†Water hook-up fits in back air clearance when calculating
installation depth.
If installed against a wall, allow clearance of 13-15/16" on freezer
side to remove bin.
Clearance required to remove fresh food full-size pan without
disassembling is 18-5/8".
Allow additional space for any necessary leveling adjustments.
"94 SxS Refer
A
Front View
Top View
G
D
C
F
BE
H
Listed by
Underwriters
Laboratories
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Specification Revised 7/10 210296
Dimensions and Installation Information (in inches)
Overall
Dimensions
Height to top of hinge (in.) A72-1/8
Height to top of case (in.) B71-5/8
Case depth without door (in.) C†23-7/8
Case depth less door handle (in.) D†27-1/8
Case depth with door handle (in.) E†29-5/8
Depth with fresh food door open 90° (in.) F†46
Width (in.) G35-3/4
Width with door open 90° inc. door handle (in.) H41-3/8
Air
Clearances
Each side (in.) 1/8
Top (in.) 1
Back (in.) 1
PSCS5RGX
GE Profile™Counter-Depth 24.6 Cu. Ft. Side-By-Side Refrigerator

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Installation Tips to Maximize the Built-In Look
• All wall/floor molding should be removed prior to installation.
• Water recess on rear wall recommended to prevent water
line damage. 48" minimum length, 1/4" diameter water
line tubing recommended.
• When possible, recess both copper water line and electrical
outlet. (See local codes)
• Front and rear leveling legs are adjustable for the built-in look.
(See owner’s manual)
*The rough-in dimensions of 70" for 23 cu. ft. models and 72-
1/2" for 25 cu. ft. models are minimum and measured from the
finished floor to top of opening (or the underside of the overhead
cabinets). For Models with Trim Kit: If frameless style cabinets
are planned for above the refrigerator, you may need to consider
adding a maximum of 1/4" (70-1/4") to height of opening for 23
cu. ft. models and 1/8" (72-5/8") for 25 cu. ft. models to allow for
additional clearance between the cabinet doors and the top of
refrigerator trim when the cabinet doors are in open position.
†Model PSDW3YGX is 71-3/4"
Rough-In Dimensions and Installation Information (in inches)
8' Ceiling
13" to 14"
Cabinet
12"
Soffit
36-1/8"
24-1/2"
Collar Tr im In. w/ceiling
70"*†
23 cu. ft. models
72-1/2"*
25 cu. ft. models
*The rough-in dimensions of 70" for 23 cu. ft. models and 72-1/2" for 25 cu. ft.
models are minimum and measured from the finished floor to top of opening
(or the underside of the overhead cabinets). For Models with Tr im Kit:
If frameless style cabinets are planned for above the refridgerator, you may
need to consider adding a maximum of 1/4" (70-1/4") to height of opening
for 23 cu. ft. models and 1/8" (72-5/8") for 25 cu. ft. models to allow additional
clearance between cabinet doors and top of refridgerator trim when cabinet
doors are in open position.
†Model PSDW3YGX is 71-3/4".
Listed by
Underwriters
Laboratories
Specification Revised 7/10 210296
25"
Counter
Top
ElectricalWater
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
24"
Cabinet
25"
Counter
Top
Electrical Water
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
24"
Cabinet
25"
Counter
Top
ElectricalWater
Trim
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
24"
Cabinet
25"
Counter
Top
Electrical Water
Trim
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
24"
Cabinet
FOR 21 CUBIC FOOT MODELS
FOR 24 CUBIC FOOT MODELS
Fig 2A eps
PSCS5RGX
GE Profile™Counter-Depth 24.6 Cu. Ft. Side-By-Side Refrigerator

Specification Revised 7/10 210296
Features and Benefits
• Counter-depth configuration - Counter-depth configuration makes it possible to have the look of a
built-in without the added expense
• Stainless steel exterior - Stainless steel adds elegance to any kitchen décor
• ClimateKeeper2™system - Electronic controls, multiple electronic sensors and a multi-flow air
system help keep foods fresh longer
• Integrated dispenser with LED lighting and UltraFlow100 - This bright dispenser pours up to 100
ounces of water per minute
• Quick Ice™setting - Speed up your icemaker to keep up with your life
• TurboCool™setting - Restores proper temperature to the refrigerator after frequent door openings
• Integrated Ice™system - Designed to give you more room to store your favorite frozen foods
• Integrated shelf support system - Strong shelf supports add a contemporary look
• Adjustable ClearLook™door bins - Store gallon containers with ease in the door and free up valuable
shelf space
• In-the-door beverage rack - Beverages are easy to grab when you’re on the go
• Adjustable, slide-out spillproof glass shelves - Adjustable shelves are designed to make clean up
quick and easy
• Tilt-out freezer door bins - Even when bins are filled to capacity, items are easy to remove
• FrostGuard™technology - Controlled defrosting keeps frozen foods from feeling the burn
• Premium quiet design - Enjoy the sound of GE’s most advanced sound control system
• Model PSCS5RGXSS - Stainless steel
PSCS5RGXSS
PSCS3RGXSS
PSCS5RGX
