GE JGBS30 User manual

Write the model and serial
numbers here:
Model #_________________
Serial # _________________
You can find the rating label on the
front behind the range drawer.
ESPAÑOL
Para consultar una version en
español de este manual de
instrucciones, visite nuestro sitio de
internet GEAppliances.com.
OWNER’S MANUAL
RANGES
Thermostat Gas
49-2000315 Rev. 4 11-21 GEA
SAFETY INFORMATION .......... 3
USING THE RANGE
In Case of a Power Failure ............... 7
Surface Burners ........................ 7
Using the Clock and Timer ............... 9
Oven Controls..........................10
Sabbath Usage .........................10
Oven Racks ............................11
Aluminum Foil and Oven Liners...........11
Cookware..............................12
Cooking Modes.........................12
Oven Air Vents .........................12
Cooking Guide .........................13
CARE AND CLEANING
Range – Exterior........................14
Range – Interior ........................15
Cooktop ...............................16
Door and Drawer .......................18
Oven Light.............................19
Oven Door .............................19
TROUBLESHOOTING TIPS.......20
LIMITED WARRANTY ............ 22
ACCESSORIES .................... 23
CONSUMER SUPPORT ...........24
GE is a trademark of the General Electric Company. Manufactured under trademark license.
JGBS10
JGBS30
JGB450
RGBS100
RGBS200
RGBS300
RGBS330

249-2000315 Rev. 4
THANK YOU FOR MAKING GE APPLIANCES A PART OF YOUR HOME.
Whether you grew up with GE Appliances, or this is your first, we’re happy to have you in the family.
We take pride in the craftsmanship, innovation and design that goes into every GEAppliances
product, and we think you will too. Among other things, registration of your appliance ensures that we
can deliver important product information and warranty details when you need them.
Register your GE appliance now online. Helpful websites and phone numbers are available in the
Consumer Support section of this Owner’s Manual. You may also mail in the pre-printed registration
card included in the packing material.

49-2000315 Rev. 4 3
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
SAFETY INFORMATION
ANTI-TIP DEVICE To reduce the risk of tipping the range,
the range must be secured by a properly
installed anti-tip bracket. See installation
instructions shipped with the bracket for
complete details before attempting to
install.
For Free-Standing and Slide-In Ranges
To check if the bracket is installed and
engaged properly, look underneath the
range to see that the rear leveling leg is engaged in the bracket. On
some models, the storage drawer or kick panel can be removed for easy
inspection. If visual inspection is not possible, slide the range forward,
confirm the anti-tip bracket is securely attached to the floor or wall, and
slide the range back so the rear leveling leg is under the anti-tip bracket.
If the range is pulled from the wall for any reason, always repeat this
procedure to verify the range is properly secured by the anti-tip bracket.
Never completely remove the leveling legs or the range will not be secured
to the anti-tip device properly.
WARNING If the information in this manual is not followed exactly, a fire or
explosion may result, causing property damage, personal injury or death.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
 Ŷ 'RQRWWU\WROLJKWDQ\DSSOLDQFH
 Ŷ 'RQRWWRXFKDQ\HOHFWULFDOVZLWFKGRQRWXVHDQ\SKRQHLQ\RXUEXLOGLQJ
Ŷ,PPHGLDWHO\FDOO\RXUJDVVXSSOLHUIURPDQHLJKERU¶VSKRQH)ROORZWKHJDV
VXSSOLHU¶VLQVWUXFWLRQV
 Ŷ ,I\RXFDQQRWUHDFK\RXUJDVVXSSOLHUFDOOWKHILUHGHSDUWPHQW
- Installation and service must be performed by a qualified installer, service agency or
the gas supplier.
WARNING Read all safety instructions before using the product. Failure to follow these instructions may result
in fire, electrical shock, serious injury or death.
Anti-Tip
Bracket
Leveling Leg
Free-Standing and Slide-In Ranges
• A child or adult can tip the range and be killed.
• Install the anti-tip bracket to the wall or floor.
• Engage the range to the anti-tip bracket by sliding the
range back such that the foot is engaged.
• Re-engage the anti-tip bracket if the range is moved.
• Failure to do so can result in death or serious burns
to children or adults.
Tip-Over Hazard
WARNING

449-2000315 Rev. 4
SAFETY INFORMATION
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
WARNING GENERAL SAFETY INSTRUCTIONS
WARNING
NEVER use this appliance
as a space heater to heat or warm the room.
