ZDP36L6DSS - GE Monogram 36" Professional Range with 6 Burners
Dimensions and Specifications (in inches)
These ranges are factory set for either natural gas or
liquid propane gas.
36" Natural Gas Model:
ZDP36N6WSS–6 gas burners
36" Liquid Propane Gas Model:
ZDP36L6WSS–6 gas burners, grill and griddle
Accessory Requirements:
All models require the installation of a backguard. A
backguard should be ordered at the same time as the
range. Both must be on site at the time of installation.
Order one backguard for 36" models:
ZX1B36WSS–1-1/2" high backguard
(required for island installations)
ZX12B36WSS–12" high backguard
ZX22B36WSS–22" high backguard with warming rack
(2 piece)
Important!
Please call for your exclusive
40-Point Inspection! 800.444.1845
Owners of Monogram™professional ranges enjoy the
additional benefit of a complimentary visit by a specially
trained technician. This includes temperature calibration
of each oven and cooktop element. This is Monogram’s
way of ensuring correct installation and precise operation
of your new professional range.
Our Preferred Service Specialists are always at
your service.
21-1/4"
12"
1-1/2"
35-1/4"-36-3/4"
28-1/4" 35-7/8"
Available Backguards
ZX22B36WSS
ZX12B36WSS
ZX1B36WSS
R
Listed by
Underwriters
Laboratories

For answers to your Monogram,
®GE Profile™or
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.
Monogram.
™
Specification Created 7/01
ZDP36L6DSS - GE Monogram 36" Professional Range with 6 Burners
Dimensions and Specifications (in inches)
Advance Planning:
Refer to dimensional drawings for appropriate placement
and necessary clearances when planning
the installation.
•Cabinetry cannot be installed directly above the range.
•This range requires the installation of a vent hood,
30" to 36" above the surface.
–The vent hood must be at least 24" deep.
–The vent hood must be the same width as the range.
–The vent hood must provide at least 600 CFM and
up to 800 CFM.
–When installing a range that includes a grill, select a
blower on the high end of the CFM recommendation.
•Working areas adjacent to the range should have
18" minimum clearance between countertop and cabinet
bottom.
•Clearance between range and side wall or combustible
material must be at least 12" on each side.
If the range is installed in an island:
•Allow 12" min. clearance at the back to combustible
materials.
•Allow 36" min. above the cooking surface to
combustible materials.
•The vent hood must provide at least 600 CFM and
up to 1200 CFM.
•Installation must conform with local codes. In the
absence of local codes, the range must comply with
the National Fuel Gas Code, ANSI Z223.1-1990.
A.G.A. approved
Installation Information:
Before installing, consult installation instructions
(Pub. #49-8786) packed with product for current
dimensional data.
3/-1/4"
18" Min.
4"
35-3/8" Max. for Counter Level
36-3/4" Max. with Range Leveling Legs Fully Extended
3/-1/2"
Gas Supply
Electrical Supply
Cooking Surface
13"
Max.
4"
12"
36" Wide Range Hood
12" Min. to
Combustible
Material
Each Side
36" Min. to
Combustible
Material From
Cooking Surface
12"
Low Back
High
Shelf
29-1/16"
12"
3-1/4"
21-1/4"
12"
36" Min.
to Combustibles
28-1/4"
31-1/2"
45-5/8"
0" Clearance
Island Trim
1-1/2"
36" Min.
to Combustibles
0" Clearance
12" Min. to Combustibles
Without Backguard
R
Listed by
Underwriters
Laboratories

Monogram.
™
Specification Created 7/01
ZDP36L6DSS - GE Monogram 36" Professional Range with 6 Burners
Monogram
FRONT REAR FRONT REAR OVEN
FRONT REAR
OVEN
LIGHT
Features and Benefits
•Stainless Steel Model
•Liquid Propane Gas
•Six (15,000/500 BTU) Dual-Ring Gas Burners
•Cast-Iron, Porcelainized Burner Grates
•Stainless Steel, Slide-Out Drip Tray
•Electronic Ignition with Automatic Re-Ignition
•4.3 Cubic Foot Capacity Electric Convection Oven
•Self-Cleaning Oven
•Commercial-Style Controls
•10-Pass Bake Element and 8-Pass Broil Element
•Porcelain-Enameled Broiler Pan with
Chrome-Plated Grid
•3 Oven Racks
•Stainless Steel Door with Window
•Tubular Stainless Steel Handle
•Model ZDP36N6DSS—Natural Gas
•Model ZDP36L6DSS—Liquid Propane Gas
