GE Monogram ZISS420NXSS Manual

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
110186
Specification Revised 11/08
Listed by
Underwriters
Laboratories
ZISS420NXSS
GE Monogram® 42" Built-In Professional Side-by-Side Refrigerator
Dimensions and Installation Information (in inches)
Water and electrical locations
The opening must be prepared with the electrical and water
supply located as shown.
The cutout depth must be 24".
The refrigerator will project forward, slightly beyond
adjacent cabinetry, depending on your installation.
The cutout depth beneath a soffit:
When installed beneath a soffit, the soffit cannot exceed the
24" installation depth shown. The top case trim overlaps the
bottom of the soffit.
Frameless cabinets:
The case trim overlaps cabinets at the top and sides.
Therefore, frameless cabinets may require filler strips to
prevent interference with cabinet door swing. The opening
must allow for filler strips.
Additional Specifications
• A 115 volt 60Hz., 15 or 20 amp power supply is required.
An individual properly grounded branch circuit or circuit
breaker is recommended. Install a properly grounded 3-
prong electrical receptacle recessed into the back wall.
Electrical must be located on rear wall as shown.
Note: GFI (ground fault interrupter) is not recommended.
• Water line can enter the opening through the floor or back
wall. The water line should be 1/4" O.D. copper tubing or
GE SmartConnect™kit between the cold water line and
water connection location, long enough to extend to the
front of the refrigerator. Installation of an easily accessible
shut off valve in the water line is recommended.
The Installation Space
* Shipping height.
The refrigerator
can be adjusted to
fit into a cutout that
is 83-1/2" min. to
84-1/2” max. height.
Note that the top
case trim at the
front is 1/2" higher
and will overlap
upper cabinetry or
soffit. Use leveling
legs and wheels
for a maximum 1"
height adjustment.
Product Clearances
These refrigerators are equipped with a 2 position door stop.
The factory set 130° door swing can be adjusted to 90° if
clearance to adjacent cabinets or walls is restricted.
Allow minimum clearances for freezer door and fresh food
door for a full 130° door swing and to allow for pan removal.
4" minimum clearance is required when door swing is
adjusted to 90°. If the 90° door stop position is used, pan
access is maintained, but pan removal is restricted.
Installation Information: Before installing, consult
installation instructions packed with product, or online
at Monogram.com, for current dimensional data.
19"
130° Door Swing
13"
*Finished Width
6"
5"
Electrical
Area
84-1/2" max
83-1/2" min
Finished
Opening 75" From Floor
to Bottom
of Electrical
Area
24"
5" 5" 3-1/2"
Water Supply
3-1/2"
36" Models 12"
42" Models 18"
48" Models 20"
35-1/2" for 36" models
41-1/2" for 42" models
47-1/2" for 48" models
696Dia15
429Dia8
*84" From
Floor to
Top Frame
42"
Frame to Frame
41"
Case Width
*83-1/2"
at
Rear
25-3/4"
27-3/4"
including
handle
23-7/8"
Behind
Frame
90°Door Swing
4" Min.
to Wall
28-5/8"

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
110186
Specification Revised 11/08
ZISS420NXSS
GE Monogram® 42" Built-In Professional Side-by-Side Refrigerator
ZISS420NRSS
Features and Benefits
• Halogen Light Columns - Located in the freezer and fresh
food compartments, extend the full length of the interior
compartments providing brilliant, all-level illumination
• LED Lighting - Located at the top of the fresh food
compartment, and inside the high-humidity and climate-
control drawers, illuminates contents without
compromising space
• Advanced Temperature Management System with Multi-Shelf
Air Tower - Provides even distribution of air throughout
the refrigerator
• Climate-Control Drawer - Allows you to express-chill
beverages, express-thaw meats and select specific
temperatures for perishable foods
• Humidity-Controlled Vegetable Drawer - Helps preserve the
freshness of foods
• Gallon-Size Door Bin - Holds milk containers, two-liter bottles
and pitchers
• Adjustable Spillproof Glass Shelves - Easily accommodate
party trays and platters
• Drop-Down Shelf - Provides additional space for a casserole
dish or pizza box
• Adjustable Deli Drawer on Full-Extension Slides - Keeps
meats, cheeses and other everyday foods within easy reach
• Dairy Bin with Center Divider - Has a unique magnetic seal
that locks in freshness
• Adjustable Door Bins - Can be moved to one of two positions
in seven locations
• GE®Water Filter - Has been moved from the fresh food
compartment to the overhead cabinet, where it is discreetly
out of sight
• Model ZISS420NXSS – Stainless steel wrap, non-dispenser
