Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
JGBS17PEK/BEL
GE® 30" Free-Standing Standard Clean Gas Range
Specification Revised 6/06
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
330510
24
30" FS Gas Ranges-CL
A10325
30
8
4
9
2
2-1/2
Recommended area for
thru the floor connection
of pipe stub and shut-off valve
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
and shut-off valve
30
46-7/8
26-1/4*
46-3/8
36-1/4 ±1/4
Installation Information (Dimensions in inches)
Recommended common
area for gas outlet and
electrical outlet
C
L
24
30" FS Gas Ranges-CL
A10325
30
8
4
9
2
2-1/2
Recommended area for
thru the floor connection
of pipe stub and shut-off valve
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
and shut-off valve
30
46-7/8
26-1/4*
46-1/4
36-1/4 ±1/4
Installation Information (Dimensions in inches)
Recommended common
area for gas outlet and
electrical outlet
C
L
*Dimension from the wall to the front of the closed door
handle is 29". Depth to the front edge of cooktop 25-1/4".
Factory set for Natural gas. A set of LP orifices
is included with each range for LP conversion.
Gas Self-Clean Range Anti-Tip Bracket
(Part No. 205C1714P001)
Electrical Rating: 120V, 60Hz, 5A
Installation Information: Before installing,
consult installation instructions packed with
product for current dimensional data.

JGBS17PEK/BEL
GE® 30" Free-Standing Standard Clean Gas Range
Specification Revised 6/06 330510
Features and Benefits
• Extra-Large Oven Capacity – Provides a large oven interior ideal for cooking more
items at once
• All Purpose Burners – Deliver a wide range of heat output ideal for most
cooking requirements
• Electronic Clock and Timer – Features a convenient digital clock and easy-to-use
timer with an audible signal to help coordinate cooking times in the kitchen
• Standard Grates – Provide a sturdy and convenient cookware surface for
everyday cooking
• Porcelain Oven Door – Offers a scratch-resistant porcelain coating for easy cleaning
• ClearView™Window – Features a convenient viewing area to check the
progress of food
• Two Oven Racks – Feature a durable construction to help accommodate any size or
type of cookware
• Model JGBS17PEKWW - White on white (white door and cooktop)
• Model JGBS17BELBB - Black on black (black door and cooktop)
JGBS17PEK
CLOCK
SET
TIMER
ONOFF
