Geely EX7 User manual

Warranty and Maintenance Manual
(EX7 Model)

Table of Content
Delivery Test Certification
Car purchase inspection has been completed for this car
and it is hereby proven that the quality meets the technical
specification of the manufacturer.
To users 1
Contact us 3
Importance of the warranty and maintenance manual 4
Vehicle warranty 5
Spare parts warranty 9
Type of oil & fluid applicable to GEELY cars and the
consumption 11
Table of Geely Automobile initial maintenance item 12
Initial maintenance card 14
Table of regular part replacement 16
Regular maintain items 19
Regular maintenance record 22
Warranty service record registration 27
User change (transfer) record 28
Owner:
ID Card No./Company Code:
Address/Zip Code:
Telephone:
Model:
VIN No.:
Engine No.:
Qualified Certificate No.:
Car Purchase Date:
Dealer Address/Telephone
Signature/Seal

To Users 1
Dear Users：
Thank you for buying and using GEELY cars!
Please keep this manual in your car.
In order to protect your investment in new car purchase
and keep a good condition and optimum performance of your
new car in future use, please read this manual carefully
because it will help you better understand and use Geely car,
introduce to you the basic solution in case of problems, and
effectively maintain your rights and interests. The Vehicle
Owner’s Manual supplied with the car also includes a great
number of important descriptions on use and maintenance,
and we suggest that you could read them carefully.
The car you are driving is of superior safety, comfort,
power and economy. If you find some problems during your
using, please contact the nearby service station authorized by
Geely International Corporation. The service station will
provide knight service in warranty, maintenance and spare
parts. Make sure you finish the maintenance on schedule
specified in the owner’s manual and the maintenance
regulation.
Please use the gasoline, oil, brake fluid and anti-freezer
in strict accordance with the recommendation of this
manual, otherwise it may damage your car. Only the spare
parts recommended by the service stations authorized
by Geely International Corporation can extend the
life-span of your car. Here, we’d like to request your
particular attention to the fact that Geely only supply
the original spare parts to the service stations, therefore,
you can only acquire the genuine spare parts from the
service stations authorized by Geely International
Corporation.
With this manual, your car will enjoy a warranty of 36
months/100,000 km, (whichever occurs first since the day
of car purchase). Also, when your car has been driven for
less than 3 months or the mileage falls within 5000
kilometers (whichever occurs first), please go to the nearby
Geely international service stations for initial maintenance
service with this manual.
Correct regular maintenance will help keep your car in
optimum conditions and improve the reliability and

lifespan.
Hence, within the warranty term, make sure you drive
to the Geely service station for regular maintenance every
5000km or within 6 months upon last maintenance.
All information in this manual are up to date and will be
subject to change without prior notice.
We call for your attention to the fact that any
discretional change on your car may influence its mechanical
performance, safety or service lifespan, or even violate the
regulation of the local government.
Your comments on the quality and after-sale service of
Geely car are welcome.
Geely International Corporation
2

Contact Us 3
Geely International Corporation is committed to the
promotion of the service concept of “Focus on Details” of
Geely cars and to the improvement of user’s satisfaction. All
of the Geely International service stations have necessary &
required tools and facilities to provide maintenance and
services for your Geely cars and all the staffs have received
professional trainings.
In case of problems occurring during the operation of
your car, please do the following things:
1. Provide necessary information:
·problem symptom and corresponding conditions
·vehicle model, VIN number, engine number, delivery
date
·mileage covered.
·dealers and Geely International service stations ever
provided maintenance and servicing
·vehicle maintenance history record
2. In order to have a fast processing, we suggest that
you may contact us based on the following steps:
Step 1: report your problems to the service station
authorized by Geely International Corporation, this is the
most direct way of troubleshooting.
The service station authorized by Geely International
Corporation will provide you possible maintenance services.
First, please report your problems to the maintenance
consultant of the Geely car service station in clear
explanation. If you think the problems remain unsolved, you
can directly report them to the service station master.
If the service station can not solve your problem, go to
step 2: contact the customer call center of the dealer in your
home country.
If the dealer can not solve your problem, go to step 3:
contact Geely International Corporation.
Hotline：[phone]
Complaint Email：[e-mail]
Fax: [phone]
Address: No. 87 Qianyang Road, Putuo District,
Shanghai, China
Zip Code: 200333
Website: http://www.geelyglobal.com

