GE PZS23KPEBV Manual

Listed by
Underwriters
Laboratories
For answers to your Monogram®or GE appliance
questions, visit our website at geappliances.com or
call GE Answer Center®service, 800.626.2000.
*Height to top of door trim (in.): 70-1/4
†Water hook-up fits in back air clearance when calculating
installation depth.
If installed against a wall, allow clearance of 13-15/16" on
freezer side to remove bin.
Clearance required to remove fresh food full-size pan without
disassembling is 18-5/8".
Allow additional space for any necessary leveling adjustments.
Dimensions and Installation Information (in inches)
A
G
D
C
F
BE
H
Overall
Dimensions
Height to top of hinge (in.) A69-1/4
68-3/4
23-7/8
27-1/8
28-3/4
46
35-3/4
40-1/8
1/8
1
2
Height to top of case (in.) B
Case depth without door (in.) C
Case depth less door handle (in.) D
Case depth with door handle (in.) E
Depth with fresh food door open 90˚ (in.) F
Width (in.) G
Width with door open 90˚ inc. door handle (in.) H
Air
Each side (in.)
Top (in.)
Back (in.)
A
G
D
C
F
BE
H
Overall
Dimensions
Height to top of hinge (in.) A69-1/4
68-3/4
23-7/8
27-1/8
28-3/4
46
35-3/4
40-1/8
1/8
1
2
Height to top of case (in.) B
Case depth without door (in.) C
Case depth less door handle (in.) D
Case depth with door handle (in.) E
Depth with fresh food door open 90˚ (in.) F
Width (in.) G
Width with door open 90˚ inc. door handle (in.) H
Air
Each side (in.)
Top (in.)
Back (in.)
210320
Specification Revised 9/13
PZS23KPE
GE Profile™Series 23.3 Cu. Ft. Counter-Depth Side-By-Side Refrigerator

8' Ceiling
13" to 14"
Cabinet
12"
Soffit
36-1/8"
24-1/2"
Collar Tr im In. w/ceiling
70"*
23 cu. ft. models
72-1/2"*
25 cu. ft. models
*The rough-in dimensions of 70" for 23 cu. ft. models and 72-1/2" for 25 cu. ft.
models are minimum and measured from the finished floor to top of opening
(or the underside of the overhead cabinets). For Models with Tr im Kit:
If frameless style cabinets are planned for above the refridgerator, you may
need to consider adding a maximum of 1/4" (70-1/4") to height of opening
for 23 cu. ft. models and 1/8" (72-5/8") for 25 cu. ft. models to allow additional
clearance between cabinet doors and top of refridgerator trim when cabinet
doors are in open position.
†Model PSDW3YGX is 71-3/4".
Listed by
Underwriters
Laboratories
25"
Counter
Top
ElectricalWater
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
24"
Cabinet
25"
Counter
Top
Electrical Water
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
24"
Cabinet
25"
Counter
Top
ElectricalWater
Trim
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
24"
Cabinet
25"
Counter
Top
Electrical Water
Trim
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
24"
Cabinet
FOR 21 CUBIC FOOT MODELS
FOR 24 CUBIC FOOT MODELS
Fig 2A eps
For answers to your Monogram®or GE appliance
questions, visit our website at geappliances.com or
call GE Answer Center®service, 800.626.2000.
Rough-In Dimensions and Installation Information (in inches)
Installation Tips to Maximize the Built-In Look
• All wall/floor molding should be removed prior to installation.
• Water recess on rear wall recommended to prevent water
line damage. 48" minimum length, 1/4" diameter water
line tubing recommended.
• When possible, recess both copper water line and electrical
outlet. (See local codes)
• Front and rear leveling legs are adjustable for the built-in look.
(See owner’s manual)
• If optional collar trim kit is to be used or anticipated, see collar
trim installation for different rough-in dimensions
*The rough-in dimensions of 70" for 23 cu. ft. models and 72-1/2"
for 25 cu. ft. models are minimum and measured from the
finished floor to top of opening (or the underside of the overhead
cabinets). For Models with Trim Kit: If frameless style cabinets
are planned for above the refrigerator, you may need to consider
adding a maximum of 1/4" (70-1/4") to height of opening for 23
cu. ft. models and 1/8" (72-5/8") for 25 cu. ft. models to allow for
additional clearance between the cabinet doors and the top of
refrigerator trim when the cabinet doors are in open position.
210320
Specification Revised 9/13
PZS23KPE
GE Profile™Series 23.3 Cu. Ft. Counter-Depth Side-By-Side Refrigerator

Listed by
Underwriters
Laboratories
For answers to your Monogram®or GE appliance
questions, visit our website at geappliances.com or
call GE Answer Center®service, 800.626.2000.
Collar Trim Installation
An enclosure is required to match up to the
trim, see Typical Installation. To obtain the
most integrated look, the cabinet or soffit
above the refrigerator should extend out
to the same depth as the side panels. The
refrigerator opening must have minimum
dimensions of 70" high x 36-1/8" wide x
24-1/2" deep as shown at right. If there is
an overhead cabinet, allow 1" for cabinet
door clearance with the top trim piece so
the cabinet doors can be opened without
hitting the top trim. If 1/2" side panels are
used, then side trim and panel will be even.
If 3/4" side panels are used, then some of
the side panel will extend beyond the trim
and must be finished.
IMPORTANT: Before finalizing specifications
for your GE Profile Counter-Depth
Refrigerator, please NOTE:
• A minimum of 36-1/8" is required for
refrigerator installation with collar
• Be sure to allow for 1/2" or 3/4" side
panels in addition to the 36-1/8"
minimum.
Typical Installation
Shaded areas represent front surfaces of side panels and
overhead cabinet or soffit that contacts trim.
Refer collar trim install
70"*
36-1/8"
24-1/2"*
1/2" minimum
*The rough-in dimension of 70" is minimum and is measured from the
finished floor to top of opening (or the underside of the overhead cabinets).
For Models with Trim Kit: If frameless style cabinets are planned for above the
refrigerator, you may need to consider adding a maximum of 1/4" (70-1/4") to
height of opening to allow additional clearance between cabinet doors and
top of refrigerator trim when cabinet doors are in open position.
Rough-In Dimensions and Installation Information (in inches)
Magnetic
Tape
3/4" Cabinet
Side Panel
1/2" Cabinet
Side Panel
Side trim must be installed
flush with the gasket contact
surface on the case.
Refrigerator
Case
Side TrimDoor Gasket
Overhead
Cabinet
Cabinet
Door
Top Trim
Case
1"
210320
Specification Revised 9/13
PZS23KPE
GE Profile™Series 23.3 Cu. Ft. Counter-Depth Side-By-Side Refrigerator

