GECKO® DESTINY EQ 7043
www.geckomusic.net
www.geckomusic.net
O NER'S MANUAL
O NER'S MANUAL

GECKO® SAFETY INSTRUCTIONS & SYMBOLS GUIDE
GECKO® SAFETY INSTRUCTIONS & SYMBOLS GUIDE
For your own safety and to avoid invalidation of the warranty, all text marked with these symbols should be
read carefully.
SYMBOLS:
SYMBOLS:
SAFETY INSTRUCTIONS:
SAFETY INSTRUCTIONS:
•To reduce the risk of electrical shock, do not remove covers. No user serviceable parts inside. Please
refer servicing to qualified personnel.
•To reduce the risk of electrical shock or fire, do not expose the equipment to rain or moisture.
•o not impose unnecessary stress on your equipment (i.e. placing heavy objects on it, overscrewing its
mounting etc).
•Read and keep the instruction manuals in a safe place for future references.
•o not attempt to clean the equipment with chemical solvents as this may damage the finish. Clean only
with dry cloth.
•o not block any ventilation openings.
•o not install near any heat sources such as radiators, heat registers, stoves, or other apparatus that
produce heat.
•o not defeat the purpose of the polarized or grounding type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide
blade or the grounding prong is provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician for the replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
•Unplug the apparatus during lightning storms or when it is not in use for a long period of time.
NOTES
NOTES
Contain important information and useful tips on the operation of your equipment.
WARNING
WARNING
The lightning flash with arrowhead symbol within an equilateral triangle, is intended to
alert the user to the presence of uninsulated dangerous voltage within the product’s
enclosure that may be of sufficient magnitude to constitute a risk of electric shock.
CAUTIONS
CAUTIONS
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in thee
literature accompanying the appliance. Please read the manual carefully.
H
HEADPHONES
EADPHONES
SAFETY
SAFETY
WARNIN
WARNING
G
Contain important information and use
useful tips on headphones outputs and monitoring
levels.
!

•Use only attachments / accessories specified by the manufacturer.
•Always shut down power supply when not in use to save energy and for prolonged lifespan.
•Exposure to extremely high noise levels may cause permanent hearing loss. Individuals vary
considerably in susceptibility to noise-induced hearing loss, but nearly everyone will lose some hearing if
exposed to sufficiently intense noise for a period of time. The U.S. Government’s Occupational Safety
and Health Administration (OSHA) has specified the permissible noise level exposures shown in the
following chart. According to OSHA, any exposure in excess of these permissible limits could result in
some hearing loss. To ensure against potentially dangerous exposure to high sound pressure levels, it is
recommended that all persons exposed to equipment capable of producing high sound pressure levels
use hearing protectors while the equipment is in operation. Ear plugs or protectors in the ear canals or
over the ears must be worn when operating the equipment in order to prevent permanent hearing loss if
exposure is in excess of the limits set forth here:
Duratio /Day (Hours) dB, Sou d Pressure Level (SPL) Descriptio s
Below 90 dB Safe zone
8.00 90 Hearing damage
6.00 92
4.00 95
3.00 97
2.00 100 Serious hearing damage
1.50 102
1.00 105
0.50 110
0.25 or less 115 Human pain threshold
GECKO MUSIC GROUP
GECKO MUSIC GROUP
No. 59, 59-1, 61, 61-1, 63, 63-1, Jalan PE 3, Taman Paya Emas,
Paya Rumput, 76450 Melaka, Malaysia.
Mobile: +6012.204 2175
Email: [email protected]t • Website: www.geckomusic.net

FOREWORD
FOREWORD
ear Friends,
Thank you very much for purchasing quality products by GECKO MUSIC GROUP. I am indeed very
delighted that we have journeyed this far, setting new standards in the audio and music industry while
touching and changing lives along the way!
At GECKO MUSIC GROUP we focus on developing nothing but the best professional audio equipment and
premium grade musical instruments you ever need! It has been our philosophy all this while that good sound
reproductions can be achieved at a fraction of a premium. Our engineering team is constantly doing research
and development to meet this objective. We thank God that by HIS grace, we have succeeded in developing
the revolutionary C.R.I.S.T.A.L.® Audiophile technology that is changing the way how sound is being
encoded, reproduced and managed!
On behalf of GECKO MUSIC GROUP, I would like to pledge our continuing commitment to uphold our
traditions in serving music and audio communities around the world with more value-added highest possible
quality GECKO® professional audio equipment and premium grade musical instruments!
Once again, thank you very much for your support.
Yours truly,
aniel Foo
Founder / Chairman
GECKO MUSIC GROUP

TABLE OF CONTENTS
TABLE OF CONTENTS
INTRODUCTION 1
CONTROL ELEMENTS 2
MAKING CONNECTIONS 4
INSTALLATION CONSIDERATIONS 5
SPECIFICATIONS 6
WARRANTY 7
NOTES: Congratulations on purchasing the GECKO® ESTINY EQ
7043 graphic equalizer! We recommend that you take a moment and
read through the manual as it provides information that will assist you
in using your unit to its fullest potential.
______________________________________________________________________________________
© GECKO MUSIC GROUP. All Rights Reserved.

