GE Cafe CSHS5UGXSS Manual

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Dimensions and Installation Information (in inches)
†Water hook-up fits in back air clearance when calculating
installation depth.
If installed against a wall, allow clearance of 14-3/16" on freezer
side to remove bin.
Clearance required to remove fresh food full-size pan without
disassembling is 18-15/16".
Allow additional space for any necessary leveling adjustments.
"94 SxS Refer
A
Front View
Top View
G
D
C
F
BE
H
CSHS5UGX
GE Café 25.4 Cu. Ft. Side-By-Side Refrigerator with Dispenser
Overall
Dimensions
Height to top of hinge (in.) A 69-5/8
Height to top of case (in.) B 68-3/4
Case depth without door (in.) C†28
Case depth less door handle (in.) D†32-1/4
Case depth with door handle (in.) E†34-3/4
Depth with fresh food door open 90° (in.) F†50-1/8
Width (in.) G36
Width with door open 90° inc. door handle (in.) H 41-3/4
Air
Clearances
Each side (in.) 1/8
Top (in.) 1
Back (in.) 1/2
Listed by
Underwriters
Laboratories
Specification Revised 4/08 310194
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.

Features and Benefits
• Stainless Steel - Provides stainless steel doors and side panels for a truly dramatic look
• ClimateKeeper™Temperature Management System - Best Temperature
Management System You Can Buy
• Integrated Dispenser with LED Lighting & UltraFlow100 - Illuminates the dispenser
and pours up to 100 ounces of water per minute
• ExpressChill™with 1 setting - Chills beverages quickly with easy one-button
selection of 45 minutes
• Slide 'n Store™Full-Extension Freezer Baskets - Extends 12" to 16" beyond the
cabinet, providing easy loading and unloading
• Quick Ice™Option - Makes ice up to 50% faster than normal settings-ideal
for entertaining
• TurboCool™Setting - Cools the refrigerator quickly after frequent door openings
• Integrated Ice™System - Frees up valuable freezer space; It tilts down, providing
easy access to bulk ice
• Tilt-Out Freezer Door Bins - Move forward for convenient access
• Integrated Shelf Support System - Provides strong, yet flexible support
• Adjustable ClearLook™Door Bins - Hold gallon-size containers with style and ease
• In-the-Door Beverage Rack - Conveniently located inside the refrigerator door to
increase flexibility and to free up valuable shelf space
• Adjustable Slide-Out, Spillproof Glass Shelves - Raised edges help contain spills and
slide-out shelves make clean up quick and easy
• Model CSHS5UGXSS - Stainless steel
CSHS5UGX
GE Café 25.4 Cu. Ft. Side-By-Side Refrigerator with Dispenser
Specification Revised 4/08 310194
