GE 25 Safety guide

ge.com
Refrigerators
Side by Side
200D8074P003 49-60412 11-05 JR
La section française commence à la page 40
La sección en español empieza en la página 74
Safety Instructions . . . . . . . . . . . . . . .2–4
Operating Instructions
Automatic Icemaker . . . . . . . . . . . . . . .11
Care and Cleaning . . . . . . . . . . . . . .13, 14
Crispers and Pans . . . . . . . . . . . . . . . . .10
Ice and Water Dispenser . . . . . . . . .12, 13
Refrigerator Doors . . . . . . . . . . . . . . . . .9
Replacing the Light Bulbs . . . . . . . . . . .15
Shelves and Bins . . . . . . . . . . . . . . . . .7, 8
Temperature Controls . . . . . . . . . . . . . . .5
TurboCool™. . . . . . . . . . . . . . . . . . . . . . .5
Water Filter . . . . . . . . . . . . . . . . . . . . . . .6
Installation Instructions
Installing the Refrigerator . . . . . . . .21–24
Moving the Refrigerator . . . . . . . . .17–20
Preparing to Install
the Refrigerator . . . . . . . . . . . . . . . . . . .16
Water Line Installation . . . . . . . . . .25–27
Troubleshooting Tips . . . . . . . . . . .28–31
Normal Operating Sounds . . . . . . . . . .28
Consumer Support
Consumer Support . . . . . . . . .Back Cover
Performance Data Sheet . . . . . . . . . . . .32
Product Registration (U.S.) . . . . . . .33, 34
Product Registration (Canadian) . . .35, 36
State of California Water
Treatment Device Certificate . . . . . . . . .37
Warranty (Canadian) . . . . . . . . . . . . . . .38
Warranty (U.S.) . . . . . . . . . . . . . . . . . . .39
Réfrigérateurs
Côte à Côte
Refrigeradores
Lado a Lado
Models 23, 25 and 27
Write the model and serial numbers here:
Model # __________________________
Serial # __________________________
Find these numbers on a label inside
the refrigerator compartment at the
top on the right side.
Owner’s Manual
and Installation
Manuel d’utilisation
et d’installation
Manual del propietario
e instalación

Consumer Support Troubleshooting Tips Operating Instructions Safety InstructionsInstallation Instructions
2
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
Use this appliance only for its intended purpose as described in this Owner’s Manual.
SAFETY PRECAUTIONS
When using electrical appliances, basic safety precautions should be followed, including the following:
■
■This refrigerator must be properly installed
and located in accordance with the Installation
Instructions before it is used.
■
■Do not allow children to climb, stand or hang
on the shelves in the refrigerator. They could
damage the refrigerator and seriously injure
themselves.
■
■Do not touch the cold surfaces in the freezer
compartment when hands are damp or wet. Skin
may stick to these extremely cold surfaces.
■
■Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
■
■In refrigerators with automatic icemakers,
avoid contact with the moving parts of the
ejector mechanism, or with the heating element
located on the bottom of the icemaker. Do
not place fingers or hands on the automatic
icemaking mechanism while the refrigerator
is plugged in.
■
■Keep fingers out of the “pinch point” areas;
clearances between the doors and between
the doors and cabinet are necessarily small.
Be careful closing doors when children are
in the area.
■
■Unplug the refrigerator before cleaning and
making repairs.
NOTE: We strongly recommend that any servicing be
performed by a qualified individual.
■
■Setting either or both controls to 0 (off) does not
remove power to the light circuit.
■
■Do not refreeze frozen foods which have
thawed completely.

Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions Installation Instructions
ge.com
PROPER DISPOSAL OF THE REFRIGERATOR
Child entrapment and suffocation are not problems
of the past. Junked or abandoned refrigerators are
still dangerous…even if they will sit for “just a few
days.” If you are getting rid of your old refrigerator,
please follow the instructions below to help prevent
accidents.
Before You Throw Away Your Old Refrigerator
or Freezer:
■Take off the doors.
■Leave the shelves in place so that children may
not easily climb inside.
Refrigerants
All refrigeration products contain refrigerants,
which under federal law must be removed prior
to product disposal. If you are getting rid of an
old refrigeration product, check with the
company handling the disposal about what
to do.
USE OF EXTENSION CORDS
Because of potential safety hazards under certain conditions, we strongly recommend against the use
of an extension cord.
However, if you must use an extension cord, it is absolutely necessary that it be a UL-listed (in the United
States) or a CSA-listed (in Canada), 3-wire grounding type appliance extension cord having a grounding
type plug and outlet and that the electrical rating of the cord be 15 amperes (minimum) and 120 volts.
DANGER! RISK OF CHILD ENTRAPMENT
3

4
Consumer Support Troubleshooting Tips Operating Instructions Safety InstructionsInstallation Instructions
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove the third (ground) prong from the power cord. For
personal safety, this appliance must be properly grounded.
The power cord of this appliance is equipped with
a 3-prong (grounding) plug which mates with
a standard 3-prong (grounding) wall outlet to
minimize the possibility of electric shock hazard
from this appliance.
Have the wall outlet and circuit checked by a
qualified electrician to make sure the outlet is
properly grounded.
If the outlet is a standard 2-prong outlet, it is
your personal responsibility and obligation to
have it replaced with a properly grounded
3-prong wall outlet.
The refrigerator should always be plugged into its
own individual electrical outlet which has a voltage
rating that matches the rating plate.
This provides the best performance and also
prevents overloading house wiring circuits which
could cause a fire hazard from overheated wires.
Never unplug your refrigerator by pulling on
the power cord. Always grip plug firmly and pull
straight out from the outlet.
Repair or replace immediately all power cords that
have become frayed or otherwise damaged. Do not
use a cord that shows cracks or abrasion damage
along its length or at either end.
When moving the refrigerator away from the
wall, be careful not to roll over or damage the
power cord.
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS

TurboCool rapidly cools the refrigerator
compartment in order to more quickly
cool foods. Use TurboCool when adding a
large amount of food to the refrigerator
compartment, putting away foods after they
have been sitting out at room temperature
or when putting away warm leftovers. It can
also be used if the refrigerator has been
without power for an extended period.
Once activated, the compressor will turn on
immediately and the fans will cycle on and
off at high speed as needed for eight hours.
The compressor will continue to run until
the refrigerator compartment cools to
approximately 34°F (1°C), then it will cycle
on and off to maintain this setting. After 8
hours, or if TurboCool is pressed again, the
refrigerator compartment will return to
the original setting.
How to Use
Press TurboCool. The TurboCool
indicator light will come on; however,
the refrigerator temperature display
will still show the current setting.
After TurboCool is complete, the TurboCool
indicator light will go out.
NOTES: The refrigerator temperature
cannot be changed during
TurboCool.
The freezer temperature is not
affected during TurboCool.
When opening the refrigerator
door during TurboCool, the fans
will continue to run if they have
cycled on.
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions Installation Instructions
5
About the temperature controls. ge.com
WARMERCOLDER
ADJUST REFRIGERATOR TEMP
9 IS COLDEST
WARMERCOLDER
ADJUST FREEZER TEMP
9 IS COLDEST
Initially, set the refrigerator control at 5and the freezer control at 5and allow 12–24
hours for the temperature to stabilize.
Several adjustments may be required. Adjust the controls one increment at a time, and
allow 12 hours after each adjustment for the refrigerator to reach the temperature you
have set.
Setting the controls to 0stops cooling in both the refrigerator and freezer compartments
but does not shut off electrical power to the refrigerator. On some models, only the
refrigerator control has a 0setting.
Touch pad controls
•Setting either control at 0will automatically set the other control at 0. The zeros will
blink until you set the controls.
•If both controls are set at 0and either COLDER pad is pressed, the controls will
automatically reset to 5.
Control settings will vary based on personal preferences, usage and operating
conditions and may require more than one adjustment.
NOTE: On some models, the refrigerator is shipped with protective film covering the temperature
controls. If this film was not removed during installation, remove it now.
About TurboCool.™(on some models)
How it Works

