GE JGBP27WELWW User manual

For answers to your Monogram,® GE Profile™ or
GE® appliance questions, visit our website at
ge.com or call GE Answer Center® service,
800.626.2000.
Specification Created 10/05 330430
24
30" FS Gas Ranges-CL
30
8
4
9
2
2-1/2
Recommended area for
thru the floor connection
of pipe stub and shut-off valve
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
and shut-off valve
30
46-7/8
26-1/4*
46-3/8
36-1/4±1/4
Installation Information (Dimensions in inches)
Recommended common
area for gas outlet and
electrical outlet
24
30" FS Gas Ranges-CL
30
8
4
9
2
2-1/2
Recommended area for
thru the floor connection
of pipe stub and shut-off valve
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
and shut-off valve
30
46-7/8
26-1/4*
46-3/8
36-1/4±1/4
Installation Information (Dimensions in inches)
Recommended common
area for gas outlet and
electrical outlet
CERTIFIED
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
* Dimension from the wall to the front of the closed door
handle is 28-1/4". Depth to the front edge of cooktop 25-1/4".
Optional Gas Range Accessory Drip Pans for
Sealed and Standard Burner Models
(Available at additional cost)
To order these accessory drip pans,
call toll-free 800-626-2002
Gas Self-Clean Range Anti-Tip Bracket
(Part No. 205C1714P001)
Electrical Rating: 120V, 60Hz, 5A
Installation Information: Before installing,
consult installation instructions packed with
product for current dimensional data.
JGBP27WEL
GE® 30" Free-Standing Self-Clean Gas Range
Dimensions and Installation Information (in inches)

Features and Benefits
• Self Clean Oven - Conveniently cleans the oven cavity without need of scrubbing
• Upfront Controls - Controls are placed within easy reach at the front center of
the cooktop
• Extra-Large Oven Capacity - Provides a large oven interior ideal for cooking more
items at once
• All Purpose Burners - Deliver a wide range of heat output ideal for most
cooking requirements
• ADA-Compliant - Designed for easy operation and easy access
• Sealed Cooktop Burners - Eliminate the space between the burners and the
cooktop to help contain spills and boil over liquids, ensuring easy cleanup
• Heavy Steel Grates - Constructed from quality steel for long-lasting performance
and durability
• Big ClearView™ Window - An extra large clear window makes monitoring the
progress of food easy
• Model JGBP27WELWW - White on white
BROILSELF
CLEAN
OVEN
LIGHT
CLOCK
TIME CONTROLS
OVEN CONTROLS True Temp
ON
TEMP
NORMAL
HI LO
OFF
KITCHEN
TIMER
ONOFF
BAKESTART
ON
CLEAR
OFF
JGBP27WEL
OFF
FRONT
LO
2
4
6
HI
LITE
8
OFF
REAR
LO
2
4
6
HI
LITE
8
OFF
REAR
LO
2
4
6
HI
LITE
8
OFF
FRONT
LO
2
4
6
HI
LITE
8
OVEN CYCLE
SELF CLEAN
OVENTEMP
Specification Created 10/05 330430
JGBP27WEL
GE® 30" Free-Standing Self-Clean Gas Range
