GE Profile PDCF1NBW Manual

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Dimensions and Installation Information (in inches)
Listed by
Underwriters
Laboratories
Front View Top View
B
A
E
F
G
TCX22 QSART
CD
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
Specification Revised 4/07 210843
Overall
Dimensions
Height to top of hinge (in.) A 69-5/8
Height to top of case (in.) B 69
Case depth without door (in.) C 24-1/8
Case depth less door handle (in.) D 28
Case depth with door handle (in.) E 31
Depth with fresh food door open 90° (in.) F 61-3/8
Width (in.) G 35-7/8
Width with door open 90° inc. door handle (in.) H 40-7/8
Air
Clearances
Each side (in.) 1/8
Top (in.) 1
Back (in.) 1/2
PDCF1NBW
GE Profile™ENERGY STAR® 21.1 Cu. Ft. Bottom-Freezer Drawer Refrigerator
Note:
Anti-tip bracket part number 200D8494P001 will be shipped with
every counter-depth model

As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
Specification Revised 4/07 210843
PDSF5NFWWW
PDSF5NBWWW
PDCF1NFWWW
PDCF1NBWWW
Features and Benefits
• Counter-Depth Configuration - Offers a built-in look by fitting almost completely flush with
surrounding cabinetry and blending in with décor
• High-Gloss, Contoured Doors, Sculptured Handles and Top and Bottom Bevels - Offer a
dramatic look and touch of personal style to any kitchen
• Optional Automatic Icemaker - Equipped for a automatic icemaker
• Freshness Center™- Offers maximum convenience by utilizing two humidity-controlled
drawers and 1 full-length drawer for large storage
• BrightSpace™Interior with GE Reveal™Lighting - Cast a natural-looking glow throughout
the refrigerator
• Multi-Level Slide 'n Store™Basket System - Includes three full-extension baskets for
tremendous storage flexibility and keeps contents perfectly in place
• Condiment Bin and Beverage Rack - Provides convenient storage for canned drinks
and condiments
• QuickSpace™Shelf - Slides out of the way to make room for tall items
• Upfront Temperature Controls with Actual Temperature Display & TurboCool™Setting -
Features easy-to-reach, easy-to-read temperature controls and a setting to quickly restore
proper temperature after frequent door openings
• Self-Closing Drawer - Self-closing hinges automatically pull the drawer shut when it's within
one inch of the closed position
• Adjustable Gallon Door Bins - Make room for milk and other gallon-size containers
• NeverClean™Condenser - Condenser coils are encased, so they don't require cleaning in
normal operating environments
• Model PDCF1NBWWW - White on white
• Model PDCF1NBWBB - Black on black
PDCF1NBW
GE Profile™ENERGY STAR® 21.1 Cu. Ft. Bottom-Freezer Drawer Refrigerator