Importance of the Warranty and Maintenance Manual 4
Based on the related data recorded in this manual, Geely International Corporation and its affiliated service stations are
able to have clear visibility in the car purchase date and car conditions and confirm the starting date of the warranty.
Based on the related data recorded in this manual, Geely International Corporation and its affiliated service stations can
provide you with spare parts applicable to your car and corresponding maintenance services. In order to keep your car always
in good conditions, this manual specifies the maintenance period and maintenance items for Geely cars, please make sure that
you will go to the Geely International service stations for the specified maintenance of your car and the service station
personnel will make records for the maintenance process. It is required to prove that your car has been maintained based on the
requirements of this manual. In case of problems of your car, the maintenance certification in this manual will be one of the
bases for our company to confirm the claim.
Based on the above significance described in this manual, please make sure this manual is properly kept. Loss of this
manual or failure in maintaining the car in accordance with the related rules and regulations will be regarded as abandonment
of the warranty of your car. In addition, if you transfer your car to another one, please make sure this manual is also handed
over the new owner together with the car.

Vehicle Warranty 5
I. Warranty Scope
■The vehicle enjoys a warranty of 36 months or
100,000km (whichever occurs first).
■The Warranty Policy takes effect from the date of car
purchase.
■Use and maintain the car based on the rules of the warranty
and maintenance manual as well as owner’s manual.
■Quality defect or damage arising from the design,
manufacture, assembly and raw material defects.
■Parts replacement or maintenance during the warranty term.
The warranty term of the vehicle or parts can not be
extended.
■Warranty requested by the user, the damaged parts shall be
protected and the user is required to explain the facts.
■The proprietary right of the warranted old parts shall be
owned by Geely International Corporation.
II. Non-warranty Scope
■Non-conformance to any of the articles within the above
warranty scope.
■Within the warranty term, the user goes by himself/herself to
other service stations not authorized by Geely International
Corporation for maintenance of his/her car.
■Failure in using, maintaining, repairing the car based on the
requirements in the warranty and maintenance manual as well
as owner’s manual, e.g. operating conditions go beyond the
specified range, over-speed and overload
■Damaged car arising from the use of fuel failing in meeting the
requirement or of bad quality.
■Damage caused by the traffic accidents due to reasons other
than quality problem.
■Damaged car due to discretional change, modification, removal
of the parts in the car.

Vehicle Warranty
■Without effective invoice and warranty evidence, and
failure in proving that the car is within the warranty term.
■Damage enlarged due to discretional disposal after the
problem occurs without the approval of Geely International
service station.
■The user makes a discretional change on the reading of the
odometer, leading to the failure in verifying the mileage.
■Damage due to force majeure.
■Car damage due to incorrect operation or misuse (e.g.
racing, testing).
■Normal maintenance (regular maintenance), inspection and
adjustment (four-wheel alignment, tire dynamic balance,
fuel consumption…etc.).
■Normal wear of damageable parts (friction plate, belt,
6
spark plug, tire…etc.).
■Indirect loss (parking fee, travel expense, room and board
fee, and charge for loss of working time).

Vehicle Warranty 7
No.
Item
Content
1
Whole vehicle
（whichever
occurs first）
36 months or 100 thousands kilometers
3
Non-warranty
Adjustments, wheel alignment, wheel balance, normal service maintenance , Air filter, gasoline filter,
air conditioning filter oil filter, fuse (wire), lamp bulb, spark plug, regular consumption lubricant,
regular consumption lubricating grease, regular consumption brake oil, regular consumption coolant,
regular consumption washer fluid, regular consumption A/C refrigerant,
4
Limited
warranty
（whichever
occurs first）
24 months or 60
thousands
kilometers
Catalysis, oxygen sensor, shock absorber, CD player, engine ignition system
(engine ECU exclude).
6 months or 10
thousands
kilometers
Glasses, wiper blade, tires, battery, brake disk, brake drum, brake lining, brake
pad, clutch disk, clutch pressure plate, V belt, rubber(include window
weatherstrip, oil sealing, pipe)