6
Consumer Support Troubleshooting Tips Operating Instructions Safety InstructionsInstallation Instructions
About the water filter (on some models).
On some models
Water Filter Cartridge
The water filter cartridge is located in the back upper right
corner of the refrigerator compartment.
When to Replace the Filter on Models With a
Replacement Indicator Light
There is a replacement indicator light for the water filter
cartridge on the dispenser. This light will turn orange to tell
you that you need to replace the filter soon.
The filter cartridge should be replaced when the
replacement indicator light turns red or if the flow of water
to the dispenser or icemaker decreases.
When to Replace the Filter on Models Without a
Replacement Indicator Light
The filter cartridge should be replaced every six months
or earlier if the flow of water to the water dispenser or
icemaker decreases.
Removing the Filter Cartridge
If you are replacing the cartridge, first remove the old one
by slowly turning it to the left. Do not pull down on the
cartridge. A small amount of water may drip down.
Installing the Filter Cartridge
If you are replacing a SmartWater cartridge with an
adapter, the adapter must be removed before installing
the cartridge. To remove the adapter, turn it to the left
about 1/4 turn.
If you are replacing a Water by Culligan cartridge,
leave the adapter in place. This adapter will stay in the
refrigerator when you replace future cartridges.
On models without a replacement indicator light,
apply the month and year sticker to the new cartridge
to remind you to replace the filter in six months.
Fill the replacement cartridge with water from the tap
to allow for better flow from the dispenser immediately
after installation.
Line up the arrow on the cartridge and the cartridge
holder. Place the top of the new cartridge up inside the
holder. Do not push it up into the holder.
Slowly turn it to the right until the filter cartridge stops.
DO NOT OVERTIGHTEN. As you turn the cartridge, it will
automatically raise itself into position. The cartridge will
move about 1/2 turn.
Run water from the dispenser for 3 minutes (about 1-1/2
gallons) to clear the system and prevent sputtering.
Press and hold the RESET WATER FILTER pad (on some
models) on the dispenser for 3 seconds.
NOTE: A newly-installed water filter cartridge may cause
water to spurt from the dispenser.
Filter Bypass Plug
You must use the filter bypass plug when a replacement
filter cartridge is not available. The dispenser and the
icemaker will not operate without the filter or filter
bypass plug.
To use the filter bypass plug on Water by Culligan models,
you must first remove the filter adapter from the cartridge
holder by turning it to the left.
If you have questions—visit our Website
at ge.com,
or call 1.800.GE.CARES (1.800.432.2737).
Replacement filters:
To order additional filter cartridges in the United States,
visit our Website at ge.com, or call GE Parts and Accessories,
800.626.2002.
MWF
Suggested Retail $38.95–47.95
Customers in Canada should consult the yellow pages for
the nearest Camco Service Center.
(appearance may vary)
Cartridge
Holder
Filter
Bypass
Plug
Filter
Bypass
Plug
SmartWater Water by Culligan
With adapter Without adapter

7
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions Installation Instructions
About the shelves and bins. ge.com
Refrigerator Door Bins and Freezer Door Tilt-Out Bins
Large Bins
The larger refrigerator door bins and
freezer tilt-out door bins are adjustable.
To remove: Lift the front of the bin straight
up, then lift up and out.
To replace or relocate: Engage the back side
of the bin in the molded supports of the
door. Then push down on the front of the
bin. Bin will lock in place.
Small Bins
To remove: Lift the front of the bin straight
up then out.
To replace: Position the bin above the
rectangular molded supports on the door.
Then slide the bin down onto the support
to lock it in place.
The snugger helps prevent tipping, spilling
or sliding of small items stored on the door
shelf. Place a finger on either side of the
snugger near the rear and move it back
and forth to fit your needs.
CAUTION: On
models with an ice
chute inside the top
freezer door bin, be
careful when placing
items in the bin.
Make sure that
items do not block
or fall into the ice
chute.
Not all features are on all models.
Refrigerator bin
Freezer tilt-out bin
Snugger
Freezer bin
Slide-Out Spillproof Shelf
The slide-out spillproof shelf allows you
to reach items stored behind others. The
special edges are designed to help prevent
spills from dripping to lower shelves.
To remove:
Slide the shelf out until it reaches the stop,
then press down on the tab and slide the
shelf straight out.
Press tab and pull shelf
forward to remove
To replace or relocate:
Line the shelf up with the supports and
slide it into place. The shelf can be
repositioned when the door is at 90° or
more. To reposition the shelf, slide the shelf
past the stops and angle downward. Slide
shelf down to the desired position, line up
with the supports and slide into place.
Make sure you push the shelves all the way back
in before you close the door.
Do not block

