weight
of this approximate 80-pound oven and 30-
pound drawer, plus additional oven loads of up
to 50 pounds or a total weight of 160 pounds.
30” 23-1/2”
25-1/4”
Min.
21”
Construct
Base
Min. 3/8”
Plywood
Supported
by 2x4 or 2x2
Runners all
Four Sides
5” min.
from floor
1” min.
above
toekick
Preparation WITH an Accessory Drawer

Specification Created 9/08 240441
PSB2201NSS
GE Profile Advantium® 240 Wall Oven
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Features and Benefits
• Speedcook Technology - Cooks up to 8 times faster than a conventional oven
• 4 Ovens in 1 to Meet Your Cooking Needs - Speedcook, True European Convection,
Warming/Proofing, Sensor Microwave
• Optimizes cook time for consistent results
• Saves valuable time by eliminating preheating
• 16" Turntable - Allows complete rotation of a 9" x 13" casserole dish
• Over 175 preprogrammed recipes
• Full-width oven rack for multi-level cooking
• Includes speedcooking grill tray for preparing meats
• Model PSB2201NSS - Stainless steel
OVEN MICROWAVE
CONV
BAKE
BROIL
WARM
PROOF
SPEED
COOK
CUSTOM
SPEED COOK
EXPRESS
REHEAT
COOK
DEFROST
FAVORITE
RECIPES
TIMER
HELP
OPTIONS
BACK
POWER
TEMP
START
PAUSE
CLEAR
OFF
PSB2201NSS
JX2201NSS
Accessories:
Optional
Storage Drawer
Available
(JX2201NSS)