Doing so may result in carbon monoxide
poisoning and overheating of the oven.
Ŷ 8VHWKLVDSSOLDQFHIRULWVLQWHQGHGSXUSRVHDV
described in this owner’s manual.
Ŷ +DYH\RXUUDQJHLQVWDOOHGDQGSURSHUO\JURXQGHGE\
a qualified installer in accordance with the provided
installation instructions.
Ŷ $Q\DGMXVWPHQWDQGVHUYLFHVKRXOGEHSHUIRUPHG
only by a qualified gas range installer or service
technician. Do not attempt to repair or replace
any part of your range unless it is specifically
recommended in this manual.
Ŷ <RXUUDQJHLVVKLSSHGIURPWKHIDFWRU\VHWIRUXVH
with natural gas. It can be converted for use with
propane gas. If required, these adjustments must be
made by a qualified technician in accordance with
the installation instructions and local codes. The
agency performing this work assumes responsibility
for the conversion.
Ŷ +DYHWKHLQVWDOOHUVKRZ\RXWKHORFDWLRQRIWKH
range gas shut-off valve and how to turn it off if
necessary.
Ŷ 3OXJ\RXUUDQJHLQWRDYROWJURXQGHGRXWOHW
only. Do not remove the round grounding prong
from the plug. If in doubt about the grounding of the
home electrical system, it is your responsibility and
obligation to have an ungrounded outlet replaced
with a properly grounded, three prong outlet in
accordance with the National Electrical Code. Do
not use an extension cord with this appliance.
Ŷ %HIRUHSHUIRUPLQJDQ\VHUYLFHXQSOXJWKHUDQJH
or disconnect the power supply at the household
distribution panel by removing the fuse or switching
off the circuit breaker.
Ŷ )RUWKHFRUGOHVVUDQJHEHIRUHSHUIRUPLQJDQ\
service, remove the 9V battery from the range to
disable the spark ignition system.
Ŷ %HVXUHDOOSDFNLQJPDWHULDOVDUHUHPRYHGIURPWKH
range before operating to prevent ignition of these
materials.
Ŷ $YRLGVFUDWFKLQJRULPSDFWLQJJODVVGRRUV
cooktops, or control panels. Doing so may lead
to glass breakage. Do not cook on a product with
broken glass. Shock, fire, or cuts may occur.
Ŷ 'RQRWOHDYHFKLOGUHQDORQHRUXQDWWHQGHGLQDQ
area where an appliance is in use. They should
never be allowed to climb, sit or stand on any part
of the appliance.
Ŷ
CAUTION
Do not store items of interest
to children in cabinets above an oven - children
climbing on the oven to reach items could be
seriously injured.
Ŷ 1HYHUEORFNWKHYHQWVDLURSHQLQJVRIWKHUDQJH
They provide the air inlets and outlets that are
necessary for the range to operate properly with
correct combustion. Air openings are located at the
rear of the cooktop, at the top and bottom of the
oven door, and at the bottom of the range under the
warming drawer, lower oven drawer or kick panel.
Ŷ 8VHRQO\GU\SRWKROGHUV²PRLVWRUGDPSSRW
holders on hot surfaces may result in burns from
steam. Do not let pot holders touch surface burners,
burner grate, or oven heating element. Do not use a
towel or other bulky cloth in place of pot holders.
Ŷ 'RQRWWRXFKWKHKHDWLQJHOHPHQWVRUWKHLQWHULRU
surface of the oven. These surfaces may be hot
enough to burn even though they are dark in color.
During and after use, do not touch, or let clothing
or other flammable materials contact any interior
area of the oven; allow sufficient time for cooling
first. Other surfaces of the appliance may become
KRWHQRXJKWRFDXVHEXUQV3RWHQWLDOO\KRWVXUIDFHV
include the burners, grates, oven vent opening,
surfaces near the opening, and crevices around the
oven door.
Ŷ 'RQRWKHDWXQRSHQHGIRRGFRQWDLQHUV3UHVVXUH
could build up and the container could burst,
causing an injury.
Ŷ &RRNIRRGWKRURXJKO\WRKHOSSURWHFWDJDLQVW
foodborne illness. Minimum safe food temperature
recommendations can be found at IsItDoneYet.gov
and fsis.usda.gov8VHDIRRGWKHUPRPHWHUWRWDNH
food temperatures and check several locations.
