Gefen HDMI Super Booster User manual

HDMI Super
Booster
USER MANUAL
www.gefen.com

Technical Support:
Telephone [phone]
[phone]
Fax [phone]
Technical Support Hours:
9:00 AM to 5:00 PM Monday thru Friday.
Write To:
Gefen Inc.
C/O Customer Service
6265 Variel Ave.
Woodland Hills, CA91367-9897
Notice
Gefen Inc. reserves the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.
HDMI Super Booster is a trademark of Gefen Inc.
© 2006 Gefen Inc., All Rights Reserved
ASKING FOR ASSISTANCE

TABLE OF CONTENTS
Introduction
Features
Panel Descriptions
Connecting and Operating the HDMI Super Booster
Specifications
Warranty
1
2
3
4
5
6

Congratulations on your purchase of the HDMI Super Booster. Your complete
satisfaction is very important to us. Gefen’s line of KVM (Keyboard Video & Mouse),
DVI, ADC, USB, switches, extenders, converters and hubs is designed to make
computer use more comfortable, more productive and less expensive.
The ex•tend•it HDMI Super Booster extends the length of any HDMI cable by regener-
ating the HDCP-HDMI signal before it outputs to the HDCP-HDMI monitor or projector.
The HDMI Super Booster will clean out the digital noise (sparkles) in your picture. The
HDMI Super Booster enables you to relocate your DVD player or satellite receiver to a
safe, quiet and clutter-free environment.
Our Commitment
Gefen will always offer the finest quality product at the best possible price. Included in
that price is a lifetime of free support from a team of outstanding engineers.
Introduction
The HDMI Super Booster extends the length of any HDMI cable by regenerating the
HDMI signal before it outputs to the HDMI monitor or projector. The HDMI Super Boost-
er will clean out the digital noise (sparkles) in your picture. The ex•tend•it HDMI Super
Booster is connected with a HDMI (male to male) cable from the computer HDMI graph-
ic port to the HDMI Super Booster input. The HDMI Super Booster output uses a second
HDMI (male to male) cable to go from the output to any HDMI display or projector with a
HDMI connector. The box is placed near the display to remove any noise that has been
generated by a long HDMI cable.
INTRODUCTION
1

FEATURES
Features
• Connects HDMI set top boxes and computers with HDMI outputs to HDMI compatible
displays or projectors
• Maintains highest HDMI single link video resolution 1080p
• Supports DDWG standard for HDMI compliant monitors
• Supports full HDMI audio and video
• HDCP Compliant
• Installs in minutes
Includes:
HDMI Super Booster
User's Manual
2

PANEL DESCRIPTIONS
3

Connecting and Operating the HDMI Super Booster
How to Connect the HDMI Super Booster
1- Connect the long HDMI cable from the source into the “HDMI In”. The HDMI Super
Booster is placed next to your display to regenerate the HDMI cable.
2- Connect a short HDMI cable from the “HDMI Out” to your display or projector.
3- If there is no video signal or there is signal noise in the picture, adjust the EQ trimpod
located underneath the HDMI Super Booster using a small flat head screw driver.
4

SPECIFICATIONS
5
Video Amplifier Bandwidth ................................................................................ 1.65 Gbps
Input Video Signal ......................................................................................... 1.2 volts p-p
Input DDC Signal .................................................................................... 5 volts p-p (TTL)
Maximum Single Link Range .................................................................................. 1080p
Input/Output Connector Type ................................................. HDMI type A 19 pin female
Dimensions ............................................................................ 1.625”W x 0.75”H x 1.75”D
Shipping Weight ....................................................................................................... 2 lbs.

Gefen Inc. warrants the equipment it manufactures to be free from defects in material
and workmanship.
If equipment fails because of such defects and Gefen Inc. is notified within one
(1) year from the date of shipment, Gefen Inc. will, at its option, repair or replace
the equipment, provided that the equipment has not been subjected to mechanical,
electrical, or other abuse or modifications.
Equipment that fails under conditions other than those covered will be repaired at the
current price of parts and labor in effect at the of repair. Such repairs are warranted for
ninety (90) days from the day of reshipment to the Buyer.
This warranty is in lieu of all other warranties expressed or implied, including without
limitation, any implied warranty or merchantability or fitness for any particular purpose,
all of which are expressly disclaimed.
The information in this manual has been carefully checked and is believed to be
accurate. However, Gefen Inc. assumes no responsibility for any inaccuracies that may
be contained in this manual. In no event will Gefen Inc., be liable for direct, indirect,
special, incidental, or consequential damages resulting from any defect or omission
in this manual, even if aHDMIsed of the possibility of such damages. The technical
information contained herein regarding HDMI Super Booster features and specifications
is subject to change without notice.
WARRANTY
6