INTRODUCTION
INTRODUCTION
The GECKO® ESTINY EQ 7043 graphic equalizer is a very useful audio signal processing tool in situation
where precise frequency control is required across the audible frequency spectrum (i.e. music masterings).
The GECKO® ESTINY EQ 7043 graphic equalizer can be used in tuning any acoustical environment (i.e.
home theater rooms, recording and mastering studios, concert halls), to stop ringing, increase clarity, and
flatten the overall frequency response of the environment.
______________________________________________________________________________________
1
1
© GECKO MUSIC GROUP. All Rights Reserved.

CONTROL ELEMENTS
CONTROL ELEMENTS
FRONT PANEL
1. INPUT GAIN CONTROL
This control sets the signal level to the equalizer. It is capable of -12dB to +12dB of gain. Its effect is
apparent by viewing the OUTPUT LEVEL METER.
2. EQ BYPASS SWITCH
This switch removes the graphic equalizer section from the signal path. The BYPASS switch does not,
however, affect the INPUT GAIN, or LOW CUT filters.
3. EQ BYPASS LED
This red LE lights when the EQ is in BYPASS mode. Note that BYPASS mode only affects the graphic
equalizer section. The INPUT GAIN and LOW CUT controls remain unaffected when the EQ is bypassed.
4. BOOST (+) / CUT (-) RANGE SELECTION SWITCH AND LED
This RANGE switch selects which of the two BOOST (+) / CUT (-) range the equalizer will use, either 6dB or
15dB. The red LE lights up when the 15dB range is selected, and the amber LE lights up when the 6dB
range is selected.
NOTES: The BOOST (+) / CUT (-) switch is slightly recessed. This is to prevent
accidental activation of the switch, possibly causing damage to other sound system
components.
5. OUTPUT LEVEL LED METER
These four LE s indicate output level of the equalizer. The red LE is 3dB below clipping and is marked as
+18dBu. It monitors the level at the OUTPUT of the equalizer after all other processing.
6. CLIP LED
This LE lights whenever any internal signal level reaches 3dB clipping, which may occur when any of the
followings happen: (1) the input signal is “hotter” than +22dBu; (2) excessive gain is applied by the INPUT
GAIN control; or (3) excessive boost is applied using the FREQUENCY BAN SLI ERS.
______________________________________________________________________________________
2
2
© GECKO MUSIC GROUP. All Rights Reserved.
5 76
123 48

7. FREQUENCY BAND SLIDERS
Each one of this slider potentiometer will boost or cut at its noted frequency by 6dB or 15dB, depending upon
the RANGE switch. When all the sliders are in the center demented position, the OUTPUT of the equalizer is
linear (flat). The frequency band centers of the GECKO® ESTINY EQ 7043 are marked at ⅓ or ⅔ of an
octave interval on ISO standard spacing.
8. LOW CUT SWITCH
The LOW CUT switch inserts or removes the 18dB/Octave 40Hz Bessel low-cut filter from the signal path.
When the LOW CUT switch is pressed in, the 18dB/Octave 40Hz Bessel low-cut filter is in the audio path.
REAR PANEL
9. POWER SWITCH
Switch the power ON [I] and OFF [O]. Always make audio connections with the power switch in the OFF
position.
10. IEC - AC POWER CORD RECEPTACLE
Plug the AC power cord (supplied) into the GECKO® ESTINY EQ 7043. Plug the other end into a standard
wall power outlet. Take care to route power cables away from audio lines.
WARNING: Be sure to verify your actual line voltage is the same as the voltage level
printed below the AC power receptacle. Connection to an inappropriate power
source may result in extensive damage which is not covered by the warranty.
11. INPUTS
Three types of input connectors are provided for INPUT connections: female locking XLR type connectors,
¼” TRS connectors, and a barrier terminal strip. The maximum input level that the equalizer can accept is
+22dBu (ref: 0.775 Vrms).
______________________________________________________________________________________
3
3
© GECKO MUSIC GROUP. All Rights Reserved.
9
10 1112
13