8
Consumer Support Troubleshooting Tips Operating Instructions Safety InstructionsInstallation Instructions
About the shelves and bins.
Not all features are on all models.
QuickSpace™Shelf (on some models)
This shelf splits in half and slides under
itself for storage of tall items on the shelf
below.
This shelf can be removed and replaced
or relocated just like Slide-Out Spillproof
Shelves.
On some models, this shelf can not be used
in the lowest position.
Slide-Out Freezer Shelves
To remove, slide out to the stop position,
lift the front past the stop position, and
slide out from rib.
Make sure you push the shelves all the way back
in before you close the door.
Freezer Baskets
To remove, slide out to the stop position,
lift the front past the stop position, and
slide out.
Make sure you push the baskets all the way back
in before you close the door.
Fixed Freezer Shelves
To remove, lift the shelf up at the left side
and then bring the shelf out.
NOTE FOR DISPENSER MODELS: In order
to take full advantage of the tilt-out ice bin
(on some models), only store items on the
shelf below the ice bin that are no taller
than the lowest point on the bin.

9
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions Installation Instructions
About the refrigerator doors. ge.com
Refrigerator Doors
The refrigerator doors may feel different
than the ones you are used to. The
special door opening/closing feature
makes sure the doors close all the way
and are securely sealed.
When opening and closing the door you
will notice a stop position. If the door is
opened past this stop point, the door will
remain open to allow you to load and
unload food more easily. When the door
is only partially open, it will automatically
close.
The resistance you feel at the stop
position will be reduced as the door
is loaded with food.
When the door is only partially open,
it will automatically close.
Beyond this stop the door will
stay open.
Door Alignment
If doors are uneven, adjust the
refrigerator door.
Using a 7/16″socket wrench, turn
the door adjusting screw to the right
to raise the door; to the left, to lower
it. (A nylon plug, imbedded in the
threads of the pin, prevents the pin
from turning unless a wrench is
used.)
After one or two turns of the
wrench, open and close the
refrigerator door and check the
alignment at the top of the doors.
To remove the base
grille, open the doors,
remove the screw at
each end of the base
grille and then pull
the grille straight out.
7/16″Socket Wrench
Raise

About crisper removal.
Not all features are on all models.
Crisper Removal
Crispers can easily be removed by pulling
the drawer straight out and lifting the
drawer up and over the stop location.
If the door prevents you from taking out
the drawers, first try to remove the door
bins. If this does not offer enough
clearance, the refrigerator will need to
be rolled forward until the door opens
enough to slide the drawers out. In some
cases, when you roll the refrigerator out,
you will need to move the refrigerator
to the left or right as you roll it out.
Consumer Support Troubleshooting Tips Operating Instructions Safety InstructionsInstallation Instructions
10
About the crispers and pans.
Not all features are on all models.
Fruit and Vegetable Crispers
Excess water that may accumulate in the
bottom of the drawers should be wiped dry.
Adjustable Humidity Crispers
Slide the control all the way to the HI setting
to provide high humidity recommended for
most vegetables.
Slide the control all the way to the LO
setting to provide lower humidity levels
recommended for most fruits.
HI LO

Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions Installation Instructions
11
About the automatic icemaker. ge.com
Automatic Icemaker
The icemaker will produce seven cubes
per cycle—approximately 100–130 cubes
in a 24-hour period, depending on freezer
compartment temperature, room
temperature, number of door openings
and other use conditions.
See below for how to access ice and reach
the power switch on dispenser models.
If the refrigerator is operated before the
water connection is made to the icemaker,
set the power switch in the O (off) position.
When the refrigerator has been connected
to the water supply, set the power switch to
the l (on) position.
The icemaker will fill with water when it
cools to 15°F (–10°C). A newly installed
refrigerator may take 12 to 24 hours to begin
making ice cubes.
You will hear a buzzing sound each time
the icemaker fills with water.
Throw away the first few batches of ice to
allow the water line to clear.
Be sure nothing interferes with the sweep
of the feeler arm.
When the bin fills to the level of the feeler
arm, the icemaker will stop producing
ice. It is normal for several cubes to be
joined together.
If ice is not used frequently, old ice cubes
will become cloudy, taste stale and shrink.
NOTE: In homes with lower-than-average water
pressure, you may hear the icemaker cycle multiple
times when making one batch of ice.
A newly installed refrigerator may take 12 to 24 hours to begin making ice.
Lift the bin, then pull it
forward until the bin stops.
Icemaker
Feeler Arm
Power
Switch
Green
Power Light
Lower the bin to access ice
or reach the power switch.
NOTE: In order to take full advantage
of the tilt-out ice bin, only store items
on the shelf below the ice bin that
are no taller than the lowest point
on the bin.
Models without a shelf
above the ice bin
To access ice and reach the
icemaker power switch:
Accessing Ice and Reaching the
Power Switch on Dispenser Models
There are two types of ice storage bins on
dispenser models. One has a shelf above
the bin, the other does not.
Special note about dispenser models
without a shelf above the ice bin:
■These models have a tilt-out ice bin.
The bin can be tilted out as shown in
the illustrations, and it will hold itself
up while you take ice out or turn the
icemaker power switch on and off.
Be sure to put the bin back in place
before closing the door.
■To restore your ice level from an empty
bucket stage, the following steps are
recommended:
12 hours after the first batch of ice
has fallen into the bin, dispense
3 to 4 cubes.
After an additional 6 hours, dispense
3 to 4 cubes again.
These steps will restore your ice level
in the shortest amount of time.
To access ice, pull the bin forward.
To reach the power switch, pull the
shelf straight out. Always be sure to
replace the shelf.
Models with a shelf
above the ice bin
Shelf
Ice Bin
Shelf
Ice Bin

12
Consumer Support Troubleshooting Tips Operating Instructions Safety InstructionsInstallation Instructions
About the ice and water dispenser (on some models).
To Use the Dispenser
Select CUBED ICE , CRUSHED ICE
or WATER .
Press the glass gently against the top of the
dispenser cradle.
The spill shelf is not self-draining. To
reduce water spotting, the shelf and its
grille should be cleaned regularly.
If no water is dispensed when the refrigerator is
first installed, there may be air in the water line
system. Press the dispenser arm for at least two
minutes to remove trapped air from the water
line and to fill the water system. To flush out
impurities in the water line, throw away the first
six glassfuls of water.
CAUTION: Never put fingers or any other
objects into the ice crusher discharge opening.
Locking the Dispenser
Press the LOCK CONTROL
pad for 3 seconds to
lock the dispenser and
control panel. To
unlock, press and
hold the pad again
for 3 seconds.
Dispenser Light
This pad turns the night
light in the dispenser on
and off. The light also
comes on when the
dispenser cradle is
pressed. If this light
burns out, it should be
replaced with a 6 watt
12V maximum bulb.
Quick Ice (on some models)
When you need ice
in a hurry, press this
pad to speed up ice
production. This will
increase ice production
for the following
48 hours or until you
press the pad again.
Door Alarm
To set the alarm,
press this pad until the
indicator light comes
on. This alarm will
sound if either door
is open for more than
3 minutes. The light
goes out and the
beeping stops when
you close the door.
Spill Shelf
Important Facts About Your Dispenser
■Do not add ice from trays or bags to
the storage drawer. It may not crush or
dispense well.
■Avoid overfilling glass with ice and use of
narrow glasses. Backed-up ice can jam the
chute or cause the door in the chute to
freeze shut. If ice is blocking the chute,
poke it through with a wooden spoon.
■Beverages and foods should not be
quick-chilled in the ice storage drawer.
Cans, bottles or food packages in the
storage drawer may cause the icemaker
or auger to jam.
■To keep dispensed ice from missing
the glass, put the glass close to, but not
touching, the dispenser opening.
■Some crushed ice may be dispensed even
though you selected CUBED ICE. This
happens occasionally when a few cubes
accidentally get directed to the crusher.
■After crushed ice is dispensed, some
water may drip from the chute.
■Sometimes a small mound of snow will
form on the door in the ice chute. This
condition is normal and usually occurs
when you have dispensed crushed ice
repeatedly. The snow will eventually
evaporate.

Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions Installation Instructions
Care and cleaning of the refrigerator.
Cleaning the Outside
The dispenser drip area (on some models),
beneath the grille, should be wiped dry. Water
left in this area may leave deposits. Remove
the deposits by adding undiluted vinegar to
the well. Soak until the deposits disappear
or become loose enough to rinse away.
The dispenser cradle (on some models).
Before cleaning, lock the dispenser by
pressing and holding the LOCK CONTROL
pad for 3 seconds. Clean with warm
water and baking soda solution – about
a tablespoon (15 ml) of baking soda to
a quart (1 liter) of water. Rinse thoroughly
and wipe dry.
The door handles and trim. Clean with
a cloth dampened with soapy water.
Dry with a soft cloth.
Keep the outside clean. Wipe with a clean
cloth lightly dampened with kitchen
appliance wax or mild liquid dish detergent.
Dry and polish with a clean, soft cloth.
Do not wipe the refrigerator with a soiled dish
cloth or wet towel. These may leave a residue
that can erode the paint. Do not use scouring
pads, powdered cleaners, bleach or cleaners
containing bleach because these products can
scratch and weaken the paint finish.
Cleaning the Inside
To help prevent odors, leave an open box of
baking soda in the fresh food and freezer
compartments.
Unplug the refrigerator before cleaning. If this
is not practical, wring excess moisture out
of sponge or cloth when cleaning around
switches, lights or controls.
Use warm water and baking soda solution –
about a tablespoon (15 ml) of baking soda
to a quart (1 liter) of water. This both
cleans and neutralizes odors. Rinse and
wipe dry.
Use of any cleaning solution other than that
which is recommended, especially those that
contain petroleum distillates, can crack or
damage the interior of the refrigerator.
Avoid cleaning cold glass shelves with hot water
because the extreme temperature difference
may cause them to break. Handle glass shelves
carefully. Bumping tempered glass can cause
it to shatter.
Do not wash any plastic refrigerator parts in the
dishwasher.
Dispenser drip area.
ge.com
Lift the bin, then pull it
forward until the bin stops.
Lift and pull forward again
to remove the bin.
Models without a shelf
above the ice bin
To remove:
Models with a shelf
above the ice bin
To remove:
Removing and Replacing the Ice
Storage Bin on Dispenser Models
There are two types of ice storage bins on
dispenser models. One has a shelf above
the bin, the other does not.
Always set the icemaker power switch to the
O (off) position before removing the ice bin.
When replacing either type of ice bin:
Always be sure to press it firmly into place.
If it does not go all the way back, remove it
and rotate the drive mechanism 1/4 turn.
Then push the bin back again.
Pull the bin straight out, then lift past
the stop position.
Rotate
Drive
Mechanism
13

