GE JGBS20DEM Manual

Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Specification Created 5/07 330585
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Factory set for Natural gas. A set of LP orifices
is included with each range for LP conversion.
Gas Self-Clean Range Anti-Tip Bracket
(Part No. 205C1714P001)
Electrical Rating: 120V, 60Hz, 5A
Installation Information: Before installing,
consult installation instructions packed with
product for current dimensional data.
JGBS20DEM
GE® 30" Free-Standing Standard Clean Gas Range
24
30
8
4
9
2
2-1/2
Recommended area for
thru the floor connection
of pipe stub and shut-off valve
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
and shut-off valve
Recommended common
area for gas outlet and
electrical outlet
C
L
46-1/8
26-1/4*
46-3/8
36-1/4±1/4
*Dimension from wall
to front of closed
door handle is 29".
30
24
30
8
4
9
2
2-1/2
Recommended area for
thru the floor connection
of pipe stub and shut-off valve
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
and shut-off valve
Recommended common
area for gas outlet and
electrical outlet
C
L
46-1/8
26-1/4*
46-3/8
36-1/4±1/4
*Dimension from wall
to front of closed
door handle is 29".
30
24
30
8
4
9
2
2-1/2
Recommended area for
thru the floor connection
of pipe stub and shut-off valve
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
and shut-off valve
Recommended common
area for gas outlet and
electrical outlet
C
L
46-1/8
26-1/4*
46-3/8
36-1/4±1/4
*Dimension from wall
to front of closed
door handle is 29".
30

Features and Benefits
• Extra-Large Oven Capacity - Provides a large oven interior ideal for cooking more
items at once
• All Purpose Burners - Deliver a wide range of heat output ideal for most cooking
requirements
• Electronic Clock And Timer - Features a convenient digital clock and easy-to-use
timer with an audible signal to help coordinate cooking times in the kitchen
• Standard Grates - Provide a sturdy and convenient cookware surface
for everyday cooking
• Frameless Glass Oven Door - Offers an easy-to-clean and stylish design that blends
seamlessly into existing cabinetry
• ClearView™ Window - Features a convenient viewing area to check the progress
of food
• Two Oven Racks - Feature a durable construction to help accommodate any size
or type of cookware
• Six Rack Positions - Provides flexibility and allows consumers to make the most
of available oven capacity
• Interior Oven Light - Supplies light to make viewing the progress of cooking easy
and convenient
• Porcelain Upswept Cooktop - Features raised edges to help contain spills
and make clean-up easy
• Model JGBS20DEMWW - White
• Model JGBS20DEMBB - Black
• Model JGBS20DEMCC - Bisque
JGBS20DEM
LIGHT
TEMP
KITCHEN
Specification Created 5/07 330585
JGBS20DEM
GE® 30" Free-Standing Standard Clean Gas Range