Ŷ 'RQRWDOORZDQ\RQHWRFOLPEVWDQGRUKDQJRQWKH
oven door, drawer or cooktop. They could damage
the range or tip it over causing severe injury or death.

49-2000315 Rev. 4 5
WARNING KEEP FLAMMABLE MATERIALS AWAY FROM THE RANGE
Failure to do so may result in fire or personal injury.
Ŷ 'RQRWVWRUHRUXVHIODPPDEOHPDWHULDOVLQDQRYHQ
or near the cooktop, including paper, plastic, pot
holders, linens, wall coverings, curtains, drapes and
gasoline or other flammable vapors and liquids.
Ŷ 1HYHUZHDUORRVHILWWLQJRUKDQJLQJJDUPHQWVZKLOH
using the appliance. These garments may ignite if
they contact hot surfaces causing severe burns.
Ŷ 'RQRWOHWFRRNLQJJUHDVHRURWKHUIODPPDEOH
materials accumulate in or near the range. Grease
in the oven or on the cooktop may ignite.
READ AND SAVE THESE INSTRUCTIONS
WARNING IN THE EVENT OF A FIRE, TAKE THE FOLLOWING
STEPS TO PREVENT INJURY AND FIRE SPREADING
Ŷ 'RQRWXVHZDWHURQJUHDVHILUHV1HYHUSLFNXS
a flaming pan. Turn the controls off. Smother a
flaming pan on a surface unit by covering the pan
completely with a well-fitting lid, cookie sheet or flat
WUD\8VHDPXOWLSXUSRVHGU\FKHPLFDORUIRDPW\SH
fire extinguisher.
Ŷ ,IWKHUHLVDILUHLQWKHRYHQGXULQJEDNLQJVPRWKHU
the fire by closing the oven door and turning the
oven off or by using a multi-purpose dry chemical or
foam-type fire extinguisher.
Ŷ ,IWKHUHLVDILUHLQWKHRYHQGXULQJVHOIFOHDQWXUQ
the oven off and wait for the fire to go out. Do not
force the door open. Introduction of fresh air at self-
clean temperatures may lead to a burst of flame
from the oven. Failure to follow this instruction may
result in severe burns.
WARNING COOKTOP SAFETY INSTRUCTIONS
WARNING
NEVER Operate the
Top Surface Cooking Section of this
Appliance Unattended.
•Failure to follow this warning
statement could result in fire,
explosion, or burn hazard that could
cause property damage, personal
injury, or death.
•If a fire should occur, keep away from
the appliance and immediately call
your fire department.
DO NOT ATTEMPT TO EXTINGUISH
AN OIL/GREASE FIRE WITH WATER.
Ŷ 1HYHUOHDYHWKHVXUIDFHEXUQHUVXQDWWHQGHGDW
medium or high heat settings. Foods, especially oily
foods, may ignite resulting in fire that could spread
to surrounding cabinets.
Ŷ 1HYHUOHDYHRLOXQDWWHQGHGZKLOHIU\LQJ,IDOORZHG
to heat beyond its smoking point, oil may ignite
resulting in fire that may spread to surrounding
FDELQHWV8VHDGHHSIDWWKHUPRPHWHUZKHQHYHU
possible to monitor oil temperature.
Ŷ 7RDYRLGRLOVSLOORYHUDQGILUHXVHWKHPLQLPXP
amount of oil when using a shallow pan-frying
and avoid cooking frozen foods with excessive
amounts of ice.
Ŷ 8VHSURSHUSDQVL]HDQGDYRLGSDQVWKDWDUH
unstable or easily tipped. Select cookware that is
matched to the size of the burner. Burner flames
should be adjusted so that they do not extend
beyond the bottom of the pan. Excessive flame may
be hazardous.
Ŷ $OZD\VXVHWKH/,7(SRVLWLRQZKHQLJQLWLQJWKHWRS
burners and make sure the burners have ignited.
Ŷ :KHQXVLQJJODVVFHUDPLFFRRNZDUHPDNHVXUHLW
is suitable for cooktop service; others may break
because of sudden change in temperature.
Ŷ 7RPLQLPL]HWKHSRVVLELOLW\RIEXUQVLJQLWLRQRI
flammable materials and spillage, the handle of a
container should be turned toward the center of the
range without extending over nearby burners.