Vehicle Warranty 8
1. make sure you go to the Geely international service station for initial maintenance with the warranty and maintenance
manual, car purchase invoice (copy) and set up user file to obtain the warranty qualification.
2. In case of car problems occurring within the warranty term, please go to the Geely international service station for warranty
service with the maintenance manual, drive license or car purchase invoice (copy).
3. After the warranty service is completed, please sign the corresponding record.

Spare Parts Warranty 9
Spare Parts Warranty Period
Warranty Items
Spare parts without warranty
Bulbs, fuses, filters ( air filter, fuel filter, oil filter), spark plugs, any glasses of the
vehicle
Spare parts with 3months/5,000km
warranty（whichever occurs first）
horns, wiper blades, tyre , shock absorbers, brake disc, brake shoe, door glass
regulator and motor.
Spare parts with 12months/20, 000km
warranty (whichever occurs first).
not-mentioned spare parts
Remark: In the period of Spare parts warranty, if the part replaced again because of the manufacturing defect, the warranty
period should not exceed the stated time or mileage limit of the first one.

Spare Parts Warranty 10
1. The spare part submitted must be purchased by customer from GEELY authorized service station, and be equipped on the
customer’s vehicle.
2. Damage or invalidation as a result of raw material and manufacturing defects or design defects.
3. Non-warranty Scope
a. Normal wear and tear;
b. Not genuine GEELY spare parts;
c. Damage due to incorrect operation or misuse;
d. The vehicle was not repaired and maintained in GEELY authorized service station;
e. Damage enlarged due to discretional disposition after the problem occurs without the content of GIC service station;
f. No effective invoice and warranty voucher, and failure in proving that the car is within the warranty term;
g. Damage due to incorrect assemble and fix in the service station;
h. Damage due to force majeure or nature disaster;
i. Indirect expenses of the spare part damage (e.g. parking fee, travel expense, charge for loss of working time);
j. Unauthorized modification of the vehicle or parts;
k. All parts fitted during warranty repair are covered of the balance of the original warranty period, and the period will end
with the ending of the vehicle warranty period.

Engine Model
Item
Unit
JLD-4G24
JLD-4G20
JL4G18
Gasoline
0ctane number 93# lead-free gasoline(92#lead-free gasoline was used in the Beijing area)
Oil tank capacity
L
60
Engine Oil
SAE10W-30 or SAE15W-40 (SAE5W-30 for cold region in winter ) with API quality class of SL or above .SAE15W-40 (quality class of
SL or above ) or SAE20W-50 (quality class of SJ or above ) for Tropic region .
Volume(L)
L
4
3.5
Transmission
lubricating oil
Fuchs FES 209-3292
API GL-3 grade ， Mitsubishi 75W-80 viscosity
API GL-4 grades, SAE75W-90 viscosity
Volume(L)
L
7.5
2.1
2.2
Brake Fluid
DOT4 or HZY4
Volume(L)
L
0.67
Boosting steering fluid
ATF DEXRON Ⅲ
ATF Dexron Ⅲ
Volume(L)
L
0.91
Coolant
Ethylene glycol type engine coolant(antifreeze liquid）freezing point ≤ -40℃
Volume(L)
L
6.5
Windscreen detergent
Water harness is less than 205g/1000kg or moderate commercial additives aqueous solution.
Volume(L)
L
3.2
Air-conditioning
Refrigerant
R134a
Volume(L)
g
550±50
Type of oil and fluid applicable to Geely cars and the consumption per car
11