12. OUTPUTS
Three types of output connectors are provided for OUTPUT connections: male XLR type connectors, ¼” TRS
connectors, and a barrier terminal strip.
13. CHASSIS GROUND LIFT
By removing the jumper connecting the two screws on the barrier terminal strip, the chassis ground is
separated from the circuit ground of the equalizer unit. This is sometimes necessary to prevent ”ground
loops” in a sound system. When lifting the ground strap, you must make a connection from the circuit ground
terminal to some other ground point in your audio system in order for the equalizer to function properly.
Wiring connectors with ground.
MAKING CONNECTIONS
MAKING CONNECTIONS
The GECKO® ESTINY EQ 7043 graphic equalizer has balanced INPUTS and OUTPUTS that can be used
with any balanced or unbalanced line-level device. For more specific information about cabling possibilities,
please refer to INSTALLATION CONSI ERATIONS.
To connect the equalizer to your sound system, refer to the following steps:
1. Turn OFF all equipment before making any connections.
2. Mount the GECKO® ESTINY EQ 7043 on a 3U rack space (not included). It can be mounted
above or below anything that does not generate excessive heat. Although it requires no special
ventilation, ambient temperatures should not exceed 113°F (45°C) when equipment is powered.
3. Make connections using quality audio cables (i.e. GECKO® TRUTH T3AL) and connectors (i.e.
GECKO® OLYMPIAN connectors) according to your requirements. Audio connections are made via
XLR (male and female) and ¼” TRS connectors, or barrier terminal strips. All of these connectors for
the INPUTS and OUTPUTS can be used for balanced or unbalanced connections.
______________________________________________________________________________________
4
4
© GECKO MUSIC GROUP. All Rights Reserved.
Without Jumper in Place With Jumper in Place
Jumper
Chassis
Ground
Chassis
Ground
Circuit
Ground
Circuit
Ground
To
System
Ground
Output
Cable
Output
Cable
Input
Cable
Input
Cable
OptionalOptional
++
+
+
- -
- -- - +
+
+ +- -

NOTES: The use of more than one connector at a time for the INPUTS could
unbalance balanced lines, cause phase cancellation, short a conductor to ground, or
cause damage to other equipment connected to the equalizer. More than one
OUTPUT may be used simultaneously as long as the combined parallel load is not
greater than 600Ω.
4. Select the operating range with the BOOST (+) / CUT (-) RANGE selection switch. Be sure to reduce
audio levels at the power amplifiers when changing the setting of this switch as it may generate an
audible transient.
5. Connect the AC power cord (supplied) to the unit’s rear panel POWER receptacle and to an
appropriate AC power source. Route the AC power cord away from audio lines. The unit may be
turned ON and OFF using the rear panel POWER switch or a master equipment power switch (i.e.
GECKO® GALILEE series power sequencers).
INSTALLATION CONSIDERATIONS
INSTALLATION CONSIDERATIONS
HOOKUPS AND CABLING
The GECKO® ESTINY EQ 7043 graphic equalizer is designed for nominal +4dBu levels. The equalizer can
be used with either balanced or unbalanced sources, and the OUTPUTS can be used with either balanced or
unbalanced loads, provided proper cabling is used.
A balanced line is defined as two-conductor shielded cable with the two center conductors carrying the same
signal but in opposite polarity when referenced to ground (cable shield at ground potential). An unbalanced
line is generally a single-conductor shielded cable with the center conductor carrying the signal and the
shield at ground potential.
INPUT CABLE CONFIGURATIONS
The GECKO® ESTINY EQ 7043 graphic equalizer has an input impedance of 40kΩ balanced and 20kΩ
unbalanced. This makes the GECKO® ESTINY EQ 7043’s audio INPUTS suitable for use with virtually any
low source impedance (under 20kΩ).
OUTPUT CABLE CONFIGURATIONS
The GECKO® ESTINY EQ 7043 graphic equalizer’s output is capable of driving a 600Ω load to +18dBu.
For maximum hum rejection with a balanced source, avoid common grounding at the equalizer’s INPUTS
and OUTPUTS.
______________________________________________________________________________________
5
5
© GECKO MUSIC GROUP. All Rights Reserved.