Ŷ 'RQRWXVHDZRNZLWKDURXQGPHWDOVXSSRUWULQJ
The ring may trap heat and block air to the burner
resulting in a carbon monoxide hazard.
Ŷ 'RQRWDWWHPSWWROLIWWKHFRRNWRS'RLQJVRPD\
damage the gas tubing to the surface burners
resulting in a gas leak and risk of fire.
Ŷ :KHQGLVDEOLQJ/RFN&RQWURORQVRPHPRGHOV
make sure the surface controls are set to the OFF
position. This will prevent unintended gas flow from
the burners.
Ŷ 'RQRWXVHDOXPLQXPIRLOWRFRYHUWKHJUDWHVRU
line any part of the cooktop. Doing so may result
in carbon monoxide poisoning, overheating of the
cooktop surfaces, or a potential fire hazard.
SAFETY INFORMATION
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE

649-2000315 Rev. 4
WARNING SELF-CLEANING OVEN SAFETY INSTRUCTIONS
The self-cleaning feature operates the oven at temperatures high enough to burn away food soils in the oven.
Follow these instructions for safe operation.
Ŷ 'RQRWWRXFKRYHQVXUIDFHVGXULQJVHOIFOHDQ
operation. Keep children away from the oven during
self-cleaning. Failure to follow these instructions
may cause burns.
Ŷ %HIRUHRSHUDWLQJWKHVHOIFOHDQF\FOHUHPRYHSDQV
shiny metal oven racks, and other utensils from the
oven. Only porcelain-coated oven racks may be left
in the oven.
Ŷ %HIRUHRSHUDWLQJWKHVHOIFOHDQF\FOHZLSHJUHDVH
and food soils from the oven. Excessive amount
of grease may ignite leading to smoke damage to
your home.
Ŷ ,IWKHVHOIFOHDQLQJPRGHPDOIXQFWLRQVWXUQWKH
oven off and disconnect the power supply. Have it
serviced by a qualified technician.
Ŷ 'RQRWXVHRYHQFOHDQHUV1RFRPPHUFLDORYHQ
cleaner or oven liner protective coating of any kind
should be used in or around any part of the oven.
Ŷ 'RQRWFOHDQWKHGRRUJDVNHW7KHGRRUJDVNHWLV
essential for a good seal. Care should be taken not
to rub, damage or move the gasket.
Ŷ IMPORTANT: The health of some birds is
extremely sensitive to the fumes given off during
the self-cleaning cycle of any range. Move birds to
another well-ventilated room.
SAFETY INFORMATION
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
READ AND SAVE THESE INSTRUCTIONS
WARNING OVEN SAFETY INSTRUCTIONS
WARNING
NEVER cover any slots,
holes, or passages in the oven bottom or
cover an entire rack with materials such as
aluminum foil or oven liners. Doing so blocks
air flow through the oven and may cause
carbon monoxide poisoning. Never place foil
or oven liners on the oven bottom. They can
trap heat causing risk of smoke or fire.
Ŷ 6WDQGDZD\IURPWKHUDQJHZKHQRSHQLQJWKHRYHQ
door. Hot air or steam which escapes can cause
EXUQVWRKDQGVIDFHDQGRUH\HV
Ŷ 1HYHUSODFHFRRNLQJXWHQVLOVSL]]DRUEDNLQJVWRQHV
or any type of foil or liner on the oven floor. These
items can trap heat or melt, resulting in damage to
the product and risk of shock, smoke or fire.
Ŷ 3ODFHRYHQUDFNVLQGHVLUHGORFDWLRQZKLOHRYHQLV
cool. If rack must be moved while oven is hot, be
careful to avoid touching hot surfaces.
Ŷ 'RQRWOHDYHLWHPVVXFKDVSDSHUFRRNLQJXWHQVLOV
or food in the oven when not in use. Items stored in
an oven can ignite.
Ŷ 'RQRWOHDYHLWHPVRQWKHFRRNWRSQHDUWKHRYHQ
vent. Items may overheat resulting in a risk of fire or
burns.
Ŷ 1HYHUEURLOZLWKGRRURSHQ2SHQGRRUEURLOLQJLV
not permitted due to overheating of control knobs.
How to Remove Protective Shipping Film and Packaging Tape
Carefully grasp a corner of the protective shipping film
with your fingers and slowly peel it from the appliance
surface. Do not use any sharp items to remove the film.
