GE Profile PSDS3YGXSS Manual

"94 SxS Refer
A
Front View
Top View
G
D
C
F
BE
H
Listed by
Underwriters
Laboratories
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Specification Created 2/08 210204
Dimensions and Installation Information (in inches)
PSDS5YGX
GE Profile™Counter-Depth24.6 Cu. Ft. Side-By-Side Refrigerator
†Water hook-up fits in back air clearance when calculating
installation depth.
If installed against a wall, allow clearance of 13-15/16" on freezer
side to remove bin.
Clearance required to remove fresh food full-size pan without
disassembling is 18-5/8".
Allow additional space for any necessary leveling adjustments.
Overall
Dimensions
Height to top of hinge (in.) A 72-1/8
Height to top of case (in.) B 71-5/8
Case depth without door (in.) C†23-7/8
Case depth less door handle (in.) D†27-1/8
Case depth with door handle (in.) E†29-5/8
Depth with fresh food door open 90° (in.) F†46
Width (in.) G 35-3/4
Width with door open 90° inc. door handle (in.) H 41-3/8
Air
Clearances
Each side (in.) 1/8
Top (in.) 1
Back (in.) 1/2

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
8' Ceiling
13" to 14"
Cabinet
12"
Soffit
36-1/8"
24-1/2"
Collar Trim In. w/ceiling
70"*†
23 cu. ft. models
72-1/2"*
25 cu. ft. models
*The rough-in dimensions of 70" for 23 cu. ft. models and 72-1/2" for 25 cu. ft.
models are minimum and measured from the finished floor to top of opening
(or the underside of the overhead cabinets). For Models with Trim Kit:
If frameless style cabinets are planned for above the refridgerator, you may
need to consider adding a maximum of 1/4" (70-1/4") to height of opening
for 23 cu. ft. models and 1/8" (72-5/8") for 25 cu. ft. models to allow additional
clearance between cabinet doors and top of refridgerator trim when cabinet
doors are in open position.
†Model PSDW3YGX is 71-3/4".
Listed by
Underwriters
Laboratories
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
Specification Created 2/08 210204
25"
Counter
Top
ElectricalWater
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
24"
Cabinet
25"
Counter
Top
Electrical Water
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
24"
Cabinet
25"
Counter
Top
ElectricalWater
Trim
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
24"
Cabinet
25"
Counter
Top
Electrical Water
Trim
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
24"
Cabinet
FOR 21 CUBIC FOOT MODELS
FOR 24 CUBIC FOOT MODELS
Fig 2A eps
PSDS5YGX
GE Profile™Counter-Depth24.6 Cu. Ft. Side-By-Side Refrigerator
Rough-In Dimensions and Installation Information (in inches)
Installation Tips to Maximize the Built-In Look
• All wall/floor molding should be removed prior to installation.
• Water recess on rear wall recommended to prevent water
line damage. 48" minimum length, 1/4" diameter water
line tubing recommended.
• When possible, recess both copper water line and electrical
outlet. (See local codes)
• Front and rear leveling legs are adjustable for the built-in look.
(See owner’s manual)
*The rough-in dimensions of 70" for 23 cu. ft. models and 72-
1/2" for 25 cu. ft. models are minimum and measured from the
finished floor to top of opening (or the underside of the overhead
cabinets). For Models with Trim Kit: If frameless style cabinets
are planned for above the refrigerator, you may need to consider
adding a maximum of 1/4" (70-1/4") to height of opening for 23
cu. ft. models and 1/8" (72-5/8") for 25 cu. ft. models to allow for
additional clearance between the cabinet doors and the top of
refrigerator trim when the cabinet doors are in open position.
† Model PSDW3YGX is 71-3/4"

As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
Specification Created 2/08 210204
Features and Benefits
• Counter-Depth Design - Offers a built-in look without the built-in expense
• Stainless Steel - Provides stainless steel doors and side panels for a truly dramatic look
• ClimateKeeper2™System - Keeps food garden fresh longer, while protecting ice from odor transfer, with
its unique dual-evaporator system
• LED Lighting - Casts a clean, beautiful light throughout the fresh food area of the refrigerator
• Color LCD Controls with Touch Screen - Makes it easy to control all the functions of the refrigerator with
just a touch
• Integrated Dispenser with LED Lighting, PreciseFill & UltraFlow100 - Illuminates the dispenser and pours
water in accurate increments or up to 100 ounces per minute
• QuickFreeze Setting - Provides faster, fresher freezing to maintain the flavor and quality of meats
• Electronic Beverage Center - Keeps beverages and treats icy cold and easily accessible
• CustomCool™Technology - Chills in minutes, thaws in hours and keeps foods fresher, longer
• Slide 'n Store™Freezer Basket - Offers easy access and flexible storage
• Quick Ice™Option - Makes ice up to 50% faster than normal settings-ideal for entertaining
• TurboCool™Setting - Cools the refrigerator quickly after frequent door openings
• Integrated Ice™System - Frees up valuable freezer space; It tilts down, providing easy access to bulk ice
• Tilt-Out Freezer Door Bins - Move forward for convenient access
• Integrated Shelf Support System - Provides strong, yet flexible support
• Model PSDS5YGXSS - Stainless steel
PSDS5YGXSS
PSDS3YGXSS
HOME
HELP
WATER
CRUSHED
LOCK CUBED
Hold3for Seconds
SELECTAMOUNT
BACK ENTER
NEWSETTING
SELECTTYPE
2CUPS
PSDS5YGX
GE Profile™Counter-Depth24.6 Cu. Ft. Side-By-Side Refrigerator
*