Listed by
Underwriters
Laboratories
For answers to your Monogram®or GE appliance
questions, visit our website at geappliances.com or
call GE Answer Center®service, 800.626.2000.
Order your own custom wood panels to match cabinetry
or other decor.
Panels up to 1/4" thick will fit door frame with no special
preparation. Add filler behind material thinner than 1/4"
for proper fit.
Weight Limits: Total weight of panels (i.e., both freezer
panels)—Fresh Food = 38 lbs., Freezer = 28 lbs.
NOTE: Panels up to 3/4” will require special routing area
around handles. Dimensions may vary depending on
depth of panel.
IMPORTANT: Before finalizing specifications for your
GE Profile Counter-Depth Refrigerator, please NOTE:
• A minimum of 36-1/8" is required for refrigerator
installation with collar
• Be sure to allow for 1/2" or 3/4" side panels in addition
to the 36-1/8" minimum.
Door Panel Dimensions and Installation Information (in inches)
Installation of Water OutletsFreezer Panel
without Dispenser
Freezer Panel
with Dispenser
Fresh Food
Panel
(Fresh Food panel shown)
Notch required at top
corner as noted.
Detail C
Freezer Panel
Without Dispenser
Freezer Panel
With Dispenser
Fresh Food
Panel
Cut
out
1/8 1/8
14-15/32 14-15/32
14-15/32
33-5/8
17-7/8
19-15/32
5/1
6
Cut
out
Cut
out 1/8
5/165/16
FRONT
67-9/32 67-9/32
FRONT FRONT
Alternate
water
line location
through floor
1/2"
Water hook-up
on the refrigerator
Recommended water line
location using recess
in rear wall
Recommended
single loop of 1/4" copper water line
Water hook-up
on the refrigerator
Rear Wall View
18"
24"
Allow 48" minimum water
line to enable refrigerator
to be pulled forward
Alternate
water
line location
through floor
1/2"
Recommended water line
location using recess
in rear wall
Recommended single loop
of 1/4" copper water line
Water hook-up
on the refrigerator
Rear Wall View
Top View
Top View
18"
24"
Allow 48" minimum water
line to enable refrigerator
to be pulled forward
In.of water & Electric Ot. Art
Alternate
water
line location
through floor
1/2"
Water hook-up
on the refrigerator
Recommended water line
location using recess
in rear wall
Recommended
single loop of 1/4" copper water line
Water hook-up
on the refrigerator
Rear Wall View
18"
24"
Allow 48" minimum water
line to enable refrigerator
to be pulled forward
Alternate
water
line location
through floor
1/2"
Recommended water line
location using recess
in rear wall
Recommended single loop
of 1/4" copper water line
Water hook-up
on the refrigerator
Rear Wall View
Top View
Top View
18"
24"
Allow 48" minimum water
line to enable refrigerator
to be pulled forward
In.of water & Electric Ot. Art
5/16"
1/8"
Dr. Panel Dim. Detail C
1/4" Max.
Panels 1/4" thick
or less
Dr. Panel Dim. Panel 1/4 Thic
k
210320
Specification Revised 9/13
PZS23KPE
GE Profile™Series 23.3 Cu. Ft. Counter-Depth Side-By-Side Refrigerator

Lock
Controls
FreezerTemp
FridgeTemp
On/Off
Set
Features
0°FisRecommended for Freezer
37°FisRecommended for Fridge
Water
FREEZER
F
REFRIGERATOR
F
DoorAlarmOn
TurboCoolOn
ReplaceWaterFilter
Crushed CubedLight
210320
Features and Benefits
• 70" tall
• Integrated shelf support system - Provides strong, flexible support
• Adjustable slide-out, spillproof glass shelves - Raised edges help contain spills and make clean up
quick and easy
• Adjustable Clear Look door bins - Hold gallon containers with ease and free up valuable shelf space
• In-the-door beverage rack - Beverages are chilled and ready without taking up valuable space
• Quick Ice setting - Create ice up to 50% faster than normal settings
• Turbo Cool setting - Drops interior temperature to maintain freshness after frequent openings
• Advanced filtration - Removes trace pharmaceuticals from water and ice* and uses replacement
filter MWF
(*Removes ibuprofen, atenolol, fluoxetine, progesterone and trimethoprim. These pharmaceuticals
are not necessarily in all users’ water)
• Model PZS23KPEWV - White
• Model PZS23KPEBV - Black
*
Specification Revised 9/13
PZS23KPE
GE Profile™Series 23.3 Cu. Ft. Counter-Depth Side-By-Side Refrigerator