Remove all of the film before using the appliance for the
first time.
To assure no damage is done to the finish of the
product, the safest way to remove the adhesive from
packaging tape on new appliances is an application of
a household liquid dishwashing detergent. Apply with a
soft cloth and allow to soak.
NOTE: The adhesive must be removed from all parts. It
cannot be removed if it is baked on.
Consider recycling options for your appliance packaging
material.
PROPER DISPOSAL OF YOUR APPLIANCE
Dispose of or recycle your appliance in accordance with Federal and Local Regulations. Contact your local
authorities for the environmentally safe disposal or recycling of your appliance.

49-2000315 Rev. 4 7
In Case of a Power Failure
USING THE RANGE: ,Q &DVH RI D 3RZHU )DLOXUH  6XUIDFH %XUQHUV
Surface Burners
In the event of a power failure, the oven is inoperable and no attempt should be made to operate it. However, the
VXUIDFH EXUQHUV PD\ EH OLW ZLWK D PDWFK 8VLQJ H[WUHPH FDXWLRQ KROG D OLW PDWFK QHDU WKH SRUWV EHQHDWK WKH VXUIDFH
burner cap, then slowly turn the knob to the LITE position. Once lit, surface burners will continue to operate normally.
Lighting a Surface Burner
WARNING Burners should be operated only when
covered by cookware. Burner flames not covered by
cookware present a risk of fire or clothing ignition. Never
let flames extend beyond the sides of the cookware.
Failure to comply may result in serious injury.
Make sure all burners are in their correct locations and
fully assembled before attempting to operate any burner.
6HOHFW D EXUQHU DQG ILQG LWV FRQWURO NQRE 3XVK WKH NQRE
in and turn it to the LITE position.
You will hear a clicking
QRLVH²WKH VRXQG RI WKH
electric spark igniting the
burner. When one burner is
turned to LITE, all burners will
spark. Sparking will continue
as long as the knob remains
at LITE. Once gas is ignited,
turn the knob to adjust the
flame size.
Replacing the 9V Battery (cordless range)
CAUTION Battery may explode or leak and cause
burn injury, if recharged, disposed of in fire, inserted
backwards, or missassembled.
When a knob is turned to the LITE position, sparking
will occur at the burners. A weak battery will cause
the amount of time between sparks to increase. If the
time between sparks exceeds one second, replace
the battery. If a surface burner doesn’t light within five
seconds, turn gas off and wait one minute for gas to
dissipate before attempting to light again.
On some models, a Battery
Level indicator light is located to
the left of the burner knobs. This
light will glow as the burners
are being lit if the battery has
enough power. If this indicator
light fails to glow during
sparking, the battery power level
is low and the battery should be
replaced soon.
IMPORTANT: Replace with
standard 9V alkaline battery.
Follow all state and local
requirements for disposing of
the old battery.
Selecting a Flame Size
Watch the flame, not the knob, as you adjust heat. When
rapid heating is desired, the flame size should match the
size of the cookware you are using. Flames larger than
the bottom of the cookware will not heat faster and may
be hazardous. These flames are too large for the pot
3XVK WKH FRQWURO NQRE LQ DQG
turn it to the LITE position.
Battery Compartment
Location
Battery Level
OFF
LO
2
4
8
6
HI
LITE
Using the Surface Burners
NOTES:
Ŷ 'R QRW RSHUDWH WKH EXUQHU IRU DQ H[WHQGHG SHULRG RI
time without cookware on the grate. The finish on the
grate may discolor or chip without cookware to absorb
the heat.
Ŷ 'R QRW DWWHPSW WR GLVDVVHPEOH DQ\ EXUQHU ZKLOH DQRWKHU
burner is on. Damage to the product may occur.
Ŷ %H VXUH WKH EXUQHUV DQG JUDWHV DUH FRRO EHIRUH \RX
place your hand, a pot holder or cleaning materials
on them.
Your rangetop offers convenience, cleanability and
flexibility for a wide range of cooking applications.
The smallest burner is the simmer burner. A simmer
burner turned down to LO provides precise cooking
performance for foods such as delicate sauces that
require low heat for a long cooking time.

849-2000315 Rev. 4
USING THE RANGE: Surface Burners
Surface Burners (Cont.)
Stove Top Grills
Do not use an after-market stove top grill on your
gas surface burners. A stove top grill will cause
incomplete combustion resulting in carbon monoxide
levels above allowable standards. This could be
hazardous to your health.