SPECIFICATIONS
SPECIFICATIONS
I puts:
Connectors: ¼” TRS (2), XLR Female (2), and Barrier Terminal Strip
Type: Electronically Balanced/Unbalanced, RF Filtered
Impedance: 40kΩ (Balanced), 20kΩ (Unbalanced)
Max Input Level: > +21dBu, Balanced or Unbalanced
CMRR: >40dB, Typical >55dB at 1kHz
Outputs:
Connectors: ¼” TRS (2), XLR Male (2), and Barrier Terminal Strip
Type: Impedance-Balanced/Unbalanced, RF Filtered
Impedance: 200Ω (Balanced), 100Ω (Unbalanced)
Max Output Level: > +21dBu Balanced/Unbalanced into 2kΩ or greater/ > +18dBm
Max Output Impedance: Balanced/Unbalanced (into 600Ω)
System Performa ce:
Frequency Response: 20Hz ~ 20kHz, +0.5 / -1dB
Bandwidth: < 10Hz ~ >50kHz, +0.5 / -3dB
ynamic Range: 109dB (+/-15dB Range), 115dB (+/-6dB Range)
Signal-to-Noise: 90dB (+/-15dB Range), 97dB (+/-6dB Range)
TH + N: < 0.005%
Inter-Channel Crosstalk: < -80dB, 20Hz ~ 20kHz
Fu ctio Switches:
EQ BYPASS: Bypasses the GRAPHIC EQUALIZER section in the signal path
LOW CUT (Recessed): Activates the 40Hz 18dB/Octave Bessel High-Pass Filter
RANGE: Selects either +/- 6dB or +/- 15dB Slider Boost (+) / Cut (-) Range
Physical Properties:
Enclosure: Steel
Color: Metallic Grey
Net Weight: 5.50Kg
imension: (H) 135mm x (W) 483mm x ( ) 204mm
Specifications subject to change without prior notice. Manufactured under ISO9000 certified management
system.
______________________________________________________________________________________
6
6
© GECKO MUSIC GROUP. All Rights Reserved.

GECKO
GECKO®
® TERMS OF WARRANTY
TERMS OF WARRANTY
WARRANTY:
GECKO MUSIC GROUP warrants its GECKO® products for a period of three (3) years from the original date
of purchase, in accordance to the warranty regulations described below.
WHAT IS COVERED:
uring the applicable warranty period, GECKO MUSIC GROUP warrants the product against defects in
materials and workmanship and against malfunctions. GECKO MUSIC GROUP will remedy all such defects
and malfunctions without charge for parts or labour if the warranty applies. In the case that other parts are
used which constitutes an improvement, GECKO MUSIC GROUP may, at its discretion, charge the customer
for the additional cost of these parts. Final determination of warranty coverage lies solely with GECKO
MUSIC GROUP.
WHAT IS NOT COVERED:
1. If the product needs to be modified or adapted in order to comply with applicable technical or safety
standards on a national or local level, in any country which is not the country where the product was
originally developed and manufactured, this modification/adaptation shall not be considered a defect in
material or workmanship.
2. Normal wear and tear, in particular, of faders, cross faders, potentiometers, keys/buttons, valves,
guitar/bass strings, machine heads, pick-up covers, vinyl covers, illuminants, and similar parts are not
covered by this warranty.
3. Improper handling, neglect or failure to operate the unit in compliance with the instructions given in the
user or service manuals.
4. Connection or operation of the unit in any way that does not comply with the technical or safety
regulations applicable in the country where the product is used.
5. amages/defects caused by force of nature or any other condition that is beyond the control of GECKO
MUSIC GROUP.
6. Any repair or opening of the unit carried out by unauthorized personnel (user included) will void the
warranty.
7. Modification or removal of serial numbers.
OBTAINING WARRANTY SERVICE:
To return a GECKO® product for warranty service, first fill out the O li e Tech ical Report on
www.geckomusic. et and submit for an authorization/service number. Write the authorization/service
number so that it is prominently displayed on the outside of the shipping carton. Any products received
without an authorization/service number that is clearly visible upon arrival at the factory will be refused.
Enclose proof of the original delivery date or a copy of the original sales receipt/invoice. Enclose a
description of the suspected defect or malfunction and the condition, if any, which caused the problem.
Return the product to GECKO MUSIC GROUP.
WARRANTY SHIPPING:
You are responsible for prepaying shipping costs F.O.B. GECKO MUSIC GROUP, Melaka, Malaysia.
Shipped product(s) must be properly packaged. Use original shipping cartons and packing materials where
possible. GECKO MUSIC GROUP is not responsible for damages resulting from inadequate and or improper
packing. Products received with damages due to improper packaging will be deemed out of warranty.
______________________________________________________________________________________
7
7
© GECKO MUSIC GROUP. All Rights Reserved.

Products which do not meet the terms of this warranty will be repaired exclusively at the buyer’s expense.
GECKO MUSIC GROUP will inform the buyer of such circumstance. If the buyer fails to submit a written
repair order within six (6) weeks after notification, GECKO MUSIC GROUP will return the unit C.O. . with a
separate invoice for freight and packing. Such costs will also be invoiced separately when the buyer has sent
in a written repair order.
WARRANTY RIGHTS:
This warranty is exclusive and extended to the original buyer and is not transferable to anyone who may
subsequently purchase this product. No other person (apart from authorized GECKO® Stores) shall be
entitled to give any warranty promise on behalf of GECKO MUSIC GROUP.
______________________________________________________________________________________
8
8
© GECKO MUSIC GROUP. All Rights Reserved.
Table of contents
Other Gecko Stereo Equalizer manuals