Table of Geely Automobile Initial Maintenance Item 12
Item
No.
Maintenance Item
Mileage (km)
Specification and Standard
0-5000
1
Idle and acceleration
D
Based on the rules in the owner’s manual
2
Engine oil
R
JL4G18:Conform to GB11121, API quality SJ grade or above, JL δ
-4G20/JLD-4G20/JLD-4G24: Conform to GB11121, API quality SL grade or
above,
3
Engine
B
Visual-inspect whether there is leakage (oil, fuel, anti-freezer)
4
Oil filter
R
Tightened to specified torque, and check for leakage
5
Generator, water pump tension
(tightness)
B
Under the pressure of 98N, New belt deflection: 7-9mm, used belt deflection:
11.5-13.5 mm
6
Engine water temperature
D
Check when it is abnormal, until it is troubleshot
7
Coolant level and leakage
D
Check for leakage, the radiator expansion tank fluid level shall fall between the
FULL and LOW
8
Transmission
B, D
Based on the rules in the owner’s manual
9
Brake pedal free play
D
Adjust if necessary, when the car is stopped, depress the pedal several times to
remove the vacuum in the vacuum booster, then, use finger to depress the pedal
slowly and slightly until the resistance is felt, measure its free play 1~6mm
10
AT transmission oil(Optional)
R
Conform to Standard uchs FES 209-3292, examine shift position is effective or
not, if abnormal, check until problems tackled.
11
Parking brake travel, effect
D
Adjust if necessary, the brake is effective when you pull the parking brake by 4~7
clicks with a pull of 196N.
12
Clutch Pedal, Free play
D
Adjust if necessary, the standard value is 5-15mm

Table of Geely Automobile Initial Maintenance Items 13
Item
No.
Maintenance Item
Mileage (km)
Specification and Standard
0-5000
13
Minimum clearance of brake
pedal
D
The minimum clearance is 55mm depressed by 490N pressure when Engine is
running
14
Exposed bolt and nut
D
Exposed bolt and nut, inspect and tighten it in place based on the specified torque
15
Steering system
D
Check the steering wheel lash (measured at the outer rim of the steering wheel, no
more than 30mm), check steering linkages and ball end as well as boot
16
Brake and clutch oil inspection
C
Check the brake/clutch oil capacity, refill GB12981, HZY4 brake fluid if not
adequate
17
Brake hose and pipe
D
Check for oil leakage, damage, tightness, and positioning
18
Air pressure of tyres
C, D
Check air pressure of tyres with tyres cold, front wheel: 220kpa, rear wheel:
220kpa
19
Lights
D
Function
20
Oil feeding system
B, D, R
Check for leakage, pipe interference and clamp tightness
21
Horn, wiper, washer
D
Function, refill cleanser
22
Door, door lock
D
Function, adjust if necessary
23
Wiring
B, D, R
Check whether there are interferences between moving parts and wiring, whether
any wear or tear, connector clips not properly fitted, wiring fixed firmly or not.
Letter Definition: B adjustment, C add, D check, R replacement

Initial Maintenance Card 14
When you have driven your car for 3 months or 5000km (whichever occurs first), please go to the nearby Geely
International service station for your initial maintenance service with this manual and car purchase invoice (copy) or driving
license.
Owner
ID card number/company
code
Address
Zip code
Fixed Telephone
Mobile Phone
Model
Color
Date of
manufacture
Purchase Date
Engine No.
(full)
VIN No.
（17 digits）
Transmission
No. (full)
Characteristic
Private □ Public □ Commercial□
License
Plate No.
Initial warranty date:
Initial warranty mileage: user signature:
Notice: This sheet is the voucher for initial maintenance, and the card will be filled by the service station personnel and
submitted by the service station to Geely International Corporation. If the service station fails in abiding by the Table of Geely
Automobile Initial Maintenance Items, the user has the right to refuse to sign. This form will be regarded as invalid if it is
empty or not fully filled.
Service station
(seal)