Using a Wok
8VHRQO\DIODWERWWRPHGZRNZLWKDGLDPHWHURILQFKHV
or less. Make sure the wok bottom sits flat on the grate.
'RQRWXVHDZRNVXSSRUWULQJ3ODFLQJWKHULQJRYHUWKH
burner or grate may cause the burner to work improperly,
resulting in carbon monoxide levels above allowable
standards. This could be hazardous to your health. 8VHDIODWERWWRPHGZRN
Do not use stove top grills
Top-of-Range Cookware
Aluminum: Medium-weight cookware is recommended
because it heats quickly and evenly. Most foods brown
HYHQO\LQDQDOXPLQXPVNLOOHW8VHVDXFHSDQVZLWKWLJKW
fitting lids when cooking with minimum amounts of water.
Stainless Steel: This metal alone has poor heating
properties and is usually combined with copper,
aluminum or other metals for improved heat distribution.
Combination metal skillets usually work satisfactorily if
they are used with medium heat or as the manufacturer
recommends.
Cast-Iron: If heated slowly, most skillets will give
satisfactory results.
Enamelware:8QGHUVRPHFRQGLWLRQVWKHHQDPHO
of some cookware may melt. Follow the cookware
manufacturer’s recommendations for cooking methods.
Glass:7KHUHDUHWZRW\SHVRIJODVVFRRNZDUH²WKRVH
for oven use only and those for top-of-range cooking
VDXFHSDQVFRIIHHDQGWHDSRWV*ODVVFRQGXFWVKHDW
very slowly.
Heatproof Glass Ceramic: Can be used for either
surface or oven cooking. It conducts heat very slowly and
cools very slowly. Check the cookware manufacturer’s
directions to be sure it can be used on gas ranges.
Surface Burner
The round burner is for general cooking purposes. Size
cookware appropriately to the flames.
Lighting Burners with a Match (cordless range)
If the battery is too weak to light the burners, you can
light the gas surface burners on your range with a
wooden kitchen match. Hold a lit match to the burner,
then push in and turn the control knob to the LITE
SRVLWLRQ8VHH[WUHPHFDXWLRQZKHQOLJKWLQJEXUQHUVWKLV
way. Surface burners in use when an electrical power
failure occurs will continue to operate normally.

49-2000315 Rev. 4 9
Using the Clock and Timer
USING THE RANGE:8VLQJWKH&ORFNDQG7LPHU
Throughout this manual, features and appearance may vary from your model.
You have the choice of having the timer show the time
counting down or the time of day. In either case, the
timer will signal at the end of the timer period to alert you
that the time is up.
To Set the Clock
NOTE: When you first plug in the range or after a power
IDLOXUHWKHHQWLUH&ORFN7LPHUGLVSOD\ZLOOOLJKWXS
1. 3UHVVWKHClock pad.
2. 3UHVVDQGKROGWKH+or –pad and the time of day
ZLOOFKDQJHPLQXWHVDWDWLPH7RFKDQJHWKH
time by single minutes, give the pads short taps.
3. 3UHVVWKHClock pad to start the clock.
To Set the Kitchen Timer
1. 3UHVVWKHKitchen Timer On/Off pad.
2. 8VHWKH+and –pads to set the timer. Short taps on
the +or –pad change the timer’s setting one minute
DWDWLPH3UHVVLQJDQGFRQWLQXLQJWRKROGWKH+pad
LQFUHDVHVWKHVHWWLQJPLQXWHVDWDWLPH
3. Once you have set your timer, press the Kitchen
Timer On/Off pad to start timing.
As the timer counts down, a signal will indicate
when one minute is left. After this signal, the display
will count down in seconds. When time runs out, a
ILQDOVLJQDOZLOOVRXQG3UHVVWKHKitchen Timer On/
Off pad to stop the signal.
To Change or Cancel the Kitchen Timer Setting
When the timer is counting down, use the +and –pad
to change the remaining time, or press the Kitchen
Timer On/Off pad to stop the timer. The timer cannot
be cancelled unless you have fully completed “set timer”
instructions above.
Display Clock While Kitchen Timer Is Operating
3UHVVLQJWKHClock pad while the timer is operating will
not interfere with the timer’s operation; the display will
change to show the clock, but the timer will continue to
FRXQWGRZQDQGZLOOVWLOOVLJQDOZKHQWLPHLVXS3UHVV
the Kitchen Timer On/Off pad again to change the
display back to show the timer.

