GE Profile PSDW3YGXSS User manual

Listed by
Underwriters
Laboratories
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Specification Revised 5/08 210206
Overall
Dimensions
Height to top of hinge (in.) A69-5/8*
Height to top of case (in.) B68-3/4
Case depth without door (in.) C†24-3/8
Case depth less door handle (in.) D†27-5/8
Case depth with door handle (in.) E†30-1/4
Depth with fresh food door open 90° (in.) F†46
Width (in.) G36
Width with door open 90° inc. door handle (in.) H41-3/8
Air
Clearances
Each side (in.) 1/8
Top (in.) 1
Back (in.) 1
PSDW3YGX
GE Profile™Counter-Depth 23.2 Cu. Ft. Stainless-Wrapped Side-by-Side Refrigerator
*When cap is removed: 69 1/4"
†Water hook-up fits in back air clearance when calculating
installation depth.
If installed against a wall, allow clearance of 13-15/16" on freezer
side to remove bin.
Clearance required to remove fresh food full-size pan without
disassembling is 18-5/8".
Allow additional space for any necessary leveling adjustments.
"94 SxS Refer
A
Front View
Top View
G
D
C
F
BE
H
Dimensions and Installation Information (in inches)

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Listed by
Underwriters
Laboratories
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
Specification Revised 5/08 210206
To Remove Top Caps and Doors on PSDW3YGX
Step 1: the refrigerator. Remove two screws, one on each side at the rear of the top
cap. Lift off and remove top cap.
Step 2: Open both doors. Remove one screw on each side of the toekick. Pull forward
to remove toekick.
Step 3: On the freezer door, disconnect water line coupler by pushing against the collar
on the left side. Disconnect wire harness.
Step 4: Use a Torx T-20 screwdriver to remove 2 screws holding the top hinge. Carefully
remove hinge while supporting door. Lift door up and off bottom hinge. Remove fresh
food door in the same manner. Note: Do not remove bottom hinges! Door alignment
will be difficult if bottom hinges are removed.
Step 5: Place refrigerator onto a hand truck, upright and against one side.
Move refrigerator to the installation location.
Step 6: Carefully lower doors onto bottom hinges. Be sure to route the tubing and
electrical connector through the bottom hinge. Reinstall top hinges.
Step 7: Place cap over the top of the refrigerator. Reinstall the original screws in the top
and back of the cap.
Step 8: Reconnect the wiring harness and waterline.
Water Line Coupler
1.
366-15A
Hinge Screws
Wire Harness
Toekick Screw
4.
3.
2.
PSDW3YGX
GE Profile™Counter-Depth 23.2 Cu. Ft. Stainless-Wrapped Side-by-Side Refrigerator

As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
PSFW3YGXSS
HOME
HELP
WATER
CRUSHED
LOCK CUBED
Hold3for Seconds
SELECTAMOUNT
BACK ENTER
NEWSETTING
SELECTTYPE
2CUPS
Specification Revised 5/08 210206
Features and Benefits
• Counter-Depth Design - Offers a built-in look without the built-in expense
• Stainless Steel Exterior - Convey a look of utmost polish and sophistication
• ClimateKeeper2™System - Keeps food garden fresh longer, while protecting ice from odor transfer, with
its unique dual-evaporator system
• LED Lighting - Casts a clean, beautiful light throughout the fresh food area of the refrigerator
• Color LCD Controls with Touch Screen - Makes it easy to control all the functions of the refrigerator with
just a touch
• Integrated Dispenser with LED Lighting, PreciseFill & UltraFlow100 - Illuminates the dispenser and pours
water in accurate increments or up to 100 ounces per minute
• QuickFreeze Setting - Provides faster, fresher freezing to maintain the flavor and quality of meats
• Electronic Beverage Center - Keeps beverages and treats icy cold and easily accessible
• CustomCool™Technology - Chills in minutes, thaws in hours and keeps foods fresher, longer
• Slide 'n Store™Freezer Basket - Offers easy access and flexible storage
• Quick Ice™Option - Makes ice up to 50% faster than normal settings-ideal for entertaining
• TurboCool™Setting - Cools the refrigerator quickly after frequent door openings
• Integrated Ice™System - Frees up valuable freezer space; It tilts down, providing easy access to bulk ice
• Tilt-Out Freezer Door Bins - Move forward for convenient access
• Integrated Shelf Support System - Provides strong, yet flexible support
• Adjustable ClearLook™Door Bins - Hold gallon-size containers with style and ease
• Adjustable Slide-Out, Spillproof Glass Shelves - Raised edges help contain spills and slide-out shelves
make clean up quick and easy
• GE Water Filtration System - Delivers clean great-tasting water and ice through the LightTouch! Dispenser
• Model PSDW3YGXSS - Stainless steel
PSDW3YGX
GE Profile™Counter-Depth 23.2 Cu. Ft. Stainless-Wrapped Side-by-Side Refrigerator
