Dual Cavity Gas, Free Standing Ranges
Café, Profile & GE
JGB870DET
JGB870SET
PGB900DET
PGB900SET
PGB910DET
PGB910SET
PGB915SET
PGB930DET
PGB930SET
PGB935SET
P2B930DET
P2B930SET
PGB980SET
PGB995DET
PGB995SET
CGS990SET
CGS985SET
C2S985SET
CaféProfile & GE

IMPORTANT SAFETY NOTICE
The information in this presentation is intended for use by individuals
possessing adequate backgrounds of electrical, electronic, &
mechanical experience. Any attempt to repair a major appliance may
result in personal injury & property damage. The manufacturer or seller
cannot be responsible for the interpretation of this information, nor can it
assume any liability in connection with its use.
WARNING
To avoid personal injury, disconnect power before servicing this product.
If electrical power is required for diagnosis or test purposes, disconnect
the power immediately after performing the necessary checks.
RECONNECTALL GROUNDING DEVICES
If grounding wires, screws, straps, clips, nuts, or washers used to
complete a path to ground are removed for service, they must be
returned to their original position & properly fastened.

GE Factory Service Employees are required to use safety glasses with
side shields, safety gloves & steel toe shoes for all repairs.
Dyneema®Cut
Resistant Glove
Safety Glasses must be
ANSI Z87.1-2003 compliant
Prescription Safety Glasses
Plano Type Safety Glasses
Steel Toe Work
Boot
Electrically Rated Glove
and Dyneema®Cut
Resistant Glove Keeper
Brazing Glasses

4 /
Copyright General Electric 2011
11/28/2011

5 /
Copyright General Electric 2011
11/28/2011
Mini Manual Profile & GE
Model Tag
The Mini Manual is located in the control panel area on GE & Profile units. Back top left
rear corner on Café models.
The Nomenclature Tag is on the bottom left side front frame of the main oven.
Mini Manual Cafe

6 /
Copyright General Electric 2011
11/28/2011
Cooktop
•Tri-Ring Burner
•Tri-Bridge Burner
•Tri-Bridge Griddle
Café, Profile, and GE Brands
Double Oven
•Upper Oven 2.5 cuft
•Lower Oven 4.0 cuft
•Both Self Clean
2x Lighting
Full Visibility Door (Glass
Liner)
Black Enameled Cavity
New Doors & SS trims
Overview-Product Info

7 /
Copyright General Electric 2011
11/28/2011
9100 btu/h Max.
850 btu/h Min.
5000 btu/h Max.
1000 btu/h Min.
Cooktop Burners
9.1K
9.1K
5.0K
9.5K
5.0K
20/19K
17000 btu/h Max.
3000 btu/h Max.
400 btu/h Min.
•Tri Ring 20K BTUs- Café / 19K Profile
•Tri Bridge 23K BTUs
•New cooktop configurations
•New Griddles / Double-Bridge Griddle
3 Ring = 19/20K BTUs
3 Bridge = 24K BTUs
Overview-Feature Detail

8 /
Copyright General Electric 2011
11/28/2011
Cooktop Grates & Griddle Designs

9 /
Copyright General Electric 2011
11/28/2011
Note: The center griddle is used without the center grate installed, the Chef griddle is
installed on top of the left grate.

10 /
Copyright General Electric 2011
11/28/2011

11 /
Copyright General Electric 2011
11/28/2011
Control Overview, ERC & Thermostat
The lower oven is controlled by an (ERC) electronic control, the upper oven is controlled by
an hydraulic thermostat. Both upper and lower ovens have self clean capability.
Café Models
Profile & GE Models

12 /
Copyright General Electric 2011
11/28/2011
Anti-Tip Bracket
•Range must be secured by the Anti-Tip Bracket supplied.

13 /
Copyright General Electric 2011
11/28/2011
Control Panel Removal –GE & Profile

14 /
Copyright General Electric 2011
11/28/2011
Lower Oven Door Removal

15 /
Copyright General Electric 2011
11/28/2011
Upper Oven Door Removal –Hinge Release

16 /
Copyright General Electric 2011
11/28/2011
Upper Oven Door Removal
Release Button
Open the oven door to a 45 degree angle from the oven frame, press in on both release
buttons and lift the door off of the door hinges.

17 /
Copyright General Electric 2011
11/28/2011
Component View, Back –Profile & GE
Gas Valve UO
Gas Valve LO
Regulator
Convection
Fan Motor
Igniters UO
ERC
Spark Module
Igniter LO
Gas Lockout
Valve
Oven Sensor
Thermostat
Capillary

18 /
Copyright General Electric 2011
11/28/2011
Component View, Back –Café
Gas Valve UO
Gas Valve LO
Regulator
Convection
Fan Motor
Spark Module
Igniter LO
Gas Lockout
Valve
Broil Element LO
Oven Sensor
Igniters UO
Cooling Fan
Thermostat
Capillary

19 /
Copyright General Electric 2011
11/28/2011
Component View, LH Side –All Models
Lock Out
Relay UO
TCO UO
TCO LO
Gas Lockout
Valve
Self Clean
Latch Assy

20 /
Copyright General Electric 2011
11/28/2011
Component View, Oven Cavities
Bake Burner
Bake Burner
Broil Element, Café Only
Broil Burner
Thermostat Capillary
Sensor
Convection Fan