For long vacations or absences, remove
food and unplug the refrigerator. Clean
the interior with a baking soda solution
of one tablespoon (15 ml) of baking soda
to one quart (1 liter) of water. Leave the
doors open.
Set the icemaker power switch to the
O (off) position and shut off the water
supply to the refrigerator.
If the temperature can drop below
freezing, have a qualified servicer drain
the water supply system (on some models)
to prevent serious property damage due
to flooding.
14
Consumer Support Troubleshooting Tips Operating Instructions Safety InstructionsInstallation Instructions
Care and cleaning of the refrigerator.
Behind the Refrigerator
Be careful when moving the refrigerator
away from the wall. All types of floor
coverings can be damaged, particularly
cushioned coverings and those with
embossed surfaces.
Pull the refrigerator straight out and return
it to position by pushing it straight in.
Moving the refrigerator in a side direction
may result in damage to the floor covering
or refrigerator.
When pushing the refrigerator back, make sure
you don’t roll over the power cord or icemaker
supply line (on some models).
Preparing for Vacation
Preparing to Move
Secure all loose items such as shelves and
drawers by taping them securely in place
to prevent damage.
When using a hand truck to move the
refrigerator, do not rest the front or back
of the refrigerator against the hand truck.
This could damage the refrigerator. Handle
only from the sides of the refrigerator.
Be sure the refrigerator stays in an upright
position during moving.

Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions Installation Instructions
Replacing the light bulbs. ge.com
Setting either or both controls to 0does not remove power to the light circuit.
Refrigerator Compartment—Upper Light
Unplug the refrigerator.
The bulbs are located at the top of the
compartment, inside the light shield.
Remove the screw at the front of the
light shield.
To remove the light shield, press in on
the tabs on the sides of the shield and
slide forward and out.
After replacing the bulb with an
appliance bulb of the same or lower
wattage, replace the light shield and
screw. When replacing the light shield,
make sure that the tabs at the back of
the shield fit into the slots at the back
of the light shield housing.
Plug the refrigerator back in.
Refrigerator Compartment—Lower Light
This light is located above the top drawer.
Unplug the refrigerator.
Lift the light shield up and pull it out.
After replacing the bulb with an
appliance bulb of the same or lower
wattage, replace the shield.
Plug the refrigerator back in.
Freezer Compartment
Unplug the refrigerator.
Remove the shelf just above the light
shield. (The shelf will be easier to
remove if it is emptied first.) Remove
the screw at the top of the light shield.
To remove the light shield, press in on
the sides, and lift up and out.
Replace the bulb with an appliance
bulb of the same or lower wattage,
and reinstall the light shield. When
reinstalling the light shield, make
sure the top tabs snap securely
into place. Replace the screw.
Reinstall the shelf and plug the
refrigerator back in.
15
Dispenser
Unplug the refrigerator.
The bulb is located on the dispenser
under the control panel.
Remove the light bulb by turning
it counterclockwise.
Replace the bulb with a bulb of the
same size and wattage.
Plug the refrigerator back in.
Tabs

16
BEFORE YOU BEGIN
Read these instructions completely
and carefully.
•IMPORTANT —Save these
instructions for local inspector’s use.
•IMPORTANT —Observe all
governing codes and ordinances.
•Note to Installer – Be sure to leave these
instructions with the Consumer.
•Note to Consumer – Keep these
instructions for future reference.
•Skill level – Installation of this appliance
requires basic mechanical skills.
•Completion time – Refrigerator Installation
30 minutes
Water Line Installation
30 minutes
•Proper installation is the responsibility of
the installer.
•Product failure due to improper installation
is not covered under the Warranty.
If the refrigerator has already been installed,
remove the base grille (see Step 2 in Moving
the Refrigerator), then skip to Step 5 in
Installing the Refrigerator.
Questions? Call 800.GE.CARES (800.432.2737) or Visit our Website at: ge.com
In Canada, call 1.800.361.3400 or Visit our Website at: www.geappliances.ca
Installation Refrigerator
Instructions Models 25 & 27
If the refrigerator has an icemaker, it will have
to be connected to a cold water line. A GE
water supply kit (containing tubing, shutoff
valve, fittings and instructions) is available
at extra cost from your dealer, by visiting
our Website at ge.com (in Canada at
www.geappliances.ca) or from Parts and
Accessories, 800.626.2002 (in Canada
1.888.261.3055).
PREPARATION
WATER SUPPLY TO THE ICEMAKER
TOOLS YOU WILL NEED
Phillips Head Screwdriver
3/8″and 5/16″Socket 1/2″and 7/16″Wrench
Plastic Putty Knife

