Specification Created 7/01
ZDP30N4DSS - GE Monogram™30" Free-Standing Professional Gas Range
Dimensions and Specifications (in inches)
These ranges are factory set for either natural gas or
liquid propane gas.
30" Natural Gas Model:
ZDP30N4YSS–4 gas burners
30" Liquid Propane Gas Model:
ZDP30L4YSS–4 gas burners
Accessory Requirements:
All models require the installation of a backguard. A
backguard should be ordered at the same time as the
range. Both must be on site at the time of installation.
Order one backguard for 30" models:
ZX1B30YSS–1-1/2" high backguard
(required for island installations)
ZX12B30YSS–9" high backguard
ZX22B30YSS–22" high backguard with warming rack
(2 piece)
Advance Planning:
Refer to dimensional drawings for appropriate placement
and necessary clearances when planning
the installation.
•Cabinetry cannot be installed directly above the range.
•This range requires the installation of a vent hood,
30" to 36" above the surface.
–The vent hood must be at least 24" deep.
–The vent hood must be the same width as the range.
–The vent hood must provide at least 600 CFM and
up to 800 CFM.
•Working areas adjacent to the range should have
18" minimum clearance between countertop and
cabinet bottom.
•Clearance between range and side wall or combustible
material must be at least 12" on each side.
21-1/4"
12"
1-1/2"
35-1/4"-36-3/4"
26-3/4" 29-7/8"
Available Backguards
ZX22B30YSS
ZX12B30YSS
ZX1B30YSS
R
Listed by
Underwriters
Laboratories
For answers to your Monogram,
®GE Profile™or
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.

Monogram.
™
Specification Created 7/01
ZDP30N4DSS - GE Monogram™30" Free-Standing Professional Gas Range
Dimensions and Specifications (in inches)
If the range is installed in an island:
•Allow 12" min. clearance at the back to combustible
materials.
•Allow 36" min. above the cooking surface to
combustible materials.
•The vent hood must provide at least 600 CFM and
up to 1200 CFM.
•Installation must conform with local codes. In the
absence of local codes, the range must comply with
the National Fuel Gas Code, ANSI Z223.1-1990.
A.G.A. approved
Installation Information:
Before installing, consult installation instructions
(Pub. #49-8786) packed with product for current
dimensional data.
3/-1/4"
18" Min.
4"
35-3/8" Max. for Counter Level
36-3/4" Max. with Range Leveling Legs Fully Extended
3/-1/2"
Gas Supply
Electrical Supply
Cooking Surface
13"
Max.
4"
12"
30" Wide Range Hood
12" Min. to
Combustible
Material
Each Side
36" Min. to
Combustible
Material From
Cooking Surface
12"
Low Back
High
Shelf
27-3/8"
12"
3-1/4"
21-1/4"
12"
36" Min.
to Combustibles
26-3/4"
29-1/4"
43-7/8"
0" Clearance
Island Trim
12" Min. to Combustables
Without Backgaurd
1-1/2"
36" Min.
to Combustibles
0" Clearance
R
Listed by
Underwriters
Laboratories
For answers to your Monogram,
®GE Profile™or
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.

Monogram.
™
Specification Created 7/01
ZDP30N4DSS - GE Monogram™30" Free-Standing Professional Gas Range
Features and Benefits
•Natural Gas
•Four (15,000/500 BTU) Dual-Ring Gas Burners
•Porcelainized, Cast-Iron Burner Grates
•Stainless Steel, Slide-Out Drip Tray
•Electronic Ignition with Automatic Reignition
•4.0 cu. ft Electric Convection Oven
•Self-Clean Oven
•Commercial-Style Controls
•Six-Pass Bake Element and Eight-Pass
Broil Element
•Porcelain-Enameled Broiler Pan with
Chrome-Plated Grid
•3 Oven Racks
•Stainless Steel Door with Window
•Tubular Stainless Steel Handle
•Model ZDP30N4DSS - Natural gas
•Model ZDP30L4DSS - Liquid propane gas