Initial Maintenance Card 15
When you have driven your car for 3 months or 5000km (whichever occurs first), please go to the nearby Geely
International service station for your initial maintenance service with this manual and car purchase invoice (copy) or driving
license.
Owner
ID card number/company code
Address
Zip code
Fixed Telephone
Mobile Phone
Model
Color
Date of
manufacture
Purchase Date
Engine No.
(full)
VIN No.
（17 digits）
Transmission
No. (full)
Characteristic
Private □ Public □ Commercial □
License
Plate No.
Initial warranty date:
Initial warranty mileage: user signature:
Notice: This sheet is the voucher for initial maintenance, and the card will be filled by the service station personnel and
submitted by the service station to Geely International. If the service station fails in abiding by the Table of Geely Automobile
Initial Maintenance Items, the user has the right to refuse to sign. This form will be regarded as invalid if it is empty or not
fully filled.
Service station
(seal)

Table of Regular Part Replacement 16
No.
Oil Name
Maintenance mileage (whichever occurs first)
Notes
1
Engine Oil *4
Replace 5000km or 3 months for the first time ,
replace every 5000km or every 6 mouths later
on(as per required)
also replace engine oil filer *4
2
Manual Transmission Oil
Replace 5000 km for the first time, replace every 2
years or 40000km in future,
3
Automatic Transmission Oil
Every 3 year or 60000km
4
Automotive gear lubricant
Every 2 year or 40000km
5
Power steering oil
Every 2 year or 40000km
6
Brake Fluid
Every 2 year or 30000km
7
Engine cooling fluid
(antifreeze liquid)*5
Every 1 year or 30000km
①shall always check fluid level
height, ②shall use specified
model and specification of
product manual

Table of Regular Part Replacement 17
A-1: Driving on uneven, muddy, or melting snow road
□ Inspect brake pad and disc
Every 5,000km or 3 months.
□ Check brake pipeline and hose
Every 10,000km or 6 months
□ Check ball joint and anti-dust cover
Every 10,000km or 6 months
□ Check anti-dust sleeve of drive shaft
Every 10,000km or 12 months
□ Inspect steering wheel, steering connecting rod, and gearbox
oil
Every 5,000km or 3 months.
□ Inspect the front and rear suspension
Every 10,000km or 6 months
A-2: Driving on the dusty section.
□ Replace engine oil
Every 5,000km or 6 months.
□ Replacement of oil filter
Every 5,000km or 6 months.
□ Inspect or replace air filter elements
I: Every 2,500km or 3 months
R: Every 7,500km or 6 months
□ Inspect brake pad and disc
Every 5,000km or 3 months.
□ Replacement of A/C cleaning screen
Every 15,000km

Table of Regular Part Replacement 18
B-1: Towing, used camping frame or roof mounting
□ Replace engine oil
Every 5,000km or 6 months.
□ Replacement of oil filter
Every 5,000km or 6 months.
□ Inspect brake pad and disc
Every 5,000km or 3 months.
□ Inspect or replace the transmission oil
Every 60,000km or 24 months
□ Inspect the front and rear suspension
Every 10,000km or 6 months
□ Tighten the bolt and nut between the chassis and body
Every 10,000km or 6 months
B-2: Repeated short-distance driving within 8km and the outdoor temperature is below 0°C
□ Replace engine oil
Every 5,000km or 6 months.
□ Replacement of oil filter
Every 5,000km or 6 months.
B-3: Vehicles always drive for a long distance at idle speed or low speed, such as police cars, taxies or door-to-door delivery
vehicles.
□ Replace engine oil
Every 5,000km or 6 months.
□ Replacement of oil filter
Every 5,000km or 6 months.
□ Inspect PCV valve and pipelines
Every 5,000km or 6 months.
□ Inspect brake pad and disc
Every 5,000km or 3 months.
B-4: Always driving at high speed for over 2 hours. (Driving at a speed rate that is 80% of the maximum speed)
□ Replace the transmission oil
Every 40,000km or 12 months
B-5: Extended period of idle, low speed and frequent acceleration and deceleration, such as a driving training vehicle.
□ Replace engine oil
Every 3,000km or 3 months
□ Replacement of oil filter
Every 3,000km or 3 months
□Inspect PCV valve and pipelines
Every 3,000km or 3 months