 49-2000315 Rev. 4
Oven Controls
Sabbath Usage
USING THE RANGE: 2YHQ&RQWUROV6DEEDWK8VDJH
Oven Temperature Knob (on some models)
Turn the Oven Temp knob to the setting you want.
Ŷ7KH2YHQ&\FOHOLJKWFRPHVRQZKHQWKHEXUQHULVRQ
It will cycle on and off during cooking.
To Adjust the Thermostat
(on models with an Oven Temp Knob):
 3XOOWKHOven Temp knob off the range and look
at the back side. To make an adjustment, loosen
DSSUR[LPDWHO\RQHWXUQEXWGRQRWFRPSOHWHO\
remove, the two screws on the back of the knob.
2. With the back of the knob facing you, hold the outer
edge of the knob with one hand and turn the front of
the knob with the other hand.
To increase the oven temperature, move the top
screw toward the right. You’ll hear a click for each
notch you move the knob.
To decrease the oven temperature, move the top
screw toward the left.
Each click will change the oven temperature
DSSUR[LPDWHO\)
5DQJHLVSOXVRU
PLQXV)IURPWKH
DUURZ:HVXJJHVW
that you make the
adjustment one click
from the original
setting and check oven
performance before
making any additional
adjustments.
3. After the adjustment is
made, retighten screws
so they are snug,
but be careful not to
overtighten.
4. Replace the knob,
matching the flat area
of the knob to the shaft,
and check performance.
Certain models comply with the Star-K Jewish Sabbath requirements for use during the Sabbath and holidays. For
the latest list of models, see star-k.org.
Start a Baking
To start a baking, simply turn the thermostat knob to the
desired temperature. Because a thermostat model will
respond with a clicking sound when the thermostat knob
is used to turn on the oven, this operation should take
place before the Sabbath or Holidays begin.
Adjusting the Temperature
To adjust the oven temperature while in compliance with
Sabbath requirements, the user must observe the oven
ON indicator light:
Ŷ7RDGMXVWWKHRYHQWHPSHUDWXUHWRDKLJKHUYDOXH
the user must first confirm the "OVEN ON" light is
on. Only then, can the user turn the knob to a higher
temperature than was previously set.
Ŷ7RDGMXVWWKHRYHQWHPSHUDWXUHWRDORZHUYDOXH
the user must first confirm the "OVEN ON" light is
off. Only then, can the user turn the knob to a lower
temperature than was previously set.
Stop Baking
To stop a baking, simply turn the thermostat knob to the
off position. Because a thermostat model will respond
with a clicking sound when the thermostat knob is used
to turn off the oven, this operation should take place after
the Sabbath or Holidays end.
)URQWRI29(17(03NQRE
NQREDSSHDUDQFHPD\YDU\
%DFNRI29(17(03NQRE
NQREDSSHDUDQFHPD\YDU\
OVEN TEMP
2
0
0
2
5
0
3
0
0
3
5
0
4
0
0
4
5
0
5
0
0
B
R
O
I
L
C
L
E
A
N
O
F
F
L
O
O
S
E
N
S
C
R
E
W
S
T
O
R
O
T
A
T
E
M
A
K
E
C
O
O
L
E
R
M
A
K
E
H
O
T
T
E
R
Lighting the Oven with a Match (cordless range)
The oven of a battery-powered cordless range may be lit
with a match and operated normally, even if the battery
is too weak to activate the spark system. Follow these
steps to match-light the oven burner:
 5HPRYHWKHRYHQGRRURYHQUDFNVDQGRYHQ
ERWWRP7RUHPRYHRYHQERWWRPUHPRYHWZR´
hex head screws at the rear of the oven.
2. Locate the oven burner pilot at the left rear of the
oven burner.
3. Hold a lit match to the oven burner pilot. Turn the
oven control knob to the PILOT position and push
in completely.
4. After pilot lights, continue to hold in firmly on the
NQREIRUVHFRQGVEHIRUHUHOHDVLQJ
 3LORWVKRXOGUHPDLQOLW,IQRWUHSHDWVWHSVDQG
6. Replace oven bottom, racks, and oven door.
7. Turn knob to the desired temperature setting. Oven
will operate normally.
Turn oven control knob to Off when finished baking.