17
Installation Instructions
LOADING THE RERIGERATOR
ONTO A HAND TRUCK
Leave all tape and door pads on doors
until the refrigerator is in its final location.
To move the refrigerator, use a padded
hand truck. Center the refrigerator on the
hand truck and secure the strap around
the refrigerator. DO NOT OVERTIGHTEN
THE STRAP.
1
REMOVE THE BASE GRILLE
Remove the grille by removing the two
Phillips head screws.
2
If the refrigerator must go through
any entrance that is less than 38″
wide, the doors must be removed.
Proceed to Step 3.
DO NOT remove the handles.
If all entrances are more than
38″wide, skip to Installing
the Refrigerator.
DISCONNECT THE WATER
COUPLING (on some models)
If the refrigerator has a water dispenser,
there is a water line from the cabinet into
the bottom hinge on the freezer door that
must be disconnected.
To disconnect, push in on the white collar
of the coupling and pull out the tubing.
3
White collar
Bottom
freezer
hinge
MOVING THE REFRIGERATOR

18
Installation Instructions
DISCONNECT THE POWER
COUPLING (on some models)
If the refrigerator has a water dispenser,
there is a power line (harness) from the
cabinet into the bottom hinge on the
freezer door that must be disconnected.
To disconnect, pull apart at the coupling.
4
Bottom
freezer
hinge
DISCONNECT THE ELECTRICAL
CONNECTORS (on some models)
If the refrigerator has a refreshment
center, there are electrical connectors
(harnesses) from the cabinet into the
bottom hinge on the refrigerator door
that must be disconnected.
To disconnect, pull apart each connector.
5
Bottom
refrigerator
hinge
CLOSE THE FREEZER AND
REFRIGERATOR DOORS
6
REMOVE THE FREEZER DOOR
Remove the freezer door top hinge cover
by either squeezing it and pulling it up or
by prying it off with a plastic putty knife.
Remove the two 5/16” hex head screws,
then lift the hinge straight up to free the
hinge pin.
Open the freezer door to 90.°
7
A
C
B
5/16” Hex Head
90°
MOVING THE REFRIGERATOR (CONT.)

19
Installation Instructions
REMOVE THE
FREEZER DOOR (cont.)
As one person slowly lifts the freezer door
up and off the bottom hinge, the second
person should carefully guide the water
line and power line (harness) through the
bottom hinge.
Set the door on a non-scratching surface
with the inside up.
7
D
E
90°
REMOVE THE
REFRIGERATOR DOOR
Remove the refrigerator door top hinge
cover by either squeezing it and pulling
it up or by prying it off with a plastic
putty knife.
8
A
REMOVE THE
REFRIGERATOR DOOR (cont.)
Remove the two 5/16” hex head screws,
then lift the hinge straight up to free the
hinge pin.
Open the refrigerator door to 90.°
8
B
C
5/16” Hex Head
90°

20
Installation Instructions
REMOVE THE
REFRIGERATOR DOOR (cont.)
Lift the refrigerator door up and off the
bottom hinge.
If the refrigerator has a refreshment
center, one person should slowly lift the
door up and off the bottom hinge and the
second person should carefully guide the
electrical lines (harnesses) through the
bottom hinge.
Set the door on a non-scratching surface
with the inside up.
8
D
E
90°
REPLACING THE DOORS
To replace the doors, simply reverse
steps 3 through 8.
However, please note the following:
•When lowering the doors onto the
bottom hinges, make sure the second
person carefully guides the tube and
harnesses through the holes in the
hinges.
•When connecting the water line, make
sure you insert the tubing all the way
to the mark.
•Do not pinch the tubing and harnesses
when placing the doors on the bottom
hinges.
•When connecting the power line and
the electrical lines (refreshment center
models only), be sure that the
connectors are seated together fully.
9
Mark
MOVING THE REFRIGERATOR (CONT.)
Refreshment Center Models only
